Tennant t500e User manual

R
For the latest Parts manuals and other
language Operator manuals, visit:
www.tennantco.com/manuals
T500e
*9015505*
www.tennantco.com
Parts Manual
9015505
Rev. 01 (02-2017)
North America / International
Walk-Behind Floor Scrubber
(S/N 10000000- 20000000)
TennantTrue®Parts
IRIS®a Tennant Technology
Insta-Fit™ Adapter
Smart-Fill™ Automatic Battery Watering

Ref Part No. Serial Number Description Qty.
1 82681 (000000- ) Bracket Wldt, Lpg Mount 1
o2 63810 (000000- ) Latch Assy, Lpg Tank Mtg, W/Nut 4
Y3 51839 (000000- ) Nut Adjustable, Lpg Tank Mtg 2
4 49263 (000000- ) Tie, Cable 3
5 82556 (000000- 001039) Bracket, Vaporizer 1
6 54930 (000000- ) Vaporizer, LPG 1
C
D
A
B
HOW TO ORDER PARTS - See diagram above
Only use TENNANT Company supplied or equivalent parts. Parts and supplies may be ordered online,
by phone, by fax or by mail.
Follow the steps below to ensure prompt delivery.
1. (A) Identify the machine model.
2. (B) Identify the machine serial number from the data label.
3. (C) Ensure the proper serial number is used from
the parts list.
4. Identify the part number and quantity.
Do not order by page or reference numbers.
5. Provide your name, company name, customer ID number,
billing and shipping address, phone number and
purchase order number.
6. Provide detail shipping instructions.
(D) - identifies an assembly
Y- identifies parts included in assembly
Please fill out at time of installation for
future reference.
Model No. -
Serial No. -
Machine Options -
Sales Rep. -
Sales Rep. phone no. -
Customer ID Number -
Installation Date -
Tennant Company
PO Box 1452
Minneapolis, MN 55440 USA
Phone: [phone] or
(763) 513- 2850
www.tennantco.com
Specifications and parts are subject to change without notice.
Copyright E2017 TENNANT Company, Printed in U.S.A.

CÓMO SOLICITAR PIEZAS - Consulte el diagrama anterior.
Utilice sólo las piezas suministradas por TENNANT Company o piezas equivalentes. Puede solicitar las piezas a través de internet,
por teléfono, por fax o por correo.
Siga los siguientes pasos para que la entrega sea rápida.
1. (A) Indique el modelo de máquina.
2. (B) Indique el número de serie de la etiqueta de datos.
3. (C) Asegúrese de que indica el número de serie correcto de la lista de piezas.
4. Indique la cantidad y el número de la pieza.
No realice el pedidoindicando el número de página o el de referencia.
5. Incluya su nombre, el nombre de la empresa, el ID de cliente,
las direcciones de envío y facturación, el número de teléfono y el número del pedido de compra.
6. Facilite instrucciones de envío.
(D) o- identifica un conjunto
Y- identifica piezas de un conjunto
ES
Rellene estos datos cuando realice la instalación para utilizarlos
como referencia en el futuro.
Nº modelo -
Nº serie -
Opciones de la máquina -
Vendedor -
Nº teléfono vendedor -
Nº cliente -
Fecha de instalación -
COMMENT COMMANDER DES PIÈCES DÉTACHÉES - Voir le schéma ci- dessus.
Utilisez uniquement des pièces fournies par la société TENNANT ou équivalentes. Les pièces et fournitures peuvent être commandées en ligne, par téléphone, fax, ou par
courrier.
Suivez les étapes ci- dessous pour assurer une livraison rapide.
1. (A) Identifiez le modèle de la machine.
2. (B) Identifiez le numéro de série de la machine, à partir de l’étiquette signalétique.
3. (C) Assurez- vous que le numéro de série correct est utilisé à partir de la liste de pièces détachées.
4. Identifiez le numéro de pièce et la quantité. Ne commandez pas par page ou numéros de référence.
5. Fournissez votre nom, le nom de votre société, votre numéro d’identification de client, l’adresse
de facturation et d’expédition, le numéro de téléphone et le numéro du bon de commande.
6. Fournissez des instructions d’expédition détaillées.
(D) o- identifie un assemblage
Y- identifie les pièces composant l’assemblage
FR
A remplir au moment de l’installation à titre de référence.
Nº du modèle -
Nº de série -
Optionsdelamachine-
Agent commercial -
Nº tél. de l’agent commercial -
Numéro d’identification client -
Date d’installation -

TABLE OF CONTENTS
Tennant T500e (02- 2017) 5
STANDARD PARTS
GENERAL RECOMMENDED MAINTENANCE
ITEMS 7...................................
REPLACEMENT BRUSHES AND PAD
DRIVER DISK 10............................
REPLACEMENT BRUSHES CYLINDRICAL 12....
REPLACEMENT PADS ORBITAL 13.............
SCRUB HEAD GROUP, DISK 650MM / 26IN 14...
SCRUB HEAD GROUP, DISK 700MM / 28IN 16...
SCRUB HEAD GROUP, DISK 800MM / 32IN 18...
SCRUB HEAD GROUP, CYLINDRICAL
700MM / 28IN 20............................
SCRUB HEAD GROUP, CYLINDRICAL
700MM / 28IN - CONT’D 22...................
SCRUB HEAD GROUP, ORBITAL
700MM / 28IN 24............................
RECOVERY TANK GROUP 26..................
SOLUTION TANK GROUP 28...................
STANDARD ELECTRICAL GROUP 30...........
FRAME AND DRIVE GROUP 32.................
HEAD LIFT GROUP, DISK 34...................
HEAD LIFT GROUP, CYLINDRICAL 36...........
HEAD LIFT GROUP, ORBITAL 38................
LOWER CONSOLE GROUP, ON- BOARD
CHARGER 40...............................
LOWER CONSOLE GROUP, OFF- BOARD
CHARGER 42...............................
CONSOLE GROUP 44.........................
SQUEEGEE LIFT GROUP 46...................
SQUEEGEE ASSEMBLY, 500MM / 20IN 48.......
SQUEEGEE ASSEMBLY, 650MM / 26IN 50.......
SQUEEGEE ASSEMBLY, 700MM / 28IN 52.......
SQUEEGEE ASSEMBLY, 800MM / 32IN 54.......
STANDARD SOLUTION GROUP 56.............
STANDARD BATTERY CABLES GROUP 58......
LABEL GROUP 59.............................
ELECTRICAL DIAGRAM 60.....................
ELECTRICAL HARNESS, MAIN 64..............
ELECTRICAL HARNESS, OPERATOR STATION 70
ELECTRICAL HARNESS, BAIL SWITCH 72.......
OPTIONS
TELEMETRY BATTERY CABLES GROUP 73.....
TELEMETRY ELECTRICAL GROUP 74..........
ec-H2O SOLUTION GROUP 76.................
PARKING BRAKE GROUP 78...................
CONTROL VALVE DRAIN HOSE 80..............
BATTERY GROUP, WET 225AH 81..............
BATTERY GROUP, WET 260AH 82..............
BATTERY GROUP, AGM 220AH 83..............
SMART-FILLtAUTOMATIC BATTERY
WATERING GROUP 84......................
HYDROLINKRMANUAL BATTERY
WATERING KIT 86...........................
DOCUMENTATION GROUP 88..................
BREAKDOWNS
ec- H2O NANOCLEAN MODULE BREAKDOWN 90
ORBITAL HEAD ECCENTRIC DRIVE
BREAKDOWN 92............................
AUTOMATIC BATTERY WATERING MODULE
BREAKDOWN 94............................

TABLE OF CONTENTS
6Tennant T500e (01- 2017)

RECOMMENDED MAINTENANCE ITEMS
Tennant T500e (01- 2017) 7
GENERAL RECOMMENDED MAINTENANCE ITEMS
Part No. Serial Number Description Qty.
1223989 (10000000- 20000000 )Brush Assy, Disk, Scb, 13.0d, Pyp 2
1223991 (10000000- 20000000 ) Brush Assy, Disk, Scb, 13.0d, Nyl 2
1223990 (10000000- 20000000 ) Brush Assy, Disk, Scb, 13.0d, Sab 2
89046 (10000000- 20000000 ) Pad, Stripping, 13.0d, Brown[1pick=1pad] 2
89047 (10000000- 20000000 ) Pad, Scb, 13.0d, Blu 2
89048 (10000000- 20000000 )Pad, Buff, 13.0d, Red [1pick=1pad] 2
89049 (10000000- 20000000 ) Pad, Polish, 13.0d, White [1pick=1pad] 2
1051024 (10000000- 20000000 ) Pad, Surf Prep, 13.0d [Mar, 1pick=1pad] 2
1220218 (10000000- 20000000 ) Brush Assy, Disk, Scb, 14.0d, Pyp 2
1221541 (10000000- 20000000 ) Brush Assy, Disk, Scb, 14.0d, Nyl 2
1220217 (10000000- 20000000 )Brush Assy, Disk, Scb, 14.0d, Sab 2
222327 (10000000- 20000000 ) Pad, Stripping, 14.0d, Brown[1pick=1pad] 2
222326 (10000000- 20000000 ) Pad, Scb, 14.0d, Blu [1pick=1pad] 2
222325 (10000000- 20000000 ) Pad, Buff, 14.0d, Red 2
222324 (10000000- 20000000 ) Pad, Polish, 14.0d, White [1pick=1pad] 2
370091 (10000000- 20000000 )Pad, Stripping, 14.0d, Blk [Hi Prod] 2
1051026 (10000000- 20000000 ) Pad, Surf Prep, 14.0d [Mar, 1pick=1pad] 2
1220216 (10000000- 20000000 ) Brush Assy, Disk, Scb, 16.0d, Pyp 2
1220215 (10000000- 20000000 ) Brush Assy, Disk, Scb, 16.0d, Nyl 2
1220214 (10000000- 20000000 ) Brush Assy, Disk, Scb, 16.0d, Sab 2
63248- 1 (10000000- 20000000 )Pad, Stripping, 16.0d, Brown[1pick=1pad] 2
63248- 2 (10000000- 20000000 ) Pad, Scb, 16.0d, Blu [1pick=1pad] 2
63248- 3 (10000000- 20000000 ) Pad, Buff, 16.0d, Red [1pick=1pad] 2
63248- 4 (10000000- 20000000 ) Pad, Polish, 16.0d, White [1pick=1pad] 2
370092 (10000000- 20000000 ) Pad, Stripping, 16.0d, Blk [Hi Prod] 2
1051027 (10000000- 20000000 )Pad, Surf Prep, 16.0d [Mar, 1pick=1pad] 2
222304 (10000000- 20000000 ) Brush, Scb, 28l, 18sr, Pyp, Spl 2
222305 (10000000- 20000000 ) Brush, Scb, 28l, 18sr, Nyl, Spl 2
222306 (10000000- 20000000 ) Brush, Scb, 28l, 18sr, Abr, Spl 2
1223247 (10000000- 20000000 ) Pad, Scb, 28 X 14, Blu [1pick=1pc] 1
1218157 (10000000- 20000000 )Pad, Buff, 28 X 14, Red [1pick=1pc] 1
1223246 (10000000- 20000000 ) Pad, Polish, 28 X 14, White [1pick=1pc] 1
1223248 (10000000- 20000000 ) Pad, Surf Prep, 28 X 14, Mar [1pick=1pc] 1
1223250 (10000000- 20000000 ) Pad, Scb, 28 X 14, Green [1pick=1ctn] 1
1075563 (10000000- 20000000 )Pad, Stripping, 28 X 14, Blk [1pick=1ctn] 1
1221839 (10000000- 20000000 )Pad, Backer, 28 X 14 1
222403 (10000000- 20000000 )Wheel, 02.0d 0.88w 0.50b (Disk Head) 2
1221522 (10000000- 20000000 ) Bumper, Head, 65cm, Skirt, Im [T500] 1
1221520 (10000000- 20000000 ) Bumper, Head, 70cm, Skirt, Im [T500] 1
1221512 (10000000- 20000000 ) Bumper, Head, 80cm, Skirt, Im [T500] 1
630477 (10000000- 20000000 )Wheel, Pyu, 02.0d 0.38w, Gray (Cylindrical Head) 6
1023067 (10000000- 20000000 ) Motor, Ele, 24vdc 0220rpm 0.75hp Gear (Disk Head) 2
Y1031775 (10000000- 20000000 ) Brush Kit, Carbon, Motor, Replmt [T5] (Disk Head) 1
1223429 (10000000- 20000000 ) Motor, Ele, 24vdc 1500rpm 0.60hp (Cylindrical Head) 2
Y1031775 (10000000- 20000000 )Brush Kit, Carbon, Motor, Replmt [T5] (Cylindrical Head) 1
1218573 (10000000- 20000000 )Skirt, Side, Scrb, Cyl [T500] 4
9015765 (10000000- 20000000 )Belt Kit, Motor, Ci (Cylindrical Head) 1
Y1213132 (10000000- 20000000 ) Tool, Installation, Belt (Cylindrical Head) 1
1219913 (10000000- 20000000 ) Motor, Ele, 24vdc, 2200rpm, 0.75hp 28.0a (Orbital Head) 1
Y1059370 (10000000- 20000000 )Brush, Motor, Replmt [Bag Of 4) (Orbital Head) 1
1014918 (10000000- 20000000 )Wheel, 03.0d 0.88w 0.31b, W/ Bshg, Rbr (Orbital Head) 2

RECOMMENDED MAINTENANCE ITEMS
Tennant T500e (01- 2017)
8
GENERAL RECOMMENDED MAINTENANCE ITEMS
Part No. Serial Number Description Qty.
9015731 (10000000- 20000000 )Blade Kit, 500mm, Linatex (Standard) 1
Y1203953 (10000000- 20000000 )Blade, Sqge, Rear, 836l, Linatex[500mm] (Standard) 1
Y1203954 (10000000- 20000000 )Blade, Sqge, Front, 788l, Linatex[500mm] (Standard) 1
9015732 (10000000- 20000000 )Blade Kit, 500mm, Urethane (Option) 1
Y1215609 (10000000- 20000000 )Blade, Sqge, Rear, 836l, Urethane[500mm] (Option) 1
Y1215611 (10000000- 20000000 )Blade, Sqge, Front, 788l, Urethane[500mm (Option) 1
9015730 (10000000- 20000000 )Blade Kit, 500mm, Gum (Option) 1
Y1215610 (10000000- 20000000 )Blade, Sqge, Rear, 836l, Gum[500mm] (Option) 1
Y1215612 (10000000- 20000000 ) Blade, Sqge, Front, 788l, Gum[500mm] (Option) 1
9015734 (10000000- 20000000 )Blade Kit, 650mm, Linatex (Standard) 1
Y1221585 (10000000- 20000000 )Blade, Sqge, Rear, 1166l, Linatex[650mm] (Standard) 1
Y1221586 (10000000- 20000000 )Blade, Sqge, Front, 1072l Linatex[650mm] (Standard) 1
9015735 (10000000- 20000000 )Blade Kit, 650mm, Urethane (Option) 1
Y1228909 (10000000- 20000000 )Blade, Sqge, Rear, 1136l,Urethane[650mm] (Option) 1
Y1228915 (10000000- 20000000 )Blade, Sqge, Front,1072l,Urethane[650mm] (Option) 1
9015733 (10000000- 20000000 )Blade Kit, 650mm, Gum (Option) 1
Y1228910 (10000000- 20000000 )Blade, Sqge, Rear, 1136l, Gum[650mm] (Option) 1
Y1228919 (10000000- 20000000 )Blade, Sqge, Front, 1072l Gum[650mm] (Option) 1
9015737 (10000000- 20000000 )Blade Kit, 700mm, Linatex (Standard) 1
Y1221572 (10000000- 20000000 )Blade, Sqge, Rear, 1204l, Linatex[700mm] (Standard) 1
Y1221573 (10000000- 20000000 )Blade, Sqge, Front, 1148l Linatex[700mm] (Standard) 1
9015738 (10000000- 20000000 )Blade Kit, 700mm, Urethane (Option) 1
Y1228904 (10000000- 20000000 )Blade, Sqge, Rear, 1204l,Urethane[700mm] (Option) 1
Y1228906 (10000000- 20000000 )Blade, Sqge, Front,1148l Urethane[700mm] (Option) 1
9015736 (10000000- 20000000 )Blade Kit, 700mm, Gum (Option) 1
Y1228905 (10000000- 20000000 )Blade, Sqge, Rear, 1204l, Gum[700mm] (Option) 1
Y1228907 (10000000- 20000000 )Blade, Sqge, Front, 1148l Gum[700mm] (Option) 1
9015740 (10000000- 20000000 )Blade Kit, 800mm, Linatex (Standard) 1
Y1221115 (10000000- 20000000 )Blade, Sqge, Rear, 1306l, Linatex[800mm] (Standard) 1
Y1221116 (10000000- 20000000 )Blade, Sqge, Front, 1256l Linatex[800mm] (Standard) 1
9015741 (10000000- 20000000 )Blade Kit, 800mm, Urethane (Option) 1
Y1228920 (10000000- 20000000 )Blade, Sqge, Rear, 1306l,Urethane[800mm] (Option) 1
Y1228922 (10000000- 20000000 )Blade, Sqge, Front,1256l Urethane[800mm] (Option) 1
9015739 (10000000- 20000000 )Blade Kit, 800mm, Gum (Option) 1
Y1228921 (10000000- 20000000 )Blade, Sqge, Rear, 1306l, Gum[800mm] (Option) 1
Y1228923 (10000000- 20000000 )Blade, Sqge, Front, 1256l Gum[800mm] (Option) 1

RECOMMENDED MAINTENANCE ITEMS
Tennant T500e (01- 2017) 9
GENERAL RECOMMENDED MAINTENANCE ITEMS
Part No. Serial Number Description Qty.
630052 (10000000- 20000000 )Float, Shut- Off, (2)Ball, 1.75d 1
9015756 (10000000- 20000000 )Seal, Cover, Recvy, Ci [T500] 1
1224414 (10000000- 20000000 )Hose Assy, W/2cuff,1.5d 033l 1.5/1.5[Pu] (Gray) 1
1211220 (10000000- 20000000 )Hose Assy,W/2cuff,1.5d 022l 1.5/1.5[Pvc] (Black) 1
1228242 (10000000- 20000000 )Hose Assy, Drain, 1.5d 024l 2/1.5cap[Pu] (Gray) 1
Y1219134 (10000000- 20000000 )Cap, Drain Assy [Gray] 1
1228252 (10000000- 20000000 )Hose Assy, Drain, 1.5d 014l 2/1.5cap Pvc (Black) 1
Y1218955 (10000000- 20000000 ) Cap, Drain Assy [Black] 1
9015758 (10000000- 20000000 )Seal, Tank, Soltn, Ci [T500/T500e] 1
1066431 (10000000- 20000000 )Seal, Afmkt, Bulb, Dual, 03ft [F/.30gap](Soltn Tank Front) 1
1212422 (10000000- 20000000 )Caster, Swivel [Wicke 224051] 2
9004909 (10000000- 20000000 )Wheel Kit, Solid, Ci [T5 T5e Ss5] 1
Y1223583 (10000000- 20000000 )Wheel, Scrbr, 213mm, W/ Taper 2
1031723 (10000000- 20000000 ) Motor, Transaxle, 24vdc, Afmkt [T5] 1
Y614166 (10000000- 20000000 ) Brush Kit, Carbon, Transaxle, Replmt [4] 1
1219312 (10000000- 20000000 )Fan, Vacuum, 5.7d, 024vdc, 2 Stage 1
Y372883 (10000000- 20000000 ) Vr, Brush Kit, Motor, Ele 1
100038 (10000000- 20000000 )Gasket, .50, 02.63id 05.75od, Adh [Epdm] 1
1211537 (10000000- 20000000 ) Filter, In- Line, Pf06/Pf06 080m 2.6l Epd 1
Y1218885 (10000000- 20000000 ) Gasket [Epdm, F/1211537] 1
Y1218883 (10000000- 20000000 )Screen, Fltr, 80 Mesh, Ss [W/ Cage] 1
Y613991 (10000000- 20000000 ) Bowl, Clr, Short, F/1005302 1
9011810 (10000000- 20000000 ) Module Kit, Replmt [Ec- H2o, B 02] (Includes Cartridge) 1
9014127 (10000000- 20000000 )Controller Kit, Replmt [Ec- H2o Nc] (Includes Cartridge) 1
Y9013646 (10000000- 20000000 ) Cartridge, Ec- H2o Nanoclean Wcm, 270ml 1
9015727 (10000000- 20000000 )Hose Kit, Drain, Pu, W/ Valve, Ci[T500e] (Gray) 1
Y1051986 (10000000- 20000000 )Valve, Ball, 2way, 1.0id Pvc, W/Handle 1
Y1228335 (10000000- 20000000 )Hose Assy, W/2cuff,1.5d 022l 2.0/1.5[Pu] (Gray) 1
Y1229567 (10000000- 20000000 )Strap, Hanger 1

STANDARD PARTS
Tennant T500e (01- 2017)
10
REPLACEMENT BRUSHES AND PAD DRIVER DISK
1
2
3
4
5
6
7
8
9
355426

STANDARD PARTS
Tennant T500e (01- 2017) 11
REPLACEMENT BRUSHES AND PAD DRIVER DISK
Ref. Part No. Serial Number Description Qty.
11223989 (10000000- 20000000 )Brush Assy, Disk, Scb, 13.0d, Pyp 2
1 1223991 (10000000- 20000000 ) Brush Assy, Disk, Scb, 13.0d, Nyl 2
1 1223990 (10000000- 20000000 ) Brush Assy, Disk, Scb, 13.0d, Sab 2
1 1220218 (10000000- 20000000 ) Brush Assy, Disk, Scb, 14.0d, Pyp 2
1 1221541 (10000000- 20000000 ) Brush Assy, Disk, Scb, 14.0d, Nyl 2
11220217 (10000000- 20000000 )Brush Assy, Disk, Scb, 14.0d, Sab 2
1 1220216 (10000000- 20000000 ) Brush Assy, Disk, Scb, 16.0d, Pyp 2
1 1220215 (10000000- 20000000 ) Brush Assy, Disk, Scb, 16.0d, Nyl 2
1 1220214 (10000000- 20000000 ) Brush Assy, Disk, Scb, 16.0d, Sab 2
Y2 9014667 (10000000- 20000000 ) Brush Kit, Hub Assy, Drive, Ci [Comm] 1
31220220 (10000000- 20000000 )Driver Assy, Pad, 13.0d, Brush 2
3 1220221 (10000000- 20000000 ) Driver Assy, Pad, 14.0d, Brush 2
3 1220222 (10000000- 20000000 ) Driver Assy, Pad, 16.0d, Brush 2
Y4 9014667 (10000000- 20000000 ) Brush Kit, Hub Assy, Drive, Ci [Comm] 1
Y5 370095 (10000000- 20000000 ) Device, Centering, Clip On, Tl [Gf Pp] 1
Y641579 (10000000- 20000000 )Washer, Flat, 08, Ss 3
Y7 04403 (10000000- 20000000 ) Screw, Pan, Phl, M4 X 0.70 X 25, Nl, Ss 3
Y8 10908 (10000000- 20000000 ) Nut, T, M4 X 0.70 3
9 89046 (10000000- 20000000 ) Pad, Stripping, 13.0d, Brown[1pick=1pad] 2
9 89047 (10000000- 20000000 ) Pad, Scb, 13.0d, Blu 2
989048 (10000000- 20000000 )Pad, Buff, 13.0d, Red [1pick=1pad] 2
9 89049 (10000000- 20000000 ) Pad, Polish, 13.0d, White [1pick=1pad] 2
9 1051024 (10000000- 20000000 ) Pad, Surf Prep, 13.0d [Mar, 1pick=1pad] 2
9 222327 (10000000- 20000000 ) Pad, Stripping, 14.0d, Brown[1pick=1pad] 2
9 222326 (10000000- 20000000 ) Pad, Scb, 14.0d, Blu [1pick=1pad] 2
9222325 (10000000- 20000000 )Pad, Buff, 14.0d, Red 2
9 222324 (10000000- 20000000 ) Pad, Polish, 14.0d, White [1pick=1pad] 2
9 370091 (10000000- 20000000 ) Pad, Stripping, 14.0d, Blk [Hi Prod] 2
9 1051026 (10000000- 20000000 ) Pad, Surf Prep, 14.0d [Mar, 1pick=1pad] 2
9 63248- 1 (10000000- 20000000 ) Pad, Stripping, 16.0d, Brown[1pick=1pad] 2
963248- 2 (10000000- 20000000 )Pad, Scb, 16.0d, Blu [1pick=1pad] 2
9 63248- 3 (10000000- 20000000 ) Pad, Buff, 16.0d, Red [1pick=1pad] 2
9 63248- 4 (10000000- 20000000 ) Pad, Polish, 16.0d, White [1pick=1pad] 2
9 370092 (10000000- 20000000 ) Pad, Stripping, 16.0d, Blk [Hi Prod] 2
91051027 (10000000- 20000000 )Pad, Surf Prep, 16.0d [Mar, 1pick=1pad] 2
ASSEMBLY
YINCLUDED IN ASSEMBLY

STANDARD PARTS
Tennant T500e (01- 2017)
12
REPLACEMENT BRUSHES CYLINDRICAL
355427
1
Ref. Part No. Serial Number Description Qty.
1222304 (10000000- 20000000 )Brush, Scb, 28l, 18sr, Pyp, Spl 2
1 222305 (10000000- 20000000 ) Brush, Scb, 28l, 18sr, Nyl, Spl 2
1 222306 (10000000- 20000000 ) Brush, Scb, 28l, 18sr, Abr, Spl 2

STANDARD PARTS
Tennant T500e (01- 2017) 13
REPLACEMENT PADS ORBITAL
355478
1
2
Ref. Part No. Serial Number Description Qty.
11223247 (10000000- 20000000 )Pad, Scb, 28 X 14, Blu [1pick=1pc] 1
1 1218157 (10000000- 20000000 ) Pad, Buff, 28 X 14, Red [1pick=1pc] 1
1 1223246 (10000000- 20000000 ) Pad, Polish, 28 X 14, White [1pick=1pc] 1
1 1223248 (10000000- 20000000 ) Pad, Surf Prep, 28 X 14, Mar [1pick=1pc] 1
1 1223250 (10000000- 20000000 ) Pad, Scb, 28 X 14, Green [1pick=1ctn] 1
11075563 (10000000- 20000000 )Pad, Stripping, 28 x 14, Blk [1pick=1ctn] 1
2 1221839 (10000000- 20000000 ) Pad, Backer, 28 X 14 (Includes Velcro Fasteners) 1

STANDARD PARTS
Tennant T500e (01- 2017)
14
SCRUB HEAD GROUP, DISK 650MM / 26IN
1
2
3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21 20
4
5
6
7
22
8
9
10
11
12
13
14
23
23
24
25
26
27
28
29
24
25
26
27
28
29
355421

STANDARD PARTS
Tennant T500e (01- 2017) 15
SCRUB HEAD GROUP, DISK 650MM / 26IN
Ref. Part No. Serial Number Description Qty.
11023067 (10000000- 20000000 )Motor, Ele, 24vdc 0220rpm 0.75hp Gear 2
Y2 1031775 (10000000- 20000000 ) Brush Kit, Carbon, Motor, Replmt [T5] 1
Y3 1031681 (10000000- 20000000 ) Harness, Connector, Brush- Motor [T5] Us 1
4 1022549 (10000000- 20000000 ) Spacer, Shaft, 17.15b 30.0d 3.0l, Ss 2
5 1025853 (10000000- 20000000 ) Screw, Set, M6 X 1.00 X 35, Nl, Ss 8
61222988 (10000000- 20000000 )Knob, Rnd, 31.0d 27.0l M10, Plstc 2
7 626081 (10000000- 20000000 ) Spring, Cmpr, 0.48od .04wir 03.5l 2
81227865 (10000000- 20000000 ) Screw, Trs, M6 X 1.0 X 12, Phl, Ss, Nl 4
901684 (10000000- 20000000 )Washer, Flat, 0.27b 0.69d .05, Ss 4
10 397826 (10000000- 20000000 ) Screw, Btn, M8 X 1.25 X 40, Ss 2
11 1227709 (10000000- 20000000 )Bracket, Roller, Wall 2
12 222496 (10000000- 20000000 )Sleeve, P/M, 0.32b 0.50d 0.9l [430ss] 2
13 222403 (10000000- 20000000 )Wheel, 02.0d 0.88w 0.50b 2
14 08713 (10000000- 20000000 ) Nut, Hex, Lock, M8 X 1.25, Nl, Ss 2
15 1222365 (10000000- 20000000 ) Housing, Disc, Dual, 65cm [Machined] 1
16 1221522 (10000000- 20000000 )Bumper, Head, 65cm, Skirt, Im [T500] 1
17 1034731 (10000000- 20000000 ) Screw, Hex, M6 X 1.00 X 16, Sems, Ss 1
18 1074344 (10000000- 20000000 ) Harness, Ele [Ring With .250m Tail] 1
19 1210807 (10000000- 20000000 ) Wire, Tie [W/.25” Fir Tree Clip] 1
20 130773 (10000000- 20000000 ) Tie, Cable, Nyl, 11.0l, .14w, 3.0 Max. D 2
21 9014145 (10000000- 20000000 )Hose, Afmkt, Pe, .375id .50od, 05ft 1
22 1212858 (10000000- 20000000 ) Fitting, Plstc, Tee, Qf08/Qf08/Qf08 1
23 09746 (10000000- 20000000 ) Screw, Hex, M10 X 1.50 X 90, Ss 2
24 01684 (10000000- 20000000 ) Washer, Flat, 0.27b 0.69d .05, Ss 8
25 08712 (10000000- 20000000 ) Nut, Hex, Lock, M6 X 1.00, Nl, Ss 8
26 1014328 (10000000- 20000000 )Key, Sq, 05mm X 05mm, 25mml 2
27 1071637 (10000000- 20000000 ) Hub, Drive, Brush, Disk, 17mmb 2
28 1017218 (10000000- 20000000 ) Washer, Flat, 0.32b 1.00d .12, Ss 2
29 12273 (10000000- 20000000 ) Screw, Hex, M8 X 1.25 X 20, Nl, Ss 2
ASSEMBLY
YINCLUDED IN ASSEMBLY

STANDARD PARTS
Tennant T500e (01- 2017)
16
SCRUB HEAD GROUP, DISK 700MM / 28IN
1
2
3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21 20
4
5
6
722
8
9
10
11
12
13
14
23
23
24
25
26
27
28
29
24
25
26
27
28
29
355422

STANDARD PARTS
Tennant T500e (01- 2017) 17
SCRUB HEAD GROUP, DISK 700MM / 28IN
Ref. Part No. Serial Number Description Qty.
11023067 (10000000- 20000000 )Motor, Ele, 24vdc 0220rpm 0.75hp Gear 2
Y2 1031775 (10000000- 20000000 ) Brush Kit, Carbon, Motor, Replmt [T5] 1
Y3 1031681 (10000000- 20000000 ) Harness, Connector, Brush- Motor [T5] Us 1
4 1022549 (10000000- 20000000 ) Spacer, Shaft, 17.15b 30.0d 3.0l, Ss 2
5 1025853 (10000000- 20000000 ) Screw, Set, M6 X 1.00 X 35, Nl, Ss 8
61222988 (10000000- 20000000 )Knob, Rnd, 31.0d 27.0l M10, Plstc 2
7 626081 (10000000- 20000000 ) Spring, Cmpr, 0.48od .04wir 03.5l 2
81227865 (10000000- 20000000 ) Screw, Trs, M6 X 1.0 X 12, Phl, Ss, Nl 4
901684 (10000000- 20000000 )Washer, Flat, 0.27b 0.69d .05, Ss 4
10 397826 (10000000- 20000000 ) Screw, Btn, M8 X 1.25 X 40, Ss 2
11 1227709 (10000000- 20000000 )Bracket, Roller, Wall 2
12 222496 (10000000- 20000000 ) Sleeve, P/M, 0.32b 0.50d 0.9l [430ss] 2
13 222403 (10000000- 20000000 )Wheel, 02.0d 0.88w 0.50b 2
14 08713 (10000000- 20000000 ) Nut, Hex, Lock, M8 X 1.25, Nl, Ss 2
15 1222364 (10000000- 20000000 ) Housing, Disc, Dual, 70cm [Machined] 1
16 1221520 (10000000- 20000000 )Bumper, Head, 70cm, Skirt, Im [T500] 1
17 1034731 (10000000- 20000000 ) Screw, Hex, M6 X 1.00 X 16, Sems, Ss 1
18 1074344 (10000000- 20000000 ) Harness, Ele [Ring With .250m Tail] 1
19 1210807 (10000000- 20000000 ) Wire, Tie [W/.25” Fir Tree Clip] 1
20 130773 (10000000- 20000000 ) Tie, Cable, Nyl, 11.0l, .14w, 3.0 Max. D 2
21 9014145 (10000000- 20000000 )Hose, Afmkt, Pe, .375id .50od, 05ft 1
22 1212858 (10000000- 20000000 ) Fitting, Plstc, Tee, Qf08/Qf08/Qf08 1
23 09746 (10000000- 20000000 ) Screw, Hex, M10 X 1.50 X 90, Ss 2
24 01684 (10000000- 20000000 ) Washer, Flat, 0.27b 0.69d .05, Ss 8
25 08712 (10000000- 20000000 ) Nut, Hex, Lock, M6 X 1.00, Nl, Ss 8
26 1014328 (10000000- 20000000 )Key, Sq, 05mm X 05mm, 25mml 2
27 1071637 (10000000- 20000000 ) Hub, Drive, Brush, Disk, 17mmb 2
28 1017218 (10000000- 20000000 ) Washer, Flat, 0.32b 1.00d .12, Ss 2
29 12273 (10000000- 20000000 ) Screw, Hex, M8 X 1.25 X 20, Nl, Ss 2
ASSEMBLY
YINCLUDED IN ASSEMBLY

STANDARD PARTS
Tennant T500e (01- 2017)
18
SCRUB HEAD GROUP, DISK 800MM / 32IN
355423
1
2
3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 21
21 20
4
5
6
722
8
9
10
11
12
13
14
23
23
24
25
26
27
28
29
24
25
26
27
28
29

STANDARD PARTS
Tennant T500e (01- 2017) 19
SCRUB HEAD GROUP, DISK 800MM / 32IN
Ref. Part No. Serial Number Description Qty.
11023067 (10000000- 20000000 )Motor, Ele, 24vdc 0220rpm 0.75hp Gear 2
Y2 1031775 (10000000- 20000000 ) Brush Kit, Carbon, Motor, Replmt [T5] 1
Y3 1031681 (10000000- 20000000 ) Harness, Connector, Brush- Motor [T5] Us 1
4 1022549 (10000000- 20000000 ) Spacer, Shaft, 17.15b 30.0d 3.0l, Ss 2
5 1025853 (10000000- 20000000 ) Screw, Set, M6 X 1.00 X 35, Nl, Ss 8
61222988 (10000000- 20000000 )Knob, Rnd, 31.0d 27.0l M10, Plstc 2
7 626081 (10000000- 20000000 ) Spring, Cmpr, 0.48od .04wir 03.5l 2
81227865 (10000000- 20000000 ) Screw, Trs, M6 X 1.0 X 12, Phl, Ss, Nl 4
901684 (10000000- 20000000 )Washer, Flat, 0.27b 0.69d .05, Ss 4
10 397826 (10000000- 20000000 ) Screw, Btn, M8 X 1.25 X 40, Ss 2
11 1227709 (10000000- 20000000 )Bracket, Roller, Wall 2
12 222496 (10000000- 20000000 )Sleeve, P/M, 0.32b 0.50d 0.9l [430ss] 2
13 222403 (10000000- 20000000 )Wheel, 02.0d 0.88w 0.50b 2
14 08713 (10000000- 20000000 ) Nut, Hex, Lock, M8 X 1.25, Nl, Ss 2
15 1222293 (10000000- 20000000 ) Housing, Disc, Dual, 80cm [Machined] 1
16 1221512 (10000000- 20000000 )Bumper, Head, 80cm, Skirt, Im [T500] 1
17 1034731 (10000000- 20000000 ) Screw, Hex, M6 X 1.00 X 16, Sems, Ss 1
18 1074344 (10000000- 20000000 ) Harness, Ele [Ring With .250m Tail] 1
19 1210807 (10000000- 20000000 ) Wire, Tie [W/.25” Fir Tree Clip] 1
20 130773 (10000000- 20000000 ) Tie, Cable, Nyl, 11.0l, .14w, 3.0 Max. D 2
21 9014145 (10000000- 20000000 )Hose, Afmkt, Pe, .375id .50od, 05ft 1
22 1212858 (10000000- 20000000 ) Fitting, Plstc, Tee, Qf08/Qf08/Qf08 1
23 09746 (10000000- 20000000 ) Screw, Hex, M10 X 1.50 X 90, Ss 2
24 01684 (10000000- 20000000 ) Washer, Flat, 0.27b 0.69d .05, Ss 8
25 08712 (10000000- 20000000 ) Nut, Hex, Lock, M6 X 1.00, Nl, Ss 8
26 1014328 (10000000- 20000000 )Key, Sq, 05mm X 05mm, 25mml 2
27 1071637 (10000000- 20000000 ) Hub, Drive, Brush, Disk, 17mmb 2
28 1017218 (10000000- 20000000 ) Washer, Flat, 0.32b 1.00d .12, Ss 2
29 12273 (10000000- 20000000 ) Screw, Hex, M8 X 1.25 X 20, Nl, Ss 2
ASSEMBLY
YINCLUDED IN ASSEMBLY

STANDARD PARTS
Tennant T500e (01- 2017)
20
SCRUB HEAD GROUP, CYLINDRICAL 700MM / 28IN
355424
1
2
34
5
6
8
7
9
10
11
12
13
14
15
16 17 1
18
19
17
20
21
22
23
24
25
25
10 9
8765
432
1
26
27
28
21
1
29
17
14
14
