Application Report
SLEA104–July 2010
TVP5154A VBI Quick Start
.....................................................................................................................................................
ABSTRACT
The TVP5154A video decoder has an internal vertical data processor (VDP) that can be used to slice
various VBI data services such as V-Chip, Teletext (WST, NABTS), closed captioning (CC), wide screen
signaling (WSS), copy generation management system (CGMS), video program system (VPS), electronic
program guide (EPG or Gemstar), program delivery control (PDC) and vertical interval time code (VITC).
This application report provides an introduction to the VBI data slicing capabilities of the TVP5154A and
focuses on configuring the TVP5154A for the more commonly used VBI data services.
Contents
1 Introduction .................................................................................................................. 2
2 VDP Configuration RAM ................................................................................................... 4
3 Line Mode Registers ........................................................................................................ 5
4 Sliced Data Retrieval ....................................................................................................... 7
5 Managing Data Retrieval ................................................................................................... 7
6 FIFO Access ................................................................................................................. 8
7 Ancillary Data ................................................................................................................ 9
8 Full-Field Mode ............................................................................................................ 10
9 VBI Raw Data Mode ...................................................................................................... 10
Appendix A Subset of the TVP5154A VDP I2C Registers ................................................................. 12
Appendix B Sample WinVCC CMD File for VBI Setup ..................................................................... 20
Appendix C Example TVP5154A C Code .................................................................................... 21
Appendix D VBI Raw Data I2C Registers .................................................................................... 22
List of Figures
1 The VDP Configuration RAM is Loaded Prior to Line Mode Register Setup ....................................... 3
2 Example Load of WSS/CGMS Configuration RAM..................................................................... 5
3 Line Mode Setup for WSS/CGMS ........................................................................................ 6
4 Example WSS/CGMS Data Retrieval .................................................................................... 7
5 Line 21 Closed Caption ITU-R BT.656 Digital Output Capture with YUV Samples Present Raw Data
Mode disabled ............................................................................................................. 11
6 Line 21 Closed Caption ITU-R BT.656 Digital Output Capture in Raw Data ModeUV (chroma) data are
replaced with Y (luma) data.............................................................................................. 11
List of Tables
1 Supported Data Services .................................................................................................. 2
2 Configuration RAM Recommended Settings............................................................................ 4
3 Line Mode Configuration Bits for Supported Modes.................................................................... 6
4 Dedicated VDP Data Registers ........................................................................................... 7
5 Ancillary Data Header ...................................................................................................... 9
6 525-Line Raw Data Setup to Include Line 21.......................................................................... 10
7 625-Line Raw Data Setup................................................................................................ 10
1
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

Introduction www.ti.com
1 Introduction
The TVP5154A video decoder has an internal Vertical Data Processor (VDP) that can be used to slice
various VBI data services such as V-Chip, Teletext (WST, NABTS), Closed Captioning (CC), Wide Screen
Signaling (WSS), Copy Generation Management System (CGMS), Video Program System (VPS),
Electronic Program Guide (EPG or Gemstar), Program Delivery Control (PDC), and Vertical Interval Time
Code (VITC). These data services are typically transmitted during the vertical blanking interval of the video
frame. Table 1 provides a summary of the supported data services including the line numbers on which
they are typically transmitted.
Table 1. Supported Data Services
VBI System Standard Line Number Number of Bytes Specification
Teletext WST A SECAM 6-23 (field 1, 2) 38 ITU-R BT 653-3
Teletext WST B PAL 6-22 (field 1, 2) 43 ITU-R BT 653-3
Teletext NABTS C NTSC-M 10-21 (field 1, 2) 34 ITU-R BT 653-3
Teletext NABTS D NTSC-J 10-21 (field 1, 2) 35 ITU-R BT 653-3
Closed Caption PAL 22 (field 1, 2) 2 EIA-608-D
Closed Caption NTSC 21 (field 1, 2) 2 EIA-608-D
WSS/CGMS PAL 23 (field 1, 2) 14 bits ITU-R BT 1119-1
WSS/CGMS NTSC 20 (field 1, 2) 20 bits IEC 61880
VITC PAL 6-22 9 SMPTE 12M-1999
VITC NTSC 10-20 9 SMPTE 12M-1999
VPS (PDC) PAL 16 13 ETS 300 231
V-Chip NTSC 21 (field 2) 2 EIA-744-A
Gemstar 1x NTSC 2
Gemstar 2x NTSC 5 with frame byte
User Any Programmable Programmable
A host or backend receiver can retrieve the sliced data using one of three methods:
• I2C access of dedicated Closed Caption, WSS, CGMS, VPS, Gemstar, VITC, and V-Chip data
registers.
• I2C access of an internal 512-byte FIFO used primarily for high-bandwidth data services such as
full-field teletext.
• As ITU-R BT.656 ancillary data, inserted by the TVP5154A in the data stream during the horizontal
blanking interval.
Note: This document will focus primarily on the more commonly used dedicated I2C data registers.
Prior to accessing the VBI sliced data, the TVP5154A must be configured for the desired VBI data service.
This includes loading of the VDP Configuration RAM (C-RAM) and the Line Mode registers that are used
to enable various data services. Detailed descriptions of the VBI related I2C registers are shown in
Appendix A.
2TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Introduction
Figure 1. The VDP Configuration RAM is Loaded Prior to Line Mode Register Setup
3
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

VDP Configuration RAM www.ti.com
2 VDP Configuration RAM
The first step in configuring the TVP5154A for VBI data slicing is to load the VDP Configuration RAM
(C-RAM). The C-RAM defines the data slicing modes for the various data services, with each mode
having its own unique RAM address and 16 byte block of memory. Table 2 shows the recommended
setup values for the various data services that are supported. Prior to loading the C-RAM, the Line Mode
registers must all be programmed with a value of FFh to avoid conflict between the VDP and
microprocessor during the load process. Full field mode must also be disabled in I2C register CFh.
Table 2. Configuration RAM Recommended Settings
Index Address 0 1 2 3 4 5 6 7 8 9 A B C D E F
Reserved 000h Reserved
WST SECAM 010h AA AA FF FF E7 2E 20 A6 E4 B4 OE 0 7 0 10 0
Reserved 020h Reserved
WST PAL B 030h AA AA FF FF 27 2E 20 AB A4 72 10 0 7 0 10 0
Reserved 040h Reserved
WST PAL C 050h AA AA FF FF E7 2E 20 22 A4 98 0D 0 0 0 10 0
Reserved 060h Reserved
WST NTSC 070h AA AA FF FF 27 2E 20 23 63 93 0D 0 0 0 10 0
Reserved 080h Reserved
NABTS, NTSC 090h AA AA FF FF E7 2E 20 A2 63 93 0D 0 7 0 15 0
Reserved 0A0h Reserved
NABTS, NTSC-J 0B0h AA AA FF FF A7 2E 20 A3 63 93 0D 0 7 0 10 0
Reserved 0C0h Reserved
CC, PAL/SECAM 0D0h AA 2A FF 3F 04 51 6E 02 A4 7B 09 0 0 0 27 0
Reserved 0E0h Reserved
CC, NTSC 0F0h AA 2A FF 3F 04 51 6E 02 63 8C 09 0 0 0 27 0
Reserved 100h Reserved
WSS/CGMS, PAL/SECAM 110h 5B 55 C5 FF 0 71 6E 42 A4 CD 0F 0 0 0 3A 0
Reserved 120h Reserved
WSS/CGMS, NTSC 130h 38 0 3F 0 0 71 6E 43 63 7C 08 0 0 0 39 0
Reserved 140h Reserved
VITC, PAL/SECAM 150h 0 0 0 0 0 8F 6D 49 A4 85 08 0 0 0 4C 0
Reserved 160h Reserved
VITC, NTSC 170h 0 0 0 0 0 8F 6D 49 63 94 08 0 0 0 4C 0
Reserved 180h Reserved
VPS, PAL 190h AA AA FF FF BA CE 2B 8D A4 DA 0B 0 7 0 60 0
Reserved 1A0h Programmable
Gemstar Custom 1 1B0h 99 99 FF FF 05 51 6E 05 63 18 13 80 0 0 60 0
The C-RAM is accessed through the use of three I2C registers (C3h-C5h). Registers C4h and C5h must
be programmed with the 9-bit starting address of the block of C-RAM to be programmed. I2C read and
write operations are then performed indirectly using register C3h. The C-RAM address is automatically
incremented following each I2C transaction. Only the portion of the C-RAM that includes the data service
to be used needs to be programmed. If WSS/CGMS for NTSC is the only desired data service, for
example, only the 16 bytes starting at C-RAM address 130h need to be programmed. Figure 2 shows
example C code for loading the WSS/CGMS C-RAM.
4TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

// TVP5154A NTSC WSS/CGMS C-RAM Load Example
#define TVP5154A 0xB8; // TVP5154A main I2C address
byte I2C_Data;
int CRAM_Address, count;
byte I2CData ={0x14,0x02};
// recommended WSS/CGMS settings
byte WSS_ARRAY[]={0x38,0,0x3F,0,0,0x71,0x6E,0x43,0x63,0x7C,0x08,0,0,0,0x39,0};
I2C_RegAddress = 0xD0; // starting address of Line Mode registers
I2C_Data = 0xFF;
For (count = 0; count < 44; count ++)
{
I2CWriteByte(TVP5154A, I2C_RegAddress, I2C_Data); //write FFh to Line Mode registers
I2C_RegAddress ++;
}
I2CWriteByte(TVP5154A, 0xCF, 0); // disable full field mode
CRAM_Address = 0x130; // address of NTSC WSS/CGMS C-RAM block
I2CWriteByte(TVP5154A, 0xC4, 0x30); // load C4h with C-RAM address[7:0]
I2CWriteByte(TVP5154A, 0xC5, 0x01); // load C5h with C-RAM address[8]
For (count = 0; count < 16; count++)
{
I2CWriteByte(TVP5154A, 0xC3, WSS_ARRAY[count]); // write 16 bytes of WSS/CGMS C-RAM
} // data to register C3h.
www.ti.com Line Mode Registers
Configuration RAM I2C Access Registers
Address C3h-C5h
Address 7 6 5 4 3 2 1 0
C3h Configuration data
C4h RAM address [7:0]
C5h Reserved RAM
address 8
Example: (Write 2 data bytes starting at C-RAM address 130h).
1. Set C-RAM starting address.
(a) Write 30h to register C4h (C-RAM address [7:0]).
(b) Write 01h to register C5h (C-RAM address [8]).
2. Write the two bytes (38h and 00h)
(a) Write 38h to register C3h. Write first byte to C-RAM address 130h.
(b) Write 00h to register C3h. Write next byte to C-RAM address 131h.
Figure 2. Example Load of WSS/CGMS Configuration RAM
3 Line Mode Registers
After the VDP Configuration RAM is loaded, the Line Mode Registers (D0h-FBh) must be properly
configured for the desired VBI data service. Each register in this register bank is linked to a specific video
line number and video field. Video lines 6 through 27 of both Field 1 and Field 2 are supported. For each
desired data service, the proper mode configuration bits need to be loaded into the line mode register that
is linked to the correct video line number. Additional data slicing options such as filtering, error correction,
and FIFO routing are also available in the line mode registers. Unused line mode and line address
registers must be programmed with FFh. A detailed description of these registers is shown in Appendix A.
The TVP5154A VDP is based on an NTSC line numbering convention, resulting in a 3-line VDP offset
5
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

// Example C Code for setting up WSS/CGMS Line Mode Registers
//
// Load C-RAM
//
// NTSC WSS/CGMS Line Mode setup for line 20 of both fields
I2CWriteByte(TVP5154A, 0xEC, 0x09); // line 20 field 1 (0xEC), mode bits = 0x09
I2CWriteByte(TVP5154A, 0xED, 0x09); // line 20 field 2 (0xED), mode bits = 0x09
I2CWriteByte(TVP5154A, 0xCB, 0x4E); // Set Pixel Alignment [7:0]to 0x4E
I2CWriteByte(TVP5154A, 0xCC, 0x00); // Set Pixel Alignment [9:8]to 0x00
// PAL WSS/CGMS Line Mode setup for line 23 (source input) of both fields.
// PAL line numbering has 3 line offset so the Line 26 line mode registers are used.
I2CWriteByte(TVP5154A, 0xF8, 0x08); // line 26 field 1 (0xF8), mode bits = 0x08
I2CWriteByte(TVP5154A, 0xF9, 0x08); // line 26 field 2 (0xF9), mode bits = 0x08
I2CWriteByte(TVP5154A, 0xCB, 0x4E); // Set Pixel Alignment [7:0]to 0x4E
I2CWriteByte(TVP5154A, 0xCC, 0x00); // Set Pixel Alignment [9:8]to 0x00
Line Mode Registers www.ti.com
relative to actual PAL line numbers. For PAL systems, the Line Mode register for line “N+3” must be used
to configure a data service transmitted on line N of the input source. Figure 3 shows example C code for
configuring WSS/CGMS data services for NTSC and PAL. Included in this example is an I2C write to the
Pixel Alignment Registers (CBh-CCh), which define the horizontal position where data slicing begins. The
value used (4Eh) is recommended for all data services.
Table 3. Line Mode Configuration Bits for Supported Modes
Line Mode Register Name Video Line Number Description
(D0h-FCh) Bits [3:0]
0000b WST SECAM 6-23 (field 1, 2) Teletext, SECAM
0001b WST PAL B 6-22 (field 1, 2) Teletext, PAL, System B
0010b WST PAL C 6-22 (field 1, 2) Teletext, PAL, System C
0011b WST, NTSC B 10-21 (field 1, 2) Teletext, NTSC, System B
0100b NABTS, NTSC C 10-21 (field 1, 2) Teletext, NTSC, System C
0101b NABTS, NTSC D 10-21 (field 1, 2) Teletext, NTSC, System D (Japan)
0110b CC, PAL/SECAM 22 (field 1, 2) Closed caption PAL/SECAM
0111b CC, NTSC 21 (field 1, 2) Closed caption NTSC
1000b WSS/CGMS, PAL/SECAM 23 (field 1, 2) Wide-screen signal, PAL/SECAM
1001b WSS/CGMS, NTSC 20 (field 1, 2) Wide-screen signal, NTSC
1010b VITC, PAL/SECAM 6-22 Vertical interval timecode, PAL/SECAM
1011b VITC, NTSC 10-20 Vertical interval timecode, NTSC
1100b VPS, PAL 16 Video program system, PAL
1101b EPG/Gemstar Electronic program guide - Custom mode
1110b x x Reserved
1111b Active Video Active Video Active video/full field
Figure 3. Line Mode Setup for WSS/CGMS
6TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

// Example C Code for WSS/CGMS NTSC Sliced Data Read
// Load C-RAM
// Configure Line Mode Registers
byte Status;
byte WSSData[3];
I2CReadBuffer(TVP5154A,0xC6,&Status,1); //read 1 byte(status)from register C6h
if ((Status & 0x20) == 1)
{
I2CReadBuffer(TVP5154A,0x94,&WSSData[0],3); // if WSS/CGMS bit set,
// read the 3 WSS/CGMS bytes
// at WSS/CGMS data registers 94h–96h.
I2CWriteByte(TVP5154A,0xC6,0x20); // clear WSS/CGMS available status bit
}
www.ti.com Sliced Data Retrieval
4 Sliced Data Retrieval
The TVP5154A provides dedicated I2C registers (see Table 4) for the retrieval of sliced data. Due to
higher bandwidth requirements, teletext data is stored in a 512-byte FIFO. With all other data services,
sliced data can be automatically sent to the dedicated registers or to the FIFO depending on the line mode
setup. The WSS/CGMS example in Figure 3 results in WSS/CGMS data being routed to the dedicated
WSS/CGMS data registers.
Table 4. Dedicated VDP Data Registers
Register Name I2C Address
VDP Closed Caption Data (field 1) 90h - 91h
VDP Closed Caption Data (field 2) 92h - 93h
VDP WSS/CGMS Data (field 1) 94h - 96h
VDP WSS/CGMS Data (field 2) 97h - 99h
VDP VPS (PAL) /Gemstar 2x (NTSC) 9Ah - A6h
Data
VDP VITC Data A7h - AFh
The internal 512-byte FIFO is used primarily for high-bandwidth teletext acquisition but can also be used
for capture of the other data services if enable in the Line Mode register. A header containing information
about the sliced data precedes all sliced data that is routed to the FIFO. The FIFO can be directly
accessed by the host at I2C address B0h. Bit 0 of the FIFO output control register (CDh) must be set to a
logic1 to enable host access to the FIFO.
5 Managing Data Retrieval
The VDP Status Registers (C6h) can be used to determine if sliced data is available. Unmasked data
available bits for the supported data services are available in this register.
VDP Status Register
Address C6h
76543210
FIFO full error FIFO empty TTX available CC field 1 CC field 2 WSS/CGMS VPS/Gemstar VITC available
available available available 2x available
A logic 1 indicates that sliced data is available. Once set, these bits need to be cleared after data retrieval. Writing a 1 to the appropriate
bit(s) in this register clears the status bit. Figure 4 shows an example WSS/CGMS data retrieval.
Figure 4. Example WSS/CGMS Data Retrieval
7
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

FIFO Access www.ti.com
6 FIFO Access
The internal 512-byte FIFO is used primarily for high-bandwidth teletext acquisition but can also be used
for capture of the other data services. The FIFO can be directly accessed by the host at I2C address B0h.
Bit 0 of the VDP FIFO output control register (CDh) must be set to logic 1 to enable host access to the
FIFO. A header containing information about the sliced data precedes all sliced data that is routed to the
FIFO. A VDP FIFO Interrupt threshold register (C8h), FIFO word count register (C7h), and FIFO full/empty
status bits (C6h) are available for managing FIFO data flow.
8TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Ancillary Data
7 Ancillary Data
An option is available to enable transmission of sliced VBI data as ancillary data in the ITU-R BT.656
video data stream. In this mode, the sliced data is inserted on the Y[7:0] output terminals during the
horizontal blanking interval. An 8-byte header containing information about the sliced data is also inserted
in the data stream prior to the sliced data. The header includes a 00h, FFh, FFh preamble that identifies
the data as VBI ancillary data, so the host or backend must be able to distinguish between this preamble
and the ITU-R BT.656 embedded sync codes (FFh, 00h, 00h, E/SAV). The first header byte is inserted
immediately following the EAV code during the horizontal blanking interval of the digital line where it
occurred. The ancillary data header is summarized in Table 5.
The ancillary data mode is enabled by setting bit 6 in the appropriate line-mode register to a logic 1 and
the host-access enable bit (bit 0) in register CDh to a logic 0. When the ancillary data mode is enabled in
register CDh, sliced data is not routed to the internal 512-byte FIFO.
Table 5. Ancillary Data Header
Byte No. D7 (MSB) D6 D5 D4 D3 D2 D1 D0 (LSB) Description
0 0 0 0 0 0 0 0 0 Ancillary data preamble
111111111
211111111
3 NEP EP 0 1 0 DID2 DID1 DID0 Data ID (DID)
4 NEP EP F5 F4 F3 F2 F1 F0 Secondary data ID (SDID)
5 NEP EP N5 N4 N3 N2 N1 N0 Number of 32 bit data (NN)
6 Video line # [7:0] Internal Data ID0 (IDID0)
7 0 0 0 Data error Match #1 Match #2 Video line # [9:8] Internal Data ID1 (IDID1)
8 1. Data Data byte 1st word
9 2. Data Data byte
10 3. Data Data byte
11 4. Data Data byte
... ... ...
m-1. Data Data byte Nth word
m. data Data byte
CS [7:0] Checksum
4N+7 0 0 0 0 0 0 0 0 Fill byte
EP: Even parity for D0-D5
NEP: Negate even parity
DID: 91h: Sliced data from the vertical blanking interval of first field
53h: Sliced data from outside of the vertical blanking interval of first field
55h: Sliced data from the vertical blanking interval of second field
97h: Sliced data from outside of the vertical blanking interval of second field
SDID: This field holds the data format taken from the line-mode register of the corresponding line.
NN: Number of Dwords beginning with byte 8 through 4N+7. Note that each Dword is 4 bytes.
IDID0: Transaction video line number [7:0]
IDID1: Bit Transaction video line number [9:8].
0/1:
Bit 2: Match 2 flag.
Bit 3: Match 1 flag.
Bit 4: Value = 1 if a single error was detected in the EDC block. Value = 0 if no error was detected.
CS: Sum of D0-D7 of 1.Data through last data byte.
Fill byte: Fill byte makes a multiple of 4 bytes from byte zero to last fill byte.
Note: The number of bytes (m) varies depending on the VBI data service.
9
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

Full-Field Mode www.ti.com
8 Full-Field Mode
Some teletext services transmit data on multiple video lines occurring anywhere in the video field. The
TVP5154A provides a full-field mode which arms VDP slicing for all lines in the video field. When full-field
mode is enabled, all video lines excluding those defined in the line-mode registers are sliced as specified
in the VDP full-field mode register (FCh). The full-field mode register uses the same mode configuration
format as the line-mode registers. Full-field mode is enabled by setting the full-field enable bit in register
CFh to a logic 1. Sliced data is then retrieved by I2C FIFO access or as ancillary data in the ITU-R BT.656
data stream.
9 VBI Raw Data Mode
The TVP5154A offers a VBI raw data mode for use in systems where VBI data slicing and processing is
handled in the digital backend receiver instead of the video decoder. In this mode of operation, the
decoders are configured to output raw 2x over-sampled luma data on the ITU-R BT.656 output during the
defined VBLK (vertical blanking) interval. The raw, un-sliced A/D video data is transmitted during the
active video portion of the line with chroma samples being replaced with the luma samples.
The default VBLK interval for Field 1 is defined as lines 1 through 20 for 525-line video formats and lines
623 through 23 for 625-line video formats. This interval may be adjusted to include additional lines.
Support for NTSC line 21 closed caption data, for example, requires extension of the VBLK interval to
include line 21.
The default VBLK interval for the TVP5154A is defined as lines 1 through 20 for 525-line video formats
and lines 623 through 23 for 625-line formats. The TVP5154A VBLK interval can be adjusted with the
VBLK Start and Stop registers (18h-19h). The TVP5154A VBLK Start and Stop registers provide relative
adjustments to the default VBLK interval. After configuring the desire VBLK interval, the Luma bypass (bit
4) in the Luminance Processing Control #1 register (07h) must be set to a logic 1 to enable raw data
output. Table 6 shows the default I2C registers with a modified VBLK interval for Line 21 inclusion, while
Table 7 shows the default 625-line setup. Also shown in Figure 5 and Figure 6 are digital captures of the
TVP5154A ITU-R BT.656 output for comparison of normal operation and raw data operation. Insertion of a
4-byte preamble (00h FFh FFh 60h) prior to the start of the raw data is optional in I2C register 07h.
Table 6. 525-Line Raw Data Setup to Include Line 21
I2C Subaddress Default I2C Data Description
07h 00h 10h Enable raw data (Luma bypass) and Preamble
18h 00h 00h VBLK Start = default line 1
19h 00h 01h VBLK Stop = default +1 to include line 21
Table 7. 625-Line Raw Data Setup
I2C Subaddress Default I2C Data Description
07h 00h 10h Enable raw data (Luma bypass) and Preamble
18h 00h 00h VBLK Start = default line 623
19h 00h 00h VBLK Stop = default
Note: Detailed descriptions of the TVP5154A I2C registers related to VBI Raw Data Mode are shown in
Appendix A.
Example (set up NTSC for raw data on lines 1 through 21)
1. Set up VBLK interval.
• Write 01h to register 19h to include line 21.
2. Enable Raw Data Mode
• Write 10h to register 07h to enable raw data mode.
10 TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

www.ti.com VBI Raw Data Mode
Figure 5. Line 21 Closed Caption ITU-R BT.656 Digital Output Capture with YUV Samples Present
Raw Data Mode disabled
Figure 6. Line 21 Closed Caption ITU-R BT.656 Digital Output Capture in Raw Data Mode
UV (chroma) data are replaced with Y (luma) data
Note: The full-scale transitions are embedded sync codes.
11
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

www.ti.com
Appendix A Subset of the TVP5154A VDP I2C Registers
VDP Closed Caption Data
Address 90h-93h
Read only
Address 7 6 5 4 3 2 1 0
90h Closed Caption Field 1 byte 1
91h Closed Caption Field 1 byte 2
92h Closed Caption Field 2 byte 1
93h Closed Caption Field 2 byte 2
These registers contain the closed caption data arranged in bytes per field.
VDP WSS/CGMS Data
Address 94h-99h
WSS/CGMS NTSC:
Read only
Address 7 6 5 4 3 2 1 0 Byte
94h b5 b4 b4 b2 b1 b0 WSS/CGMS Field 1 byte 1
95h b13 b12 b11 b10 b9 b8 b7 b6 WSS/CGMS Field 1 byte 2
96h b19 b18 b17 b16 b15 b14 WSS/CGMS Field 1 byte 3
97h b5 b4 b4 b2 b1 b0 WSS/CGMS Field 2 byte 1
98h b13 b12 b11 b10 b9 b8 b7 b6 WSS/CGMS Field 2 byte 2
99h b19 b18 b17 b16 b15 b14 WSS/CGMS Field 2 byte 3
These registers contain the wide screen signaling data for NTSC.
Bits 0 - 1 Represent word 0, aspect ratio
Bits 2 - 5 Represent word 1, header code for word 2
Bits 6 - 13 Represent word 2, copy control
Bits 14 - 19 Represent word 3, CRC
WSS/CGMS PAL/SECAM:
Read only
Address 7 6 5 4 3 2 1 0 Byte
94h b7 b6 b5 b4 b4 b2 b1 b0 WSS/CGMS Field 1 byte 1
95h b13 b12 b11 b10 b9 b8 WSS/CGMS Field 1 byte 2
96h Reserved
97h b7 b6 b5 b4 b4 b2 b1 b0 WSS/CGMS Field 2 byte 1
98h b11 b10 b9 b8 b7 b6 WSS/CGMS Field 2 byte 2
99h Reserved
These registers contain the wide screen signaling data for PAL/SECAM:
Bits 0 - 3 Represent group 1, aspect ratio
Bits 4 - 7 Represent group 2, enhanced services
Bits 8 - 10 Represent group 3, subtitles
Bits 11 - 13 Represent group 4, others
12 TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Appendix A
VDP VPS, EPG Data
Address 9Ah-A6h
VPS:
Read only
Address 7 6 5 4 3 2 1 0
9Ah VPS byte 1
9Bh VPS byte 2
9Ch VPS byte 3
9Dh VPS byte 4
9Eh VPS byte 5
9Fh VPS byte 6
A0h VPS byte 7
A1h VPS byte 8
A2h VPS byte 9
A3h VPS byte 10
A4h VPS byte 11
A5h VPS byte 12
A6h VPS byte 13
These registers contain the entire VPS data line except the clock run-in code or the frame code.
EPG:
Read Only
Address 7 6 5 4 3 2 1 0
9Ah EPG Frame Code
9Bh EPG byte 1
9Ch EPG byte 2
9Dh EPG byte 3
9Eh EPG byte 4
9Fh Reserved
A0h Reserved
A1h Reserved
A2h Reserved
A3h Reserved
A4h Reserved
A5h Reserved
A6h Reserved
VDP VITC Data
Address A7h-AFh
Read only
Address 7 6 5 4 3 2 1 0
A7h VITC Frame byte 1
A8h VITC Frame byte 2
A9h VITC Seconds byte 1
AAh VITC Seconds byte 2
ABh VITC Minutes byte 1
ACh VITC Minutes byte 2
ADh VITC Hours byte 1
AEh VITC Hours byte 2
AFh VITC CRC byte
These registers contain the VITC data.
13
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

Appendix A www.ti.com
VDP FIFO Read Data
Address B0h
Read only
76543210
FIFO read data [7:0]
FIFO read data [7:0]: This register is provided to access VBI FIFO data through the host port. All forms of teletext data come directly from
the FIFO, while all other forms of VBI data can be programmed to come from registers or from the FIFO. Current status of the FIFO can be
found at address C6h and the number of bytes in the FIFO is located at address C7h. If the host port is to be used to read data from the
FIFO, the FIFO output control register CDh bit 0 must be set to 1.
VDP Configuration RAM Register
Address C3h-C5h
Address 7 6 5 4 3 2 1 0
C3h Configuration data
C4h RAM address [7:0]
C5h Reserved RAM
address 8
The configuration RAM data is provided to initialize the VDP with initial constants. The configuration RAM is 512 bytes organized as 32
different configurations of 16 bytes each. The first 12 configurations are defined for the current VBI standards. An additional 2 configurations
can be used as a custom programmed mode for unique standards like Gemstar.
Address C3h is used to read or write to the RAM. The RAM internal address counter is automatically incremented with each transaction.
Addresses C5h and C4h make up a 9-bit address to load the internal address counter with a specific start address. This can be used to
write a subset of the RAM for only those standards of interest. Registers D0h-FBh must all be programmed with FFh, before writing or
reading the configuration RAM. Full field mode (CFh) must be disabled as well.
14 TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Appendix A
VDP Status
Address C6h
Read only
76543210
FIFO full FIFO TTX CC field 1 CC field 2 WSS/CGMS VPS/Gemstar VITC
error empty available available available available 2x available available
The VDP status register indicates whether data is available in either the FIFO or data registers, and status information about the FIFO.
Reading data from the corresponding register does not clear the status flags automatically. These flags are only reset by writing a 1 to the
respective bit. However, bit 6 is updated automatically.
FIFO full error:
0 No FIFO full error
1 FIFO was full during a write to FIFO.
The FIFO full error flag is set when the current line of VBI data can not enter the FIFO. For example, if the FIFO has only 10 bytes left and
teletext is the current VBI line, the FIFO full error flag is set, but no data is written because the entire teletext line will not fit. However, if the
next VBI line is closed caption requiring only 2 bytes of data plus the header, this goes into the FIFO. Even if the full error flag is set.
FIFO empty:
0 FIFO is not empty.
1 FIFO is empty.
TTX available:
0 Teletext data is not available.
1 Teletext data is available.
CC field 1 available:
0 Closed caption data from field 1 is not available.
1 Closed caption data from field 1 is available.
CC field 2 available:
0 Closed caption data from field 2 is not available.
1 Closed caption data from field 2 is available.
WSS/CGMS available:
0 WSS/CGMS data is not available.
1 WSS/CGMS data is available.
VPS/Gemstar 2x available:
0 VPS/Gemstar 2x data is not available.
1 VPS/Gemstar 2x data is available.
VITC available:
0 VITC data is not available.
1 VITC data is available.
VDP FIFO Word Count
Address C7h
76543210
Number of words
This register provides the number of words in the FIFO. 1 word equals 2 bytes.
VDP FIFO Interrupt Threshold
Address C8h
76543210
Number of words
This register is programmed to trigger an interrupt when the number of words in the FIFO exceeds this value (default 80h). This interrupt
must be enabled at address C1h. 1 word equals 2 bytes.
15
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

Appendix A www.ti.com
VDP FIFO Reset
Address C9h
76543210
Any data
Writing any data to this register resets the FIFO and clears any data present.
VDP Line Number Interrupt
Address CAh
76543210
Field 1 Field 2 Line number
enable enable
This register is programmed to trigger an interrupt when the video line number matches this value in bits 5:0. This interrupt must be enabled
at address C1h. The value of 0 or 1 does not generate an interrupt.
Field 1 enable:
0 Disabled (default)
1 Enabled
Field 2 enable:
0 Disabled (default)
1 Enabled
Line number: (default 00h)
VDP Pixel Alignment
Address CBh-CCh
Address 7 6 5 4 3 2 1 0
CBh Switch pixel [7:0]
CCh Reserved Switch pixel [9:8]
These registers form a 10-bit horizontal pixel position from the falling edge of sync, where the VDP controller initiates the program from one
line standard to the next line standard. For example, the previous line of teletext to the next line of closed caption. This value must be set
so that the switch occurs after the previous transaction has cleared the delay in the VDP, but early enough to allow the new values to be
programmed before the current settings are required.
VDP FIFO Output Control
Address CDh
Default (00h)
7654321 0
Reserved Host access enable
Host access enable:
This register is programmed to allow host port access to the FIFO or allow all VDP data to go out the video port.
0 Output FIFO data to the video output Y[7:0]
1 Allow host port access to the FIFO data (default)
16 TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Appendix A
VDP Full-Field Enable
Address CFh
Default (00h)
76543210
Reserved Full field enable
Full field enable:
0 Disable full field mode (default)
1 Enable full field mode
This register enables the full-field mode. In this mode, all lines outside the vertical blank area and all lines in the line-mode register
programmed with FFh are sliced with the definition of register FCh. Values other than FFh in the line-mode registers allow a different slice
mode for that particular line.
17
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

Appendix A www.ti.com
VDP Line Mode
Address D0h-FBh
Read only
Address 7 6 5 4 3 2 1 0
D0h Line 6 Field 1
D1h Line 6 Field 2
D2h Line 7 Field 1
D3h Line 7 Field 2
D4h Line 8 Field 1
D5h Line 8 Field 2
D6h Line 9 Field 1
D7h Line 9 Field 2
D8h Line 10 Field 1
D9h Line 10 Field 2
DAh Line 11 Field 1
DBh Line 11 Field 2
DCh Line 12 Field 1
DDh Line 12 Field 2
DEh Line 13 Field 1
DFh Line 13 Field 2
E0h Line 14 Field 1
E1h Line 14 Field 2
E2h Line 15 Field 1
E3h Line 15 Field 2
E4h Line 16 Field 1
E5h Line 16 Field 2
E6h Line 17 Field 1
E7h Line 17 Field 2
E8h Line 18 Field 1
E9h Line 18 Field 2
EAh Line 19 Field 1
EBh Line 19 Field 2
ECh Line 20 Field 1
EDh Line 20 Field 2
EEh Line 21 Field 1
EFh Line 21 Field 2
F0h Line 22 Field 1
F1h Line 22 Field 2
F2h Line 23 Field 1
F3h Line 23 Field 2
F4h Line 24 Field 1
F5h Line 24 Field 2
F6h Line 25 Field 1
F7h Line 25 Field 2
F8h Line 26 Field 1
F9h Line 26 Field 2
FAh Line 27 Field 1
FBh Line 27 Field 2
18 TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Appendix A
(continued)
These registers program the specific VBI standard at a specific line in the video field.
Bit 7:
0 Disable filtering of null bytes in closed caption modes
1 Enable filtering of null bytes in closed caption modes (default)
In teletext modes, bit 7 enables the data filter function for that particular line. If it is set to 0, then the data filter passes all data on that line.
Bit 6:
0 Send VBI data to registers only.
1 Send VBI data to FIFO and the registers. Teletext data only goes to FIFO. (default)
Bit 5:
0 Allow VBI data with errors in the FIFO
1 Do not allow VBI data with errors in the FIFO (default)
Bit 4:
0 Do not enable error detection and correction
1 Enable error detection and correction (when bits [3:0] = 1 2, 3, and 4 only) (default)
Bits [3:0]:
0000 WST SECAM
0001 WST PAL B
0010 WST PAL C
0011 WST NTSC
0100 NABTS NTSC
0101 TTX NTSC
0110 CC PAL
0111 CC NTSC
1000 WSS/CGMS-A PAL
1001 WSS/CGMS NTSC
1010 VITC PAL
1011 VITC NTSC
1100 VPS PAL
1101 Gemstar 2x Custom 1
1110 Custom 2
1111 Active video (VDP off) (default)
A value of FFh in the line mode registers is required for any line to be sliced as part of the full field mode.
VDP Full-Field Enable
Address FCh
Default (7Fh)
76543210
Full field mode [7:0]
Full field mode [7:0]: This register programs the specific VBI standard for full-field mode. It can be any VBI standard. Individual line settings
take priority over the full-field register. This allows each VBI line to be programmed independently but have the remaining lines in full-field
mode. The full-field mode register has the same bits definition as line-mode registers. (default 7Fh)
19
SLEA104–July 2010 TVP5154A VBI Quick Start
Copyright © 2010, Texas Instruments Incorporated

/////////////////////////////////////////////////////////////////////////////////////////
////////////////////////////////////////////////////////
// These commands can be used with the WinVCC4 EVM software to configure the Line Mode
// registers for a typical NTSC VBI setup.
// The WR_REG commands are direct writes to the I2C registers.
// Each command shown writes 1 byte to the I2C address
// specified in the command line.
BEGIN_DATASET
DATASET_NAME,"TVP5154A NTSC VDP/VBI SETUP"
INCLUDE, VDPRegsIdle.inc // Set VDP registers to their default state
INCLUDE, SlicerRAM_601.inc // Load VDP configuration RAM
WR_REG,VID_DEC,0x01,0xD8,0x44 // Line10 (Field 1)-TTX NTSC
WR_REG,VID_DEC,0x01,0xD9,0x44 // Line10 (Field 2)-TTX NTSC
WR_REG,VID_DEC,0x01,0xE0,0x0B // Line14 (Field 1)-VITC NTSC
WR_REG,VID_DEC,0x01,0xE1,0x0B // Line14 (Field 2)-VITC NTSC
WR_REG,VID_DEC,0x01,0xEC,0x09 // Line20 (Field 1)-WSS/CGMS NTSC
WR_REG,VID_DEC,0x01,0xED,0x09 // Line20 (Field 2)-WSS/CGMS NTSC
WR_REG,VID_DEC,0x01,0xEE,0x07 // Line21 (Field 1)-CC NTSC
WR_REG,VID_DEC,0x01,0xEF,0x07 // Line21 (Field 2)-CC NTSC
WR_REG,VID_DEC,0x01,0xCD,0x01 // Enable FIFO access, disable ANC data
WR_REG,VID_DEC,0x01,0xCB,0x4E // Set Pixel Alignment [7:0] to 4Eh
WR_REG,VID_DEC,0x01,0xCC,0x00 // Set Pixel Alignment [9:8] to 0
END_DATASET
/////////////////////////////////////////////////////////////////////////////////////////
///////////////////////////////////////////////////////
// These commands can be used with the WinVCC4 EVM software to configure the Line Mode
// registers for a typical PAL VBI setup. For PAL systems, the Line Mode register has
// a +3 line offset relative to the actual line number. Each command shown writes
// 1 byte to the I2C address specified in the command line.
/////////////////////////////////////////////////////////////////////////////////////////
//////////////////////////////////////////////////////////
BEGIN_DATASET
DATASET_NAME,"TVP5154A PAL VDP/VBI SETUP"
INCLUDE, VDPRegsIdle.inc // Set VDP registers to their default FFh state
INCLUDE, SlicerRAM_601.inc // Load VDP configuration RAM
WR_REG,VID_DEC,0x01,0xD8,0x41 // Line10 (Field 1)-TTX-B PAL(Line7)
WR_REG,VID_DEC,0x01,0xD9,0x41 // Line10 (Field 2)-TTX-B PAL (Line7
WR_REG,VID_DEC,0x01,0xEA,0x0C // Line19 (Field 1)-VPS PAL (Line 16)
WR_REG,VID_DEC,0x01,0xEB,0x0C // Line19 (Field 2)-VPS PAL (Line 16)
WR_REG,VID_DEC,0x01,0xF0,0x0A // Line22 (Field 1)-VITC PAL(Line 19)
WR_REG,VID_DEC,0x01,0xF1,0x0A // Line22 (Field 2)-VITC PAL(Line 19)
WR_REG,VID_DEC,0x01,0xF6,0x06 // Line25 (Field 1)-CC PAL(Line 22)
WR_REG,VID_DEC,0x01,0xF7,0x06 // Line25 (Field 2)-CC PAL(Line 22)
WR_REG,VID_DEC,0x01,0xF8,0x08 // Line26 (Field 1)-WSS/CGMS PAL(Line 23)
WR_REG,VID_DEC,0x01,0xF9,0x08 // Line26 (Field 2)-WSS/CGMS PAL(Line 23)
WR_REG,VID_DEC,0x01,0xCD,0x01 // Enable FIFO access, disable ANC data
WR_REG,VID_DEC,0x01,0xCB,0x4E // Set Pixel Alignment [7:0] to 4Eh
WR_REG,VID_DEC,0x01,0xCC,0x00 // Set pixel Alignment [9:8] to 0
END_DATASET
/////////////////////////////////////////////////////////////////////////////////////////
///////////////////////////////////////////////////////
www.ti.com
Appendix B Sample WinVCC CMD File for VBI Setup
20 TVP5154A VBI Quick Start SLEA104–July 2010
Copyright © 2010, Texas Instruments Incorporated
