TESTO 320 basic User manual

testo 320 basic - Flue gas analyzer
Instruction manual

2
Register your Testo product at www.testo.com/register and receive a one-year
free warranty extension.
The product registration is valid for 30 days after purchase.
For product registration terms and conditions and participating countries, please
go to www.testo.com/register

1 Contents
3
1 Contents
1Contents ...................................................................................................3
2Safety and the environment....................................................................6
2.1. About this document........................................................................6
2.2. Ensure safety...................................................................................7
2.3. Protecting the environment..............................................................8
3Specifications ..........................................................................................9
3.1. Use ..................................................................................................9
3.2. Technical data .................................................................................9
3.2.1. Examinations and licenses ..............................................................................9
3.2.2. Measurement ranges and resolution..............................................................10
3.2.3. Accuracy and response time..........................................................................10
3.2.4. Other instrument data ....................................................................................11
4Product description...............................................................................13
4.1. Measuring instrument ....................................................................13
4.1.1. Front view ......................................................................................................13
4.1.2. Keypad ..........................................................................................................14
4.1.3. Display...........................................................................................................15
4.1.4. Instrument connections..................................................................................16
4.1.5. Condensate outlet and interfaces ..................................................................16
4.1.6. Rear view.......................................................................................................17
4.1.7. Components ..................................................................................................18
4.2. Compact flue gas probe ................................................................19
5First steps ..............................................................................................20
5.1. Commissioning ..............................................................................20
5.2. Getting to know the product...........................................................20
5.2.1. Mains operation .............................................................................................20
5.2.2. Connecting probes.........................................................................................20
5.2.3. Switching on ..................................................................................................21
5.2.4. Calling up the function ...................................................................................21
5.2.5. Entering values..............................................................................................22
5.2.6. Printing/saving data .......................................................................................23
5.2.7. Saving data to the clipboard (temporary memory)..........................................24
5.2.8. Confirming an error message.........................................................................24
5.2.9. Switching off ..................................................................................................24
5.3. Measurement records....................................................................24
5.4. Instrument diagnosis .....................................................................25

1 Contents
4
6Using the product ................................................................................. 26
6.1. Performing settings ....................................................................... 26
6.1.1. Assigning the right function key ..................................................................... 26
6.1.2. Instrument settings ........................................................................................ 26
6.1.2.1. Measurement view .......................................................................... 26
6.1.2.2. Alarm limits...................................................................................... 28
6.1.2.3. Date / time....................................................................................... 28
6.1.2.4. Power Options................................................................................. 28
6.1.2.5. Display brightness ........................................................................... 29
6.1.2.6. Printer ............................................................................................. 29
6.1.2.7. Language ........................................................................................ 29
6.1.2.8. Country version ............................................................................... 30
6.1.2.9. Password protection........................................................................ 30
6.1.3. Sensor settings.............................................................................................. 31
6.1.3.1. O2reference.................................................................................... 31
6.1.3.2. Recalibration/adjustment................................................................. 31
6.1.4. Fuels.............................................................................................................. 32
6.2. Measuring ..................................................................................... 33
6.2.1. Preparing for measurement ........................................................................... 33
6.2.1.1. Testing for leaks.............................................................................. 33
6.2.1.2. Zeroing phases................................................................................ 33
6.2.1.3. Using the modular flue gas probe.................................................... 34
6.2.1.4. Measurement view .......................................................................... 35
6.2.1.5. Setting the fuel ................................................................................ 35
6.2.2. Flue gas......................................................................................................... 35
6.2.3. Draught measurement ................................................................................... 36
6.2.4. Smoke number/HCT ...................................................................................... 36
6.2.5. Pressure ........................................................................................................ 37
6.2.6. Differential temperature ................................................................................. 38
6.2.7. Ambient CO................................................................................................... 38
6.3. Transferring data........................................................................... 40
6.3.1. Report printer................................................................................................. 40
6.3.2. PC ................................................................................................................. 40
7Maintaining the product ....................................................................... 41
7.1. Cleaning the measuring instrument .............................................. 41
7.2. Replacing the rechargeable battery .............................................. 41
7.3. Charging the battery ..................................................................... 43
7.4. Replacing sensors ........................................................................ 43
7.5. Recalibrating/adjusting sensors .................................................... 44
7.6. Compact flue gas probe................................................................ 44
7.6.1. Cleaning the probe shaft................................................................................ 44
7.6.2. Replacing the thermocouple .......................................................................... 45
7.6.3. Checking the particle filter.............................................................................. 47
7.6.4. Replacing the particle filter............................................................................. 47
7.7. Condensate container................................................................... 48

1 Contents
5
8Tips and assistance...............................................................................49
8.1. Questions and answers .................................................................49
8.2. Accessories and spare parts .........................................................49
8.3. Updating the instrument software..................................................52

2 Safety and the environment
6
2 Safety and the environment
2.1. About this document
Use
> Please read this documentation through carefully and
familiarize yourself with the product before putting it to use. Pay
particular attention to the safety instructions and warning advice
in order to prevent injuries and damage to the products.
> Keep this document to hand so that you can refer to it when
necessary.
> Hand this documentation on to any subsequent users of the
product.
Warnings
Always pay attention to information that is marked by the following
warnings with warning pictograms. Implement the specified
precautionary measures.
Representation Explanation
WARNING Indicates potential serious injuries
CAUTION indicates potential minor injuries
NOTICE indicates circumstances that may lead to
damage to the products

2 Safety and the environment
7
Symbols and writing standards
Represen-
tation
Explanation
Note: Basic or further information.
1. ...
2. ...
Action: more steps, the sequence must be followed.
> ... Action: a step or an optional step.
- ... Result of an action.
[OK] Control keys of the instrument or buttons of the
program interface.
2.2. Ensure safety
> The testo 320 basic must be checked before commissioning
for any visible damage. Do not commission the testo
320 basic if there are signs of damage on the housing,
mains unit or supply lines. Electrical risk.
> Only operate the product properly, for its intended purpose and
within the parameters specified in the technical data. Do not
use any force.
> Do not operate the instrument if there are signs of damage at
the housing, mains unit or feed lines.
> Do not perform contact measurements on non-insulated, live
parts.
> The testo 320 basic is not suitable for long-term measurements
and should not be used as a safety (alarm) instrument.
> Do not store the product together with solvents. Do not use any
desiccants.
> Carry out only the maintenance and repair work on this
instrument that is described in the documentation. Follow the
prescribed steps exactly. Use only original spare parts
from Testo.
> Any further or additional work must only be carried out by
authorised personnel. Testo will otherwise refuse to accept
responsibility for the proper functioning of the measuring
instrument after repair and for the validity of certifications.
> Only use the device in closed, dry rooms and protect it from rain
and moisture.

2 Safety and the environment
8
> Temperatures given on probes/sensors relate only to the
measuring range of the sensors. Do not expose handles and
feed lines to any temperatures in excess of 70 °C unless they
are expressly permitted for higher temperatures.
> Dangers may also arise from the systems being measured or
the measuring environment: Note the safety regulations valid in
your area when performing the measurements.
2.3. Protecting the environment
> Dispose of faulty rechargeable batteries/spent batteries in
accordance with the valid legal specifications.
> At the end of its useful life, send the product to the separate
collection for electric and electronic devices (observe local
regulations) or return the product to Testo for disposal.

3 Specifications
9
3 Specifications
3.1. Use
The testo 320 basic is a handheld measuring device for the
professional flue gas analysis of combustion plants:
• Small combustion plants (burning oil, gas, wood, coal)
• Low-temperature and condensing boilers
• Gas water heaters
These systems can be adjusted using the testo 320 basic and
checked for compliance with the applicable limit values.
The following tasks can also be carried out with the testo 320 basic:
• Regulating the O2, CO and CO2 values in combustion plants
for the purpose of ensuring optimal operation.
• Draught measurement.
• Measuring and regulating the gas flow pressure in gas water
heaters.
• Measuring and optimising the flow and return temperatures of
heating systems.
3.2. Technical data
3.2.1. Examinations and licenses
As declared in the certificate of conformity, this product complies
with Directive 2014/30/EC.
This product is TÜV-tested. The O2 sensor and the sensors for
temperature and pressure are TÜV-tested in accordance with EN
50379 part 2.
The measuring cell 0393 0053 (CO) is TÜV-tested as per EN
50379 part 3.
This product is EMC-tested as per DIN EN 61326-1.

3 Specifications
10
3.2.2. Measurement ranges and resolution
Measurement
parameter
Measuring range Resolution
O20 to 21 Vol.% 0.1 vol.%
CO 0...4000 ppm 1 ppm
Draught1-9.99 to 40.00 hPa 0.01 hPa
Fine draught1-9.999 hPa to
+40.000 hPa
0.001 hPa
∆P (only with gas
pressure set 0554
1203)
0 to 300 hPa 0.1 hPa
Fine pressure11
oben (only with
gas pressure set
0554 1203)
0 to 300 hPa 0.01 hPa
temperature -40 to 1200°C 0.1°C (-40.0 to 999.9°C)
1°C (from 1000°C)
Efficiency 0 to 120 % 0.1 %
Flue gas loss 0 to 99.9 % 0.1 %
3.2.3. Accuracy and response time
Measurement
parameter
Accuracy Response
time (t90)
O2 ±0.2 vol.% < 20 s
CO ±20 ppm (0 to 400 ppm)
±5% of meas. val. (401 to 2000
ppm)
±10% of meas. val. (2001 to
4000 ppm)
< 60 s
Draught1±0.02 ppm or ±5% of meas. val.
(-0.50 to 0.60 hPa)
± 0.03 hPa (0.61 to 3.00 hPa)
±1.5% of meas. val. (3.01 to
40.00 hPa)
-
1Depending on the country version

3 Specifications
11
Measurement
parameter
Accuracy Response
time (t90)
Fine draught11
oben
±0.02 ppm or ±5% of meas. val.
(-0.50 to 0.60 hPa)
± 0.03 hPa (0.61 to 3.00 hPa)
±1.5% of meas. val. (3.01 to
40.00 hPa)
∆P (only with gas
pressure set 0554
1203)
± 0.5 hPa (0.0 to 50.0 hPa)
±1% of meas. val. (50.1 to 100.0
hPa)
±1.5% of meas. val. (rest of
range)
-
Fine pressure1
(only with gas
pressure set 0554
1203)
± 0.5 hPa (0.0 to 50.0 hPa)
±1% of meas. val. (50.1 to 100.0
hPa)
±1.5% of meas. val. (rest of
range)
Temperature ± 0.5°C (0.0 to 100.0°C)
±0.5% of meas. val. (rest of
range)
depending on
the probe
Efficiency - -
Flue gas loss - -
3.2.4. Other instrument data
Feature Values
Storage and
transport
temperature
-20 to 50°C
Operating
temperature
-5 to 45°C
Ambient humidity 0…90 % rH, not condensing
Power supply Rech. batt.: 3.7 V / 2.4 Ah
Mains unit: 5.0 V/1000 mA
Protection class IP40
Weight 573 g
Dimensions 240 x 85 x 65 mm
Memory 20 protocols

3 Specifications
12
Feature Values
Display Graphic colour display, 240 x 320 pixels
Optimum rech. batt.
storage conditions
Charge level: capacity at 50-80% ambient
temperature: 10-20°C
Battery charge time Approx. 5-6 h with mains unit supplied
Rechargeable
battery life
Approx. 6 h (pump on, 20°C ambient
temperature)
Data transfer IrDA, USB
Sensor protection
switch-off
4000 ppm
Warranty Measuring instrument: 24 months
O2 sensor: 24 months
CO sensor: 24 months
Flue gas probe: 24 months
Thermocouple: 12 months
Rech. batt.: 12 months
Terms of warranty: see website
www.testo.com/warranty

4 Product description
13
4 Product description
4.1. Measuring instrument
4.1.1. Front view
1 Display
2 Function keys
3 Keypad

4 Product description
14
4.1.2. Keypad
Button Functions
[] Switch measuring instrument on / off
[OK]
Example
Function key (orange, 3x), relevant function is shown on
the display
[▲]Scroll up, increase value, navigate
[▼]Scroll down, reduce value, navigate
[esc] Back, cancel function
[] Open main menu
[] Transmit data to the Testo protocol printer.

4 Product description
15
4.1.3. Display
1 Status bar (dark grey background):
• Warning symbol (only if there is an instrument error,
display of error in instrument diagnosis menu), otherwise:
Instrument designation.
• Symbol (only if data is stored in the temporary memory).
• Display of date and time.
• Indication of Bluetooth®status, power supply and remaining
rechargeable battery capacity:
Icon Feature
Battery operation
Display of remaining rechargeable battery
capacity by colour and fill level of the battery icon
(green = 5-100%, red = < 5%)
Mains operation
Display of remaining rechargeable battery
capacity: see above
2 Info field of register tabs: Indication of chosen fuel and chosen
measurement type.
3 Selection field for functions (selected function appears against a
white background, unavailable functions are identified by grey
font) or display of measured values.
4 Function display for function keys.

4 Product description
16
4.1.4. Instrument connections
1 Probe socket
2 Gas outlet
3 Probe socket
4 Micro USB socket (battery charging, data transfer)
4.1.5. Condensate outlet and interfaces
1 Infrared interface (IrDA)
2 Condensate outlet

4 Product description
17
4.1.6. Rear view
1 Attachment for carrying strap
2 Condensate trap
3 Magnetic holder
WARNING
Magnetic field
May be harmful to those with pacemakers.
> Keep a minimum distance of 15 cm between pacemaker and
instrument.
ATTENTION
Magnetic field
Damage to other devices!
>Keep a safe distance away from products which could be
damaged by the effects of magnetism (e.g. monitors,
computers or credit cards).
4 Service lid

4 Product description
18
4.1.7. Components
1 Rechargeable battery
2 Measured gas pump
3 Slot for O2 sensor
4 Slot for CO sensor

4 Product description
19
4.2. Compact flue gas probe
1 Removable filter chamber with window and particle filter
2 Probe handle
3 Connector plug for measuring instrument
4 Connecting cable

5 First steps
20
5 First steps
5.1. Commissioning
The measuring instrument is supplied with a rechargeable battery
already fitted.
> Charge the rechargeable battery fully before using the
measuring instrument, see Charging the battery, page 43.
5.2. Getting to know the product
5.2.1. Mains operation
If the mains unit is connected, the measuring instrument is
automatically powered from the unit.
1. Connect the mains unit instrument plug to the instrument's
micro USB socket.
2. Connect the mains plug of the mains unit to a mains socket.
In mains operation the battery is automatically charged.
5.2.2. Connecting probes
Probe detection at the flue gas socket is carried out
continuously. New probes are recognised automatically.
Connecting flue gas probes/gas pressure
adapters/temperature adapters
> Insert the connector plug into the flue gas socket and lock by
slightly turning it clockwise (bayonet lock).
There must be no more than one extension lead
(0554 1201) between measuring instrument and flue gas
probe.
