Tennant 510E User manual

510E
MM239
Rev. 09 (3--95)

This manual is furnished with each new TENNANT Model 510E. It provides necessary operating and
preventive maintenance instructions. Read this manual completely and understand the machine before
operating or servicing it.
This manual covers all machine variations and standard accessories. The instruction portion of the
manual consists of the Specification, Operation, Maintenance, and Appendix sections. The parts portion
consists of the Standard Parts; Options; Breakdowns; and Cross Reference sections.
All right side and left side references to the machine are determined by facing the direction of forward
travel. All hardware considered to be of a common nature or locally available has been omitted from the
parts sections. Be aware that this machine may contain metric hardware. Make sure you use equivalent
hardware when replacement becomes necessary.
This machine will provide excellent service. However, the best results will be obtained at minimum costs if:
DThe machine is operated with reasonable care.
DThe machine is maintained regularly -- per the maintenance instructions provided.
DThe machine is maintained with TENNANT supplied or equivalent parts.
Parts and supplies may be ordered by phone or mail from any TENNANT parts and service center,
distributor, or from any of the TENNANT subsidiaries. Before ordering parts or supplies, be sure to have
your machine model number and serial number handy. Fill out the data block below for future reference.
The telephone numbers, telex numbers, mailing addresses, and locations of those outlets are listed in the
Customer Documents section of the manual.
MACHINE DATA
Please fill out at time of installation.
Machine Serial Number --
Engine Serial Number --
Sales Representative --
Customer Number --
Date of Installation --
Manual Number -- MM239
Revision: 09
Published: 3--95
Trademark Registered in: Austria, Benelux, Denmark, England, France, Germany, Italy, Spain,
Switzerland, United States, Argentina, Australia, Canada, Japan, Mexico, Sweden, by TENNANT
COMPANY, Minneapolis, Minnesota, U.S.A.
Copyright 1990, 1991, 1992, 1993, 1994, 1995 TENNANT, Printed in U.S.A.

GENERAL INFORMATION
i
510E MM239 (8--92)
SAFETY PRECAUTIONS
The following symbols are used throughout this
manual as indicated in their description:
WARNING: To warn of hazards or
unsafe practices which could result in
severe personal injury or death.
FOR SAFETY: To identify actions which must
be followed for safe operation of equipment.
The machine is suited for scrubbing disposable
debris. Do not use the machine other than
described in this manual. The machine is not
designed for use on public roads.
The following information signals potentially
dangerous conditions to the operator or
equipment:
FOR SAFETY:
1. Do Not Operate Machine:
-- Unless Trained And Authorized.
-- Unless Operation Manual Is Read And
Understood.
-- In Flammable Or Explosive Areas
Unless Designed For Use In Those
Areas.
-- In Areas With Possible Falling Objects
Unless Equipped With Overhead
Guard.
2. Before Starting Machine:
-- Make Sure All Safety Devices Are In
Place And Operate Properly.
-- Check Brakes And Steering For Proper
Operation.
3. When Starting Machine:
-- Keep Foot On Brake And Directional
Pedal In Neutral.
4. When Using Machine:
-- Use Brakes To Stop Machine.
-- Go Slow On Inclines And Slippery
Surfaces.
-- Use Care When Reversing Machine.
-- Do Not Carry Riders On Machine.
-- Always Follow Safety And Traffic
Rules.
-- Report Machine Damage Or Faulty
Operation Immediately.
5. Before Leaving Or Servicing Machine:
-- Stop On Level Surface.
-- Set Parking Brake.
-- Turn Off Machine And Remove Key.
6. When Servicing Machine:
-- Avoid Moving Parts. Do Not Wear
Loose Jackets, Shirts, Or Sleeves.
-- Block Machine Tires Before Jacking
Machine Up.
-- Jack Machine Up At Designated
Locations Only. Block Machine Up
With Jack Stands.
-- Use Hoist Or Jack Of Adequate
Capacity To Lift Machine.
-- Wear Eye And Ear Protection When
Using Pressurized Air Or Water.
-- Disconnect Battery Connections
Before Working On Machine.
-- Avoid Contact With Battery Acid.
-- Use TENNANT Supplied Or Approved
Replacement Parts.
WARNING: Batteries Emit Hydrogen
Gas. Explosion Or Fire Can Result.
Keep Sparks And Open Flame Away. Keep
Covers Open When Charging.
WARNING: Flammable Materials Can
Cause An Explosion Or Fire. Do Not
Use Flammable Materials In Tank(s).
WARNING: Flammable Materials Or
Reactive Metals Can Cause Explosion
Or Fire. Do Not Pick Up.

GENERAL INFORMATION
510E MM239 (1--90)
ii
The following safety labels are mounted on the
machine in the locations indicated. If these, or any
labels become damaged or illegible, install a new
label in its place.
05912
CLEANING SOLUTION LABEL -- LOCATED ON
TANKS COVER.
BATTERY CHARGING LABEL -- LOCATED ON
LINTEL.
FOR SAFETY LABEL -- LOCATED ON MOTOR
COVER PANEL.
FLAMMABLE SPILLS LABEL -- LOCATED ON
MOTOR COVER PANEL.

GENERAL INFORMATION
iii
510E MM239 (8--93)
CONTENTS
Page
GENERAL INFORMATION i...............
SAFETY PRECAUTIONS i............
SPECIFICATIONS 1-1.......................
MACHINE SPECIFICATIONS 1-3.........
POWER TYPE 1-3...................
POWER TRAIN 1-3..................
STEERING 1-3......................
BRAKING SYSTEM 1-3..............
SUSPENSION SYSTEM 1-3..........
SYSTEM FLUID CAPACITIES 1-3.....
GENERAL MACHINE DIMENSIONS --
CAPACITIES 1-3...............
MACHINE WEIGHTS 1-3.............
GENERAL MACHINE
PERFORMANCE 1-3..............
MACHINE DIMENSIONS 1-4.............
OPERATION 2-1............................
PREPARATION FOR OPERATION 2-3....
AFTER UNCRATING AND BEFORE
OPERATING MACHINE: 2-3.......
OPERATION OF CONTROLS 2-4........
MACHINE COMPONENTS 2-4........
HOW IT WORKS 2-5.................
INSTRUMENT PANEL SYMBOLS 2-6..
CONTROLS AND INSTRUMENTS 2-7.
BRAKE PEDAL 2-8..................
DIRECTIONAL PEDAL 2-8............
STEERING WHEEL 2-8..............
SOLUTION FLOW LEVER 2-8.........
CLOGGED VACUUM INDICATOR 2-8..
RECOVERY TANK FULL INDICATOR 2-8
HOUR METER 2-8...................
BRUSH PRESSURE INDICATOR AND
SWITCH 2-8...................
EDGE SCRUB SWITCH 2-9...........
BATTERY DISCHARGE INDICATOR 2-9
ELECTRICAL POWER INDICATOR 2-9
BRUSH CIRCUIT BREAKER
INDICATOR 2-9...................
REAR SQUEEGEE AND VACUUM FAN
SWITCH 2-9...................
SCRUB BRUSH SWITCH 2-9.........
HORN BUTTON 2-9..................
KEY-OPERATED ON-OFF SWITCH 2-9
OPERATING LIGHTS SWITCH 2-10....
REVOLVING LIGHT SWITCH 2-10......
PRE-SWEEPtSWITCH 2-10..........
EStSWITCH 2-10...................
PARKING BRAKE LEVER 2-10.........
POWER WAND SWITCH 2-10..........
CIRCUIT BREAKERS 2-11.............
Page
MACHINE OPERATION 2-12..............
NORMAL SCRUBBING OPERATION 2-12
PRE-START CHECKLIST 2-12.......
TO START MACHINE 2-12..........
TO FILL SOLUTION TANK 2-12......
TO SCRUB 2-14...................
TO DRAIN AND CLEAN RECOVERY
TANK 2-15...................
POST OPERATION CHECKLIST --
MACHINE ON 2-17...........
TO STOP MACHINE 2-17...........
POST OPERATION CHECKLIST --
MACHINE OFF 2-17..........
DOUBLE SCRUBBING OPERATION 2-18
TO RAISE SIDE SQUEEGEES 2-18..
TO LOWER SIDE SQUEEGEES 2-18
OPERATIONONGRADES 2-18........
MACHINE TROUBLESHOOTING 2-19..
OPTIONS OPERATION 2-20..............
VACUUM WAND 2-20.................
TO OPERATE THE VACUUM
WAND 2-20.....................
POWER WAND 2-21..................
TO OPERATE THE POWER
WAND 2-21.....................
PRE-SWEEPt2-23...................
TO REPLACE THE PRE-SWEEPt
DEBRIS HOPPER LINER 2-23.
TO REMOVE PRE-SWEEPt
ASSEMBLY 2-23................
TO MOUNT PRE-SWEEPt
ASSEMBLY 2-24................
TRANSPORTING MACHINE 2-25..........
PUSHING OR TOWING 2-25...........
MACHINE JACKING 2-25..............
TO JACK UP MACHINE 2-25........
MACHINE TIE DOWNS 2-26...........
MACHINE STORAGE 2-27................
STORING MACHINE 2-27.............
MACHINE OPERATION 2-11..............
MAINTENANCE 3-1.........................
RECOMMENDED FIRST 50-HOUR
MACHINE INSPECTION 3-3..........
MAINTENANCE CHART 3-4.............
LUBRICATION 3-6......................
PROPELLING GEARBOX 3-6.........
FRONT WHEEL SUPPORT
BEARING 3-6....................
SCRUB HEAD PARALLEL ARMS 3-6..
ELECTRICAL SYSTEM 3-7..............
BATTERIES 3-7.....................
TO CHARGE BATTERIES 3-8......
TO REPLACE 380 A/h
BATTERIES 3-9................

GENERAL INFORMATION
510E MM239 (8--94)
iv
Page
ELECTRICAL SCHEMATIC (For machines
below serial number 001840) 3-11....
ELECTRICAL SCHEMATIC (For machines
serial number 001840 and above) 3-12
BELTS AND CHAINS 3-13................
STEERING GEAR CHAIN 3-13.........
STATIC DRAG CHAIN 3-13............
SCRUB HEAD 3-14......................
SCRUB HEAD 3-14...................
TO CENTER SCRUB HEAD 3-14....
TO ADJUST EDGE SCRUB
SWITCH 3-15...................
TO ADJUST SCRUB HEAD DOWN
PRESSURE 3-15.............
SCRUB BRUSHES 3-16...............
TO REPLACE SCRUB BRUSHES 3-16
SCRUB HEAD FLOOR SKIRTS 3-17....
SOLUTION AND RECOVERY TANKS 3-18.
SOLUTION TANK 3-18................
SOLUTION VALVE 3-18...............
RECOVERY TANK 3-19...............
TO DRAIN AND CLEAN RECOVERY
TANK 3-19.....................
EStSOLUTION TANKS 3-21..........
TO DRAIN AND CLEAN ESt
SOLUTION TANKS 3-21.........
SQUEEGEES 3-23.......................
SIDE SQUEEGEES 3-23..............
TO REPLACE SIDE SQUEEGEE
BLADES 3-23...................
SIDE SQUEEGEE ADJUSTMENT 3-23..
REAR SQUEEGEE 3-24...............
TO REPLACE OR ROTATE REAR
SQUEEGEE BLADE 3-24........
TO LEVEL REAR SQUEEGEE 3-25..
TO ADJUST REAR SQUEEGEE
DEFLECTION (For machines below
serial number 001724) 3-26.......
TO ADJUST REAR SQUEEGEE
DEFLECTION (For machines serial
number 001724 and 002669) 3-26.
TO ADJUST REAR SQUEEGEE
DEFLECTION (For machines serial
number 002670 and above) 3-26..
BRAKES AND TIRES 3-28................
SERVICE BRAKES 3-28...............
TIRES 3-28..........................
OPTIONS 3-29..........................
PRE-SWEEPt3-29...................
PRE-SWEEPtMAIN BRUSH 3-29.....
TO REPLACE PRE-SWEEPtMAIN
BRUSH 3-29....................
TO CHECK AND ADJUST
PRE-SWEEPtMAIN BRUSH
PATTERN 3-30..................
PRE-SWEEPtSIDE BRUSH 3-31......
TO REPLACE PRE-SWEEPtSIDE
BRUSH 3-31....................
Page
PRE-SWEEPtBRUSH SIDE
SKIRTS 3-32......................
PRE-SWEEPtREAR SKIRT 3-32......
DEBRIS HOPPER SLIT SKIRT 3-32.....
PRE-SWEEPtDEBRIS HOPPER
SEALS 3-32.......................
PRE-SWEEP
t MAIN BRUSH DRIVE
BELT 3-33.........................
TO REPLACE THE MAIN BRUSH
DRIVE BELT 3-33...............
PRE-SWEEPtSIDE BRUSH DRIVE
BELT 3-34.........................
TO REPLACE AND ADJUST THE
SIDE BRUSH BELT 3-34.........
APPENDIX 4-1..............................
HARDWARE INFORMATION 4-3.........
STANDARD BOLT TORQUE CHART 4-3
METRIC BOLT TORQUE CHART 4-3..
BOLT IDENTIFICATION 4-3...........
THREAD SEALANT AND LOCKING
COMPOUNDS 4-3................
HOW TO USE THIS MANUAL 5-1............
IMPORTANT INFORMATION 5-1.........
FINDING A TENNANT PART NUMBER 5-2
PLACING AN ORDER 5-3...............
STANDARD MODEL PARTS 6-1.............
Fig. 1 -- Recommended General
Maintenance Items 6-2.......
Fig. 2 -- Replacement Brushes 6-2........
Fig. 3 -- Main Frame and Cover Group 6-4.
Fig. 4 -- Seat Assembly 6-6..............
Fig. 5 -- Steering Group 6-8..............
Fig. 6 -- Drive Wheel Group 6-10..........
Fig. 7 -- Front Brake Linkage Group 6-12...
Fig. 8 -- Rear Brake Linkage Group 6-13....
Fig. 9 -- Rear Wheel and Brake Group 6-14.
Fig. 10 -- Floor Plate Group 6-15...........
Fig. 11 -- Directional Pedal Group 6-16......
Fig. 12 -- Scrub Head Drive Group 6-18.....
Fig. 13 -- Scrub Head Mount Group 6-20....
Fig. 14 -- Scrub Head Lift Group 6-21.......
Fig. 15 -- Edge Scrub Group 6-22..........
Fig. 16 -- Scrub Head Stops and
Squeegee Mount Group 6-23...
Fig. 17 -- Solution Valve Group 6-24........
Fig. 18 -- Right Side Squeegee Group 6-26..
Fig. 19 -- Left Side Squeegee Group 6-27...
Fig. 20 -- Rear Squeegee Mount Group 6-28.
Fig. 21 -- Left Side Squeegee Group 6-30...
Fig. 22 -- Rear Squeegee Linkage Group 6-31
Fig. 23 -- Recovery Tank Group 6-32........
Fig. 24 -- Solution Tank Group 6-34.........
Fig. 25 -- Demister and Cover Group 6-36...
Fig. 26 -- Vacuum Fan Group 6-38..........
Fig. 27 -- Instrument Panel Group 6-40......
Fig. 28 -- Electronic Panel Group 6-41......

GENERAL INFORMATION
v
510E MM239 (3--95)
Page
Fig. 29 -- Control Box Group 6-42..........
Fig. 30 -- Wire Harness Group 6-44.........
Fig. 31 -- Label Group 6-50................
OPTIONS 7-1..............................
Fig. 1 -- Pre-SweeptFrame Group 7-2...
Fig. 2 -- Pre-SweeptDrive Group 7-4....
Fig. 3 -- Pre-SweeptBrush Idler Group 7-6
Fig. 4 -- Pre-SweeptBrush Wrap Group 7-7
Fig. 5 -- Pre-SweeptSide Brush Group 7-8
Fig. 6 -- Pre-SweeptHopper Group 7-10...
Fig. 7 -- Pre-SweeptCover Group 7-11....
Fig. 8 -- Pre-SweeptElectrical Group 7-12.
Fig. 9 -- Pre-SweeptDolly Assembly 7-13..
Fig. 10 -- Extended Scrub Group 7-14.......
Fig. 11 -- Auto Water Valve Group 7-16......
Fig. 12 -- Light Kit 7-18....................
Fig. 13 -- Revolving Light Kit, Lintel 7-20.....
Fig. 14 -- Revolving Light Kit,
Overhead Guard 7-21.........
Fig. 15 -- Overhead Guard Kit 7-22.........
Fig. 16 -- Heavy Duty Bumper Kit 7-23......
Fig. 17 -- Suspension Slide Seat Kit 7-24....
Fig. 18 -- Heavy Duty Motor Kit 7-25........
Fig. 19 -- Vacuum Wand Kit 7-26...........
Fig. 20 -- Demo Kit 7-27...................
Fig. 21 -- Grooved Tire Assembly 7-28......
Fig. 22 -- Non-Mark, Non-Skid Tires 7-29....
Fig. 23 -- Battery Kit, 380 A/h, Wet 7-30.....
Fig. 24 -- Battery Kit, 420 A/h, Wet 7-31.....
Fig. 25 -- Battery Kit, 570 A/h, Wet 7-32.....
Fig. 26 -- Battery Kit, 570 A/h, Dry,
International Only 7-33........
Fig. 27 -- Battery Charger Group,
380 A/h Batteries, 60Hz 7-34...
Fig. 28 -- Battery Charger Group,
380 A/h Batteries, 50Hz,
International Only 7-35........
Fig. 29 -- Battery Charger Group,
420 A/h Batteries, 60Hz 7-36...
Fig. 30 -- Battery Charger Group,
420 A/h Batteries, 50Hz,
International Only 7-37........
Fig. 31 -- Battery Charger Group,
570 A/h Batteries, 60Hz 7-38...
Fig. 32 -- Battery Charger Group,
570 A/h Batteries, 50Hz,
International Only 7-39........
Fig. 33 -- Power Wand Mount and
Pump Group 7-40............
Fig. 34 -- Power Wand Assembly 7-42......
Fig. 35 -- Power Wand Hose Assembly 7-44.
Fig. 36 -- Fire Extinguisher Kit 7-45.........
Fig. 37 -- Front Squeegee Blade
Group, Tile 7-46..............
Fig. 38 -- Positive Solution Control Drain
System Kit, Standard 7-47......
Page
Fig. 39 -- Positive Solution Control Drain
System Kit, ESt7-48..........
Fig. 40 -- Documentation Group 7-50........
ELECTRICAL COMPONENTS 8-1............
Fig. 1 -- Electric Motor Breakdown,
17363 8-2..................
Fig. 2 -- Battery Charger Breakdown,
41390 8-4..................
Fig. 3 -- Electric Motor Breakdown,
16225 8-6..................
Fig. 4 -- Electric Motor Breakdown,
16224 8-7..................
Fig. 5 -- Electric Motor Breakdown,
86356 8-8..................
Fig. 6 -- Electric Motor Breakdown,
60196 8-9..................
Fig. 7 -- Electric Motor Breakdown,
04922 8-10..................
Fig. 8 -- Electric Motor Breakdown,
60198 8-11..................
Fig. 9 -- Water Pump Breakdown,
17333 8-12..................
Fig. 10 -- Water Pump Breakdown,
65590 8-13..................
CROSS REFERENCE 9-1...................
PART NUMBER TO PAGE NUMBER CROSS
REFERENCE LIST 9-1............

GENERAL INFORMATION
510E MM239 (1--90)
vi

SPECIFICATIONS
1--1
510E MM239 (1--90)
SECTION 1
CONTENTS
Page
MACHINE SPECIFICATIONS 1-3............
POWER TYPE 1-3......................
POWER TRAIN 1-3.....................
STEERING 1-3.........................
BRAKING SYSTEM 1-3..................
SUSPENSION SYSTEM 1-3.............
SYSTEM FLUID CAPACITIES 1-3........
GENERAL MACHINE DIMENSIONS --
CAPACITIES 1-3......................
MACHINE WEIGHTS 1-3................
GENERAL MACHINE PERFORMANCE 1-3
MACHINE DIMENSIONS 1-4................

SPECIFICATIONS
510E MM239 (1--90)
1--2

SPECIFICATIONS
1--3
510E MM239 (8--92)
MACHINE SPECIFICATIONS
POWER TYPE
Electric propelling motor -- nominal voltage
36 VDC, 2 hp (1.5 kW) @ 2000 rpm
Electric vacuum fan motor (2) -- nominal voltage
36 VDC, 0.85 hp (0.63 kW) @ 14,000 rpm
Electric brush drive motor (2) -- nominal voltage
36 VDC, 1 hp (0.75 kW) @ 2200 rpm
Electric heavy duty brush drive motor (option) (2)
-- nominal voltage 36 VDC, 1.5 hp
(1.12 kW) @ 2200 rpm
Electric Pre-Sweeptmotor (option) -- nominal
voltage 36 VDC, 0.8 hp (0.60 kW)
@ 320 rpm
Batteries (3) -- 12 V, 380 A/h @ 6 hour rate
(1) 36 V, 570 A/h @ 6 hour rate
Battery charger (option) -- 36 VDC 120 A,
208--240--480 VAC, 60 Hz, 1 ph
36 VDC 120 A, 208--240--480 VAC, 60 Hz,
3ph
36 VDC 120 A, 208--240--480 VAC, 50 Hz,
1ph
36 VDC 120 A, 208--240--480 VAC, 50 Hz,
3ph
36 VDC 75 A, 208--240--480 VAC, 50 Hz,
3ph
36 VDC 75 A, 208--240--480 VAC, 60 Hz,
1ph
36 VDC 75 A, 208--240--480 VAC, 60 Hz,
3ph
36 VDC 50 A, 240 VAC, 60 Hz, 1 ph
36 VDC 50 A, 230 VAC, 50 Hz, 1 ph
36 VDC 45 A, 200 VAC, 50 & 60 Hz, 1 ph
POWER TRAIN
Propelling -- electric motor to gearbox driven
Scrub brushes -- electric motor to gearbox driven
Vacuum fan -- electric motor direct driven
Pre-Sweeptbrushes (option) -- electric motor
belt driven
STEERING
Type -- front wheel controlled, universal joint to
gear and chain
Power source -- manual
BRAKING SYSTEM
Service brakes -- mechanical drum brakes (2),
1 per rear wheel, linkage actuated
Parking brake -- utilizes service brakes, linkage
actuated
SUSPENSION SYSTEM
Front -- 16.25 x 6 solid tire (1)
Rear --- 16 x 3.5 solid tire (2)
SYSTEM FLUID CAPACITIES
Gearbox grease capacity, propelling -- 2.7 qt
(2.6 L)
Solution tank capacity -- 55 gal (210 L)
Recovery tank capacity -- 50 gal (190 L)
Tank capacity with EStoption -- 80 gal (303 L)
GENERAL MACHINE DIMENSIONS --
CAPACITIES
Length -- 83 in (2110 mm)
Length with Pre-Sweept-- 97 in (2465 mm)
Width -- 42 in (1065 mm)
Width with edge scrub -- 47 in (1195 mm)
Height -- 57 in (1450 mm)
Height with overhead guard -- 80 in (2030 mm)
Track -- rear 34.8 in (885 mm)
Wheel base -- 42.8 in (1085 mm)
Scrub brush diameter -- 20 in (510 mm)
Pre-Sweeptmain brush (option) diameter --
8in(205mm)
Pre-Sweeptmain brush (option) length --
36 in (915 mm)
Pre-Sweeptside brush (option) diameter --
13 in (330 mm)
Scrubbing path width -- 40 in (1015 mm)
Pre-Sweepthopper capacity -- 0.75 cu ft
(0.02 m#)75lb(34kg)
Rear squeegee path width -- 47.5 in (1210 mm)
MACHINE WEIGHTS
GVWR -- 4600 lb (2087 kg)
GENERAL MACHINE PERFORMANCE
Maximum forward speed -- 5 mph (8 km/h)
Maximum reverse speed -- 3 mph (4.8 km/h)
Aisle turnaround width -- 90 in (2290 mm)
Aisle turnaround width with Pre-Sweept--
104 in (2640 mm)
Maximum rated ramp climb with empty tanks --
8.5_
Maximum rated ramp descent angle with empty
tanks -- 8.5_
Maximum rated ramp climb with full tanks -- 5.7_
Maximum rated ramp descent angle with full
tanks -- 5.7_

SPECIFICATIONS
510E MM239 (1--90)
1--4
MACHINE DIMENSIONS
80 in
(2030 mm)
83 in (2110 mm)
97 in (2465 mm)
42 in
(1065 mm)
57 in
(1450 mm)
TOP VIEW
SIDE VIEW
05424

OPERATION
2-1
510E MM239 (8--92)
SECTION 2
CONTENTS
Page
PREPARATION FOR OPERATION 2-3........
AFTER UNCRATING AND BEFORE
OPERATING MACHINE: 2-3...........
OPERATION OF CONTROLS 2-4............
MACHINE COMPONENTS 2-4............
HOW IT WORKS 2-5.....................
INSTRUMENT PANEL SYMBOLS 2-6......
CONTROLS AND INSTRUMENTS 2-7.....
BRAKE PEDAL 2-8......................
DIRECTIONAL PEDAL 2-8................
STEERING WHEEL 2-8..................
SOLUTION FLOW LEVER 2-8............
CLOGGED VACUUM INDICATOR 2-8......
RECOVERY TANK FULL INDICATOR 2-8..
HOUR METER 2-8.......................
BRUSH PRESSURE INDICATOR AND
SWITCH 2-8.........................
EDGE SCRUB SWITCH 2-9..............
BATTERY DISCHARGE INDICATOR 2-9...
ELECTRICAL POWER INDICATOR 2-9....
BRUSH CIRCUIT BREAKER INDICATOR 2-9
REAR SQUEEGEE AND VACUUM FAN
SWITCH 2-9.........................
SCRUB BRUSH SWITCH 2-9.............
HORN BUTTON 2-9......................
KEY-OPERATED ON-OFF SWITCH 2-9....
OPERATING LIGHTS SWITCH 2-10........
REVOLVING LIGHT SWITCH 2-10..........
PRE-SWEEPtSWITCH 2-10..............
EStSWITCH 2-10.......................
PARKING BRAKE LEVER 2-10.............
POWER WAND SWITCH 2-10..............
CIRCUIT BREAKERS 2-11.................
MACHINE OPERATION 2-12..................
NORMAL SCRUBBING OPERATION 2-12...
PRE-START CHECKLIST 2-12..........
TO START MACHINE 2-12..............
TO FILL SOLUTION TANK 2-12.........
TO SCRUB 2-14.......................
TO DRAIN AND CLEAN RECOVERY
TANK 2-15.........................
POST OPERATION CHECKLIST --
MACHINE ON 2-17..................
TO STOP MACHINE 2-17...............
POST OPERATION CHECKLIST --
MACHINE OFF 2-17.................
DOUBLE SCRUBBING OPERATION 2-18...
TO RAISE SIDE SQUEEGEES 2-18......
TO LOWER SIDE SQUEEGEES 2-18....
OPERATIONONGRADES 2-18............
MACHINE TROUBLESHOOTING 2-19......
Page
OPTIONS OPERATION 2-20..................
VACUUM WAND 2-20.....................
TO OPERATE THE VACUUM WAND 2-20
POWER WAND 2-21......................
TO OPERATE THE POWER WAND 2-21.
PRE-SWEEPt2-23......................
TO REPLACE THE PRE-SWEEPt
DEBRIS HOPPER LINER 2-23........
TO REMOVE PRE-SWEEPt
ASSEMBLY 2-23....................
TO MOUNT PRE-SWEEPt
ASSEMBLY 2-24....................
TRANSPORTING MACHINE 2-25.............
PUSHING OR TOWING 2-25...............
MACHINE JACKING 2-25..................
TO JACK UP MACHINE 2-25............
MACHINE TIE DOWNS 2-26...............
MACHINE STORAGE 2-27...................
STORING MACHINE 2-27.................

OPERATION
510E MM239 (1--90)
2-2

OPERATION
2-3
510E MM239 (3--91)
PREPARATION FOR OPERATION
AFTER UNCRATING AND BEFORE
OPERATING MACHINE:
1. Check the machine for shipping damage.
2. Read this manual carefully before operating
or serving the machine.
FOR SAFETY: Do Not Operate Machine,
Unless Operation Manual Is Read And
Understood.
3. Open the machine cover.
05915
OPENING MACHINE COVER
4. Check the batteries electrolyte level as
described in BATTERIES in the
MAINTENANCE section.
A
B
00879
CHECKING BATTERY ELECTROLYTE LEVEL
A. Battery
B. Electrolyte Indicator Ring
FOR SAFETY: When Servicing Machine, Avoid
Contact With Battery Acid.
5. Check the battery specific gravity to
determine the state of charge as described
in BATTERIES in the MAINTENANCE
section. Charge the batteries if necessary.
6. Connect the battery connector to the
machine connector.
A
B
05920
MACHINE TO BATTERY CONNECTOR
A. Machine Connector
B. Battery Connector
7. Install the scrub brushes as described in
SCRUB BRUSHES in the MAINTENANCE
section.
8. Pre-Sweeptmachines: Install the
Pre-Sweeptassembly as described in TO
MOUNT PRE-SWEEPtASSEMBLY.

OPERATION
510E MM239 (1--90)
2-4
OPERATION OF CONTROLS
A
B
C
D
E
F
G
H
I
J
K
L
M
N
M
H
C
DE
F
K
05912
05924
MACHINE COMPONENTS
A. Operator Seat H. Side Squeegee
B. Steering Wheel I. Solution Tank Drain
C. Machine Cover J. Recovery Tank Drain
D. Recovery Tank K. Pre-SweeptAssembly
E. Solution Tank L. Side Brush
F. Tanks Cover M. Rear Wheel
G. Rear Squeegee N. Seat Support

OPERATION
2-5
510E MM239 (1--90)
HOW IT WORKS
The Model 510E is a rider scrubber. The machine
is propelled by a electric motor via the front wheel.
The machine is steered with the steering wheel
and is very responsive.
The main scrubbing components include a
solution tank, two disc-type brushes, rear and side
squeegees, a vacuum fan, and a recovery tank.
Water and detergent solution flows from the
solution tank through the water control valve to
the scrub brushes. The rotating scrub brushes
scrub the floor. As the machine moves forward,
the squeegees collect the dirty solution and
channel it into the vacuum of the squeegee
pick-up hose. The pick-up hose deposits the dirty
solution in the recovery tank.
Machines with the EStoption filter the dirty
solution in the recovery tank and return it to the
solution tank.

OPERATION
510E MM239 (1--90)
2-6
INSTRUMENT PANEL SYMBOLS
These symbols are used to identify controls and
displays on the machine:
Headlights
Revolving Light
Brushes On (Pre-Sweept)
ESt
Horn
Key Switch
Battery Charging System
Scrub Brush Edge Clean
Down Pressure
Scrub Brush Down
Scrub Brush Shut Down
Squeegee Down
Scrub Brush Down and On
Vacuum Clogged
Recovery Tank Full
Solution Flow
Hour Meter
Circuit Breaker #1
Circuit Breaker #2
Circuit Breaker #3
Circuit Breaker #4
Circuit Breaker #5
Circuit Breaker #6
Circuit Breaker #7
Circuit Breaker #8

OPERATION
2-7
510E MM239 (8--92)
B
C
D
EF
G
HIJK
L
M
N
O
P
Q
RS T
UA
V
05913
CONTROLS AND INSTRUMENTS
A. Brake Pedal M. Brush Circuit Breaker Indicator
B. Directional Pedal N. Rear Squeegee and
C. Steering Wheel Vacuum Fan Switch
D. Solution Flow Lever O. Scrub Brush Switch
E. Clogged Vacuum Indicator P. Horn Button
F. Recovery Tank Full Indicator Q. Key-Operated On-Off Switch
G. Hour Meter R. Operating Lights Switch/Revolving
H. Brush Pressure Indicator Light Switch
I. Brush Pressure Switch S. Pre-SweeptSwitch
J. Edge Scrub Switch T. EStSwitch
K. Battery Discharge Indicator U. Parking Brake
L. Electrical Power Indicator V. Power Wand Switch

OPERATION
510E MM239 (3--95)
2-8
BRAKE PEDAL
The brake pedal operates the brakes on the two
rear wheels.
To stop the machine, return the direction control
pedal to neutral, then apply pressure to the brake
pedal.
DIRECTIONAL PEDAL
The directional pedal controls the propelling drive.
The pedal is used to select the direction of travel
and the speed of the machine.
A
B
C
D
E
00116
DIRECTIONAL PEDAL POSITIONS
A. “Reverse” Position
B. “Neutral” Position
C. “Forward” Position
D. “Heel” Portion
E. “Toe” Portion
Gradually press the “toe” portion of the pedal for
forward travel or the “heel” portion for reverse
travel. Regulate the machine speed by varying the
pressure on the pedal.
The machine will coast for a short distance before
changing direction when it is moving and the
directional pedal is reversed. Use the brakes to
stop the machine.
FOR SAFETY: When Using Machine, Use
Brakes To Stop Machine.
STEERING WHEEL
The steering wheel controls the front drive wheel.
The machine is very responsive to the movement
of the steering wheel. The operator should use
care until he or she becomes experienced in
guiding the machine.
SOLUTION FLOW LEVER
The solution flow lever controls the flow of
solution to the floor. To start the solution flow,
push the lever slightly up. To increase the solution
flow to maximum, push the lever all the way up.
To stop the solution flow to the floor, pull the lever
all the way down.
CLOGGED VACUUM INDICATOR
The clogged vacuum indicator lights when
the vacuum system is obstructed and the vacuum
is no longer picking solution from the floor.
When the clogged vacuum indicator lights, check
the vacuum system hoses for obstructions
starting at the rear squeegee pick-up hose.
RECOVERY TANK FULL INDICATOR
The recovery tank full indicator lights when
the recovery tank is full.
HOUR METER
The hour meter records the number of hours
the machine has operated. This information is
useful in determining when to service the
machine.
BRUSH PRESSURE INDICATOR AND SWITCH
The brush pressure indicator shows the
brush pressure selection. The brush pressure
switch controls how aggressive the brushes
are scrubbing the floor.
The brush pressure switch has four positions.
Under normal conditions, the brush pressure
should be set in the light zone. Under heavy grime
conditions, the brush pressure should be set in
the heavy zones. Travel speed and floor
conditions will affect the scrubbing performance.
To change the brush pressure, touch the brush
pressure switch. Each time the switch is touched,
it will increase brush pressure until it reaches the
maximum setting. Then it will return to the
minimum setting as shown on the pressure
indicator.
