Getting Started
The EVM ships with a Power On Self Test
(POST) flashed into I2C EEPROM. The POST
automatically executes when the board is
powered ON. POST performs memory test
and internal EMAC loopback test. At
power ON, the user LEDs are OFF by
default. The LEDs blink and turn OFF to
indicate successful DSP booting.
After booting, User LED-1 turns ON to
indicate successful RAM test and User
LED-2 turns ON to indicate successful
internal EMAC loop-back test. These LEDs
remain ON to indicate success of both
the tests.
Please refer to the EVM User Guide for
software installation and other details.
Important Notes when handling the
EVM
•Plug in all the cables before powering
ON the EVM to ensure proper grounding.
•Do not unnecessarily flex the boards,
while inserting cables. Excessive flexing
can break the PCB traces.
•Use proper ESD procedures when
handling the EVM.
•Warning: Some components on the EVM
may be too hot to touch with your bare
hand when power is on.
Online Documentation
•TMS320C6670 processor website
http://focus.ti.com/docs/prod/folders/pr
int/tms320c6670.html
•MCSDK website for updates
http://focus.ti.com/docs/toolsw/folders/
print/bioslinuxmcsdk.html
•CCS v5
http://processors.wiki.ti.com/index.php/
Category:Code_Composer _Stu dio_v5
This link contains
•Hardware & Software details
•User Guide
•Technical Reference Manual
•TMS320C6670 Datasheet
TI Worldwide Technical Support
Internet
TI Semiconductor Product Information Center Home Page
support.ti.com
TI Semiconductor KnowledgeBase Home page
support.ti.com/sc/knowledgebase
Product Information Centers
Americas
Phone [phone] Fax [phone]
Internet/Email support.ti.com/sc/pic/americas.htm
Europe, Middle East and Africa
Phone
European Free Call 00800-ASK-TEXAS
(00800 275 83927)
International [phone]
Russian Support [phone]
Note: The European Free Call (Toll Free) number is not active in
all countries. If you have technical difficulty calling the free call
number, please use the international number above.
Fax +(49) (0) 8161 80 2045
Internet support.ti.com/sc/pic/euro.htm
Japan
Fax
International [phone]
Domestic 0120-81-0036
Internet/Email
International support.ti.com/sc/pic/japan.htm
Domestic www.tij.co.jp/pic
Asia
Phone
International [phone]-
Domestic Toll-Free-Number
Australia 800-999-084
China 800-820-8682
Hong Kong 800-96-5941
India 1-800-425-7888
Indonesia 001-803-8861-1006
Korea 080-551-2804
Fax [phone]
Email [email protected]
[email protected]
Internet support.ti.com/sc/pic/asia.htm
Important Notice: The products and services of Texas
Instruments Incorporated and its subsidiaries described herein
are sold subject to TI's standard terms and conditions of sale.
Customers are advised to obtain the most current and complete
information about TI products and services before placing
orders. TI assumes no liability for applications assistance,
customer's applications or product designs, software
performance, or infringement of patents. The publication of
information regarding any other company's products or services
does not constitute TI's approval, warranty or endorsement
thereof.
The floating bar is a trademark of Texas Instruments.
All other trademarks are the property of their respective owners
©2011 Texas Instruments Incorporated
Toll-Free-Number
Malaysia 1-800-80-3973
New Zealand 0800-446-934
Philippines 1-800-765-7404
Singapore 800-886-1028
Taiwan 0800-006800
Thailand 001-800-886-0010

The TMDXEVM6670L (Evaluation Module) kit includes
• TMX320C6670 Evaluation Module
• Power adapter and power cord
• USB cable for on-board JTAG emulation (XDS100v1)
• Ethernet cable
• RS-232 serial cable
• Software (DVD) and documentation
Ensure EVM configuration switch
(SW3) are set as shown to run
Power On Self Test (POST)
1Connect the USB mini-B cable
to USB1 plug for on board
embedded emulation and
serial console port, as shown in
figure. (For use with CCS
debugger only)
2
Connect Ethernet switch /
Router / PC to the Giga Ethernet
port (LAN1) of EVM6678 board
using an Ethernet cable to
access EMAC0
3Connect the 12V DC power
adapter (supplied with the kit)
to power jack (DC_IN1)
4Load the DVD on your
computer and follow the
instructions provided in the
“Read_Me_First.txt” file
5
TMDXEVM6670L
TMX320C6670 Evaluation Module
DC 12V
DDR3 SDRAM
512 MB
60-pin header for
external emulator
On-Board RS-232
Serial Port
Warm Reset
AMC
Type B+
TMS320C6670
(4 core DSP)
NAND Flash
64 MB
Gigabit
Ethernet
Miscellaneous
I/O 80pin
connector
Full Reset
USB mini-B for XDS100
embedded emulator
Boot Mode /
Configuration
Setting
4 1 2
3
