Service and Repair Manual
Serial Number Range
GS™-3384
from GS8413-42181
to GS8415-
42382
from GS8416F-42383
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic Schematics
GS™-3390
to GS8416F-45499
from GS84F-
45500
to GS84F-45999
GS™-4390
from GS84D-101
to GS84D-
400
GS™-5390
from GS9013-48427
to GS9015-
51063
from GS9016F-
51064
to GS9016F-53299
from GS90F-53300
to GS90F-
55999
from GS90D-
101
to GS90D-3200
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Part No. 1272222GT
Rev B
1
June 2021

Service and Repair Manual June 2021
Introduction
ii GS-84 • GS-90 Part No. 1272222GT
Introducti on Introduction
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
procedure.
This manual provides troubleshooting and repair
procedures for qualified service professionals.
Basic mechanical, hydraulic and electrical skills
are required to perform most procedures.
However, several procedures require specialized
skills, tools, lifting equipment and a suitable
workshop. In these instances, we strongly
recommend that maintenance and repair be
performed at an authorized Genie dealer service
center.
Compliance
Machine Classification
Group A/Type 2, 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Copyright © 2016 by Terex Corporation
1272222GT Rev B, October 2020
First Edition, Second Printing
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
“GS” is a trademark of Terex South Dakota, Inc.

June 2021 Service and Repair Manual
Introduction
Part No. 1272222GT GS-84 • GS-90 iii
Revision History
Revision Date Section Procedure / Page / Description
A 3/2016 Initial Release
A1 9/2016 Introduction Serial Number Legend
A2 5/2017 Specifications Machine Specifications
B 8/2020 Cover Add ending serial break
Repair Engine Fault Codes
Schematics Electrical schematics
B1 6/2021 Repair 9-1
Reference Examples:
Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Repair Procedure, 4-2
Section – Fault Codes, All charts
Section – Schematics, Legends and schematics

Service and Repair Manual June 2021
Introduction
iv GS-84 • GS-90 Part No. 1272222GT
Serial Number Legend
To August 31, 2016
1 Model
2 Model year
3 Facility code
4 Sequence number
5 Serial label (located inside cover)
6 Serial number (stamped on chassis)
F
rom September 1, 2016
1 Model
2 Facility code
3 Sequence number
4 Serial label (located inside cover)
5 Serial number (stamped on chassis)

June 2021 Service and Repair Manual
Safety Rules
Part No. 1272222GT GS-84 • GS-90 v
Section 1 Safety Rul es
Danger
Failure to obey the instructions and safety
rules in this manual and the appropriate
Operator's Manual on your machine will result
in death or serious injury.
Many of the hazards identified in the
operator's manual are also safety hazards
when maintenance and repair procedures are
performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety
rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Service and Repair Manual June 2021
Safety Rules
vi GS-84 • GS-90 Part No. 1272222GT
Personal Safety
Any person working on or around a machine
must be aware of all known safety hazards.
Personal safety and the continued safe
operation of the machine should be your top
priority.
Read each procedure thoroughly. This
manual and the decals on the
machine, use signal words to identify
the following:
Safety alert
symbol—used to
alert personnel to potential
personal injury hazards. Obey
all safety messages that follow
this symbol to avoid poss
ible
injury or death.
Indicates a imminently
hazardous situation which, if
not avoided, will result in death
or serious in
jury.
Indicates a potentially
hazardous situation which, if
not avoided, could result in
death or serious injury.
Indicates a
potentially
hazardous situation which, if
not avoided, may cause minor
or moderate injury.
Indicates a
potentially
hazardous situation which, if
not avoided, may result in
property damage.
Be sure to wear protective eye wear
and other protective clo
thing if the
situation warrants it.
Be aware of potential crushing
hazards such as moving parts, free
sw
inging or unsecured components
when lifting or placing loads. Always
wear approved steel
-toed shoes.
Workplace Safety
Any person working on or around a machine
must be aware of all known safety hazards.
Personal safety and the continued safe
operation of the machine should be your top
priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable
and combustible materials like ba
ttery
gases and engine fuels. Always have
an approved fire extinguisher within
easy reach.
Be
sure that all tools and working
areas are properly maintained and
ready for use. Keep work surfaces
clean and free of debris that could get
into machine compon
ents and cause
damage.
Be sure any forklift, overhead crane or
other lifting or supporting de
vice is
fully capable of supporting and
stabilizing the weight to be lifted. Use
only chains or straps that are in good
condition and of ample capacity.
Be s
ure that fasteners intended for
one time use (i.e., cotter pins and self
-
locking nuts) are not r
eused. These
components may fail if they are used
a second time.
Be sure to properly dispose of old oil
or other fluids. Use an approved
container. Please be
environmentally
safe.
Be sure that your workshop or work
area is properly
ventilated and well lit.

June 2021
Table of Contents
Part No. 1272222GT GS-84 • GS-90 vii
Introduction Introduction...........................................................................................................ii
Important Information ............................................................................................. ii
Revision History..................................................................................................... iii
Serial Number Legend .......................................................................................... iv
Section 1 Safety Rules..........................................................................................................v
General Safety Rules ............................................................................................. v
Section 2 Specifications .......................................................................................................1
Machine Specifications...........................................................................................1
Performance Specifications....................................................................................2
Hydraulic Oil Specifications....................................................................................3
Hydraulic Component Specifications .....................................................................6
Manifold Component Specifications.......................................................................7
Ford MSG-425 EFI Engine Specifications .............................................................8
Deutz D2011 L03i Engine Specifications ...............................................................9
Deutz D 2.9 L4 Engine Specifications..................................................................10
Hydraulic Hose and Fitting Torque Specifications ...............................................12
Torque Procedure ................................................................................................13

June 2021
Table of Contents
viii GS-84 • GS-90 Part No. 1272222GT
Section 3 Repair Procedures ............................................................................................. 15
Introduction .......................................................................................................... 15
Platform Controls............................................................................................... 17
1-1 Circuit Board .................................................................................................. 17
How to Remove the Platform Controls Circuit Board ..................................... 17
Platform Components ....................................................................................... 18
2-1 Platform.......................................................................................................... 18
How to Remove the Platform.......................................................................... 18
2-2 Platform Extension Deck ............................................................................... 20
How to Remove the Platform Extension Deck................................................ 20
Scissor Components ......................................................................................... 21
3-1 Scissor Assembly, GS-3384 and GS-3390 ................................................... 22
How to Disassemble the Scissor Assembly ................................................... 22
How to Disassemble a Scissor Arm Pair ........................................................ 26
3-2 Scissor Assembly, GS-4390.......................................................................... 28
How to Disassemble the Scissor Assembly ................................................... 28
How to Disassemble a Scissor Arm Pair ........................................................ 32
3-3 Scissor Assembly, GS-5390.......................................................................... 35
How to Disassemble the Scissor Assembly ................................................... 35
How to Disassemble a Scissor Arm Pair ........................................................ 40
3-4 Wear Pads ..................................................................................................... 41
How to Replace the Scissor Arm Wear Pad................................................... 41
How to Replace the Chassis Scissor Arm Wear Pads ................................... 42
3-5 Lift Cylinders .................................................................................................. 44
How to Remove the Lift Cylinder - GS-3384, GS-3390 and GS-4390 ........... 44
How to Remove the Lift Cylinder - GS-5390 .................................................. 46

June 2021
Table of Contents
Part No. 1272222GT GS-84 • GS-90 ix
Engines................................................................................................................48
4-1 RPM Adjustment ............................................................................................48
4-2 Flex Plate .......................................................................................................48
How to Remove the Flex Plate - Ford Models ................................................48
How to Remove the Flex Plate - Deutz Models ..............................................49
How to Install the Flex Plate............................................................................50
4-3 Ford MSG-425 Engine Fault Codes...............................................................51
6-6 Engine Fault Codes - Deutz D 2.9 L4 and Perkins 404F-22 Models.............52
Ground Controls.................................................................................................53
5-1 Auxiliary Platform Lowering............................................................................53
5-2 Controller Adjustments...................................................................................53
How to Determine the Revision Level.............................................................54
How to Adjust the Stowed Drive Speed ..........................................................54
How to Adjust the High Torque Drive Speed ..................................................55
How to Adjust the Raised Drive Speed...........................................................56
How to Adjust the Lift Speed...........................................................................58
How to Adjust the Platform Lower Speed .......................................................59
How to Adjust the Platform Settling Speed .....................................................60
How to Adjust the Steer Speed.......................................................................61
5-3 Software Configuration...................................................................................61
5-4 Level Sensor - Models without Outriggers .....................................................66
How to Install and Calibrate the Level Sensor - Models without Outriggers...66
5-5 Level Sensor - Models with Outriggers ..........................................................68
How to Install and Calibrate the Level Sensor - Models with Outriggers........68

June 2021
Table of Contents
x GS-84 • GS-90 Part No. 1272222GT
Hydraulic Pump.................................................................................................. 72
6-1 Lift/Steer Pump .............................................................................................. 72
How to Remove the Lift/Steer Pump .............................................................. 72
6-2 Drive Pump .................................................................................................... 73
How to Remove the Drive Pump .................................................................... 73
How to Prime the Pump.................................................................................. 74
How to Adjust the Pump Neutral..................................................................... 75
Manifolds ............................................................................................................ 77
7-1 Function Manifold Components - Models with Outriggers............................. 77
7-2 Function Manifold Components - Models without Outriggers........................ 79
7-3 Traction Manifold Components...................................................................... 81
7-4 Oscillate Manifold Components, GS-90 (option) ........................................... 83
7-5 Welder Manifold Components (option) .......................................................... 85
7-6 Valve Adjustments - Function Manifold ......................................................... 86
How to Adjust the System Relief Valve .......................................................... 86
How to Adjust the Steer Relief Valve.............................................................. 87
7-7 Valve Adjustments - Traction Manifold .......................................................... 88
How to Adjust the Charge Pressure Relief Valve........................................... 88
7-8 Generator Manifold Components .................................................................. 89
7-9 Valve Adjustments - Generator Manifold....................................................... 90
How to Adjust the Generator Voltage ............................................................. 90
7-10 Generator Relief Valve Manifold Components ............................................ 91
7-11 Valve Coils................................................................................................... 92

June 2021
Table of Contents
Part No. 1272222GT GS-84 • GS-90 xi
Fuel and Hydraulic Tanks..................................................................................94
8-1 Fuel Tank .......................................................................................................94
8-2 Hydraulic Tank ...............................................................................................95
Steer Axle Components.....................................................................................97
9-1 Yoke Assembly ..............................................................................................97
How to Remove the Yoke and Drive Motor.....................................................97
How to Remove a Drive Motor ........................................................................98
9-2 Steer Cylinder.................................................................................................99
9-3 Oscillating Axle Option - GS-90 Models.........................................................99
Non-steer Axle Components...........................................................................101
10-1 Drive Motor and Brake ...............................................................................101
How to Remove a Drive Motor and Brake ....................................................101
10-2 Drive Hub ...................................................................................................102
How to Remove a Drive Hub.........................................................................102
10-3 Oscillating Axle...........................................................................................103
Outrigger Components ....................................................................................104
11-1 Outrigger Cylinder ......................................................................................104
How to Remove an Outrigger Cylinder (if equipped) ....................................104
Platform Overload Components .....................................................................105
12-1 Platform Overload System (if equipped) ....................................................105
How to Calibrate the Platform Overload System (if equipped) .....................105
12-2 Platform Overload Recovery Message (software version B3 and later)....114

June 2021
Table of Contents
xii GS-84 • GS-90 Part No. 1272222GT
Section 4 Fault Codes....................................................................................................... 116
Introduction ........................................................................................................ 116
Control System Fault Codes........................................................................... 118
Fault Code Display - Deutz Models ................................................................ 122
How to Retrieve Active Engine Fault Codes Deutz D 2.9 L4 Models........... 122
Fault Code Display - Flashing and Solid LED's - Deutz D 2.9 L4 Models.... 123
Soft Key Functions and Icons - Deutz D 2.9 L4 Models............................... 124
Main Menu Structure - Deutz D 2.9 L4 Models ............................................ 125
Deutz D 2.9 L4 Engine Fault Codes................................................................ 126
Ford MSG-425 Engine Fault Codes................................................................ 137
How to Retrieve Ford Engine Fault Codes ................................................... 137
How to Clear Engine Fault Codes from the ECM......................................... 137
Ford MSG-425 Engine Fault Codes................................................................... 138
Section 5 Schematics ....................................................................................................... 143
Introduction ........................................................................................................ 143
Electrical Symbols Legend................................................................................. 144
Hydraulic Symbols Legend ................................................................................ 145
Electrical Component and Wire Color Legends................................................. 146
Ford Engine Relay Layout ................................................................................. 148
Electronic Control Module Layout...................................................................... 149
Electronic Control Module Pin-Out Legend ....................................................... 150
Ground Controls Wiring Panel Layout ............................................................... 152
Wiring Diagram - Platform Control Box.............................................................. 153
Limit Switch Legend........................................................................................... 154
Wiring Diagram - 12 kW Hydraulic Generator (option) ...................................... 155

June 2021
Table of Contents
Part No. 1272222GT GS-84 • GS-90 xiii
Electrical Schematics - Engine Harness........................................................157
Ford MSG-425 EFI Engine Wire Harness..........................................................158
Deutx D 2.9 L4 Engine Wire Harness ................................................................159
Hydraulic Schematics ......................................................................................161
Hydraulic Schematic,
To Serial Numbers GS8415-42316 and GS9015-50184 ...........................162
Hydraulic Schematic,
From Serial Numbers GS84154-42317 and GS9015-50185 .....................164
Electrical Schematics – ANSI and CSA Models ............................................167
Electrical Schematic, Ford Engine Models (ANSI/CSA)
(from GS84D-101) • (to GS84F-45671, GS90D-2776, GS90F-54948)......168
Electrical Schematic, Ford Engine Models (ANSI/CSA)
(from GS84F-45672 to 45680, GS90D-2777 to 2861,
GS90F-54949 to 55081).............................................................................169
Electrical Schematic, Ford Engine Models (ANSI/CSA)
(from GS84F-45681, GS90D-2862, GS90F-55082) ..................................172
Platform Controls, Ford Engine Models (ANSI/CSA) .........................................173
Electrical Schematic, Deutz Engine Models (ANSI/CSA)
(from GS84D-101) • (to GS84F-45671, GS90D-2776, GS90F-54948)......176
Electrical Schematic, Deutz Engine Models (ANSI/CSA)
(from GS84F-45672 to 45680, GS90D-2777 to 2861,
GS90F-54949 to 55081).............................................................................177
Electrical Schematic, Deutz Engine Models (ANSI/CSA)
(from GS84F-45681, GS90D-2862, GS90F-55082) ..................................180
Platform Controls, Deutz Engine Models (ANSI/CSA).......................................181

June 2021
Table of Contents
xiv GS-84 • GS-90 Part No. 1272222GT
Electrical Schematics – AS and CE Models .................................................. 183
Electrical Schematic, Ford Engine Models (AS/CE)
(from GS84D-101) • (to GS84F-45671, GS90D-2776, GS90F-54948) ..... 184
Electrical Schematic, Ford Engine Models (AS/CE)
(from GS84F-54672 to 45680, GS90D-2777 to 2861,
GS90F-54949 to 55081) ............................................................................ 185
Electrical Schematic, Ford Engine Models (AS/CE)
from GS84F-45681, GS90D-2862, GS90F-55082) ................................... 188
Platform Controls, Ford Engine Models (AS/CE)............................................... 189
Electrical Schematic, Deutz Engine Models (AS/CE)
(from GS84D-101) • (to GS84F-45671, GS90D-2776, GS90F-54948) ..... 192
Electrical Schematic, Deutz Engine Models (AS/CE)
(from GS84F-45672 to 45680, GS90D-2777 to 2861,
GS90F-54949 to 55081) ............................................................................ 193
Electrical Schematic, Deutz Engine Models (AS/CE)
(from GS84F-45681, GS90D-2862, GS90F-55082) .................................. 196
Platform Controls, Deutz Engine Models (AS/CE)............................................. 197

June 2021 Service and Repair Manual
Specifications
Part No. 1272222GT GS-84 • GS-90 1
Section 2 Specificati ons
Machine Specifications
Fluid capacities
Hydraulic tank
30 g
allons
114 l
iters
Hydraulic
system (including tank)
GS
-3384 and GS-3390
37.5 g
allons
142 l
iters
H
ydraulic system (including tank)
GS
-4390
38.25 g
allons
145 l
iters
Hydraulic system (including tank)
GS
-5390
38.75 g
allons
147 l
iters
Fuel tank
Deutz D 2.9 L4, Ford MSG
-425
20 g
allons
76 l
iters
Fuel tank
Deutz D2011 L03i to serial number
GS84F
-45518 and GS90F-54370
30 g
allons
114 l
iters
Fuel tank
Deutz D2011 L03i from serial number
GS84F
-45519 and GS90F-54371
20 g
allons
20 l
iters
Tires and wheels
High Flotation,
air-filled and foam-filled (all models)
Tire size
33/16LL500
Tire ply rating
10
T
ire diameter x Tire width 33 in x 16 i
n
83.8 cm x 41 c
m
Wheel diameter x width
19.5 in x 14 i
n
49.5 cm x 35.6 c
m
Weight, foam filled
419 lbs (+/- 10 l
bs)
190 kg (+/- 4.5 k
g)
Weight, air
-filled 157 l
bs
71.2 k
g
Pressure, air
-filled 38 p
si
2.6 b
ar
Rough Terrain, foam-filled (GS-90)
Tire size
LSW 305-
546 NHS
Tire ply rating
10
Tire weight, new foam
-filled
(minimum) (Rough terrain)
265 l
bs
120 k
g
Tire
diameter x width 33 in x 12 i
n
83.8 cm x 30 c
m
Rough Terrain, foam
-filled (GS-84)
Tire size
51S3D1-
16.5 NHS
Tire ply rating, minimum
8
Tire diameter x width
30.8 in x 10.4 i
n
78.2 cm x 26.4 c
m
Weight, new foam
-filled
(minimum)
(Rough terrain)
224 l
bs
101.6 k
g
Weight, new foam
-filled
(minimum)
(Rough terrain, non
-marking)
228 l
bs
103.4 k
g
Tires a
nd wheels
Wheel lugs
9 @ 5/8-
18
Lug nut torque, dry
125 ft-
lbs
169.5 Nm
Lug nut torque, lubricated
94 ft-
lbs
127.4 Nm

Service and Repair Manual June 2021
Specifications
2 GS-84 • GS-90 Part No. 1272222GT
Performance Specifications
Drive speed, maximum (GS-90)
Platform stowed
5 m
ph
40 ft / 5.5 s
ec
8 k
m/h
12.2 m / 5.5 s
ec
Platform raised
0.7 m
ph
40 ft / 39 s
ec
1.1 k
m/h
12.2 m / 39 s
ec
Drive speed, maximum (GS
-84)
Platform stowed
4 m
ph
40 ft / 6.8 s
ec
6.4 k
m/h
12.2 m / 6.8 s
ec
Platform raised
0.7 m
ph
40 ft / 39 s
ec
1.1 k
m/h
12.2 m / 39 s
ec
Braking distance, maximum
High range on paved
surface
60 i
n
152.4 c
m
Gradeability
See Operator's Manual
Function speed, maximum from platform controls
(with maximum rated load in platform)
GS
-3384 and GS-3390
Platform up
Platform down
40 to 50 s
econds
24 to 34 s
econds
GS-4390
Platform up
Platform down
42 to 52 s
econds
34 to 44 s
econds
GS
-5390
Platform up
Platform down
50 to 60 s
econds
44 to 54 s
econds

June 2021 Service and Repair Manual
Specifications
Part No. 1272222GT GS-84 • GS-90 3
Hydraulic Oil Specifications
Hydraulic Fluid Specifications
Genie specific
ations require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the ability to
perform over a wide
temperature range, and the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation preven
tion, corrosion inhibition, seal
conditioning, and foam and aeration suppression
properties.
Cleanliness level,
minimum
ISO 15/13
Water content,
maximum
250 p
pm
Recommended Hydraulic Fluid
Hydraulic oil type
Chevron Rando HD Premium
Viscosity grade
32
Viscosity index
200
Optional Hydraulic Fluids
Mineral based
Shell Tellus S2 V 32
Shell Tellus S2 V 46
Shell Tellus S4 VX 32
Shell Donax TG (Dexron III)
Chevron 5606A
Biodegradable
Petro Canada Environ MV
46
Fire resistant
UCON Hydrolube HP-
5046
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult Genie
Product Support before use.
Optional fluids may not have
the same hydraulic lifespan and
may result in component
da
mage.
Note: Extended machine operation can cause the
hydraulic fluid temperature to increase beyond its
maximum allowable range. If the hydraulic fluid
temperature consistently exceeds 200°F / 90°C an
optional oil cooler may be required.
Do not top off
with incompatible
hydraulic fluids. Hydraulic fluids
may be incompatible due to the
differences in b
ase additive
chemistry. When incompatible
fluids are mixed, insoluble
materials may form and deposit
in the hydraulic system,
plugging hydraulic lines, fil
ters,
control valves and may result in
component damage.
Note: Do not operate the machine when the
ambient air temperature is consistently above
120°F / 49°C.
Hydraulic Fluid Temperature
Range
Ambient air temperature
1 Chevron hydraulic oil 5606A
2 Petro-Canada Environ MV 46
3 UCON Hydrolube HP-5046D
4 Chevron Rando HD premium oil MV

Service and Repair Manual June 2021
Specifications
4 GS-84 • GS-90 Part No. 1272222GT
Chevron Rando HD Premium Oil
MV Fluid Properties
ISO Grade
32
Viscosity index
200
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
7.5
33.5
Brookfield Viscosity
cP
@ -4°F / -20°C
cP @
-22°F / -30°C
1040
3310
Flash point
375°F / 190°C
Pour point
-58°F / -
50°C
Maximum continuous operating
temperature
171°F / 77°C
Note: A hydraulic oil heating system is
recommended when the ambient temperature is
consistently below 0°F / -18°C.
Note: Do not operate the machine when the
ambient temperature is below -20°F / -29°C with
Rando HD Premium MV.
Chevron 5606A Hydraulic Oil
Fluid Properties
ISO Grade
15
Viscosity index
300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 1
04°F / 40°C
cSt @
-40°F / -40°C
5.5
15.0
510
Flash point
180°F / 82°C
Pour point
-81°F / -
63°C
Maximum continuous operating
temperature
124°F / 51°C
Note: Use of Chevron 5606A hydraulic fluid, or
equivalent, is required when ambient temperatures
are consistently below 0°F / -17°C unless an oil
heating system is used.
Continued use of Chevron
5606A hydraulic fluid, or
equivalent, when ambient
temperatures are consistently
above 32°F / 0°C may result in
component damage

June 2021 Service and Repair Manual
Specifications
Part No. 1272222GT GS-84 • GS-90 5
Petro-Canada Environ MV 46
Fluid Properties
ISO Grade
46
Viscosity index
154
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
8.0
44.4
Flash point
482°F / 250°C
Pour point
-49°F / -
45°C
Maximum continuous operating
temperature
180°F / 82°C
Shell Tellus S4 VX Fluid
Properties
ISO Grade
32
Viscosity index
300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
9
33.8
Brookfield Viscosity
cSt @
-4°F / -20°C
cSt @
-13°F / -25°C
cSt @
-40°F / -40°C
481
702.4
2624
Flash point
>100
Pour point
-76°F / -60
°C
Maximum continuous operating
temperature
103°F / 75°C
UCON Hydrolube HP-5046 Fluid
Properties
ISO Grade
46
Viscosity index
192
Kinematic Viscosity
cSt @ 149°F / 65°C
cSt @ 104°F / 40°C
cSt @ 0°F /
-18°C
22
46
1300
Flash point
None
Pour point
-81°F / -
63°C
Maximum
continuous operating
temperature
189°F / 87°C

Service and Repair Manual June 2021
Specifications
6 GS-84 • GS-90 Part No. 1272222GT
Hydraulic Component
Specifications
Drive Pump
Type: bi-
directional variable displacement piston pump
Flow rate @ 250
0 rpm 0 to 32.5 g
pm
0 to 123
L/min
Drive
pressure, maximum 3750 p
si
258.6 b
ar
Charge Pump
Type
Gerotor
Flow rate @ 250
0 rpm 9.1 g
pm
34.4 L/min
Charge pump pressure
325 p
si
22.4 b
ar
Function Pump
Type
gear pump
Displacement
0.98 c
u in
16 c
c
Flow rate @ 250
0 rpm 10.6 g
pm
40
.1 L/min
Hydraulic tank return line filter
10 micron with 25 p
si
/ 1.7 b
ar bypass
Auxiliary power unit
Relief valve
3700 p
si
255 b
ar
Function manifold
System relief valve pressure,
maximum, GS
-3384 and GS-3390
2700 to 2900 p
si
186 to 200 b
ar
Sys
tem relief valve pressure,
maximum, GS
-4390 and GS-5390
2900 to 3100 p
si
200 to 214 b
ar
Steer relief valve pressure, GS
-
3384
2700 to 2900 p
si
186 to 200 b
ar
Steer relief valve pressure, GS
-
3390, GS
-4390 and GS-5390
1950 to 2250 p
si
135 to 155 b
ar
Propor
tional valve flow regulator 0.1 g
pm
0.4 L/min
Drive manifold
Hot oil relief pressure
280 p
si
19 b
ar
Drive Motors
Displacement (
2 speed motor) 0.54 to 1.52 c
u in
8.8 to 25 c
c
Drive hubs
Fluid capacity
26 f
l oz
769 c
c
Fluid type: SAE 9
0 multipurpose hypoid gear oil API
service classification GL5
Installation torque, lubricated
180 ft-
lbs
244 Nm
