PREDISPOSITION FOR THE INSTALLATION
Minipool
The minipool is designed specifically for built-in type
installation, with the edge exactly at floor level; refer to the
dimensions indicated in the drawings when preparing the pit.
(N.B given that dimensional specifications may be
subject to slight variations, check all measurements
before proceeding with installation).
The pit for the built-in minipool should be cast in concrete,
observing the dimensions indicated in the drawing and
making certain that the structure is perfectly level. The plinth
or slab directly supporting the minipool must be able to
support the load (see table on page 2).
Leave a void (A) at least 40 cm wide all round the minipool
to ensure sufficient freedom of access to the plumbing and
electrical equipment installed beneath the tub.
The void must be covered with removable grate decking
carried on suitably sturdy supports and affording air passages
so that the pit will be adequately ventilated.
Provide channels and a drain outlet (S) at the bottom of the pit
so that water will not collect and stagnate.
PREDISPOSITIÓN CONNECTS HYDRÁULIC
The contractor will supply all the plumbing material (including
fittings, ball valves, etc.), needed to connect the minipool
to the Spa-pack and to the overflow tank, and must install
suitably proportioned gullies, inspectable and accessible for
cleaning purposes, into which the line X will be connected.
In particularly cold climates, where there is a risk of
residual water freezing in pipelines, it is advisable to
install drain valves at strategic points on the various
circuits, so that the system can be emptied completely.
IMPORTANT: before making any permanent connection to
the main drain, contact the local authorities to check on
regulations governing the disposal of chemically treated
water.
FILLING: the recommended method of filling the Teuco is to
use an ordinary hose, taking care not to immerse the end as
this could allow reflux of water back into the main (3).
IMPORTANT: Once installation is complete, if Teuco Spa-
Pack was not used, please make sure that the maximum
suction power of the intake openings is in line with
the limits set by the standard IEC 60335-2-60: "Safety -
Particular requirements for whirlpool baths and whirlpool
spas".
IMPORTANT: if the intention is to connect the minipool
permanently to the water supply, suitable non-return
devices must be incorporated to prevent reflux back to
the water main.
Contact the local authorities before proceeding with this
type of installation.
Ø
Z80 mm
X2"/63mm
I2"/63mm
A2"/63mm
W2"/63mm
PREDISPOSITION OF CONNECTIONS
Z- Drain channel
X- Recirculation and drain input
I- Hidro suction
A- Air Entry (To Injectors)
W- Water Entry (In To Jet Ring)
