Terex Genie GS-1432m User manual

Maintenance Manual -
Scissor Lifts
Slab Scissor Lifts
This manual includes detailed
procedures for each
maintenance inspection.
Rough Terrain
Scissor Lifts
For Repair procedures, Fault
Codes, Electrical and Hydraulic
Schematics, refer to the
appropriate Service and Repair
Manual for your machine.
Refer to the inside cover for a list of models
included in
this manual.
Original Instructions
Part No. 1305686GT
Rev
A
November 2021

Maintenance Manual November 2021
Introduction
ii Scissor Lifts Part No. 1305686GT
Intro ductio n Intro ductio n
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
maintenance procedure.
This manual provides detailed scheduled
maintenance information for the machine owner
and user.
Basic mechanical, hydraulic and electrical skills
are required to perform most procedures.
However, several procedures require specialized
skills, tools, lifting equipment and a suitable
workshop. In these instances, we strongly
recommend that maintenance be performed at an
authorized Genie dealer service center.
Compliance
Machine Classification
Group A/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Copyright © 2016 by Terex Corporation
1305686GT Rev A, November 2021
Second Edition, First Printing
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
“GS” is a trademark of Terex South Dakota, Inc.

November 2021 Maintenance Manual
Introduction
Part No. 1305686GT Scissor Lifts iii
Models included in this manual
Use the following chart to identify the specific
serial number for models included in this manual.
Models
Serial number
GS
-1330m
from GS30MD
-101
GS
-1432m / 1932m
GS
-1932m Lite
GS
-1932m XH
from GS32MD
-101
from GS32MP
-101
GS-1530 / 1532
GS
-1930 / 1932
GS
-1932 XH
from GS30D-40101
from GS30P
-200101
GS
-2032 / 2632 / 3232
from GS32D-10101
from GS32P
-200101
GS
-2046 / 2646 / 3246
GS
-2646 XH / 3246 XH
GS
-4046
from GS46D
-40101
from GS46P
-200101
GS
-4655
from GS55D
-101
from GS55P
-101
GS
-2669 / 3369 / 4069 RT
GS
-2669 / 3369 / 4069 DC
GS
-2669 / 3369 / 4069 BE
from GS69F
-18000
from GS69M
-101
GS
-3384
from GS84D
-401
from GS84F
-46000
GS
-3390 / 4390 / 5390
from GS90D
-3201
from GS90F
-56000
Find additional Manuals for your
Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's Manuals.
Identifying the Correct Procedure
for your Model
Unless otherwise noted, each procedure will apply
to all models. Procedures that only apply to
specific models or options will include the
information in the procedure title.
Examples of procedures that apply to specific
models:
•Test the Oscillate Axle - GS-90
•Grease the Steer Yokes - GS-30, GS-32,
GS-46
•Model Abbreviations:
GS-30m: GS-1330m
GS-32m: GS-1432m, GS-1932m,
GS-1932m Lite, GS-1932m XH
GS-30: GS-1530, GS-1532, GS-1930,
GS-1932, GS-1932 XH
GS-32: GS-2032, GS-2632, GS-3232
GS-46: GS-2046, GS-2646, GS-2646 XH,
GS-3246, GS-3246 XH, GS-4046
GS-55: GS-4655
GS-69: GS-2669, GS-3369, GS-4069
(includes DC and RT models)
GS-84: GS-3384
GS-90: GS-3390, GS-4390, GS-5390
Examples of procedures that apply to all models:
•Test the Drive Speed – Stowed Position
•Inspect the Electrical Wiring
Glossary of terms:
ECM - Electronic Control Module
GCON - Ground Controller. This ECM is located at
the ground controls.
PCON - Platform Controller. This ECM is located
at the platform controls.
CAT5 Cable - Standard Ethernet cable used for
networking purposes.

Maintenance Manual November 2021
Introduction
iv Scissor Lifts Part No. 1305686GT
Revision History
Revision Date Section Procedure / Description
A 10/2021 Initial Release
Reference Examples:
Section – Specifications Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Maintenance, (procedure)

November 2021 Maintenance Manual
Safety Rules
Part No. 1305686GTScissor Lifts v
Sec ti on 1 Safety Rul es
Danger
Failure to obey the instructions and safety
rules in this manual and the appropriate
Operator's Manual on your machine will result
in death or serious injury.
Many of the hazards identified in the
operator's manual are also safety hazards
when maintenance and repair procedures are
performed.
Do not modify or alter a MEWP without prior
written permission from the manufacturer.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety
rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Maintenance Manual November 2021
Safety Rules
vi Scissor Lifts Part No. 1305686GT
Personal Safety
Any person working on or around a machine
must be aware of all known safety hazards.
Personal safety and the continued safe
operation of the machine should be your top
priority.
Read each procedure thoroughly. This
manual
and the decals on the
machine, use signal words to identify
the following:
Safety alert symbol
—used to
alert personnel to potential
personal injury hazards. Obey
all safety messages that follow
this symbol to avoid possible
injury or death.
Indicates a imminently
hazardous situation which, if
not avoided, will result in death
or serious injury.
Indicates a potentially
hazardous situation which, if
not avoided, could result in
death or serious injury.
Indicates a potentially
hazardous
situation which, if
not avoided, may cause minor
or moderate injury.
Indicates a potentially
hazardous situation which, if
not avoided, may result in
property damage.
Be sure to wear protective eye wear
and other protective clothing if the
situation
warrants it.
Be aware of potential crushing
hazards such as moving parts, free
swinging or unsecured components
when lifting or placing loads. Always
wear approved steel
-toed shoes.
Workplace Safety
Any person working on or around a machine
must be aware of all known safety hazards.
Personal safety and the continued safe
operation of the machine should be your top
priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable
and combustible materials like battery
gases and engine
fuels. Always have
an approved fire extinguisher within
easy reach.
Be sure that all tools and working
areas are properly maintained and
ready for use. Keep work surfaces
clean and free of debris that could get
into machine components and cause
damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is
fully capable of supporting and
stabilizing the weight to be lifted. Use
only chains or straps that are in good
condition and of ample capacity.
Be sure that
fasteners intended for
one time use (i.e., cotter pins and self-
locking nuts) are not reused. These
components may fail if they are used
a second time.
Be sure to properly dispose of old oil
or other fluids. Use an approved
container. Please be
environmentally
safe.
Be sure that your workshop or work
area is properly ventilated and well lit.

November 2021
Table of Contents
Part No. 1305686GT Scissor Lifts vii
Introduction Introduction ......................................................................................................ii
Important Information ......................................................................................... ii
Models included in this manual .......................................................................... iii
Find additional Manuals for your Model.............................................................. iii
Identifying the Correct Procedure for your Model ............................................... iii
Glossary of terms: ............................................................................................. iii
Revision History ................................................................................................ iv
Section 1 Safety Rules......................................................................................................v
General Safety Rules .........................................................................................v

November 2021
Table of Contents
viii Scissor Lifts Part No. 1305686GT
Section 2 Performance Specifications ............................................................................ 1
Function Speeds GS-30, GS-32, GS-46, GS-47, GS-55 ..................................... 1
Function Speeds GS-69, GS-84, GS-90 ............................................................. 2
Drive Speeds ..................................................................................................... 3
Torque Specifications...................................................................................... 4
Tires and Wheels ............................................................................................... 4
Battery Specifications...................................................................................... 5
Battery Specifications - DC and BE Models ........................................................ 5
Engine Specifications...................................................................................... 7
Engine Operator and Maintenance Manuals....................................................... 7
Deutz Engine Models ......................................................................................... 7
Perkins Engine Models....................................................................................... 8
Ford Engine Models........................................................................................... 8
Kubota Engine Models ....................................................................................... 9
Kohler Engine Models ........................................................................................ 9
GM Engine Models........................................................................................... 10
Hydraulic Specifications................................................................................ 11
Hydraulic Relief Valves .................................................................................... 11
Hydraulic and Drive Hub Fluid Capacities......................................................... 13
Hydraulic Oil Specifications .............................................................................. 14
Hydraulic Hose and Fitting Torque Specifications............................................. 16
Torque Procedure ............................................................................................ 18

November 2021
Table of Contents
Part No. 1305686GT Scissor Lifts ix
Section 3 Maintenance Procedures ...............................................................................20
Introduction ......................................................................................................20
Maintenance Schedule .....................................................................................22
Pre-Delivery Preparation Report .......................................................................23
Scheduled Maintenance Inspection Report - Scissor Lifts .................................24
Programmed Maintenance Inspection Report - Scissor Lifts..............................25
Commissioning Procedures ..........................................................................26
C-1 Perform 50 Hour Service............................................................................26
C-2 Perform Engine Maintenance – 50 Hours ...................................................26
C-3 Perform 150 Hour Service..........................................................................27
Quarterly Maintenance Procedures ...............................................................28
Q-1 Check for Open Bulletins and Owner Registration......................................28
Q-2 Battery Inspection......................................................................................29
Q-3 Check the Module Tray Latch Components................................................31
Q-4 Inspect the Battery Balancer - GS-69 DC ...................................................32
Q-5 Inspect the Electrical Wiring.......................................................................33
Q-6 Inspect the Electrical Contactor - GS-30m, GS-30, GS-32m,
GS-32, GS-46, GS-55, GS-69 DC, GS-69 BE ...........................................34
Q-7 Inspect the Voltage Inverter (if equipped) ...................................................34
Q-8 Test the Flashing Beacons (if equipped) ....................................................36
Q-9 Visual Inspection of the Hydraulic Oil .........................................................36
Q-10 Inspect the Hydraulic Filters.....................................................................37
Q-11 Check the Exhaust System - Engine Models ............................................38
Q-12 Inspect the Fuel Tank Check Valve Venting System -
GS-69 RT Gas Models..............................................................................39
Q-13 Test the Fuel Select Operation - Gasoline/LPG Models............................39
Q-14 Check and Adjust the Engine RPM ..........................................................40
Q-15 Inspect the Tires, Wheels and Lug Nut Torque.........................................43
Q-16 Confirm the Proper Brake Configuration - GS-69, GS-84, GS-90..............43
Q-17 Test the Drive Brakes ..............................................................................44
Q-18 Test the Drive Speed – Stowed Position ..................................................44
Q-19 Test the Drive Speed - Raised Position ....................................................45
Q-20 Test the Down Limit Switch, Level Sensor and Pothole Limit Switches -
GS-30, GS-32, GS-46, GS-55 ...................................................................45

November 2021
Table of Contents
x Scissor Lifts Part No. 1305686GT
Annual Maintenance Procedures .................................................................. 51
A-1 Check the Drive Hub Oil Level and Fastener Torque.................................. 51
A-2 Test the Function Pump - GS-69 BE and GS-69 DC .................................. 52
A-3 Test the Oscillate Axle - GS-90 .................................................................. 53
A-4 Test the Down Limit Switch Descent Delay -
GS-69, GS-84 and GS-90 (if equipped)..................................................... 56
A-5 Test the Platform Overload Pressure Transducer and
Platform Height Sensor............................................................................. 57
A-6 Test the Platform Overload System -
GS-30m, GS-30, GS-32m, GS-32, GS-46, GS-55..................................... 63
A-7 Test the Platform Overload System - GS-69 (if equipped) .......................... 65
A-8 Check the Steer Yoke King Pin Fastener Torque ....................................... 67
Programmed Maintenance Procedures......................................................... 68
P0-1 Inspect the Engine Air Filter - GS-69 RT .................................................. 68
P0-2 Grease the Steer Yokes - GS-30m, GS-30, GS-32, GS-46, GS-55........... 69
P0-3 Replace the Drive Hub Oil - GS-30, GS-32m, GS-32, GS-46, GS-55........ 69
P0-4 Deutz Engine Maintenance – Under 1000 Hours...................................... 70
P0-5 Ford Engine Maintenance – Under 1000 Hours........................................ 71
P0-6 Kohler Engine Maintenance – Under 1000 Hours..................................... 72
P0-7 Kubota Engine Maintenance – Under 1000 Hours .................................... 73
P0-8 Perkins Engine Maintenance – Under 1000 Hours ................................... 74
P0-9 GM Engine Maintenance – Under 1000 Hours ......................................... 75
P1-1 Perform Engine Maintenance – 1000 Hours ............................................. 76
P1-2 Replace the Drive Hub Oil - GS-69, GS-84, GS-90................................... 77
P2-1 Perform Engine Maintenance – 2000 Hours ............................................. 77
P2-2 Replace the Hydraulic Filters ................................................................... 78
P2-3 Check the Free-wheel Configuration - GS-84 and GS-90 ......................... 80
P2-4 Check the Scissor Arm Wear Pads (and Slider Blocks, if equipped) ......... 81
P2-5 Grease the Steer Axle Wheel Bearings - GS-69 BE and GS-69 DC.......... 84
P2-6 Test or Replace the Hydraulic Oil............................................................. 86
P3-1 Perform Engine Maintenance – 3000 Hours ............................................. 87
P5-1 Perform Engine Maintenance – 5000 Hours ............................................. 88
P6-1 Perform Engine Maintenance – 6000 Hours ............................................. 88

November 2021 Maintenance Manual
Performance Specifications
Part No. 1305686GT Scissor Lifts 1
Sec ti on 2 Perfor man ce S peci fi catio ns
Function Speeds
Function speed, maximum from platform controls
(with 1 person in platform)
Models with hydraulic drive
GS-1530 / 1532, GS-1930 / 1932, GS-1932 XH
Platform up
Platform down
15 - 21 s
econds
18 - 22 s
econds
GS
-2032, GS-2632
Platform up
Platform down
28 - 35 seconds
23 - 33 s
econds
Models with electric drive
GS-1330m
Platform up
Platform down
19 - 22 s
econds
20 - 24 s
econds
GS-1432m
Platform up
Platform down
17 - 21 s
econds
18 - 22 seconds
GS
-1932m, GS-1932m Lite, GS-1932m XH
Platform up
Platform down
24 - 28 s
econds
18 - 22 s
econds
GS-1530, GS-1532
Platform up
Platform down
19 - 21 s
econds
18 - 22 s
econds
GS-1930, GS-1932, GS-1932 XH
Platform up
Platform down
21 - 26 s
econds
18 - 22 s
econds
GS-2032
Platform up
Platform down
34 - 41 seconds
23 - 33 s
econds
GS-2632
Platform up
Platform down
37 - 43 s
econds
23 - 33 s
econds
GS
-3232
Platform up
Platform down
50 - 58 s
econds
28 - 32 s
econds
Function speed, maximum from platform controls
(with
1 person in platform)
GS
-2046
Platform up
Platform down
34 to 41 s
econds
26 to 34 s
econds
GS-2646, GS-2646 XH
Platform up
Platform down
37 to 43 s
econds
26 to 34 s
econds
GS-3246, GS-3246 XH
Platform up
Platform down
53 to 61 s
econds
26 to 34 s
econds
GS-4046
Platform up
Platform down
62 to 72 s
econds
39 to 48 seconds
GS-4655
Platform up
Platform down
91 to 95 s
econds
56 to 60 s
econds
GS-3232 Outrigger leveling capacity, maximum
Side to side
Front to rear
5°
2°

Maintenance Manual November 2021
Performance Specifications
2 Scissor Lifts Part No. 1305686GT
Function Speeds
Function speed, maximum from platform controls
(with maximum rated load in platform)
GS-2669 DC, GS-2669 BE, GS-2669 RT
Platform up
Platform down
29 - 39 s
econds
26 - 46 s
econds
GS
-3369 DC, GS-3369 BE, GS-3369 RT
Platform up
Platform down
34 - 44 seconds
24 - 44 s
econds
GS-4069 DC, GS-4069 BE, GS-4069 RT
Platform up
Platform down
56 - 66 s
econds
33 - 53 seconds
GS-3384, GS-3390
Platform up
Platform down
40 - 50 s
econds
24 - 34 s
econds
GS
-4390
Platform up
Platform down
40 - 50 s
econds
34 - 44 s
econds
GS-5390
Platform up
Platform down
55 - 65 s
econds
44 - 54 s
econds

November 2021 Maintenance Manual
Performance Specifications
Part No. 1305686GT Scissor Lifts 3
Drive Speeds
Model Stowed position Elevated position Braking distance, maximum
High range on paved surface
GS
-1330m, GS-4655 10.9 seconds
40 ft / 12,2 m
55 seconds
40 ft / 12,2 m
1 - 3 ft
0,3 - 0,9 m
GS
-1530, GS-1532 10.9 seconds
40 ft / 12,2 m
55 seconds
40 ft / 12,2 m
1 - 3 ft
0,3 - 0,9 m
GS
-1930, GS-1932 10.9 seconds
40 ft / 12,2 m
55 seconds
40 ft / 12,2 m
1 - 3 ft
0,3 - 0,9 m
GS
-1432m, 1932m 10.9 seconds
40 ft / 12,2 m
55 seconds
40 ft / 12,2 m
1 - 3 ft
0,3 - 0,9 m
GS
-2032, GS-2046,
GS-2646
12.4 seconds
40 ft / 12,2 m
55 seconds
40 ft / 12,2 m
1 - 3 ft
0,3 - 0,9 m
GS
-2632, GS-3232,
GS
-3246
12.4 seconds
40 ft / 12,2 m
55 seconds
40 ft / 12,2 m
1 - 3 ft
0,3 - 0,9 m
GS
-4046 13.6 seconds
40 ft / 12,2 m
55 s
econds
40 ft / 12,2 m
1 - 3 ft
0,3 - 0,9 m
GS
-2669 RT High speed 7.8 seconds
40 ft / 12,2 m
High torque 30 seconds
40 ft / 12,2 m
91 seconds
40 ft / 12,2 m
2 ft
0,6 m
GS
-3369 RT
GS
-4069 RT
High speed 7.8 seconds
40 ft / 12,2 m
High torque 30 seconds
40 ft / 12,2 m
91 seconds
40 ft / 12,2 m
2 ft
0,6 m
GS-2669
GS
-3369
GS
-4069
(DC and BE models)
Forward - 6.1 seconds
Reverse - 9.1 seconds
40 ft / 12,2 m
91 seconds
40 ft / 12,2 m
3 ft
0,9 m
GS
-3384 6.8 s
econds
40 ft / 12,2 m
39 seconds
40 ft / 12,2 m
5 ft
1,5 m
GS-3390
GS-4390
5.5 s
econds
40 ft / 12,2 m
39 seconds
40 ft / 12,2 m
5 ft
1,5 m
GS
-5390 5.5 s
econds
40 ft / 12,2 m
39 seconds
40 ft / 12,2 m
5 ft
1,5 m

Maintenance Manual November 2021
Torque Specifications
4 Scissor Lifts Part No. 1305686GT
Tires and Wheels
Torque values are listed as lubricated unless
otherwise noted. Lug nuts must be coated with a
mineral based lubricant when removed and
replaced on the machine.
Model
GS-
1330m
GS-
1432m / 1932m
GS-1932m Lite / 1932m XH
Castle nut torque
150 ft-
lbs
203 Nm
Model
GS-1530 / 1532
GS-1930 / 1932 / 1932 XH
Castle nut torque
225 ft-
lbs
305 Nm
Model
Models with
electric
drive
GS-2032 / 2632 / 3232
GS-
2046 / 2646 / 3246 / 4046
GS-
2646 XH / 3246 XH
GS-
4655
Hex head cap screw
80 ft-
lbs
108 Nm
Model
Models with
hydraulic drive
GS-2032 / 2632
Castle nut torque
225 ft-
lbs
305 Nm
Model
GS-2669 / 3369 / 4069 RT
Castle nut torque
(steer end)
225 ft-
lbs
305 Nm
Lug nut torque
(steer end)
68 ft-
lbs
92 Nm
Lug nut torque
(non
-steer end)
130 ft-
lbs
176 Nm
Model
GS-
2669 / 3369 / 4069
(DC and BE models)
Castle nut torque
(steer end)
150 ft-
lbs
203 Nm
Lug nut
torque
(steer end)
68 ft-
lbs
92 Nm
Lug nut torque
(non
-steer end)
130 ft-
lbs
176 Nm
Model
GS-
3384
GS-
3390 / 4390 / 5390
Lug nut torque
94 ft-
lbs
127 Nm
Tire pressure
high flotation
38 p
si
2,6 b
ar

November 2021 Maintenance Manual
Battery Specifications
Part No. 1305686GT Scissor Lifts 5
GS-1330m
(standard)
Voltage
12V DC
Group 24
Type 24TMX
Quantity
2
Battery capacity, maximum 85AH
Reserve capacity @ 25A rate 140 minutes
GS-1330m
(optional)
Voltage 12V DC
Group 24
Type DC85-12
Quantity
2
Battery capacity, maximum 85AH
Reserve capacity @ 25A rate
145 minutes
GS-1432m / 1932m
GS-1932m Lite / 1932m XH
(standard)
Voltage
12V DC
Group 24
Type 27TMH
Quantity
2
Battery capacity, maximum 115AH
Reserve capacity @ 25A rate 131 minutes
GS
-1432m / 1932m
GS-1932m Lite / 1932m XH
(optional)
Voltage 12V DC
Group 24
Type EV31A-B
Quantity 2
Battery capacity, maximum
115AH
Reserve capacity @ 25A rate
minutes178
GS
-1530 / 1532
GS
-1930 / 1932 / 1932 XH
GS
-2032 / 2632
Models with hydraulic drive
(standard)
Voltage 6V DC
Group
GC2
Type T-105
Quantity
4
Battery capacity, maximum C20 = 225AH
Reserve capacity @ 25A rate 447 minutes
GS
-1530 / 1532
GS
-1930 / 1932 / 1932 XH
GS
-2032 / 2632
Models with hydraulic drive
(optional)
Voltage 6V DC
Group GC2
Type 6V-AGM
Quantity
4
Battery capacity, maximum
200AH
Reserve capacity @ 25A rate 380 m
inutes
GS-1530 / 1532
GS
-1930 / 1932 / 1932 XH
GS
-2032 / 2632 / 3232
GS
-2046 / 2646 / 3246
GS
-2646 XH / 3246 XH
Models with electric drive
(standard)
Voltage 6V DC
Group GC2
Type T-605
Quantity 4
Battery capacity, maximum
C20 = 210AH
Reserve capacity @ 25A rate
383 minutes
Note: When upgrading from standard to AGM
batteries the machine software must be configured
for the proper battery type. Refer to Repair
Procedure, Machine Setup in the appropriate
Service and Repair Manual.

Maintenance Manual November 2021
Battery Specifications
6 Scissor Lifts Part No. 1305686GT
GS
-1530 / 1532
GS
-1930 / 1932 / 1932 XH
GS
-2032 / 2632 / 3232
GS
-2046 / 2646 / 3246
GS
-2646 XH / 3246 XH
Models with electric drive
(optional)
Voltage
6V DC
Group GC2
Type
DC224-6
Quantity
4
Battery capacity, maximum 224AH
Reserve capacity @ 25A rate 441 minutes
GS-4046, GS-4655
(standard)
Voltage 12V DC
Group GC2
Type
T1275
Quantity 4
Battery capacity, maximum C = 150AH
Reserve capacity @ 25A rate 280 minutes
GS-4046, GS-4655
(optional)
Voltage 12V DC
Group GC12
Type
DC150-12
Quantity 4
Battery capacity, maximum 150AH
Reserve capacity @ 25A rate 295 minutes
GS
-2669, GS-3369, GS-4069
(DC and BE models)
(standard)
Voltage 6V DC
Group GC2
Type
T-105
Quantity 8
Battery capacity, maximum
225AH
Reserve capacity @ 25A rate
447 minutes
GS
-2669, GS-3369, GS-4069
(DC models)
(optional)
Voltage
6V DC
Group 902
Type J305GH
Quantity 8
Battery capacity, maximum 315AH
Reserve capacity @ 25A rate 678 minutes
GS
-2669, GS-3369, GS-4069
(BE models)
(optional)
Voltage 6V DC
Group
GC2
Type T145
Quantity
8
Battery capacity, maximum 260AH
Reserve capacity @ 25A rate 530 minutes
Note: When upgrading from standard to AGM
batteries the machine software must be configured
for the proper battery type. Refer to Repair
Procedure, Machine Setup in the appropriate
Service and Repair Manual.

November 2021 Maintenance Manual
Engine Specifications
Part No. 1305686GT Scissor Lifts 7
Engine Operator and
Maintenance Manuals
Deutz D2011L03i
Genie part number
139320GT
Deutz TD 2.2 L3
Genie part number
1305687GT
Deutz D 2.9 L4
Genie part number
1251561GT
Perkins 403D-11
Genie part number
131661GT
Ford MSG
-425
Genie part number
215322GT
Diagnostic Manual
Genie part number
162067GT
Kubota
D1105-E3B
Genie part number
229761GT
Kubota WG
-972
Genie part number
227584GT
Kohler KD350
Genie part number
1255885GT
GM .998L
Genie part number
1311928GT
Deutz Engine Models
D2011 L03i
Low idle
1500 r
pm
313 Hz
High idle
2500 r
pm
522 Hz
Oil capacity (including filter)
9.5 q
uarts
9 l
iters
Fan belt deflection
3/8 - 1/2 i
nch
9 - 12 m
m
TD 2.2 L3
Low idle, standby
1000 rpm
1000 Hz
Low idle, function enable
1500 r
pm
1500 Hz
High idle
2400 r
pm
2400 Hz
Oil
capacity (including filter) 8 q
uarts
7,6 l
iters
Engine coolant
Ethylene Glycol
Engine coolant capacity
2.2 g
allons
8,3 l
iters
D 2.9 L4
Low idle
1500 r
pm
1500 Hz
High idle
2500 r
pm
2500 Hz
Oil capacity (including filter)
9.4 q
uarts
9 l
iters
Engine coolant
Ethylene Glycol
Engine coolant capacity
10 q
uarts
9,4 l
iters
Fan belt deflection
3/8 - 1/2 i
nch
9 - 12 mm
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.

Maintenance Manual November 2021
Engine Specifications
8 Scissor Lifts Part No. 1305686GT
Perkins Engine Models
403D
-11
Low idle
1500 r
pm
150 Hz
High idle
3000 r
pm
300 Hz
Oil capacity (including filter)
4.6 q
uarts
4.4 l
iters
Engine coolant capacity
2.0 q
uarts
1.9 l
iters
Engine coolant
Ethylene Glycol
Fan belt deflection
3/16 i
nch
5 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.
Ford Engine Models
MSG
-425
Low idle
1600 rpm
53,3 Hz
High idle
2500 rpm
83,3 Hz
Oil capacity (including filter)
6.7 q
uarts
6,4 l
iters
Engine coolant capacity
10 quarts
9,5 l
iters
Engine coolant
Ethylene Glycol
Spark plug gap
0.049 - 0.053 i
nches
1,25 - 1,35 m
m
Fan belt deflection
3/8 - 1/2 i
nches
9 - 12 mm
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.

November 2021 Maintenance Manual
Engine Specifications
Part No. 1305686GT Scissor Lifts 9
Kubota Engine Models
D1105
-E3B, D1105-E4B
Low idle
1500 r
pm
250 Hz
High idle
3000 r
pm
500 Hz
Oil capacity (including filter)
5.4 q
uarts
5,1 l
iters
Engine coolant capacity
3.3 q
uarts
3,1 l
iters
Engine coolant
Ethylene Glycol
Fan belt deflection
5/16 i
nches
8 m
m
WG-972
Low idle
1500 r
pm
250 Hz
High idle
3000 r
pm
500 Hz
Oil capacity (including filter)
3.6 q
uarts
3,4 l
iters
Engine coolant capacity
2.4 q
uarts
2,3 l
iters
Engine coolant
Ethylene Glycol
Spark plug gap
0.024 - 0.028 i
nches
0,6 - 0,7 mm
Fan belt deflection
0.28 - 0.35 i
nches
7 - 9 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.
Kohler Engine Models
KD350
High idle
3600/3000 r
pm
Oil capacity (including filter)
1.3 q
uarts
1.2 l
iters
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.

Maintenance Manual November 2021
Engine Specifications
10 Scissor Lifts Part No. 1305686GT
GM Engine Models
.998L
Low idle
1100 r
pm
36,6 Hz
High idle
3000 r
pm
100 Hz
Oil capacity (including filter)
3.2 q
uarts
3,0 l
iters
Engine coolant
capacity 5 q
uarts
4,7 l
iters
Engine coolant
Ethylene Glycol
Spark plug gap
0.039 - 0.047 i
nches
1,0 - 1,2 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.
