TESmart HKS0801A20 Installation instructions

SUPPORT MANUAL
TESmart 8-Port HDMI KVM
Switch - Autoscan, Rackmount,
Ethernet, USB Hub, 4K 30hz
HKS0801A20
www.buytesmart.com [email protected]

INTRODUCTION
This 8x1 HDMI KVM switch provides you with great flexibility in
integrating cross-platform computer equipment easily.
It makes you available to switch easily and reliably between any HDMI
computers using one HDMI compliant display.
The 8x1 HDMI KVM switch supports USB 2.0 hub and USB 2.0
keyboard /mouse. By using USB 2.0 hub ports on the KVM, you even
can attach USB drive, printer, barcode scanner or other USB devices to
the KVM.
Switching can be controlled through variable methods, such as the front
panel source selector buttons, RS232 commands, IP commands, IR
signals and hot keys on keyboard.
With EDID emulators in every input ports, keep PCs always have correct
display information, prevent display settings changed while switching
input ports.
2
HKS0801A20

FEATURES
Using one USB console controls 8 HDMI computers.
Support UNIX, Windows, Debian, Ubuntu, Fedora, MAC OSX,
Raspbian, Ubuntu for Raspberry Pi and other Linux based systems.
With EDID emulators in every input ports, keep PCs always have the
correct display information.
Supports hot plug, connect or disconnect devices to the KVM switch
in any time and without turning off the devices.
Supports auto switching to monitor computers in a specified time
interval.
Supports front panel buttons, IR signals, keyboard hot keys, RS232
serial commands or IP commands to control the KVM switch.
Available to use keyboard without any delay after switching the input
sources.
Supports resolutions up to 3840x2160 @30Hz.
With extra standard USB 2.0 hub port, it is possible to connect
barcode scanners, USB hard drives or other USB devices to the KVM
easily as if you have plugged these devices directly yo the computer.
Supports DVI-D single link sources and displays with the use of
HDMI-to-DIV adapters.
3
HKS0801A20

PACKING LIST
1 x 8x1 HDMI KVM Switch
1 x DC 12V 2A Power Adapter
1 x IR Remote Control
1 x IR Receiver Cable
1 x 3 Pins Connector (For RS232)
2 x Rack-ears
4 x 5' KVM Cables
1 x User manual
4
HKS0801A20

PANEL DESCRIPTION
5
HKS0801A20

6
HKS0801A20

CONNECTION DIAGRAM
7
HKS0801A20

SPECIFICATION
HKS0801A20
8x1 HDMI KVM Switch
Functiona
lity:
Auto Scan
Yes
Po
rt selection
Front panel buttons
Yes
Keyboard hotkeys
Yes
IR remote control
Yes
Console commands
RS232 / IP
Technical:
Max. Resolution
3840x2160@30Hz
HDMI version
1.4
Auto to get EDID
Yes
Data rate
10.2 Gbps
Auto scan interval
5~3600 Seconds
Beep Sound
On/Off
OSD
No
Sup
ported OS
Unix/Windows/Debian /Ubuntu /Fedora /Mac OS X/
Raspbian /Ubuntu for Raspberry Pi and other Linux
based system
Co
nsole ports
Keyboard emulation
1 * USB Type A
Mouse emulation
1 * USB Type A
USB 2.0 Hub ports
2 * USB Type A
Video /Audio
1 * HDMI Type A
RS232
3 Pins jack
LAN (TCP/IP)
1 * RJ45
IR extension input
1 * AUX
S
ystem ports
USB Data
8 * USB Type B
Video / Audio
8 * HDMI Type A
ESD protection
Human body model - ±8kV (Air-gap discharge)
Mechanical:
Chasing material
Metal
Product Dimensions
440 (L) x 150 (W) x 44.5 (H) mm
Item Weight
1800g
8
HKS0801A20

BASIC OPERATIONS
1- Port selection
Use front panel keypad
Directly press button [1]-[8] to select input ports 1-8.
Use IR remote control
Press [1/A], [2/B]-[8/H] directly to select input ports 1-8.
Use keyboard hot keys
Press keyboard [Scroll Lock] key 2 times then press [1]-[8] within 2
seconds to directly select input ports 1-8.
Press keyboard [Scroll Lock] key 2 times then press [Page Up-
]/[Page Down] to select previous or next port.
2- Turn on/off auto input detection and switch
Press button [M] on the remote control to turn on/off the auto input
detection.
Auto input detection and switch mode on:
When plugging a new HDMI input source to the KVM switch or
powering on the HDMI input source, the KVM switch will automatically
select the input port that is connected to this input source.
When unplugging or powering off the HDMI input source, the KVM
switch will switch to the input port which was plugged or powered last on
the HDMI input source.
Auto input detection and switch mode off:
When plugging in a new HDMI input source to the KVM switch or
powering on the HDMI input source, the KVM switch would not do
anything, also when unplugging or powering off the HDMI input source.
9
HKS0801A20

3- Mute/Unmute buzzer
IR remote control
Press button [ ] on the remote control to mute or unmute the
buzzer.
Keyboard hot keys
Press the keyboard [Scroll Lock] key 2 times then press [F11] to
mute or unmute the buzzer.
4- Turn on/off the auto scan mode
Front panel key pad
Press [Scan] button to start auto scanning, then the KVM will auto-
matically loop among all the powered on input sources with a specified
time interval, press [Scan] again to stop scanning.
IR remote control
Press [P] button to start auto scanning, then the KVM will automati-
cally loop among all the powered on input sources with a specified time
interval, press [P] again to stop scanning.
Keyboard hot keys
Press keyboard [Scroll Lock] key 2 times then press [Space] key
within 2 seconds to start auto scanning, the KVM will automatically loop
among all the powered on input sources with a specified time interval,
press [Esc] key to stop scanning.
5- Setup time interval of auto scan mode
Press front panel button [MIN] to loop between 0-59 minutes.
Press front panel button [SEC] to loop between 0-59 seconds.
After setting the minutes and seconds, press the button [Set] to
enter the final scan time interval setting.
BASIC OPERATIONS
10
HKS0801A20

BASIC OPERATIONS
6- The use of the mouse gesture switching
Press the keyboard [Scroll Lock] key 2 times then press [F12] key
within 2 seconds to turn on or turn off the mouse gesture switching.
When the mouse gesture switching mode is on, move the mouse
pointer to hit left ot right bound of the screen within 1 second, the KVM
will switch to previous or next input source.
11
HKS0801A20

USE OF RS232 AND LAN PORT
The RS232 and LAN ports are used for selecting input source only, could
not transfer keyboard and mouse data or even the video and audio, this
is a redundant design for some special application when you want to
switch the input sources by a termination control devices. Normally you
could switch the input source by front panel keypad, IR remote control or
keyboard hot keys.
For the software application packages or the API document for the
RS232 and LAN port please contact with our sales. (Only for
windows system)
Connect RS232 port
Follow below diagram to connect the standard 9 pin RS232 port to the 3
pins connector which is included in package, then plug the connector to
the KVM "TX-RX" port.
Connect LAN port
Follow below diagram to connect the LAN port to local area network
router or directly to PC with Cat5e/6 UTP cable.
12
HKS0801A20

KEYBOARD HOT KEYS
1- Hit SCROLL LOCK twice within 2 seconds, the buzzer will beep twice.
2- After step 1 enter the following Hot Key command within 3 seconds.
The KVM will execute the corresponsing command.
Known issue: Apple Keyboard is not supported yet.
13
HKS0801A20

CONTACT
Thank you for purchasing the TESmart 4-Port KVM HDMI Video Switch.
We are here to help you!
Do you need assistance setting up your product?
Please make sure you visit:
- https://buytesmart.com for more details and product information
- https://buytesmart.com/apps/help-center for support knowledge base
and Frequently Asked Questions.
14
