TESmart HMA0808A30 User manual

English
HMA0808A30
User
Manual
8x8 HDMI Matrix
&IR HMA0808A30

English

Preface
It's our great honor that you have chosen the HDMI Matrix produced by our company, Tesla Elec Technology Co.,Ltd.
In this user manual, you will learn how to operate and use this product. Please read this user manual
comprehensively before use. If you have any questions, comments or suggestions, please contact us via the
following email:
[e-mail].
Copyright Notice
The user manual, compiled by Tesla Elec Technology Co.,Ltd, shall not be duplicated or translated by any person or
organizations without written permission. This user manual shall not be used for commodity transaction in any
form or by any means (electronically, mechanically, photocopying or recording, etc.) or be used for any business
practices or profitable activities. The ownership of the trade names and brand names adopted in this user manual
belongs to their companies.
Address of Manufacture
Tesla Elec Technology Co.,Ltd
2F, Building C, Xingzhisheng Industrial Park, No.12,
Xiawei Industrial Zone, Zhangkengjing Road,
Guanlan Street,
Longhua District, Shenzhen City, Guangdong
Province, China

Contents
1. Safety Tips and Warnings·························································································································01
2. Battery Description································································································································02
3. Warranty Information·····························································································································03
4. Preface···············································································································································04
5. Features··············································································································································05
6. Packing List·············································································································································06
7. Panel Description··································································································································07
8. Connection Description··························································································································09
8.1 Connection Diagram··························································································································09
8.2 Connection Steps·····························································································································10
9. Operation Method·································································································································12
9.1 Front Panel Button Switching Method····································································································12
9.2 IR Remote Control·····························································································································15
9.3 RS232 Control··································································································································17

1. Safety Tips and Warnings
Tips: Please read the safety tips and warnings for HDMI Matrix comprehensively before use. Use this produce in
accordance with its instructions, safety tips and warnings to prevent unnecessary damage to the product
and potential dangers to users.
Keep the product away from water.
Do not expose this product and its battery to open fire or overheating environment. Dispose the waste
battery in accordance with instructions.
Unplug the power supply of this product in thunderstorm days or when it has been not used for a long
time.
Do not touch the product and the power cord with wet hands so as to lower the risk of electric shock
and damage to the product. Do not let the product get wet or become damp.
Keep the product away from ignition sources, such as heat sinks, heat accumulators, stovepipe and
other heat production settings (including audio amplifiers).
Use the product in accordance with its instructions and do not block its vents.
Users shall not remove and repair the product without authorization.
Clean the product with dry cloth.
1. Safety Tips and Warnings
01
EN

2. Battery Description
Caution: Improper disposal of the lithium battery may
cause an explosion. Do not throw the
battery into fire. Keep the battery away from
children. Dispose the waste battery in
accordance with local regulations.
Tips: By default, the remote control is not equipped
with batteries, due to the safety requirements of
some express companies. Install CR2025 cell
before use.
02
EN
2. Battery Description

We warrant this product as free of defects in material and workmanship for a period of one (1)
year from the date of shipment. If during the period of warranty this product proves defective
under normal use, we will repair or replace this product, provided that this product has not been
subjected to mechanical, electrical, or other abuse or modifications. If it fails under conditions
other than those covered will be repaired at the current price of parts and labor in effect at the
time of repair. Such repairs are warranted for six (6) months from the day of reshipment to the
buyer.
3. Warranty Information
3. Warranty Information
03
EN

Dear Users,
HDMI Matrix can greatly facilitate your management of audio and video devices. If you have
multiple sources and display devices like game consoles, streaming boxes, projectors and
monitors, our HDMI Matrix can help you match your devices at will. You can choose which
output device to display which input device you want, and you can also display one input
device on multiple output devices at the same time, eliminating the troublesome of unplugging
cables and switching devices, and greatly simplifying the device management.
You can switch input ports with front panel buttons, IR signals LAN port and RS232 port.
4. Preface
Tips: If you need to control more devices or conduct more complex and professional switching, you can
also choose other products of our company. For more details, please visit our official website:
www.tesmart.com.
04
EN
4. Preface

5. Features
ŸAll the HDMI outputs can share same input or select standalone input
ŸSupport resolution up to 3840x2160@30Hz
ŸHDMI 1.4 compliant
ŸHDCP 1.4 compliant
ŸSupport PCM, Dolby AC3, DTS 5.1 and DSD audio format
ŸMatrix status could be memorized after power down, automatically restore previous
matrix status after next power on
ŸSmart EDID management, make it compatible with most display devices
ŸSupport 8 configurable user preset connections
ŸEasy to control matrix via IR receiver, front panel key and PC (via RS232 port or LAN port)
5. Features
05
EN

6. Packing List
Tips: After receipt of the product, please check the packing list carefully to make sure that no components have
been lost and no damage to the product has been caused during transportation. If you have any
problems, please contact us at any time.
Ÿ1 * 8x8 HDMI Matrix
Ÿ1 * IR Remote Control
Ÿ1 * IR Extension Cable
Ÿ1 * DC V Power Adapter12
Ÿ2 * Rack-ears
Ÿ1 * User Manual
06
EN
6. Packing List

7. Panel Description
ID
Name
Description
1
LCD display
Display current status and function settings.
2
Keypad
Press to control the Matrix. Please refer to Chapter 9.1 for the detail.
3
IR receiver
Receive IR remote signal.
4
Power status indicator
The LED will be lit (red) if power is on.
5
Power switch
Turn on or turn off power supply.
1235
4
7. Panel Description
07
EN

ID
Name
Description
6
DC 12V
DC 12V power supply.
7
IR extension in
Connect IR extension cable to this port to receive IR signal even the Matrix is
installed in a rack.
8
RS232 port
Connect to control termination to use RS232 commands to control the Matrix.
9
LAN port
Connect to control termination to use TCP/IP commands to control the Matrix.
10
HDMI input ports
Connect to HDMI source devices.
11
HDMI output ports
Connect to HDMI display devices.
89
7
610 11
08
EN
7. Panel Description

8.1 Connection Diagram
8. Connection Description
PC DVR STB DVD
IR receiver
Control Terminal
CAT 5e/6
RS232
...
UHD TV
x 8
Tips: 1. Please refer to Chapter 9.3 for how to use LAN port and RS232 port.
PS4/PS5
8. Connection Description
09
EN

8.2 Connection Steps
1. Connect 8 input devices to the HDMI input ports above each "Input" logo of the Matrix
using 8 HDMI cables.
2. Connect 8 display devices to the HDMI output ports above each "Output" logo of the
Matrix using 8 HDMI cables.
3. Connect the power cable to the HDMI Matrix's DC 12V port and plug it into a power
socket.
10
EN
8. Connection Description

Tips: 1. Please refer to Chapter 9 for detailed information about how to use the HDMI Matrix.
2. By default, the HDMI cables are not included in the package.
5. By now, the connection has been completed. Turn on the power supply and the HDMI
Matrix will begin to work.
8. Connection Description
11
EN

9.1 Front Panel Button Switching Method
9. Operation Method
When you use the front panel button or IR remote control to control the Matrix, the LCD
display will inquiry your target action, then execute the command according to your operation.
~
H
~
A~H buttons:
Press to choose the corresponding output port to switch to the desired input.
1~8 buttons:
1. After pressing the [A~H] button to choose the output port, press [1~8]
button to choose the desired input port.
2. If you press the other setting buttons, press [1~8] button according to LCD
prompt to choose the desired option.
12
EN
9. Operation Method

Save button:
Press [SAVE] button then press any one of [1~8] button according to LCD prompt to
save current routing status to user preset memory 1~8.
SAVE
Return button:
Press [RETURN] button then press any one of [1~8] button according to LCD prompt
to load routing status from user preset memory 1~8 and apply to current routing.
RETURN
Lock button:
Press [LOCK] button to lock or unlock the keypad. If the keypad was locked, all the
operations using the keypad or IR remote control would not take effect. Press it
again to unlock the keypad when it is locked.
Function settings button:
1. 1 to all switch: Press [FUN] button once to select desired input to be displayed on
all outputs. Press any one of [1~8] button to confirm according to LCD prompt.
2. Mirror connection: After pressing [FUN] button twice, the routing status will be
changed to Input 1-Output A, Input 2-Output B, Input 3-Output C, and so on.
Press [LOCK] button to confirm.
9. Operation Method
13
EN
LOCK
FUN

3. LCD display timeout setting: Press [FUN] button three times to set the LCD display
time out. Press any one of [1~3] button to confirm according to LCD prompt.
4. Beep state setting: Press [FUN] button four times to turn off/on the buzzer. Press
any one of [1~2] button to confirm according to LCD prompt.
5. IP address query: Press [FUN] button five times to query current IP address.
14
EN
9. Operation Method
FUN
