Terex SK315 Assembly instructions

Slow Control Functions
Personal Observation
Multimeter
Basic Hand Tools
SK315 / SK405 / SK415 / SK565 / SK575
Necessary Tools:
Type of Tip:
Applicable Models:
TECHNICAL TIPS
CRANES

Basic Safety Rules
Danger
Failure to follow the instructions and safety rules in the Operator's Manual and
Service Manual appropriate to your machine will result in death or serious
injury. Many of the risks identified in the operator's manual are also safety
risks when maintenance and repair procedures are performed.
Do not perform maintenance unless:
➢You are trained and qualified to perform maintenance on this machine.
➢You read, understand and obey:
oThe manufacturer's instructions and safety rules
oEmployer safety rules and workplace regulations
oApplicable government regulations
oYou have the appropriate tools, lifting equipment and a suitable location.
The information contained in this technical tip is a supplement to the service
manual. Consult the appropriate service manual for your machine for safety
rules and risks.
TECHNICAL TIPS
CRANES
If you have any doubts about how to perform any procedure, please contact our Technical Support team through our Web Portal
www.myterexcranes.com and access our Livechat.

Proximity Switch Failure Message on Display
•There are two ways in which the operator will receive this error message.
•The first is with a long jib configuration swinging in first step into the wind.
The crane doesn’t gain momentum within the time period set in the
PLC parameters (2 seconds) that is expects to see the signal from the
proximity switch.
TECHNICAL TIPS
CRANES
If you have any doubts about how to perform any procedure, please contact our Technical Support team through our Web Portal
www.myterexcranes.com and access our Livechat.

Other Possible Causes
•The second is the proximity switch is out of adjustment, has grease on
the face of the switch or has a broken or damaged cable.
The PLC fails to receive a signal from the proximity switch at input E10.8.
As the crane swings, this input will flasn ON and OFF as the proximity
switch passes the gear teeth of the swing bearing exterior race.
