LM5156EVM-BST User's Guide
User's Guide
SNVU696A–February 2020–Revised June 2020
LM5156EVM-BST User's Guide
The LM5156EVM-BST evaluation module showcases the features and performance of the LM5156
device, wide input voltage, non-synchronous boost controller. The standard configuration is designed to
provide a regulate output of 12 V at 36 W from a minimum input of 4 V, switching at a frequency of 440
kHz, withstanding voltage transients from 3 V to 42 V. The module is designed for ease of configuration,
enabling a user to evaluate different applications on the same module. Functionality includes dual random
spread spectrum (DRSS), external clock synchronization, programmable slope compensation, adjustable
soft-start, programmable cycle-by-cycle current limit, and output over voltage protection.
Contents
1 Features and Electrical Performance ..................................................................................... 3
2 Application Schematic....................................................................................................... 5
3 EVM Photo.................................................................................................................... 5
4 Test Setup and Procedure.................................................................................................. 6
5 Test Results .................................................................................................................. 6
6 Design Files................................................................................................................. 12
List of Figures
1 Application Circuit............................................................................................................ 5
2 EVM Photo ................................................................................................................... 5
3 Test Setup.................................................................................................................... 6
4 Efficiency vs Load ........................................................................................................... 7
5 Load Regulation ............................................................................................................. 7
6 Thermal Image VIN = 4 V IOUT = 3 A, No forced air cooling............................................................. 8
7 Steady State, VIN = 4 V, IOUT = 3 A......................................................................................... 9
8 Steady State, VIN = 6 V, IOUT = 3 A......................................................................................... 9
9 Steady State, VIN = 9 V, IOUT = 3 A......................................................................................... 9
10 Steady State, VIN = 10 V, IOUT = 3 A ....................................................................................... 9
11 Start-Up, VIN = 4V, IOUT = 3 A.............................................................................................. 10
12 Start-Up, VIN = 6V, IOUT = 3 A.............................................................................................. 10
13 Start-Up, VIN = 9 V, IOUT = 3 A............................................................................................. 10
14 Start-Up, VIN = 10 V, IOUT = 3 A ........................................................................................... 10
15 Load Transient, VIN = 4 V, IOUT = 1.5 A to 3 A .......................................................................... 11
16 Load Transient, VIN = 6 V, IOUT = 1.5 A to 3 A .......................................................................... 11
17 Load Transient, VIN = 9 V, IOUT = 1.5 A to 3 A .......................................................................... 11
18 Load Transient, VIN = 10 V, IOUT = 1.5 A to 3 A......................................................................... 11
19 Control Loop Response, VIN = 4 V, IOUT = 3 A .......................................................................... 11
20 Control Loop Response, VIN = 9 V, IOUT = 3 A .......................................................................... 11
21 Top Silkscreen.............................................................................................................. 12
22 Top Layer ................................................................................................................... 12
23 Signal Layer 1 .............................................................................................................. 12
24 Signal Layer 2 .............................................................................................................. 12
25 Bottom Layer................................................................................................................ 12
26 Bottom Silkscreen.......................................................................................................... 12

www.ti.com
2SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
27 LM5156EVM-BST Schematic............................................................................................. 13
List of Tables
1 Electrical Performance Standard Configuration ......................................................................... 3
2 Jumper Description.......................................................................................................... 4
3 Standard Configuration Jumper Connections............................................................................ 6
4 LM5156EVM-BST Bill of Materials ...................................................................................... 14
5 LM5156EVM-BST Alternate Bill of Materials, fSW = 2.2 MHz ........................................................ 15
Trademarks
All trademarks are the property of their respective owners.

www.ti.com Features and Electrical Performance
3
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
1 Features and Electrical Performance
The LM5156EVM-BST supports the following features and performance capabilities:
• Tightly regulated output voltage of 12 V with 1% accurate reference voltage
• High conversion efficiency of > 95% at full load.
• Constant cycle-by-cycle peak inductor current limit over input voltage range
• User adjustable soft-start time using CSS
• Output over-voltage protection
• Multiple BIAS pin and VCC pin connections to test multiple configurations
– BIAS connect to VCC
– BIAS supplied with external power supply
– VCC supplied by external power supply
– BIAS supplied by output voltage
• Power good (PGOOD) indicator with selectable pull-up source
• 440kHz Switching frequency
• External clock synchronization
• Programable slope compensation
1.1 Electrical Parameters
Table 1. Electrical Performance Standard Configuration
Parameter Test Conditions MIN TYP MAX UNIT
INPUT CHARACTERISTICS
Input voltage Range VIN Static, full load operation 4 9 12 V
Transient: (50% load) 3
Input voltage turn on VIN(ON) Initial turn-on 5 V
Input voltage turn off VIN(OFF) Adjusted by the UVLO/SYNC resistors 2.5 V
OUTPUT CHARACTERISTICS
Output Voltage VOUT 12 V
Maximum Output Current IOUT 3 A
Output Over-voltage VOUT_OV 13.22 V
SYSTEM CHARACTERISTICS
Switching frequency 440 kHz
External Clock Synchronization 375 505 kHz
Full load efficiency VIN = 4 V, IOUT = 3 A 95.6 %
Junction Temperature, TJ-40 150 C

Features and Electrical Performance www.ti.com
4SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
1.2 Configuration Points
Table 2 indicates the available test points and configuration jumpers. These points offer flexibility in
configuring the evaluation module and include but are not limited to;
• BIAS pin to be connected to:
– External supply (VAUX)
– Input voltage (VIN)
– Regulated output voltage (VOUT)
– VCC pin
• PGOOD pin to be supplied by either VCC or VAUX
• External clock synchronization
• Shut-down signal by pulling the UVLO pin low.
Table 2. Jumper Description
Jumper Pin Description
TP1 VIN Positive input voltage sense connection
TP2 SW Probe point for the switch node of the LM5156 boost circuit
TP3 VOUT Positive output voltage sense connection
TP4 VIN- Negative input voltage sense connection
TP5 GND Negative output voltage sense connection
TP6 VCCext Supply VCC from and external supply. Note VCCext must be less than the voltage on the
BIAS pin.
TP7 VAUX Supply the BIAS pin from and external supply. R12 also connect to this rail
TP8 VOUT+ Loop response positive injection point
TP9 VOUT- Loop response negative injection point
TP10 SYNC Input for external clock synchronization
TP11 SD High signal pulls UVLO pin to ground entering shutdown mode
J6 Pin 1 to pin 2 Connect VOUT to the BIAS pin of the LM5156 through D3
Pin 2 to pin 3 Directly connect VOUT to BIAS pin of the LM5156
J7 Pin 1 to pin 2 Connect VIN to the BIAS pin of the LM5156 through D4
Pin 2 to pin 3 Directly connect VIN to BIAS pin of the LM5156
J8 Pin 1 to pin 2 Directly Connect VCC to the BIAS pin
J9 Pin 1 to pin 2 Directly connect VAUX to the BIAS pin
J10 Pin 1 to Pin 2 Disable spread spectrum
Pin 2 to Pin 3 Enable spread spectrum
J11
VCC (Pin 1) Monitor the VCC pin
BIAS-IC (Pin 2) Monitor the BIAS pin
PGOOD (Pin 3) Monitor the PGOOD pin
COMP (Pin 4) Monitor the COMP pin
SS (Pin 5) Monitor the SS pin
UVLO (Pin 6) Monitor the UVLO pin
AGND (Pin 7) Connection to AGND plan

BIAS VCC GATE
CS
GND
FB
COMP
SS
RT
PGOOD
DITHOFF
UVLO/SYNC
VOUT
VIN
www.ti.com Application Schematic
5
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
2 Application Schematic
The LM5156EVM-BST is capable of multiple configurations. Figure 1 shows the standard configuration of
the LM5156EVM-BST for which the parameters in Table 1 are valid. Section 4.2 describes the correct
jumper settings and measurement locations recreate the data presented in Section 5.
Figure 1. Application Circuit
3 EVM Photo
Figure 2. EVM Photo

Test Setup and Procedure www.ti.com
6SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
4 Test Setup and Procedure
4.1 Test Setup
Figure 3 shows the correct jumper positions to configure the evaluation module for the typical application,
as shown in Figure 1. The correct equipment connections and measurement points are shown in Table 3
Table 3. Standard Configuration Jumper Connections
Jumper Position
J6 Jumper from pin 2 to pin 3
Figure 3. Test Setup
4.2 Test Equipment
Power Supply: The input voltage source (VIN) should be a variable supply capable of 0V to 20V and
source at least 15A.
Multi-meters:
• Voltmeter 1: Input voltage, connect from VIN to VIN-
• Voltmeter 2: Output voltage, connect from VOUT to GND
• Ammeter 1: Input current, must be able to handle 15A. Shunt resistor can be used as needed.
• Ammeter 2: Output current, must be able to handle 3A. Shunt resistor can be used as needed.
Electronic Load: The load should be constant resistance (CR) or constant current (CC) capable. It should
safely handle 3A at 12V.
Oscilloscope: 20-MHz bandwidth and AC coupling. Measure the output voltage ripple directly across an
output capacitor with a short ground lead. It is not recommended to use a long-leaded ground connection
due to the possibility of noise being coupled into the signal. To measure other waveforms, adjust the
oscilloscope as needed.
5 Test Results
Figure 4 through Figure 19 present the typical performance of the LM5156EVM-BST according to the
BOM and the configuration described in Section 4. Based on measurement techniques and environmental
variables measurements might differ slightly than the data presented.

IOUT (A)
VOUT (V)
0 0.5 1 1.5 2 2.5 3
11.8
11.9
12
12.1
12.2
VIN = 10V
VIN = 9V
VIN = 6V
VIN = 4V
IOUT (A)
Efficiency (%)
Efficiency
0 0.5 1 1.5 2 2.5 3
50
55
60
65
70
75
80
85
90
95
100
LM51
VIN = 10V
VIN = 9V
VIN = 6V
VIN = 4V
www.ti.com Test Results
7
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
5.1 Efficiency Curves
Figure 4. Efficiency vs Load
5.2 Load Regulation Curves
Figure 5. Load Regulation

Test Results www.ti.com
8SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
5.3 Thermal Performance
Figure 6. Thermal Image VIN = 4 V IOUT = 3 A, No forced air cooling

www.ti.com Test Results
9
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
5.4 Steady State Waveforms
Figure 7. Steady State, VIN = 4 V, IOUT = 3 A Figure 8. Steady State, VIN = 6 V, IOUT = 3 A
Figure 9. Steady State, VIN = 9 V, IOUT = 3 A Figure 10. Steady State, VIN = 10 V, IOUT = 3 A

Test Results www.ti.com
10 SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
5.5 Start-Up Waveforms
Figure 11. Start-Up, VIN = 4V, IOUT = 3 A Figure 12. Start-Up, VIN = 6V, IOUT = 3 A
Figure 13. Start-Up, VIN = 9 V, IOUT = 3 A Figure 14. Start-Up, VIN = 10 V, IOUT = 3 A

Frequency (Hz)
Gain (dB)
Phase (deg)
Loop Response
100 200 300 500 700 1000 2000 3000 5000 700010000 20000 30000 50000 100000 200000 400000400000
-60 -150
-40 -100
-20 -50
0 0
20 50
40 100
LM51
Gain
Phase
Frequency (Hz)
Gain (dB)
Phase (deg)
Loop Response
100 200 300 500 700 1000 2000 3000 5000 700010000 20000 30000 50000 100000 200000 400000400000
-60 -150
-40 -100
-20 -50
0 0
20 50
40 100
LM51
Gain
Phase
www.ti.com Test Results
11
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
5.6 Load Transient Waveforms
Figure 15. Load Transient, VIN = 4 V, IOUT = 1.5 A to 3 A Figure 16. Load Transient, VIN = 6 V, IOUT = 1.5 A to 3 A
Figure 17. Load Transient, VIN = 9 V, IOUT = 1.5 A to 3 A Figure 18. Load Transient, VIN = 10 V, IOUT = 1.5 A to 3 A
5.7 AC Loop Response Curves
Figure 19. Control Loop Response, VIN = 4 V, IOUT = 3 A Figure 20. Control Loop Response, VIN = 9 V, IOUT = 3 A

Design Files www.ti.com
12 SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
6 Design Files
Figure 21. Top Silkscreen Figure 22. Top Layer
Figure 23. Signal Layer 1 Figure 24. Signal Layer 2
Figure 25. Bottom Layer Figure 26. Bottom Silkscreen

www.ti.com Design Files
13
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
Figure 27. LM5156EVM-BST Schematic

Design Files www.ti.com
14 SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
Table 4. LM5156EVM-BST Bill of Materials
Designator Qty Value Description Package
Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board BMC061 Any
C2 1 100uF CAP, Polymer Hybrid, 100 uF, 50 V,
+/- 20%, 28 ohm, 10x10 SMD 10x10 EEHZC1H101P Panasonic
C3 1 1000pF CAP, CERM, 1000 pF, 50 V, +/-
10%, X7R, 0603 0603 C0603X102K5RAC TU Kemet
C4, C17, C18,
C19 4 0.1uF CAP, CERM, 0.1 µF, 50 V,+/- 10%, X7R, AEC-Q200 Grade 1, 0603 0603 C0603C104K5RA CAUTO Kemet
C5 1 0.01uF CAP, CERM, 0.01 uF, 50 V, +/- 10%,
X7R, 0603 0603 CL10B103KB8NC NC Samsung Electro- Mechanics
C6, C7, C8, C9,
C10 5 10uF CAP, CERM, 10 uF, 50 V, +/- 10%, X7R, 1210 1210 GRM32ER71H106 KA12L MuRata
C11, C12 2 100uF CAP, Aluminum Polymer, 100 uF, 50
V, +/- 20%, 0.025 ohm, AEC-Q200
Grade 2, D10xL10mm SMD
D10xL10mm HHXB500ARA101
MJA0G Chemi-Con
C14, C15, C16 3 4.7uF CAP, CERM, 4.7 µF, 50 V,+/- 10%,
X7R, AEC-Q200 Grade 1, 1210 1210 C1210C475K5RA CAUTO Kemet
C20, C23 2 100pF CAP, CERM, 100 pF, 50 V,+/- 1%,
C0G/NP0, 0603 0603 C0603C101F5GA CTU Kemet
C21 1 1uF CAP, CERM, 1 µF, 16 V,+/- 10%,
X7R, AEC-Q200 Grade 1, 0603 0603 CGA3E1X7R1C10 5K080AC TDK
C22 1 0.1uF CAP, CERM, 0.1 uF, 100 V,+/- 10%,
X7R, AEC-Q200 Grade 1, 0603 0603 GCJ188R72A104K A01D MuRata
C24 1 0.22uF CAP, CERM, 0.22 uF, 50 V, +/- 10%,
X7R, AEC-Q200 Grade 1, 0603 0603 CGA3E3X7R1H22 4K080AB TDK
C25 1 0.068uF CAP, CERM, 0.068 uF, 50 V, +/-
10%, X7R, AEC-Q200 Grade 1, 0603 0603 CGA3E2X7R1H68 3K080AA TDK
C26 1 1000pF CAP, CERM, 1000 pF, 50 V, +/- 5%,
X7R, AEC-Q200 Grade 1, 0603 0603 C0603C102J5RAC AUTO Kemet
D1 1 60V Diode, Schottky, 60 V, 10 A, AEC-
Q101, CFP15 CFP15 PMEG060V100EP DZ Nexperia
D2, D3, D4 3 60V Diode, Schottky, 60 V, 1 A, SOD-
123F SOD-123F PMEG6010CEH,1 15 Nexperia
D6 1 20V Diode, Schottky, 20 V, 0.35 A, SOD-
123 SOD-123 SD103CW-13-F Diodes Inc.
H1, H2, H3, H4 4 Machine Screw, Round, #4-40 x 1/4,
Nylon, Philips panhead Screw NY PMS 440 0025 PH B&F Fastener Supply
H5, H6, H7, H8 4 Standoff, Hex, 0.5"L #4-40 Nylon Standoff 1902C Keystone
J1, J2, J4, J5 4 Standard Banana Jack, Uninsulated,
8.9mm Keystone575-8 575-8 Keystone
J3 1 TEST POINT SLOTTED .118", TH Test point, TH
Slot Test point 1040 Keystone
J6, J7, J10 3 Header, 100mil, 3x1, Gold, TH 3x1 Header TSW-103-07-G-S Samtec
J8, J9 2 Header, 100mil, 2x1, Gold, TH 2x1 Header TSW-102-07-G-S Samtec
J11 1 Header, 100mil, 7x1, Gold, TH 7x1 Header TSW-107-07-G-S Samtec
L2 1 2.2uH Inductor, Shielded, Composite, 2.2
uH, 20 A, 0.0045 ohm, AEC-Q200
Grade 1, SMD
Inductor,
10x6x11.3mm XAL1060-222MEB Coilcraft
Q1 1 60V MOSFET, N-CH, 60 V, 17 A, AEC-
Q101, SO-8FL SO-8FL NVMFS5C670NL WFAFT1G ON Semiconductor
Q2, Q3 2 100V MOSFET, N-CH, 100 V, 0.17 A,
SOT-23 SOT-23 BSS123 Fairchild Semiconductor
R6 1 100 RES, 100, 1%, 0.1 W, 0603 0603 RC0603FR-
07100RL Yageo
R7 1 0.004 RES, 0.004, 1%, 3 W, 2512 WIDE 2512 WIDE KRL6432E-M-
R004-F-T1 Susumu Co Ltd

www.ti.com Design Files
15
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
Table 4. LM5156EVM-BST Bill of Materials (continued)
R9 1 60.4k RES, 60.4 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW060360K4F KEA Vishay-Dale
R11 1 100k RES, 100 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW0603100KF KEA Vishay-Dale
R12 1 10.0 RES, 10.0, 1%, 0.1 W, 0603 0603 RC0603FR-
0710RL Yageo
R14, R16 2 49.9k RES, 49.9 k, 1%, 0.1 W, 0603 0603 RC0603FR-
0749K9L Yageo
R15 1 80.6k RES, 80.6 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW060380K6F KEA Vishay-Dale
R17 1 4.53k RES, 4.53 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW06034K53F KEA Vishay-Dale
R19 1 2.49k RES, 2.49 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW06032K49F KEA Vishay-Dale
R20, R21 2 10.0k RES, 10.0 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW060310K0F KEA Vishay-Dale
SH-J1, SH-J2 2 Single Operation 2.54mm Pitch Open
Top Jumper Socket Single Operation
2.54mm Pitch
Open Top
Jumper Socket
M7582-05 Harwin
TP1, TP3, TP6,
TP7 4 Test Point, Miniature, Red, TH Red Miniature Testpoint 5000 Keystone
TP4, TP5 2 Test Point, Miniature, Black, TH Black Miniature
Testpoint 5001 Keystone
TP10, TP11 2 Test Point, Miniature, White, TH White
Miniature
Testpoint
5002 Keystone
U1 1 2.2-MHz Wide VIN 65-V Non-
synchronous Boost/SEPIC/Flyback
Controller with Dual Random Spread
Spectrum, DSS0012B (WSON-12)
DSS0012B LM5156DSSR Texas
Instruments
Table 5. LM5156EVM-BST Alternate Bill of Materials, fSW = 2.2 MHz
Designator Qty Value Description Package
Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board BMC061 Any
C2 1 100uF CAP, Polymer Hybrid, 100 uF, 50 V,
+/- 20%, 28 ohm, 10x10 SMD 10x10 EEHZC1H101P Panasonic
C3 1 1000pF CAP, CERM, 1000 pF, 50 V, +/-
10%, X7R, 0603 0603 C0603X102K5RAC TU Kemet
C4, C17, C18,
C19 4 0.1uF CAP, CERM, 0.1 µF, 50 V,+/- 10%, X7R, AEC-Q200 Grade 1, 0603 0603 C0603C104K5RA CAUTO Kemet
C5 1 0.01uF CAP, CERM, 0.01 uF, 50 V, +/- 10%,
X7R, 0603 0603 CL10B103KB8NC NC Samsung Electro- Mechanics
C6, C7, C8, C9,
C10 5 10uF CAP, CERM, 10 uF, 50 V, +/- 10%, X7R, 1210 1210 GRM32ER71H106 KA12L MuRata
C11 1 100uF CAP, Aluminum Polymer, 100 uF, 50
V, +/- 20%, 0.025 ohm, AEC-Q200
Grade 2, D10xL10mm SMD
D10xL10mm HHXB500ARA101
MJA0G Chemi-Con
C14, C15, C16 3 4.7uF CAP, CERM, 4.7 µF, 50 V,+/- 10%,
X7R, AEC-Q200 Grade 1, 1210 1210 C1210C475K5RA CAUTO Kemet
C20, C23 2 100pF CAP, CERM, 100 pF, 50 V,+/- 1%,
C0G/NP0, 0603 0603 C0603C101F5GA CTU Kemet
C21 1 1uF CAP, CERM, 1 µF, 16 V,+/- 10%,
X7R, AEC-Q200 Grade 1, 0603 0603 CGA3E1X7R1C10 5K080AC TDK

Design Files www.ti.com
16 SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
Table 5. LM5156EVM-BST Alternate Bill of Materials, fSW = 2.2 MHz (continued)
C22 1 0.1uF CAP, CERM, 0.1 uF, 100 V,+/- 10%,
X7R, AEC-Q200 Grade 1, 0603 0603 GCJ188R72A104K A01D MuRata
C24 1 0.22uF CAP, CERM, 0.22 uF, 50 V, +/- 10%,
X7R, AEC-Q200 Grade 1, 0603 0603 CGA3E3X7R1H22 4K080AB TDK
C25 1 6800pF CAP, CERM, 6800 pF, 25 V, +/-
10%, X7R, 0603 0603 GRM188R71E682 KA01D MuRata
C26 1 1000pF CAP, CERM, 1000 pF, 50 V, +/- 5%,
X7R, AEC-Q200 Grade 1, 0603 0603 C0603C102J5RAC AUTO Kemet
D1 1 60V Diode, Schottky, 60 V, 10 A, AEC-
Q101, CFP15 CFP15 PMEG060V100EP DZ Nexperia
D2, D3, D4 3 60V Diode, Schottky, 60 V, 1 A, SOD-
123F SOD-123F PMEG6010CEH,1 15 Nexperia
D6 1 20V Diode, Schottky, 20 V, 0.35 A, SOD-
123 SOD-123 SD103CW-13-F Diodes Inc.
H1, H2, H3, H4 4 Machine Screw, Round, #4-40 x 1/4,
Nylon, Philips panhead Screw NY PMS 440 0025 PH B&F Fastener Supply
H5, H6, H7, H8 4 Standoff, Hex, 0.5"L #4-40 Nylon Standoff 1902C Keystone
J1, J2, J4, J5 4 Standard Banana Jack, Uninsulated,
8.9mm Keystone575-8 575-8 Keystone
J3 1 TEST POINT SLOTTED .118", TH Test point, TH
Slot Test point 1040 Keystone
J6, J7, J10 3 Header, 100mil, 3x1, Gold, TH 3x1 Header TSW-103-07-G-S Samtec
J8, J9 2 Header, 100mil, 2x1, Gold, TH 2x1 Header TSW-102-07-G-S Samtec
J11 1 Header, 100mil, 7x1, Gold, TH 7x1 Header TSW-107-07-G-S Samtec
L2 1 680nH Inductor, Shielded, 680 nH, 8.2A,
0.009 Ohm, AEC-Q200 Grade 1,
SMD
Inductor,
4.1x41.1x2.1m
m
744383560068 Wurth
Q1 1 60V MOSFET, N-CH, 60 V, 17 A, AEC-
Q101, SO-8FL SO-8FL NVMFS5C670NL WFAFT1G ON Semiconductor
Q2, Q3 2 100V MOSFET, N-CH, 100 V, 0.17 A,
SOT-23 SOT-23 BSS123 Fairchild Semiconductor
R6 1 100 RES, 100, 1%, 0.1 W, 0603 0603 RC0603FR-
07100RL Yageo
R7 1 0.004 RES, 0.004, 1%, 3 W, 2512 WIDE 2512 WIDE KRL6432E-M-
R004-F-T1 Susumu Co Ltd
R9 1 243k RES, 243 k, 1%, 0.1 W, 0603 0603 RC0603FR-
07243KL Yageo
R11 1 100k RES, 100 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW0603100KF KEA Vishay-Dale
R12 1 10.0 RES, 10.0, 1%, 0.1 W, 0603 0603 RC0603FR-
0710RL Yageo
R14 1 105k RES, 105 k, 1%, 0.1 W, 0603 0603 RC0603FR-
07105KL Yageo
R16 1 9.09k RES, 9.09 k, 1%, 0.1 W, 0603 0603 RC0603FR-
079K09L Yageo
R15 1 80.6k RES, 80.6 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW060380K6F KEA Vishay-Dale
R17 1 4.53k RES, 4.53 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW06034K53F KEA Vishay-Dale
R19 1 15k RES, 15 k, 5%, 0.1 W, 0603 0603 RC0603JR-
0715KL Yageo
R20, R21 2 10.0k RES, 10.0 k, 1%, 0.1 W, AEC-Q200
Grade 0, 0603 0603 CRCW060310K0F KEA Vishay-Dale

www.ti.com Design Files
17
SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
LM5156EVM-BST User's Guide
Table 5. LM5156EVM-BST Alternate Bill of Materials, fSW = 2.2 MHz (continued)
SH-J1, SH-J2 2 Single Operation 2.54mm Pitch Open
Top Jumper Socket Single Operation
2.54mm Pitch
Open Top
Jumper Socket
M7582-05 Harwin
TP1, TP3, TP6,
TP7 4 Test Point, Miniature, Red, TH Red Miniature Testpoint 5000 Keystone
TP4, TP5 2 Test Point, Miniature, Black, TH Black Miniature
Testpoint 5001 Keystone
TP10, TP11 2 Test Point, Miniature, White, TH White
Miniature
Testpoint
5002 Keystone
U1 1 2.2-MHz Wide VIN 65-V Non-
synchronous Boost/SEPIC/Flyback
Controller with Dual Random Spread
Spectrum, DSS0012B (WSON-12)
DSS0012B LM5156DSSR Texas
Instruments

Revision History www.ti.com
18 SNVU696A–February 2020–Revised June 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Revision History
Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Original (February 2020) to A Revision .................................................................................................. Page
• Added LM5156EVM-BST Alternate Bill of Materials, fSW = 2.2 MHz table........................................................ 15

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
