Soldering & Rework Station
Features:
• Advanced integrated computer provides outstanding
thermo-control and thermo-stability for precise
temperature control
• Dual LCD displays the working and parameter
temperatures
• Quick-to-temp power up
• Highowdiaphragmpumpissuitableforavarietyof
nozzles to desolder SMD components
• Automatic shut-off and sleep mode for safety and
energy savings
• Convenient buttons on the hand piece allow instant
adjustment of temperature and air volume
• Memory stores up to three air and temperature presets
Apply
Industrial production
Research department
Maintenance industry
Students
Electronic assembly
All enterprises and institutions
An intelligent, lead-free, and space-saving rework station which combines a rework station and soldering station. It is suitable
for advanced hobbyists, repair, rework, and educational use. It is user friendly and a welcome addition to every work bench
Specications
Model 21-10130 Intelligent lead-free rework station
Total power About 900 W (maximum) Heating : 800 (maximum) pump (diaphragh) : 40 W
Range for temperature controlling Hot air rework station 100°C to 500°C
Soldering station 200°C to 480°C
Temperature unit °C/°F Convertible
Temperature controlling stability Static 2°C
Temperature controlling accuracy Static 10°C
Calibration range Celsius -50°C to 50°C
Fahrenheit -58°F to 122°F
Setting storage (3 groups) Rework station 1.2°C, 40 2.3°C 60 3.4°C 80
Soldering station 1.2°C 2.3°C 3.4°C
Range of air volume Rework station 020 - 100 level
Dormancy and standby Rework station Stopping heating, air-blowing delay and then be in
the condition of dormancy
Cold air Rework station Air-blowing made by the machine
Malfunction alert Heating elements Displaying H-E
Sensor Displaying S-E
Shutdown Shutdown in the normal condition Cold air delay shutdown, power off
www.element14.com
www.farnell.com
www.newark.com
www.cpc.co.uk
www.mcmelectronics.com
TM
TM
Page <2> V1.003/12/12
Soldering & Rework Station
Specication for Soldering Iron:
Input voltage : 220V AC / 110V AC
Power consumption : 50W
Measurement : 240mm × 40mm × 60mm
Gross weight : 0.125Kg
Compatible for : AT936B,21-10130 (AT8502D)
Safety and Caution
Thetemperatureofthehot-airnozzleis400°Csoitmayleadtoinjury,reandotheraccidentbecauseofimproperusage.
Please abide the following terms:
1. Don't make the rework station be against people or animals. And never use it as a hair drier and touch the heating element
or blow the skin directly
2. Neveroperateitneartheammablegasorsubstanceandputitbesidethemafteruse
3. After use, the power should be off and it will be automatically off when the hot air temperature is lowered, (There is fuse
inside, so great attention must be paid to superheat in case of accident)
4. Please care for using hot-air gun, never make it fall or shake heavily and put the heavy things on it or press the buttons
improperly
5. Don't operate with wet hands or wet wire in order not to result in short circuit or electronic shock
6. Keep away from children
7. Please use the nozzle offered by manufacture and don't replace the original nozzle
8. Temperature will vary from the models of the nozzles, which is normal
9. Don't touch the iron tip or surrounding metals
10. Change the components or tip after cutting off power and waiting to cool it
11. Don't use this device do other work except soldering
12. Don't rap the handle to remove the doss of tip, which is bad for it
13. Don't pull the cable but hold tightly the plug when you take out of plug
14. Please keep good ventilation because there is smoke when solder
15. Don't play with other people or would be easy to hurt others or yourself
Characteristics
1. MCU computer offers PID advanced algorithms industrial control with thermo-control and thermo-stability, which makes
more exactly control temperature
2. Dual LCD screen respectively and separately display the working state and parameter, which is very directly. So customer
can understand the output state at a glance
3. Temperature rapidly rises with large output power
4. HighowdiaphragmpumpsuitableforvariesofnozzlestodesolderSMDcomponents
5. Dormancy, automatic shut down and other power-saving features
6. Shortcut keys on the handle make it more convenient for the user to adjust temperature and air volume
7. Three groups of storage functions can bring very fast mode of switching different groups of temperature and hot-air volume
to the customers
8. All units are equipped with temperature compensation, which ensure stable state of operation
9. Indicator for malfunction alert
www.element14.com
www.farnell.com
www.newark.com
www.cpc.co.uk
www.mcmelectronics.com
TM
TM
Page <3> V1.003/12/12
Soldering & Rework Station
Important Notice : This data sheet and its contents (the “Information”) belong to the members of the Premier Farnell group of companies (the “Group”) or are licensed to it. No licence is granted
for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change
without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any
error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any
assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the
Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Group’s liability for death or personal injury resulting from its negligence.
Tenma is the registered trademark of the Group. © Premier Farnell plc 2012.
Part Number Table
Description Part Number
Soldering Iron, 60W, 220V/110V AT907-936B
Soldering & Rework Station, ESD, UK+EU 21-10130 UK+EU
Installation
Thebracketsforthehandlesmustbeinstalledwhenoperatingforthersttime.Pleaseseethefollowingillustration:
1. Pleasexthebracketbytighteningthefourscrewsaccordingtotheillustrationandyourpersonalhabit
2. Accordingtoyourselection,dismantlethetwoscrewsontheleftortheright,whichxthebracketofthehandle
3. Placethetwoinstallationholeofthebrackettothetwoxedscrewholesofthemachine,andthentightenthedismantled
two screws. Put the components of the handle on the bracket to check if it is suitable
Warning
This tool be placed on its stand when not in use. The instructions for heat guns and hand-held paint strippers shall include the
substanceoffollowing:Aremayresultiftheapplianceisnotusedwithcare,thereforebecarefulwhenusingtheappliance
in places where there are combustible materials: Do not apply to the same place for a long time; Do not use in presence of an
explosive atmosphere; Be aware that heat may be conducted to combustible materials that are out of sight ; Place the appliance
on its stand after use and allow it to cool down before storage; Do not leave the appliance unattended when it is switched on.
