Texas Instruments DAC63202W User manual

DAC63202W 12-Bit, Dual, Voltage and Current Output Smart DACs
WithAuto‑Detected I2C, SPI, or PMBus™ Interface in DSBGA
1 Features
• Programmable voltage or current outputs with
flexible configuration:
– Voltage outputs:
• 1 LSB DNL
• Gains of 1 ×, 1.5 ×, 2 ×, 3 ×, and 4 ×
– Current outputs:
• 1 LSB INL and DNL (8-bit)
• ±25 μA, ±50 μA, ±125 μA, ±250 μA output-
range options
• Programmable comparator mode for all channels
• High-impedance output when VDD is off
• High-impedance and resistive pulldown power-
down modes
• 50-MHz SPI-compatible interface
• Automatically detects I2C, SPI, or PMBus™
interface
– 1.62-V VIH with VDD = 5.5 V
• General-purpose input/output (GPIO) configurable
as multiple functions
• Predefined waveform generation: sine, cosine,
triangular, sawtooth
• User-programmable nonvolatile memory (NVM)
• Internal, external, or power-supply as reference
• Wide operating range:
– Power supply: 1.8 V to 5.5 V
– Temperature: –40˚C to +125˚C
• Tiny package:
– 16-pin DSBGA: 1.72 mm × 1.72 mm, nominal
2 Applications
•Optical module
•High performance computing
•Standard notebook PC
3 Description
The DAC63202W is a 12-bit, dual-channel, buffered,
voltage-output and current-output smart digital-to-
analog converter (DAC). The DAC63202W devices
support Hi-Z power-down mode and Hi-Z output
during power-off conditions. The DAC outputs provide
a force-sense option for use as a programmable
comparator and current sink. The multifunction GPIO,
function generation, and programmable nonvolatile
memory (NVM) enable these smart DACs for
processor-less applications and design reuse. This
device automatically detects I2C, SPI and PMBus
interfaces, and contain an internal reference.
The feature set combined with the tiny package
and low power make this smart DAC an excellent
choice for applications such as voltage margining and
scaling, dc set-point for biasing and calibration, and
waveform generation.
Package Information
PART NUMBER PACKAGE(1) BODY SIZE (NOM)
DAC63202W YBH (DSBGA, 16) 1.72 mm × 1.72 mm
(1) For all available packages, see the orderable addendum at
the end of the data sheet.
SMPS / LDO R1
R2
VFB
SENSE
PH
GND
VOUT
IN
BOOT
CL
CB
L
DAC63202W
VDD
VIN
VOUT/
IOUT
VOUT/
IOUT
DAC
REG
DAC
BUF
DAC
REG
DAC
BUF
NVM
Internal
Reference
LDO
Output Configuration
Logic
VREF CAP
AGND
Digital Interface
SCL/SYNC
SDA/SCLK
A0/SDI
PROTECT
R3
R3
1.5 μ
F
0.1 μ

10 kΩ
Power-supply: 0
Power-supply: 1
Voltage Margining and Scaling Using the DAC63202W
DAC63202W
SLASF73 – APRIL 2023
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.

Table of Contents
1 Features............................................................................1
2 Applications.....................................................................1
3 Description.......................................................................1
4 Revision History.............................................................. 2
5 Pin Configuration and Functions...................................3
6 Specifications.................................................................. 4
6.1 Absolute Maximum Ratings........................................ 4
6.2 ESD Ratings............................................................... 4
6.3 Recommended Operating Conditions.........................4
6.4 Thermal Information....................................................4
6.5 Electrical Characteristics: Voltage Output...................5
6.6 Electrical Characteristics: Current Output...................7
6.7 Electrical Characteristics: Comparator Mode..............8
6.8 Electrical Characteristics: General..............................9
6.9 Timing Requirements: I2C Standard Mode............... 10
6.10 Timing Requirements: I2C Fast Mode.....................10
6.11 Timing Requirements: I2C Fast Mode Plus............. 10
6.12 Timing Requirements: SPI Write Operation............ 11
6.13 Timing Requirements: SPI Read and Daisy
Chain Operation (FSDO = 0).......................................11
6.14 Timing Requirements: SPI Read and Daisy
Chain Operation (FSDO = 1).......................................11
6.15 Timing Requirements: GPIO...................................12
6.16 Timing Diagrams.....................................................12
6.17 Typical Characteristics: Voltage Output.................. 14
6.18 Typical Characteristics: Current Output.................. 19
6.19 Typical Characteristics: Comparator.......................23
6.20 Typical Characteristics: General............................. 24
7 Detailed Description......................................................25
7.1 Overview...................................................................25
7.2 Functional Block Diagram.........................................25
7.3 Feature Description...................................................26
7.4 Device Functional Modes..........................................27
7.5 Programming............................................................ 45
7.6 Register Map.............................................................53
8 Application and Implementation..................................71
8.1 Application Information............................................. 71
8.2 Typical Application.................................................... 71
8.3 Power Supply Recommendations.............................73
8.4 Layout....................................................................... 73
9 Device and Documentation Support............................75
9.1 Documentation Support............................................ 75
9.2 Receiving Notification of Documentation Updates....75
9.3 Support Resources................................................... 75
9.4 Trademarks...............................................................75
9.5 Electrostatic Discharge Caution................................75
9.6 Glossary....................................................................75
10 Mechanical, Packaging, and Orderable
Information.................................................................... 75
4 Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
DATE REVISION NOTES
April 2023 * Initial Release
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
2Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

5 Pin Configuration and Functions
1 2 3 4
A
B
C
D
Not to scale
VREF OUT0 NC GPIO/SDO
VDD FB0 NC SCL/SYNC
AGND FB1 NC A0/SDI
CAP OUT1 NC SDA/SCLK
Figure 5-1. YBH (16-pin DSBGA) Package, Top View
Table 5-1. Pin Functions
PIN TYPE DESCRIPTION
NO. NAME
A1 VREF Power
External reference input. Connect a capacitor (approximately 0.1 μF) between VREF and AGND.
Use a pullup resistor to VDD when the external reference is not used. This pin must not ramp up before VDD. In
case an external reference is used, make sure the reference ramps up after VDD.
A2 OUT0 Output Analog output voltage from DAC channel 0.
A3 NC NC Not connected.
A4 GPIO/SDO Input/Output
General-purpose input/output configurable as LDAC, PD, PROTECT, RESET, SDO, and STATUS. For STATUS and
SDO, connect the pin to the IO voltage with an external pullup resistor. If unused, connect the GPIO pin to VDD or
AGND using an external resistor. This pin can ramp up before VDD.
B1 VDD Power Supply voltage.
B2 FB0 Input Voltage feedback pin for channel 0. In voltage-output mode, connect to OUT0 for closed-loop amplifier output. In
current-output mode, keep this pin unconnected to minimize leakage current.
B3 NC NC Not connected.
B4 SCL/SYNC Output I2C serial interface clock or SPI chip select input. This pin must be connected to the IO voltage using an external
pullup resistor. This pin can ramp up before VDD.
C1 AGND Ground Ground reference point for all circuitry on the device.
C2 FB1 Input Voltage feedback pin for channel 1. In voltage-output mode, connect to OUT1 for closed-loop amplifier output. In
current-output mode, keep this pin unconnected to minimize leakage current.
C3 NC NC Not connected.
C4 A0/SDI Input
Address configuration pin for I2C or serial data input for SPI.
For A0, connect this pin to VDD, AGND, SDA, or SCL for address configuration (Section 7.5.2.2.1).
For SDI, this pin need not be pulled up or pulled down. This pin can ramp up before VDD.
D1 CAP Power External bypass capacitor for the internal LDO. Connect a capacitor (approximately 1.5 μF) between CAP and
AGND.
D2 OUT1 Output Analog output voltage from DAC channel 01
D3 NC NC Not connected.
D4 SDA/SCLK Input/Output Bidirectional I2C serial data bus or SPI clock input. This pin must be connected to the IO voltage using an external
pullup resistor in the I2C mode. This pin can ramp up before VDD.
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 3
Product Folder Links: DAC63202W

6 Specifications
6.1 Absolute Maximum Ratings
over operating free-air temperature range (unless otherwise noted)(1)
MIN MAX UNIT
VDD Supply voltage, VDD to AGND –0.3 6 V
Digital inputs to AGND –0.3 VDD + 0.3 V
VFBX to AGND –0.3 VDD + 0.3 V
VOUTX to AGND –0.3 VDD + 0.3 V
VREF External reference, VREF to AGND –0.3 VDD + 0.3 V
Current into any pin except the OUTx, VDD, and AGND pins –10 10 mA
TJJunction temperature –40 150 °C
Tstg Storage temperature –65 150 °C
(1) Operation outside the Absolute Maximum Ratings may cause permanent device damage. Absolute Maximum Ratings do not imply
functional operation of the device at these or any other conditions beyond those listed under Recommended Operating Conditions.
If used outside the Recommended Operating Conditions but within the Absolute Maximum Ratings, the device may not be fully
functional, and this may affect device reliability, functionality, performance, and shorten the device lifetime.
6.2 ESD Ratings
VALUE UNIT
V(ESD) Electrostatic
discharge
Human body model (HBM), per ANSI/ESDA/JEDEC JS-001, all pins(1) ±2000 V
Charged device model (CDM), per ANSI/ESDA/JEDEC JS-002, all pins((2)) ±500
(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.
6.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted)
MIN NOM MAX UNIT
VDD Positive supply voltage to ground (AGND) 1.7 5.5 V
VREF External reference to ground (AGND) 1.7 VDD V
VIH Digital input high voltage, 1.7 V < VDD ≤ 5.5 V 1.62 V
VIL Digital input low voltage 0.4 V
CCAP External capacitor on CAP pin 0.5 15 μF
TAAmbient temperature –40 125 °C
6.4 Thermal Information
THERMAL METRIC(1)
DAC63202W
UNITYBH (DSBGA)
16 PINS
RθJA Junction-to-ambient thermal resistance 80.2 °C/W
RθJC(top) Junction-to-case (top) thermal resistance 0.4 °C/W
RθJB Junction-to-board thermal resistance 18.8 °C/W
ΨJT Junction-to-top characterization parameter 0.2 °C/W
ΨJB Junction-to-board characterization parameter 18.8 °C/W
(1) For information about traditional and new thermal metrics, see the Semiconductor and IC Package Thermal Metrics application report.
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
4Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

6.5 Electrical Characteristics: Voltage Output
all minimum/maximum specifications at –40°C ≤ TA ≤ +125°C and typical specifications at TA = 25°C, 1.7 V ≤ VDD ≤ 5.5 V,
DAC reference tied to VDD, gain = 1 ×, DAC output pin (OUT) loaded with resistive load (RL = 5 kΩ to AGND) and capacitive
load (CL = 200 pF to AGND), and digital inputs at VDD or AGND (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
STATIC PERFORMANCE
Resolution 12 Bits
INL Integral nonlinearity((1)) –5 5 LSB
DNL Differential nonlinearity(1) –1 1 LSB
Zero-code error(4)
Code 0d into DAC, external reference, VDD = 5.5 V 6 12
mV
Code 0d into DAC, internal VREF, gain = 4 ×,
VDD = 5.5 V 6 15
Zero-code error temperature
coefficient(4) ±10 µV/°C
Offset error(4) (6)
1.7 V ≤ VDD < 2.7 V, VFB pin shorted to VOUT, DAC
code: 32d –0.75 0.3 0.75
%FSR
2.7 V ≤ VDD ≤ 5.5 V, VFB pin shorted to VOUT,
DAC code: 32d –0.5 0.25 0.5
Offset-error temperature
coefficient(4) VFB pin shorted to VOUT, DAC code: 32d ±0.0003 %FSR/°C
Gain error(4) Between end-point codes: 32d to 4064d –0.5 0.25 0.5 %FSR
Gain-error temperature
coefficient(4) Between end-point codes: 32d to 4064d ±0.0008 %FSR/°C
Full-scale error(4) (6) 1.7 V ≤ VDD < 2.7 V, DAC at full-scale –1 1 %FSR
2.7 V ≤ VDD ≤ 5.5 V, DAC at full-scale –0.5 0.5
Full-scale-error temperature
coefficient(4) DAC at full-scale ±0.0008 %FSR/°C
OUTPUT
Output voltage Reference tied to VDD 0 VDD V
CLCapacitive load(2) RL = infinite, phase margin = 30° 200 pF
Phase margin = 30° 1000
Short-circuit current
VDD = 1.7 V, full-scale output shorted to AGND or
zero-scale output shorted to VDD 15
mA
VDD = 2.7 V, full-scale output shorted to AGND or
zero-scale output shorted to VDD 50
VDD = 5.5 V, full-scale output shorted to AGND or
zero-scale output shorted to VDD 60
Output-voltage headroom(2)
To VDD (DAC output unloaded, internal reference =
1.21 V), VDD ≥ 1.21 V × gain + 0.2 V 0.2 V
To VDD and to AGND
(DAC output unloaded, external reference at VDD (gain
= 1 ×), the VREF pin is not shorted to VDD)
0.8
%FSR
To VDD and to AGND (ILOAD = 10 mA at VDD = 5.5 V,
ILOAD = 3 mA at VDD = 2.7 V, ILOAD = 1 mA at VDD =
1.8 V), external reference at VDD (gain = 1 ×), the VREF
pin is not shorted to VDD)
10
ZOVFB dc output impedance(3)
DAC output enabled, internal reference (gain = 1.5 ×
or 2 ×) or external reference at VDD (gain = 1 ×), the
VREF pin is not shorted to VDD
400 500 600 kΩ
DAC output enabled, internal VREF, gain = 3 × or 4 × 325 400 485
Power supply rejection ratio
(dc)
Internal VREF, gain = 2 ×, DAC at midscale,
VDD = 5 V ±10% 0.25 mV/V
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 5
Product Folder Links: DAC63202W

6.5 Electrical Characteristics: Voltage Output (continued)
all minimum/maximum specifications at –40°C ≤ TA ≤ +125°C and typical specifications at TA = 25°C, 1.7 V ≤ VDD ≤ 5.5 V,
DAC reference tied to VDD, gain = 1 ×, DAC output pin (OUT) loaded with resistive load (RL = 5 kΩ to AGND) and capacitive
load (CL = 200 pF to AGND), and digital inputs at VDD or AGND (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
DYNAMIC PERFORMANCE
tsett Output voltage settling time
1/4 to 3/4 scale and 3/4 to 1/4 scale settling to
10%FSR, VDD = 5.5 V 20
µs
1/4 to 3/4 scale and 3/4 to 1/4 scale settling to
10%FSR, VDD = 5.5 V, internal VREF, gain = 4 × 25
Slew rate VDD = 5.5 V 0.3 V/µs
Power-on glitch magnitude At start-up (DAC output disabled) 75 mV
At start-up (DAC output disabled), RL = 100 kΩ 200
Output-enable glitch
magnitude
DAC output disabled to enabled (DAC registers at zero
scale), RL = 100 kΩ 250 mV
VnOutput noise voltage (peak to
peak)
f = 0.1 Hz to 10 Hz, DAC at midscale, VDD = 5.5 V 50
µVPP
Internal VREF, gain = 4 ×, f = 0.1 Hz to 10 Hz,
DAC at midscale, VDD = 5.5 V 90
Output noise density
f = 1 kHz, DAC at midscale, VDD = 5.5 V 0.35
µV/√Hz
Internal VREF, gain = 4 ×, f = 1 kHz, DAC at midscale,
VDD = 5.5 V 0.9
Power supply rejection ratio
(ac)(3)
Internal VREF, gain = 4 ×, 200-mV 50-Hz or 60-Hz sine
wave superimposed on power supply voltage, DAC at
midscale
-68 dB
Code change glitch impulse ±1 LSB change around midscale (including
feedthrough) 10 nV-s
Code change glitch impulse
magnitude
±1 LSB change around midscale (including
feedthrough) 15 mV
POWER
IDD Current flowing into VDD(4) (5) Normal operation, DACs at full scale, digital pins static, external reference at VDD but the VREF pin is not
shorted to VDD
150 µA/ch
(1) Measured with DAC output unloaded. For external reference and internal reference VDD ≥ 1.21 × gain + 0.2 V, between end-point
codes: 32d to 4064d.
(2) Specified by design and characterization, not production tested.
(3) Specified with 200-mV headroom with respect to reference value when internal reference is used.
(4) Measured with DAC output unloaded.
(5) The total power consumption is calculated by IDD × (total number of channels powered on) + (sleep-mode current).
(6) When a DAC channel is configured in IOUT mode for long term and then switched to VOUT mode, the VOUT mode can show
parametric drift.
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
6Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

6.6 Electrical Characteristics: Current Output
all minimum/maximum specifications at –40°C ≤ TA ≤ +125°C and typical specifications at TA = 25°C, 1.7 V ≤ VDD ≤ 5.5 V,
±250-µA output range, and digital inputs at VDD or AGND (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
STATIC PERFORMANCE
Resolution 8 Bits
INL Integral nonlinearity DAC codes between 0d and 255d –1 1 LSB
DNL Differential nonlinearity DAC codes between 0d and 255d –1 1 LSB
Offset error DAC output ranges: ±25 µA, ±50 µA, ±125 µA, and
±250 µA; DAC at midscale ±1 %FSR
Gain error DAC output ranges: ±25 µA, ±50 µA, ±125 µA, and
±250 µA; DAC codes between 0d and 255d ±1.3 %FSR
OUTPUT
Output compliance voltage(1) DAC output ranges: ±25 µA, ±50 µA, ±125 µA, and
±250 µA; to VDD and to AGND 400 mV
ZOIOUT dc output impedance(2) DAC at midscale, DAC output kept at VDD/2 60 MΩ
Power supply rejection ratio
(dc)
DAC at midscale, all bipolar ranges, VDD changed from
4.5V to 5.5V 0.23 LSB/V
DYNAMIC PERFORMANCE
tsett Output current settling time
1/4 to 3/4 scale and 3/4 to 1/4 scale settling to 1 LSB
at 8-bit resolution, VDD = 5.5 V, common-mode voltage
at OUTx pin is VDD/2
60 µs
VnOutput noise current (peak to
peak)
0.1 Hz to 10 Hz, DAC at midscale,
VDD = 5.5 V, ±250-µA output range 150 nAPP
Output noise density f = 1 kHz, DAC at midscale,
VDD = 5.5 V, ±250-µA output range 1 nA/√Hz
Power supply rejection ratio
(ac)(3)
±250-µA output range, 200-mV 50-Hz or 60-Hz sine
wave superimposed on power-supply voltage, DAC at
midscale
0.65 LSB/V
POWER
IDD Current flowing into VDD(3) (4)
Normal operation, DACs at full scale, ±25-µA output
range, digital pins static 42 50
µA/ch
Normal operation, DACs at full scale, ±50-µA output
range, digital pins static 56 70
Normal operation, DACs at full scale, ±125-µA output
range, digital pins static 98 120
Normal operation, DACs at full scale, ±250-µA output
range, digital pins static 167 200
(1) Measured between DAC codes 0d and 255d.
(2) Specified by design and characterization, not production tested.
(3) The current flowing into VDD does not account for the load current sourced or sink on the OUTx pins. The VREF pin is connected to
VDD.
(4) The total power consumption is calculated by IDD × (total number of channels powered on) + (sleep-mode current).
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 7
Product Folder Links: DAC63202W

6.7 Electrical Characteristics: Comparator Mode
all minimum/maximum specifications at –40°C ≤ TA ≤ +125°C and typical specifications at TA = 25°C, 1.7 V ≤ VDD ≤ 5.5 V,
DAC reference tied to VDD, gain = 1x in voltage output mode, DAC output pin (OUT) loaded with resistive load (RL = 5 kΩ to
AGND) and capacitive load (CL = 200 pF to AGND), and digital inputs at VDD or AGND (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
STATIC PERFORMANCE
Offset error(1) (2) 1.7 V ≤ VDD ≤ 5.5 V; DAC at midscale, comparator input at Hi-Z, and DAC operating with external
reference.
–6 0 6 mV
Offset error time drift(1)
VDD = 5.5 V, external reference, TA = 125°C, FB in
Hi-Z mode, DAC at full scale and VFB at 0 V or DAC
at zero scale and VFB at 1.84 V, drift specified for 10
years of continuous operation
4 mV
OUTPUT
Input voltage
VREF connected to VDD, VFB resistor network
connected to ground 0 VDD
V
VREF connected to VDD, VFB resistor network
disconnected from ground 0
VDD
(1/3 –
1/100)
VOL Logic low output voltage ILOAD = 100 μA, output in open-drain mode 0.1 V
DYNAMIC PERFORMANCE
tresp Output response time
DAC at midscale with 10-bit resolution, FB input at
Hi-Z, and transition step at FB node is (VDAC –
2 LSB) to (VDAC + 2 LSB), transition time measured
between 10% and 90% of output, output current of
100 µA, comparator output configured in push-pull
mode, load capacitor at DAC output is 25 pF
10 µs
(1) Specified by design and characterization, not production tested.
(2) This specification does not include the total unadjusted error (TUE) of the DAC.
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
8Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

6.8 Electrical Characteristics: General
all minimum/maximum specifications at –40°C ≤ TA ≤ +125°C and typical specifications at TA = 25°C, 1.7 V ≤ VDD ≤ 5.5
V, DAC reference tied to VDD, gain = 1 × in voltage output mode or ±250-µA output range in current output mode, DAC
output pin (OUT) loaded with resistive load (RL = 5 kΩ to AGND) in voltage-output mode and capacitive load (CL = 200 pF to
AGND), and digital inputs at VDD or AGND (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
INTERNAL REFERENCE
Initial accuracy TA = 25°C 1.1979 1.212 1.224 V
Reference output temperature
coefficient(1) (2) 50 ppm/°C
EXTERNAL REFERENCE
VREF input impedance(1) (3) 192 kΩ/ch
EEPROM
Endurance(1) –40°C ≤ TA ≤ +85°C 20000 Cycles
TA = 125°C 1000
Data retention(1) TA = 25°C 50 Years
EEPROM programming write
cycle time(1) 200 ms
Device boot-up time(1) Time taken from power valid (VDD ≥ 1.7 V) to output valid state (output state as programmed in EEPROM),
0.5-µF capacitor on the CAP pin
5 ms
DIGITAL INPUTS
Digital feedthrough Voltage output mode, DAC output static at midscale,
fast mode plus, SCL toggling 20 nV-s
IDD Current flowing into VDD DAC in sleep mode, internal reference powered down,
external reference at 5.5 V 28 µA
IDD Current flowing into VDD(1) DAC in sleep mode, internal reference
enabled, additional current through internal reference 10 µA
IDD Current flowing into VDD(1) DAC channels enabled, internal reference enabled, additional current through internal reference per DAC
channel in voltage-output mode
12.5 µA
Pin capacitance Per pin 10 pF
POWER-DOWN MODE
HIGH-IMPEDANCE OUTPUT
ILEAK Current flowing into VOUTX and
VFBX
DAC in Hi-Z output mode, 1.7 V ≤ VDD ≤ 5.5 V 10 nA
VDD = 0 V, VOUT ≤ 1.5 V, decoupling capacitor between
VDD and AGND = 0.1 μF 200 nA
VDD = 0 V, 1.5 V < VOUT ≤ 5.5 V, decoupling capacitor
between VDD and AGND = 0.1 μF 500 nA
100 kΩ between VDD and AGND, VOUT ≤ 1.25 V, series
resistance of 10 kΩ at OUT pin ±2 µA
(1) Specified by design and characterization, not production tested.
(2) Measured at –40°C and +125°C and calculated the slope.
(3) Impedances for the DAC channels are connected in parallel.
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 9
Product Folder Links: DAC63202W

6.9 Timing Requirements: I2C Standard Mode
all input signals are timed from VIL to 70% of Vpull-up, 1.7 V ≤ VDD ≤ 5.5 V, –40°C ≤ TA ≤ +125°C, and 1.7 V ≤ Vpull-up ≤ VDD V
MIN NOM MAX UNIT
fSCLK SCL frequency 100 kHz
tBUF Bus free time between stop and start conditions 4.7 µs
tHDSTA Hold time after repeated start 4 µs
tSUSTA Repeated start setup time 4.7 µs
tSUSTO Stop condition setup time 4 µs
tHDDAT Data hold time 0 ns
tSUDAT Data setup time 250 ns
tLOW SCL clock low period 4700 ns
tHIGH SCL clock high period 4000 ns
tFClock and data fall time 300 ns
tRClock and data rise time 1000 ns
tVDDAT Data valid time, R = 360 Ω, Ctrace = 23 pF, Cprobe = 10 pF 3.45 µs
tVDACK Data valid acknowledge time, R = 360 Ω, Ctrace = 23 pF, Cprobe = 10 pF 3.45 µs
6.10 Timing Requirements: I2C Fast Mode
all input signals are timed from VIL to 70% of Vpull-up, 1.7 V ≤ VDD ≤ 5.5 V, –40°C ≤ TA ≤ +125°C, and 1.7 V ≤ Vpull-up ≤ VDD V
MIN NOM MAX UNIT
fSCLK SCL frequency 400 kHz
tBUF Bus free time between stop and start conditions 1.3 µs
tHDSTA Hold time after repeated start 0.6 µs
tSUSTA Repeated start setup time 0.6 µs
tSUSTO Stop condition setup time 0.6 µs
tHDDAT Data hold time 0 ns
tSUDAT Data setup time 100 ns
tLOW SCL clock low period 1300 ns
tHIGH SCL clock high period 600 ns
tFClock and data fall time 300 ns
tRClock and data rise time 300 ns
tVDDAT Data valid time, R = 360 Ω, Ctrace = 23 pF, Cprobe = 10 pF 0.9 µs
tVDACK Data valid acknowledge time, R = 360 Ω, Ctrace = 23 pF, Cprobe = 10 pF 0.9 µs
6.11 Timing Requirements: I2C Fast Mode Plus
all input signals are timed from VIL to 70% of Vpull-up, 1.7 V ≤ VDD ≤ 5.5 V, –40°C ≤ TA ≤ +125°C, and 1.7 V ≤ Vpull-up ≤ VDD V
MIN NOM MAX UNIT
fSCLK SCL frequency 1 MHz
tBUF Bus free time between stop and start conditions 0.5 µs
tHDSTA Hold time after repeated start 0.26 µs
tSUSTA Repeated start setup time 0.26 µs
tSUSTO Stop condition setup time 0.26 µs
tHDDAT Data hold time 0 ns
tSUDAT Data setup time 50 ns
tLOW SCL clock low period 0.5 µs
tHIGH SCL clock high period 0.26 µs
tFClock and data fall time 120 ns
tRClock and data rise time 120 ns
tVDDAT Data valid time, R = 360 Ω, Ctrace = 23 pF, Cprobe = 10 pF 0.45 µs
tVDACK Data valid acknowledge time, R = 360 Ω, Ctrace = 23 pF, Cprobe = 10 pF 0.45 µs
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
10 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

6.12 Timing Requirements: SPI Write Operation
all input signals are specified with tr = tf = 1 V/ns (10% to 90% of VIO) and timed from a voltage level of (VIL + VIH) / 2,
1.7 V ≤ VIO ≤ 5.5 V, 1.7 V ≤ VDD ≤ 5.5 V, and –40°C ≤ TA ≤ +125°C
MIN NOM MAX UNIT
fSCLK Serial clock frequency 50 MHz
tSCLKHIGH SCLK high time 9 ns
tSCLKLOW SCLK low time 9 ns
tSDIS SDI setup time 8 ns
tSDIH SDI hold time 8 ns
tCSS CS to SCLK falling edge setup time 18 ns
tCSH SCLK falling edge to CS rising edge 10 ns
tCSHIGH CS high time 50 ns
tDACWAIT Sequential DAC update wait time (time between subsequent LDAC falling
edges) for same channel 2 µs
tBCASTWAIT Broadcast DAC update wait time (time between subsequent LDAC falling
edges) 2 µs
6.13 Timing Requirements: SPI Read and Daisy Chain Operation (FSDO = 0)
all input signals are specified with tr = tf = 1 V/ns (10% to 90% of VIO) and timed from a voltage level of (VIL + VIH) / 2,
1.7 V ≤ VIO ≤ 5.5 V, 1.7 V ≤ VDD ≤ 5.5 V, –40°C ≤ TA ≤ +125°C, and FSDO = 0
MIN NOM MAX UNIT
fSCLK Serial clock frequency 1.25 MHz
tSCLKHIGH SCLK high time 350 ns
tSCLKLOW SCLK low time 350 ns
tSDIS SDI setup time 8 ns
tSDIH SDI hold time 8 ns
tCSS SYNC to SCLK falling edge setup time 400 ns
tCSH SCLK falling edge to SYNC rising edge 400 ns
tCSHIGH SYNC high time 1 µs
tSDODLY SCLK rising edge to SDO falling edge, IOL ≤ 5 mA, CL = 20 pF. 300 ns
6.14 Timing Requirements: SPI Read and Daisy Chain Operation (FSDO = 1)
all input signals are specified with tr = tf = 1 V/ns (10% to 90% of VIO) and timed from a voltage level of (VIL + VIH) / 2,
1.7 V ≤ VIO ≤ 5.5 V, 1.7 V ≤ VDD ≤ 5.5 V, –40°C ≤ TA ≤ +125°C, and FSDO = 1
MIN NOM MAX UNIT
fSCLK Serial clock frequency 2.5 MHz
tSCLKHIGH SCLK high time 175 ns
tSCLKLOW SCLK low time 175 ns
tSDIS SDI setup time 8 ns
tSDIH SDI hold time 8 ns
tCSS SYNC to SCLK falling edge setup time 300 ns
tCSH SCLK falling edge to SYNC rising edge 300 ns
tCSHIGH SYNC high time 1 µs
tSDODLY SCLK rising edge to SDO falling edge, IOL ≤ 5 mA, CL = 20 pF. 300 ns
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 11
Product Folder Links: DAC63202W

6.15 Timing Requirements: GPIO
all input signals are specified with tr = tf = 1 V/ns (10% to 90% of VIO) and timed from a voltage level of (VIL + VIH) / 2,
1.7 V ≤ VIO ≤ 5.5 V, 1.7 V ≤ VDD ≤ 5.5 V, and –40°C ≤ TA ≤ +125°C
MIN NOM MAX UNIT
tGPIHIGH GPI high time((1)) 2 µs
tGPILOW GPI low time((1)) 2 µs
tGPAWGD LDAC falling edge to DAC update delay((4)) 2 µs
tCS2LDAC SYNC rising edge to LDAC falling edge 1 µs
tSTP2LDAC I2C stop bit rising edge to LDAC falling edge 1 µs
tLDACW LDAC low time 2 µs
(1) The SCL, SDA, A0, and A1 pins can be configured as GPIOs that perform different channel-specific or independent operations. The
actual response time of the GPIO is determined by the delay provided by the configured function and the settling time of the DAC.
(2) The GPIOs can be configured as channel-specific or global LDAC function.
6.16 Timing Diagrams
SCL
SDA
PS
tBUF
tHDSTA
tLOW tR
tHDDAT
tHIGH
tF
tSUDAT
tSUSTA
tHDSTA
S
tSUSTO
P
Low byte ACK cycle
Figure 6-1. I2C Timing Diagram
tCSS
tSDIS tSDIH
SYNC
SDI
tCSHIGH
Bit 23
tSCLKLOW
Bit 1 Bit 0
tCSH
SCLK tSCLKHIGH
tCS2LDAC tLDACW
GPIO/
LDAC
Figure 6-2. SPI Write Timing Diagram
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
12 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

Bit 22 Bit 0
tCSH
Bit 23 Bit 1 Bit 0
SDO
FSDO = 0
Bit 23 Bit 1 Bit 0
tSDODZ tSDODLY
FIRST READ COMMAND
tCSS
tSDIS tSDIH
SDI
tCSHIGH
Bit 23
SCLK
SDO
FSDO = 1
Bit 23 Bit 1 Bit 0
tSDODLY
ANY COMMAND
DATA FROM FIRST READ COMMAND
DATA FROM FIRST READ COMMAND
tSCLKHIGH tSCLKLOW
SYNC
Figure 6-3. SPI Read Timing Diagram
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 13
Product Folder Links: DAC63202W

6.17 Typical Characteristics: Voltage Output
at TA = 25°C, VDD = 5.5 V, external reference = 5.5 V, gain = 1x, 12-bit resolution, and DAC outputs unloaded (unless
otherwise noted)
Code
Voltage Output INL (LSB)
32 544 1056 1568 2080 2592 3104 3616 4064
-5
-4
-3
-2
-1
0
1
2
3
4
5
Channel 1
Channel 0
Internal reference, gain = 4x
Figure 6-4. Voltage Output INL vs Digital Input Code
Code
Voltage Output INL (LSB)
32 544 1056 1568 2080 2592 3104 3616 4064
-5
-4
-3
-2
-1
0
1
2
3
4
5
Channel 1
Channel 0
Figure 6-5. Voltage Output INL vs Digital Input Code
Temperature (C)
Voltage Output INL (LSB)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-5
-4
-3
-2
-1
0
1
2
3
4
5
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-6. Voltage Output INL vs Temperature
Supply Voltage (V)
Voltage Output INL (LSB)
1.8 2.725 3.65 4.575 5.5
-5
-4
-3
-2
-1
0
1
2
3
4
5
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-7. Voltage Output INL vs Supply Voltage
Code
Voltage Output DNL (LSB)
32 544 1056 1568 2080 2592 3104 3616 4064
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
Channel 1
Channel 0
Internal reference, gain = 4x
Figure 6-8. Voltage Output DNL vs Digital Input Code
Code
Voltage Output DNL (LSB)
32 544 1056 1568 2080 2592 3104 3616 4064
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
Channel 1
Channel 0
Figure 6-9. Voltage Output DNL vs Digital Input Code
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
14 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

6.17 Typical Characteristics: Voltage Output (continued)
at TA = 25°C, VDD = 5.5 V, external reference = 5.5 V, gain = 1x, 12-bit resolution, and DAC outputs unloaded (unless
otherwise noted)
Temperature (C)
Voltage Output DNL (LSB)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-10. Voltage Output DNL vs Temperature
Supply Voltage (V)
Voltage Output DNL (LSB)
1.8 2.725 3.65 4.575 5.5
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-11. Voltage Output DNL vs Supply Voltage
Code
Voltage Output TUE (%FSR)
0 512 1024 1536 2048 2560 3072 3584 4095
-1.5
-1.2
-0.9
-0.6
-0.3
0
0.3
0.6
0.9
1.2
1.5
Channel 1
Channel 0
Internal reference, gain = 4x
Figure 6-12. Voltage Output TUE vs Digital Input Code
Code
Voltage Output TUE (%FSR)
0 512 1024 1536 2048 2560 3072 3584 4095
-1.5
-1.2
-0.9
-0.6
-0.3
0
0.3
0.6
0.9
1.2
1.5
Channel 1
Channel 0
Figure 6-13. Voltage Output TUE vs Digital Input Code
Temperature (C)
Voltage Output TUE (%FSR)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-1.5
-1.2
-0.9
-0.6
-0.3
0
0.3
0.6
0.9
1.2
1.5
Channel 1
Channel 0
DAC channels at midscale
Figure 6-14. Voltage Output TUE vs Temperature
Supply Voltage (V)
Voltage Output TUE (%FSR)
1.8 2.725 3.65 4.575 5.5
-1.5
-1.2
-0.9
-0.6
-0.3
0
0.3
0.6
0.9
1.2
1.5
Channel 1
Channel 0
DAC channels at midscale
Figure 6-15. Voltage Output TUE vs Supply Voltage
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 15
Product Folder Links: DAC63202W

6.17 Typical Characteristics: Voltage Output (continued)
at TA = 25°C, VDD = 5.5 V, external reference = 5.5 V, gain = 1x, 12-bit resolution, and DAC outputs unloaded (unless
otherwise noted)
Temperature (C)
Voltage Output Offset Error (%FSR)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-0.5
-0.4
-0.3
-0.2
-0.1
0
0.1
0.2
0.3
0.4
0.5
Channel 1
Channel 0
Figure 6-16. Voltage Output Offset Error vs Temperature
Temperature (C)
Voltage Output Gain Error (%FSR)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-0.5
-0.4
-0.3
-0.2
-0.1
0
0.1
0.2
0.3
0.4
0.5
Channel 1
Channel 0
Figure 6-17. Voltage Output Gain Error vs Temperature
Load Current (mA)
Voltage Output (V)
-5 -3.75 -2.5 -1.25 0 1.25 2.5 3.75 5
2.74
2.742
2.744
2.746
2.748
2.75
2.752
2.754
2.756
2.758
2.76
Channel 1
Channel 0
DAC channels at midscale
Figure 6-18. Voltage Output vs Load Current
Frequency (Hz)
AC Power-Supply Rejection Ratio (dB)
10 2030 50 100 200 5001000 10000 100000
-70
-60
-50
-40
-30
-20
-10
0
10
Figure 6-19. Voltage Output AC PSRR vs Frequency
Time (s)
0 10 20 30 40 50
LDAC (1 V/div)
VOUT (1 LSB/div)
Figure 6-20. Voltage Output Code-to-Code Glitch - Rising Edge
Time (s)
0 10 20 30 40 50
LDAC (1 V/div)
VOUT (1 LSB/div)
Figure 6-21. Voltage Output Code-to-Code Glitch - Falling Edge
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
16 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

6.17 Typical Characteristics: Voltage Output (continued)
at TA = 25°C, VDD = 5.5 V, external reference = 5.5 V, gain = 1x, 12-bit resolution, and DAC outputs unloaded (unless
otherwise noted)
Time (s)
0 10 20 30 40 50
Trigger (1 V/div)
VOUT (1 V/div)
Settling Band (+10% FSR)
Settling Band (-10% FSR)
Zero scale to full scale swing
Figure 6-22. Voltage Output Setting Time - Rising Edge
Time (s)
0 10 20 30 40 50
Trigger (1 V/div)
VOUT (1 V/div)
Settling Band (+10% FSR)
Settling Band (-10% FSR)
Full scale to zero scale swing
Figure 6-23. Voltage Output Setting Time - Falling Edge
Time (s)
0 200 400 600 800 1000 1200 1400 1600
VDD (1 V/div)
VOUT (15 mV/div)
DAC in Hi-Z power-down mode
Figure 6-24. Voltage Output Power-On Glitch
Time (s)
0 200 400 600 800 1000 1200 1400 1600
VDD (1 V/div)
VOUT (1 mV/div)
DAC at zero scale
Figure 6-25. Voltage Output Power-Off Glitch
Frequency (Hz)
Noise Density (V/Hz)
10 2030 50 100 200 5001000 10000 100000
0
0.3
0.6
0.9
1.2
1.5
1.8
2.1
2.4
2.7
3
Internal reference, gain = 4x
Figure 6-26. Voltage Output Noise Density
Frequency (Hz)
Noise Density (V/Hz)
10 2030 50 100 200 5001000 10000 100000
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2
Figure 6-27. Voltage Output Noise Density
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 17
Product Folder Links: DAC63202W

6.17 Typical Characteristics: Voltage Output (continued)
at TA = 25°C, VDD = 5.5 V, external reference = 5.5 V, gain = 1x, 12-bit resolution, and DAC outputs unloaded (unless
otherwise noted)
Time (s)
Noise Voltage (V)
0 1 2 3 4 5 6 7 8 9 10
-35
-30
-25
-20
-15
-10
-5
0
5
10
15
20
25
30
35
Internal reference, gain = 4x, f = 0.1 Hz to 10 Hz
Figure 6-28. Voltage Output Flicker Noise
Time (s)
Noise Voltage (V)
0 1 2 3 4 5 6 7 8 9 10
-25
-20
-15
-10
-5
0
5
10
15
20
25
f = 0.1 Hz to 10 Hz
Figure 6-29. Voltage Output Flicker Noise
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
18 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W

6.18 Typical Characteristics: Current Output
at TA = 25°C, VDD = 5.5 V, output range: ±250 μA (unless otherwise noted)
Code
Current Output INL (LSB)
0 32 64 96 128 160 192 224 255
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
Channel 1
Channel 0
Figure 6-30. Current Output INL vs Digital Input Code
Temperature (C)
Current Output INL (LSB)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-31. Current Output INL vs Temperature
Supply Voltage (V)
Current Output INL (LSB)
1.8 2.725 3.65 4.575 5.5
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-32. Current Output INL vs Supply Voltage
Code
Current Output DNL (LSB)
0 32 64 96 128 160 192 224 255
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
Channel 1
Channel 0
Figure 6-33. Current Output DNL vs Digital Input Code
Temperature (C)
Current Output DNL (LSB)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-34. Current Output DNL vs Temperature
Supply Voltage (V)
Current Output DNL (LSB)
1.8 2.725 3.65 4.575 5.5
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
CH1 MAX
CH0 MAX
CH1 MIN
CH0 MIN
Figure 6-35. Current Output DNL vs Supply Voltage
www.ti.com
DAC63202W
SLASF73 – APRIL 2023
Copyright © 2023 Texas Instruments Incorporated Submit Document Feedback 19
Product Folder Links: DAC63202W

6.18 Typical Characteristics: Current Output (continued)
at TA = 25°C, VDD = 5.5 V, output range: ±250 μA (unless otherwise noted)
Code
Current Output TUE (%FSR)
0 32 64 96 128 160 192 224 255
-2
-1.6
-1.2
-0.8
-0.4
0
0.4
0.8
1.2
1.6
2
Channel 1
Channel 0
Figure 6-36. Current Output TUE vs Digital Input Code
Temperature (C)
Current Output TUE (%FSR)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-2
-1.6
-1.2
-0.8
-0.4
0
0.4
0.8
1.2
1.6
2
Channel 1
Channel 0
DAC channels at midscale
Figure 6-37. Current Output TUE vs Temperature
Supply Voltage (V)
Current Output TUE (%FSR)
1.8 2.725 3.65 4.575 5.5
-2
-1.6
-1.2
-0.8
-0.4
0
0.4
0.8
1.2
1.6
2
Channel 1
Channel 0
DAC channels at midscale
Figure 6-38. Current Output TUE vs Supply Voltage
Temperature (C)
Current Output Offset Error (%FSR)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-1.5
-1.2
-0.9
-0.6
-0.3
0
0.3
0.6
0.9
1.2
1.5
Channel 1
Channel 0
Figure 6-39. Current Output Offset Error vs Temperature
Temperature (C)
Current Output Gain Error (%FSR)
-40 -25 -10 5 20 35 50 65 80 95 110 125
-1.5
-1.2
-0.9
-0.6
-0.3
0
0.3
0.6
0.9
1.2
1.5
Channel 1
Channel 0
Figure 6-40. Current Output Gain Error vs Temperature
Load Voltage (V)
Current Output (A)
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5
-1000
-800
-600
-400
-200
0
200
400
600
800
1000
CH1, DAC Code = 0
CH0, DAC Code = 0
CH1, DAC Code = 255
CH0, DAC Code = 255
Figure 6-41. Current Output vs Load Voltage
DAC63202W
SLASF73 – APRIL 2023 www.ti.com
20 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated
Product Folder Links: DAC63202W
