Terex Genie GS-2669 DC Installation and operating manual

Service and Repair Manual
Serial Number Range
GS™-2669 DC
from GS69F-18000
from GS69M-
101
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic Schematics
GS™-3369 DC
GS™-4069 DC
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Part No. 1306585GT
Rev A
May 2021

Service and Repair Manual May 2021
Introduction
ii GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Introducti on Introduction
Important Information
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
procedure.
This manual provides troubleshooting and repair
procedures for qualified service professionals.
Basic mechanical, hydraulic and electrical skills
are required to perform most procedures.
However, several procedures require specialized
skills, tools, lifting equipment and a suitable
workshop. In these instances, we strongly
recommend that maintenance and repair be
performed at an authorized Genie dealer service
center.
Compliance
Machine Classification
Group A/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Find a Manual for this Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's Manuals.
Copyright © 2020 by Terex Corporation
1306585GT Rev A, May 2021
Second Edition, First Printing
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
“GS” is a trademark of Terex South Dakota, Inc.

May 2021 Service and Repair Manual
Introduction
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC iii
Revision Hist ory
Revision History
Revision Date Section Procedure / Page / Description
A 5/2021 Initial Release
Reference Examples:
Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Repair Procedure, 4-2
Section – Fault Codes, All charts
Section – Schematics, Legends and schematics

Service and Repair Manual May 2021
Introduction
iv GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Serial Number Legend
1 Model
2 Facility code
3 Sequence number
4 Serial label, ((located inside cover))
5 Serial number, ((stamped on chassis))

May 2021 Service and Repair Manual
Safety Rules
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC v
Section 1 Safety Rules General Safety Rules
Danger
Failure to obey the instructions and safety
rules in this manual and the appropriate
Operator's Manual on your machine will result
in death or serious injury.
Many of the hazards identified in the
operator's manual are also safety hazards
when maintenance and repair procedures are
performed.
Do not modify or alter a MEWP without prior
written permission from the manufacturer.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety
rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Service and Repair Manual May 2021
Safety Rules
vi GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Personal Safety
Any person working on or around a machine
must be aware of all known safety hazards.
Personal safety and the continued safe
operation of the machine should be your top
priority.
Read each procedure thoroughly. This
manual and the decals on the
machine, use signal words to identify
the following:
Safety alert symbol
—used to
alert personnel to potential
personal injury hazards. Obey
all safety messages that follow
this symbol
to avoid possible
injury or death.
Indicates a imminently
hazardous situation which, if
not avoided, will result in death
or serious injury.
Indicates a potentially
hazardous situation which, if
not avoided, could result in
death or serious
injury.
Indicates a
potentially
hazardous situation which, if
not avoided, may cause minor
or moderate injury.
Indicates a potentially
hazardous situation which, if
not avoided, may result in
property damage.
Be sure to wear protective eye wear
an
d other protective clothing if the
situation warrants it.
Be aware of potential crushing
hazards such as moving parts, free
swinging or unsecured components
when lifting or placing loads. Always
wear approved steel
-toed shoes.
Workplace Safety
Any person working on or around a machine
must be aware of all known safety hazards.
Personal safety and the continued safe
operation of the machine should be your top
priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable
and
combustible materials like battery
gases and engine fuels. Always have
an approved fire extinguisher within
easy reach.
Be sure that all tools and working
areas are properly maintained and
ready for use. Keep work surfaces
clean and free of debris that
could get
into machine compone
nts and cause
damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is
fully capable of supporting and
stabilizing the weight to be lifted. Use
only chains or straps that are in good
condition a
nd of ample capacity.
Be su
re that fasteners intended for
one time use (i.e., cotter pins and self
-
locking nuts) are not reused. These
components may fail if they are used
a second time.
Be sure to properly dispose of old oil
or other fluids. Use
an approved
container. Please be
environmentally
safe.
Be sure that your workshop or work
area is properly ventilated and well lit.

May 2021
Table of Contents
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC vii
Introduction Introduction...........................................................................................................ii
Important Information ............................................................................................. ii
Find a Manual for this Model.................................................................................. ii
Revision History..................................................................................................... iii
Serial Number Legend .......................................................................................... iv
Section 1 Safety Rules..........................................................................................................v
General Safety Rules ............................................................................................. v
Section 2 Specifications .......................................................................................................1
Machine Specifications...........................................................................................1
Performance Specifications....................................................................................1
Hydraulic Oil Specifications....................................................................................2
Hydraulic Component Specifications .....................................................................5
Manifold Component Specifications.......................................................................5
Machine Component Weights ................................................................................6
Battery Specifications.............................................................................................6
Hydraulic Hose and Fitting Torque Specifications .................................................7
Torque Procedure ..................................................................................................8

May 2021
Table of Contents
viii GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Section 3 Repair Procedures ............................................................................................. 10
Introduction .......................................................................................................... 10
Platform Controls............................................................................................... 12
1-1 Circuit Board .................................................................................................. 13
1-2 Joystick .......................................................................................................... 14
1-3 Platfrom Controls Alarm................................................................................. 15
1-4 Platfrom Emergency Stop Button .................................................................. 15
Platform Components ....................................................................................... 17
2-1 Platform.......................................................................................................... 17
2-2 Platform Extension Deck ............................................................................... 18
Scissor Components ......................................................................................... 20
3-1 Scissor Assembly, GS-2669 DC.................................................................... 21
3-2 Scissor Assembly, GS-3369 DC.................................................................... 24
3-3 Scissor Assembly, GS-4069 DC.................................................................... 28
3-4 Wear Pads ..................................................................................................... 31
3-5 Lift Cylinders .................................................................................................. 33
3-6 Height Angle Sensor...................................................................................... 34
How to Replace the Height Angle Sensor ...................................................... 34
Ground Controls ................................................................................................ 36
4-1 Software Revision Level ................................................................................ 37
4-2 Machine Setup............................................................................................... 38
4-3 Auxiliary Platform Lowering ........................................................................... 39
4-4 Level Sensor - Models without Outriggers..................................................... 39
4-5 Level Sensor - Models with Outriggers.......................................................... 42
4-6 Service Override Mode .................................................................................. 44

May 2021
Table of Contents
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC ix
Hydraulic Pump ..................................................................................................46
5-1 Hydraulic Pump..............................................................................................46
How to Test the Hydraulic Pump.....................................................................46
How to Remove the Hydraulic Pump ..............................................................46
How to Calibrate the Hydraulic Pump .............................................................47
Manifolds.............................................................................................................49
6-1 Function Manifold Components .....................................................................49
6-2 Valve Adjustments - Function Manifold..........................................................51
How to Check the System Proportional Relief Valve......................................51
How to Adjust the Oscillate Relief Valve.........................................................52
How to Adjust the Steer Relief Valve ..............................................................53
How to Adjust the Platform Up Relief Valve....................................................54
6-3 Outrigger Manifold Components ....................................................................59
6-4 Valve Coils .....................................................................................................60
Hydraulic Tank....................................................................................................62
7-1 Hydraulic Tank ...............................................................................................62
Steer Axle Components.....................................................................................63
8-1 Yoke Assembly ..............................................................................................63
8-2 Steer Cylinder.................................................................................................65
8-3 Tie Rod...........................................................................................................65
8-4 Oscillate Cylinder ...........................................................................................66
8-5 Oscillate Hoses ..............................................................................................66
8-6 Steer Angle Sensor ........................................................................................68

May 2021
Table of Contents
x GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Non-steer Axle Components............................................................................. 73
9-1 Drive Motors................................................................................................... 73
9-2 Drive Hub ....................................................................................................... 75
Outrigger Components...................................................................................... 76
10-1 Outrigger Cylinder........................................................................................ 76
10-2 Outrigger Calibration.................................................................................... 77
Platform Overload Components....................................................................... 79
How to Calibrate the Platform Overload System............................................ 79
11-2 Platform Overload Recovery........................................................................ 81
11-3 Down Limit Height........................................................................................ 83
How to Calibrate the Down Limit Height......................................................... 83

May 2021
Table of Contents
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC xi
Section 4 Fault Codes.........................................................................................................84
Introduction...........................................................................................................84
GCON I/O Map.....................................................................................................87
Control System Fault Codes .............................................................................89
Platform Overload Fault Codes.........................................................................94
Operation Indicator Codes (OIC)..........................................................................99
Diagnostic Trouble Codes (DTC) .........................................................................99
Troubleshooting "HXXX" and "PXXX" Faults .....................................................100
Fault Inspection Procedure ................................................................................101
Type "HXXX" Faults ...........................................................................................103
Type "PXXX" Faults............................................................................................106
Type "UXXX" Faults ...........................................................................................108
Type "FXXX" Faults............................................................................................110
Type "CXXX" Faults ...........................................................................................113

May 2021
Table of Contents
xii GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Section 5 Schematics ....................................................................................................... 115
Introduction ........................................................................................................ 115
Electrical Schematic Abbreviations and Wire Color Legends............................ 116
Hydraulic Component Legend ........................................................................... 119
Electrical Symbols Legend................................................................................. 120
Hydraulic Symbols Legend ................................................................................ 121
Limit Switch Legend........................................................................................... 122
Fuse, Ground and Platform Control Boxes................................................... 123
Fuse Box Layout, All Models ............................................................................. 124
Ground Control Box Layout ............................................................................... 125
Platform Control Box Layout .............................................................................. 127
Electrical Schematics ...................................................................................... 129
Electrical Schematic........................................................................................... 130
Hydraulic Schematics...................................................................................... 133
Hydraulic Schematic .......................................................................................... 134

May 2021 Service and Repair Manual
Specifications
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC 1
Section 2 Specificati ons
Machine Specif ications
Machine Specifications
Fluid capacities
Hydraulic tank
(maximum fill capacity)
16.5 g
allons
62.5 l
iters
Hydraulic
system (including tank) 18 g
allons
68.1 l
iters
Drive hub
EP 9
0 or SAE 90 multipurpose hypoid
gear oil API service classification GL5
24.5 o
unces
725 c
c
Tires and wheels
Wheel lugs
9 @ 5/8-
18
Lug nut torque, dry
Rear
170 ft-
lbs
230 Nm
Lug nut
torque, lubricated
Rear
130 ft-
lbs
176 Nm
Lug nut torque, dry
Front
90 ft-
lbs
122 Nm
Lug nut torque, lubricated
Front
68 ft-
lbs
92 Nm
Castle nut
(steer end)
Castle nut torque
35 ft-
lbs
47.5 Nm
Non-marking, foam filled, RT
Tire size
26 x
12D380
Tire ply rating
8
Tire diameter
26 i
n
66 c
m
Tire width
12 i
n
30 c
m
Weight, each
177.5 l
bs
80.5 k
g
For operational specifications, refer to the
Operator's Manual.
Performance Spec ifications
Performance Specifications
Drive speed, maximum
Platform stowed
Forward direction
4.5 m
ph
7.2 k
m/h
40 ft / 6.1 s
ec
12.2 m / 6.1 s
ec
Platform stowed
Reverse direction
3.0 m
ph
4.8 k
m/h
40 ft / 9.1 s
ec
12.2 m / 9.1 s
ec
Platform raised
0.3 m
ph
0.5 k
m/h
40 ft / 91 s
ec
12.2 m / 91 s
ec
Braking distance, maximum
High range on paved
surface
3 f
t
0.9
m
Gradeability
See Operator's Manual
Function speed, maximum from platform controls
(with maximum rated load in platform)
GS-2669 DC
Platform up
Platform down
29 to 39 s
econds
26 to 36 s
econds
GS-3369 DC
Platform up
Platform down
34 to 44 s
econds
24 to 34 s
econds
GS-4069 DC
Platform up
Platform down
56 to 66 s
econds
23 to 33 s
econds
Outrigger leveling, maximum
Fr
ont
Back
Side to side
5.3°
4.2°
11.7°

Service and Repair Manual May 2021
Specifications
2 GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Hydraulic Oil Specific ations
Hydraulic Oil Specifications
Hydraulic Fluid Specifications
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the abil
ity to perform over a wide
temperature range, and
the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation prevention, corrosion inhibition, seal
conditioning, and foam and aeration suppression
properties.
Cleanliness level
,
minimum
ISO 15/13
Water content,
maximum
250 p
pm
Recommended Hydraulic Fluid
Hydraulic oil type
Chevron Rando HD Premium
Viscosity grade
32
Viscosity index
200
Optional Hydraulic Fluids
Mineral based
Shell Tellus S2 V 32
Shell Tellus S2 V 46
Shell
Tellus S4 VX 32
Shell Donax TG (Dexron III)
Chevron 5606A
Biodegradable
Petro Canada Environ MV
46
Fire resistant
UCON Hydrolube HP-
5046
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult Genie
Product Support before use.
Optional fluids may not have
the same hydraulic lifespan and
may result in component
damage.
Note: Extended machine operation can cause the
hydraulic fluid temperature to increase beyond its
maximum allowable range. If the hydraulic fluid
temperature consistently exceeds 200°F / 90°C an
optional oil cooler may be required.
Do not top off with incompatible
hydraulic fluids. Hydraulic fluids
may be incompatible due to the
differences in base additi
ve
chemistry. When incompa
tible
fluids are mixed, insoluble
materials may form and deposit
in the hydraulic system,
plugging hydraulic lines, filters,
control valves and may result in
component damage.
Note: Do not operate the machine when the
ambient air temperature is consistently above
120°F / 49°C.
Hydraulic Fluid Temperature
Range
Ambient air temperature
1 Chevron hydraulic oil 5606A
2 Petro-Canada Environ MV 46
3 UCON Hydrolube HP-5046D
4 Chevron Rando HD premium oil MV

May 2021 Service and Repair Manual
Specifications
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC 3
Chevron Rando HD Premium Oil
MV Fluid Properties
ISO
Grade
32
Viscosity index
200
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
7.5
33.5
Brookfield Viscosity
cP @
-4°F / -20°C
cP @
-22°F / -30°C
1040
3310
Flash point
375°F / 190°C
Pour point
-58°F / -
50°C
Maximum cont
inuous operating
temperature
171°F / 77°C
Note: A hydraulic oil heating system is
recommended when the ambient temperature is
consistently below 0°F / -18°C.
Note: Do not operate the machine when the
ambient temperature is below -20°F / -29°C with
Rando HD Premium MV.
Chevron 5606A Hydraulic Oil
Fluid Properties
ISO Grade
15
Viscosity index
300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
cSt @
-40°F / -40°C
5.5
15.0
510
Flash point
180°F / 82°C
Pour point
-81°F / -
63°C
Maximum
continuous operating
temperature
124°F / 51°C
Note: Use of Chevron 5606A hydraulic fluid, or
equivalent, is required when ambient temperatures
are consistently below 0°F / -17°C unless an oil
heating system is used.
Continued use of Chevron
5606A hydrauli
c fluid, or
equivalent, when ambient
temperatures are consistently
above 32°F / 0°C may result in
component damage

Service and Repair Manual May 2021
Specifications
4 GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Petro-Canada Environ MV 46
Fluid Properties
ISO Grade
46
Viscosity index
154
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
8.0
44.4
Flash point
482°F / 250°C
Pour point
-49°F / -
45°C
Maximum continuous operating
temperature
180°F / 82°C
Shell Tellus S4 VX Fluid
Properties
ISO Grade
32
Viscosity index
300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @
104°F / 40°C
9
33
.8
Brookfield Viscosity
cSt @
-4°F / -20°C
cSt @
-13°F / -25°C
cSt @
-40°F / -40°C
481
702.4
2624
Flash point
>100
Pour point
-76°F / -
60°C
Maximum continuous operating
temperature
103°F / 75°C
UCON Hydrolube HP-5046 Fluid
Properties
ISO Grade
46
Viscosity index
192
Kinematic Viscosity
cSt @ 149°F / 65°C
cSt @ 104°F / 40°C
cSt @ 0°F /
-18°C
22
46
1300
Flash point
None
Pour point
-81°F / -
63°C
Maximum continuous operating
temperature
189°F / 87°C

May 2021 Service and Repair Manual
Specifications
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC 5
Hydraulic Component Spec ifications
Hydraulic Component
Specifications
Function Pump
Type
gear pump
Displacement
0.4 c
u in
6 c
c
Flow rate @ 310
0 rpm 6 g
pm
22.7 L/min
Function manifold
System relief valve pressure,
maximum
3500 p
s
241 b
ari
Lift relief
valve pressure
GS
-2669 DC
3100 p
si
214 b
ar
Lift relief valve pressure
GS
-3369 DC
2900 p
si
200 b
ar
Lift relief valve pressure
GS
-4069 DC
2850 p
si
197 b
ar
Steer relief valve pressure
1500 p
si
103 b
ar
Oscillate relief valve pressure
3300 p
si
228 b
ar
Stee
r flow regulator 2 g
pm
7.6 L/min
Oscill
ate flow regulator 1 g
pm
4 L/min
Manifold Component Spec ifications
Manifold Component
Specifications
Plug torque
SAE No. 2
36 in-
lbs / 4 Nm
SAE No. 4
10 ft-
lbs / 13 Nm
SAE No. 6
14 ft-
lbs / 19 Nm
SAE No. 8
38 ft-
lbs / 51 Nm
SAE No.10
41 ft-lbs / 5
5 Nm
SAE No. 12
56 ft-
lbs / 76 Nm

Service and Repair Manual May 2021
Specifications
6 GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Machine Component Wei ghts
Machine Component Weights
Platform assembly
936 l
bs
425 k
g
Link assembly (GS
-4069) 3430 l
bs
1556 k
g
Link assembly (GS
-3369) 2607 l
bs
1183 k
g
Link assembly (GS
-2669) 2156 l
bs
978 k
g
Outrigg
er assembly (if equipped) 850 l
bs
386 k
g
Chassis assembly (GS
-3369)
(J10
5 battery option)
5084 l
bs
2306 k
g
Chassis assembly (GS
-2669)
(J10
5 battery option)
5623 l
bs
2551 k
g
Chassis
assembly (GS-4069)
(J30
5 battery option)
7233 l
bs
3281 k
g
Chassis assembly (GS
-3369)
(J30
5 battery option)
5309 l
bs
2408 k
g
Chassis assembly (GS
-2669)
(J30
5 battery option)
5848 l
bs
2653 k
g
Battery Speci fications
Battery Specifications
T105
Type
6v DC
Quantity
8
Capacity
225 AH
Reserve ca
pacity @ 25A rate 447 m
inutes
Reserve capacity @ 75A rate
115 m
inutes
Weight, each
62 lbs / 28 k
g
Weight (tray with batteries)
554 lbs / 251 k
g
J305GH
Type
6V DC
Quantity
8
Capacity
315 AH
Reserve capacity @ 25A rate
678 minutes
Reserve capaci
ty @ 75A rate 175 minutes
Weight, each
88 lbs / 40 k
g
Weight (tray with batteries)
779 l
bs / 353.5kg

May 2021 Service and Repair Manual
Specifications
Part No. 1306585GT GS™-2669 DC • GS™-3369 DC • GS™-4069 DC 7
Hydraulic Hos e and Fitting Torque Specifi cations
Hydraulic Hose and Fitting
Torque Specifications
Your machine is equipped with Parker Seal-Lok™
ORFS or 37° JIC fittings and hose ends. Genie
specifications require that fittings and hose ends
be torqued to specification when they are removed
and installed or when new hoses or fittings are
installed.
Seal-Lok™ Fittings
(hose end - ORFS)
SAE Dash Size
Torque
-4 18 ft-lbs / 25 Nm
-6 30 ft-lbs / 41 Nm
-8 40 ft-lbs / 55 Nm
-10 60 ft-lbs / 81 Nm
-12 85 ft-lbs / 115 Nm
-16 110 ft-lbs / 150 Nm
-20 150 ft-lbs / 205 Nm
-24 230 ft-lbs / 315 Nm
JIC 37° Fittings
(swivel nut or hose connection)
SAE Dash Size Thread Size Flats
-4 7/16-20 2
-6 9/16-18 1 1/2
-8 3/4-16 1 1/2
-10 7/8-14 1 1/2
-12 1 1/16-12 1 1/4
-16 1 5/16-12 1
-20 1 5/8-12 1
-24 1 7/8-12 1
SAE O-ring Boss Port
(tube fitting - installed into Aluminum)
(all types)
SAE Dash Size Torque
-4 14 ft-lbs / 19 Nm
-6 23 ft-lbs / 31,2 Nm
-8 36 ft-lbs / 49 Nm
-10 62 ft-lbs / 84 Nm
-12 84 ft-lbs / 114 Nm
-16 125 ft-lbs / 169,5 Nm
-20 151 ft-lbs / 204,7 Nm
-24 184 ft-lbs / 249,5 Nm
Adjustable Fitting Non-adjustable fitting
1 jam nut
SAE O-ring Boss Port
(tube fitting - installed into Steel)
SAE Dash Size
Torque
-4 ORFS / 37° (Adj)
ORFS (Non-adj)
37° (Non-adj)
15 ft-lbs / 20,3 Nm
26 ft-lbs / 35,3 Nm
22 ft-lbs / 30 Nm
-6 ORFS (Adj / Non-adj)
37° (Adj / Non-adj)
35 ft-lbs / 47,5 Nm
29 ft-lbs / 39,3 Nm
-8 ORFS (Adj / Non-adj)
37° (Adj / Non-adj)
60 ft-lbs / 81,3 Nm
52 ft-lbs / 70,5 Nm
-10 ORFS (Adj / Non-adj)
37° (Adj / Non-adj)
100 ft-lbs / 135,6 Nm
85 ft-lbs / 115,3 Nm
-12 (All types) 135 ft-lbs / 183 Nm
-16 (All types) 200 ft-lbs / 271,2 Nm
-20 (All types) 250 ft-lbs / 339 Nm
-24 (All types) 305 ft-lbs / 413,5 Nm

Service and Repair Manual May 2021
Specifications
8 GS™-2669 DC • GS™-3369 DC • GS™-4069 DC Part No. 1306585GT
Torque Procedure
Torque Procedure
Seal-Lok™ fittings
1 Replace the O-ring. The O-ring must be
replaced anytime the seal has been broken.
The O-ring cannot be re-used if the fitting or
hose end has been tightened beyond finger
tight.
Note: The O-ring in Parker Seal Lok™ fittings and
hose end are custom-size O-rings. They are not
standard size O-rings. They are available in the O-
ring field service kit (Genie part number 49612).
2 Lubricate the O-ring before installation.
3 Be sure the O-ring face seal is seated and
retained properly.
4 Position the tube and nut squarely on the face
seal end of the fitting, and tighten the nut
finger tight.
5 Tighten the nut or fitting to the appropriate
torque. Refer to the appropriate torque chart
in this section.
6 Operate all machine functions and inspect the
hose, fittings and related components to
confirm there are no leaks.
JIC 37° fittings
1 Align the tube flare (hex nut) against the nose
of the fitting body (body hex fitting) and
tighten the hex nut to the body hex fitting to
hand tight, approximately 30 in-lbs / 3.4 Nm.
2 Using a permanent ink marker, make a
reference mark on one the flats of the hex nut
and continue the mark onto the body of the
hex fitting. Refer to Illustration 1.
Illustration 1
1 hex nut
2 reference mark
3 body hex fitting
