1 Introduction
The LP87524B/J/P-Q1 contains four step-down DC/DC converter cores, which are configured as 4 single
phase outputs. These devices power AWR1642 and AWR1243 automotive radar devices and IWR1642
industrial radar devices.
This technical reference manual can be used as a reference for the LP87524B/J/P-Q1 default register bits
after OTP memory download. This technical reference manual does not provide information about the
electrical characteristics, external components, package, or the functionality of the device. For this
information and the full register map, refer to the LP87524B/J/P-Q1 Four 4-MHz Buck Converters for AWR
and IWR MMICs datasheet.
2 Setup
There are a few important connections to ensure the LP87524B/J/P-Q1 is configured correctly, each of
which are described in this section. Good examples of how to connect the radar devices to the
LP87524B/J/P-Q1 PMICs are shown in Figure 1,Figure 2 and Figure 3. LDOs are not required as the
device meets noise and ripple specifications with LC filters. Refer to XWR1xxx Power Management
Optimizations – Low Cost LC Filter Solution application report.
Figure 1. Typical Connection to LP87524B-Q1
Figure 2. Typical Connection to LP87524J-Q1

LC Filter
LC Filter AWR1243LP87524P-Q1
Copyright © 2019, Texas Instruments Incorporated
1.0 V
1.2 V
1.0 V
I2C from host
LC Filter
LDO / Load Switch
GPIO2
3.3 V / 5 V
LC Filter
LC Filter
LC Filter
3.3 V
Flash
AWR1243
Flash
www.ti.com Setup
3
SNVU663–June 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Figure 3. Typical Connection to LP87524P-Q1
2.1 SCL/SDA Pins
The SCL and SDA lines (pins 5 & 6, respectively) are used to communicate between the MCU and the
LP87524B/J/P-Q1 PMIC using an I2C compatible Interface. The I2C compatible synchronous serial
interface provides access to the programmable functions and registers on the device. This protocol uses a
two-wire interface for bidirectional communications between the IC's connected to the bus. The two
interface lines are the serial data line (SDA), and the serial clock line (SCL). Every device on the bus is
assigned a unique address and acts as either a master or a slave depending on whether it generates or
receives the serial clock SCL. The SCL and SDA lines must each have a pullup resistor placed on the line
and remain HIGH even when the bus is idle. The LP87524B/J/P-Q1 supports standard mode (100 kHz),
fast mode (400 kHz), fast mode plus (1 MHz), and high-speed mode (3.4 MHz). For all I2C protocol details
refer to the device datasheet.
2.2 NRST Pin
The NRST pin (pin 20) is used to reset the device logic/enable device internal logic and IO interface.
When the NRST voltage is below threshold level all power switches, references, controls, and bias
circuitry of the LP87524B/J/P-Q1 device are turned off. When NRST is set to high level (and VANA is
above UVLO level) this initiates power-on-reset (POR), OTP reading and enables the system I/O interface.
The I2C host must allow at least 1.2 ms before writing or reading data to the LP87524B/J/P-Q1. Device
enters STANDBY-mode after internal startup sequence. The host can change the default register setting
by I2C if needed. The regulator(s) can be enabled/disabled by ENx pin(s) or by I2C interface.
2.3 ENx (GPIOx) Pins
Enable pins EN1 (GPIO1), EN2 (GPIO2), EN3 (GPIO3) (pins 7, 15, 2) are I2C configurable GPIO pins.
The direction, function, and output type (open-drain or push-pull) are programmable for the GPIOs. When
configured as EN pin, they can be used to start the buck converter startup sequence based on
programmed timing. Shutdown times can be programmed as well. Drive these pins low to disable and high
to enable when programmed as enable signal.
2.4 nINT
The nINT pin (pin 19) is an open-drain, active low output from the LP87524B/J/P-Q1 PMIC, and should be
connected to a pullup resistor. After a power-on reset the LP87524B/J/P-Q1 PMIC requires a delay of 1.2
ms before there can be any communication through the I2C interface.

Configuration www.ti.com
4SNVU663–June 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
3 Configuration
This section describes the default OTP settings.
3.1 Default OTP Configurations
All LP87524B/J/P-Q1 PMIC resource settings are stored in the form of volatile registers. These settings
define, for example, buck output voltages, GPIO functionality, and power-up and power-down sequences.
Refer to the datasheet for a full list of the setting registers.
Each device has predefined values stored in OTP which control the default configuration of the device.
The tables in this section list the OTP-programmed values for each device.
Table 1 summarizes the main differences between the three OTP versions. Table 2 shows LP87524B-Q1,
Table 8 shows LP87524J-Q1 and Table 14 shows LP87524P-Q1 settings for BUCK0, BUCK1, BUCK2
and BUCK3. Maximum allowed slew-rate for BUCKx depends on the output capacitance. Refer to the
device datasheets for output capacitance boundary conditions.
Table 1. Differences between LP87524B/J/P-Q1 devices
Description Bit name LP87524B-Q1 LP87524J-Q1 LP87524P-Q1
Output voltage
BUCK0_VSET 3300 mV 3300 mV 1000 mV
BUCK1_VSET 1200 mV 1200 mV 1200 mV
BUCK2_VSET 1800 mV 1000 mV 1000 mV
BUCK3_VSET 2300 mV 1800 mV 1800 mV
Peak current limit
ILIM0 2.5 A 2.5 A 4 A
ILIM1 2.5 A 2.5 A 2.5 A
ILIM2 5 A 5 A 4 A
ILIM3 3.5 A 3.5 A 3.5 A
Force PWM mode or auto mode
BUCK0_FPWM Auto Auto Force PWM
BUCK1_FPWM Auto Auto Force PWM
BUCK2_FPWM Force PWM Force PWM Force PWM
BUCK3_FPWM Force PWM Force PWM Force PWM
Startup and shutdown delay range DOUBLE_DELAY, HALF_DELAY 0 ... 15 ms 0 ... 15 ms 0 ... 4.8 ms
Buck Startup Delays
BUCK0_STARTUP_DELAY 5 ms 5 ms 0.96 ms
BUCK1_STARTUP_DELAY 5 ms 5 ms 2.24 ms
BUCK2_STARTUP_DELAY 2 ms 2 ms 1.6 ms
BUCK3_STARTUP_DELAY 0 ms 0 ms 0 ms
Buck Shutdown Delays
BUCK0_SHUTDOWN_DELAY 0 ms 0 ms 0.32 ms
BUCK1_SHUTDOWN_DELAY 0 ms 0 ms 0.32 ms
BUCK2_SHUTDOWN_DELAY 0 ms 0 ms 0.32 ms
BUCK3_SHUTDOWN_DELAY 1 ms 1 ms 0.32 ms
GPIO2/3 Startup Delays GPIO2_STARTUP_DELAY 5 ms 5 ms 2.88 ms
GPIO3_STARTUP_DELAY 3 ms 3 ms 4.16 ms
GPIO2/3 Shutdown Delay GPIO2_SHUTDOWN_DELAY 0 ms 0 ms 0.32 ms
GPIO3_SHUTDOWN_DELAY 0 ms 0 ms 0 ms
GPIO output type GPIO1_OD Push-pull Push-pull Open drain GPIO2_OD Open drain Open drain Open drain
GPIO3_OD Open drain Open drain Open drain
Input or output in GPIO mode GPIO1_DIR Input Input Output GPIO2_DIR Output Output Output
GPIO3_DIR Output Output Output
Thermal warning level (125°C or
137°C) TDIE_WARN_LEVEL 137°C 137°C 125°C

www.ti.com Configuration
5
SNVU663–June 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
3.1.1 LP87524B-Q1 OTP Configuration
Table 2. BUCK0, BUCK1, BUCK2, BUCK3 OTP Settings
Description Bit Name LP87524B-Q1 Configurable
General settings
Buck phase configuration (e.g. four single
phase denoted as 1+1+1+1, four phase
single output denoted as 4 ph). N/A 1+1+1+1 No
Switching frequency N/A 4 MHz No
Spread spectrum EN_SPREAD_SPEC No Yes
Startup and shutdown delay range,
0...4.8 ms / 0... 9.6 ms / 0...15 ms / 0...30
ms DOUBLE_DELAY, HALF_DELAY 0...15 ms Yes
BUCK0
Output voltage BUCK0_VSET 3300 mV Yes
Enable, ENx-pin or I2C register EN_BUCK0, EN_PIN_CTRL0,
BUCK0_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK0_FPWM auto Yes
Force multiphase mode or auto mode BUCK0_FPWM_MP auto Yes
Peak current limit ILIM0 2.5 A Yes
Slew rate SLEW_RATE0 3.8 mV/µs Yes
Startup Delay BUCK0_STARTUP_DELAY 5 ms Yes
Shutdown Delay BUCK0_SHUTDOWN_DELAY 0 ms Yes
BUCK1
Output voltage BUCK1_VSET 1200 mV Yes
Enable, EN-pin or I2C register EN_BUCK1, EN_PIN_CTRL1,
BUCK1_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK1_FPWM auto Yes
Peak current limit ILIM1 2.5 A Yes
Slew rate SLEW_RATE1 3.8 mV/µs Yes
Startup Delay BUCK1_STARTUP_DELAY 5 ms Yes
Shutdown Delay BUCK1_SHUTDOWN_DELAY 0 ms Yes
BUCK2
Output voltage BUCK2_VSET 1800 mV Yes
Enable, ENx-pin or I2C register EN_BUCK2, EN_PIN_CTRL2,
BUCK2_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK2_FPWM Force PWM Yes
Force multiphase mode or auto mode BUCK2_FPWM_MP auto Yes
Peak current limit ILIM2 5 A Yes
Slew rate SLEW_RATE2 3.8 mV/µs Yes
Startup Delay BUCK2_STARTUP_DELAY 2 ms Yes
Shutdown Delay BUCK2_SHUTDOWN_DELAY 0 ms Yes
BUCK3
Output voltage BUCK3_VSET 2300 mV Yes
Enable, EN-pin or I2C register EN_BUCK3, EN_PIN_CTRL3,
BUCK3_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK3_FPWM Force PWM Yes
Peak current limit ILIM3 3.5 A Yes
Slew rate SLEW_RATE3 3.8 mV/µs Yes
Startup Delay BUCK3_STARTUP_DELAY 0 ms Yes
Shutdown Delay BUCK3_SHUTDOWN_DELAY 1 ms Yes
Table 3 lists the device settings for GPIOs.
Table 3. EN, CLKIN and GPIO Pin Settings
Description Bit Name LP87524B-Q1 Configurable
EN1 (GPIO1) pin EN1 (GPIO1) pin pulldown resistor enable
or disable EN1_PD Enabled Yes
EN2 (GPIO2) pin EN2 (GPIO2) pin pulldown resistor enable
or disable EN2_PD Disabled Yes
EN3 (GPIO3) pin EN3 (GPIO3) pin pulldown resistor enable
or disable EN3_PD Disabled Yes

Configuration www.ti.com
6SNVU663–June 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Table 3. EN, CLKIN and GPIO Pin Settings (continued)
Description Bit Name LP87524B-Q1 Configurable
CLKIN pin
CLKIN pin pull-down resistor enable or
disable CLKIN_PD Enabled Yes
Frequency of external clock when
connected to CLKIN EXT_CLK_FREQ 2 MHz Yes
Mode for the internal PLL. When PLL
disabled, internal RC OSC is used PLL_MODE[1:0] Enabled Yes
EN1 (GPIO) control
Enable or GPIO GPIO1_SEL Enable Yes
Input or output in GPIO mode GPIO1_DIR Input Yes
Output type open drain or push-pull GPIO1_OD Push-pull Yes
EN2 (GPIO) control
Enable or GPIO GPIO2_SEL GPIO Yes
Input or output in GPIO mode GPIO2_DIR Output Yes
Output type open drain or push-pull GPIO2_OD Open drain Yes
Pin control of GPIO, EN1 or EN3 EN_PIN_CTRL_GPIO2,
EN_PIN_SELECT_GPIO2 EN1 Yes
Startup Delay GPIO2_STARTUP_DELAY 5 ms Yes
Shutdown Delay GPIO2_SHUTDOWN_DELAY 0 ms Yes
EN3 (GPIO) control
Enable or GPIO GPIO3_SEL GPIO Yes
Input or output in GPIO mode GPIO3_DIR Output Yes
Output type open drain or push-pull GPIO3_OD Open drain Yes
Pin control of GPIO, EN1 or EN2 EN_PIN_CTRL_GPIO3,
EN_PIN_SELECT_GPIO3 EN1 Yes
Startup Delay GPIO3_ STARTUP_ DELAY 3 ms Yes
Shutdown Delay GPIO3_ SHUTDOWN_ DELAY 0 ms Yes
Table 4 shows device settings for PGOOD.
Table 4. PGOOD OTP Settings
Description Bit Name LP87524B-Q1 Configurable
Signals monitored
by PGOOD BUCKx output voltage / voltage and current (master bucks) PGx_SEL Voltage Yes
PGOOD mode
selections
PGOOD thresholds for BUCKx
(Undervoltage / Window (undervoltage
and overvoltage)) PGOOD_WINDOW Window Yes
PGOOD valid debounce time PGOOD_SET_DELAY 11 ms Yes
PGOOD signal mode (status / latched
until fault source read) EN_PGFLT_STAT Status Yes
PGOOD output mode (push-pull or open
drain) PGOOD_OD Open drain Yes
PGOOD polarity (active high / active low) PGOOD_POL Active high (power
valid) Yes
Table 5 lists the device settings for thermal warning. Also refer to Table 7 for interrupt settings.
Table 5. Protections OTP Settings
Description Bit Name LP87524B-Q1 Configurable
Protections Thermal warning level (125°C or 137°C) TDIE_WARN_LEVEL 137°C Yes
Input over-voltage protection N/A Enabled No
Table 6 shows device settings for I2C and OTP revision ID values.
Table 6. Device Identification and I2C Settings
Description Bit Name LP87524B-Q1 Configurable
I2C slave ID (7-bit) Slave address N/A 0x60 No

www.ti.com Configuration
7
SNVU663–June 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Table 7 lists device settings for interrupts. When interrupt from an event is unmasked, an interrupt is
generated to nINT pin.
Table 7. Interrupt Mask Settings
Interrupt event Bit Name LP87524B-Q1 Configurable
General
Sync clock appears or disappears SYNC_CLK_MASK Unmasked Yes
Thermal warning TDIE_WARN_MASK Unmasked Yes
Load measurement ready I_LOAD_READY_MASK Masked Yes
Register reset RESET_REG_MASK Masked Yes
BUCK0 Buck0 PGOOD has reached threshold
level BUCK0_PG_MASK Masked Yes
Buck0 current limit triggered BUCK0_ILIM_MASK Masked Yes
BUCK1 Buck1 PGOOD has reached threshold
level BUCK1_PG_MASK Masked Yes
Buck1 current limit triggered BUCK1_ILIM_MASK Masked Yes
BUCK2 Buck2 PGOOD has reached threshold
level BUCK2_PG_MASK Masked Yes
Buck2 current limit triggered BUCK2_ILIM_MASK Masked Yes
BUCK3 Buck3 PGOOD has reached threshold
level BUCK3_PG_MASK Masked Yes
Buck3 current limit triggered BUCK3_ILIM_MASK Masked Yes
3.1.1.1 Startup and Shutdown Sequence
Each of the bucks and GPOs on the LP87524B/J/P-Q1 can be set to startup and shutdown in a specific
sequence. To configure the desired sequence the STARTUP_DELAY and SHUTDOWN_DELAY fields for
each output need to be set to a value between 0x0 and 0xF. The delay time that this value corresponds to
depends on the DOUBLE_DELAY bit and the HALF_DELAY bit located in the CONFIG register. A value
of 0 on both of these bits will allow a delay ranging from 0 ms to 15 ms with 1 ms steps. Figure 4 shows
default startup and shutdown sequence programmed to OTP, in this case with EN1 signal. Refer to the
datasheet for a full description of all registers and their settings.

BUCK2
BUCK1
BUCK0
EN1
BUCK3
GPIO2
DOUBLE_DELAY = 0 HALF_DELAY = 0
GPIO3
5 ms
5 ms
5 ms
2 ms
3 ms
1 ms
Configuration www.ti.com
8SNVU663–June 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Figure 4. LP87524B-Q1 Startup and Shutdown Sequence Timing Diagram
3.1.2 LP87524J-Q1 OTP Configuration
Table 8. BUCK0, BUCK1, BUCK2, BUCK3 OTP Settings
Description Bit Name LP87524J-Q1 Configurable
General settings
Buck phase configuration (e.g. four single
phase denoted as 1+1+1+1, four phase
single output denoted as 4 ph). N/A 1+1+1+1 No
Switching frequency N/A 4 MHz No
Spread spectrum EN_SPREAD_SPEC No Yes
Startup and shutdown delay range,
0...4.8 ms / 0... 9.6 ms / 0...15 ms / 0...30
ms DOUBLE_DELAY, HALF_DELAY 0...15 ms Yes
BUCK0
Output voltage BUCK0_VSET 3300 mV Yes
Enable, ENx-pin or I2C register EN_BUCK0, EN_PIN_CTRL0,
BUCK0_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK0_FPWM auto Yes
Force multiphase mode or auto mode BUCK0_FPWM_MP auto Yes
Peak current limit ILIM0 2.5 A Yes
Slew rate SLEW_RATE0 3.8 mV/µs Yes
Startup Delay BUCK0_STARTUP_DELAY 5 ms Yes
Shutdown Delay BUCK0_SHUTDOWN_DELAY 0 ms Yes
BUCK1
Output voltage BUCK1_VSET 1200 mV Yes
Enable, EN-pin or I2C register EN_BUCK1, EN_PIN_CTRL1,
BUCK1_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK1_FPWM auto Yes
Peak current limit ILIM1 2.5 A Yes
Slew rate SLEW_RATE1 3.8 mV/µs Yes
Startup Delay BUCK1_STARTUP_DELAY 5 ms Yes
Shutdown Delay BUCK1_SHUTDOWN_DELAY 0 ms Yes

www.ti.com Configuration
9
SNVU663–June 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Table 8. BUCK0, BUCK1, BUCK2, BUCK3 OTP Settings (continued)
Description Bit Name LP87524J-Q1 Configurable
BUCK2
Output voltage BUCK2_VSET 1000 mV Yes
Enable, ENx-pin or I2C register EN_BUCK2, EN_PIN_CTRL2,
BUCK2_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK2_FPWM Force PWM Yes
Force multiphase mode or auto mode BUCK2_FPWM_MP auto Yes
Peak current limit ILIM2 5 A Yes
Slew rate SLEW_RATE2 3.8 mV/µs Yes
Startup Delay BUCK2_STARTUP_DELAY 2 ms Yes
Shutdown Delay BUCK2_SHUTDOWN_DELAY 0 ms Yes
BUCK3
Output voltage BUCK3_VSET 1800 mV Yes
Enable, EN-pin or I2C register EN_BUCK3, EN_PIN_CTRL3,
BUCK3_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK3_FPWM Force PWM Yes
Peak current limit ILIM3 3.5 A Yes
Slew rate SLEW_RATE3 3.8 mV/µs Yes
Startup Delay BUCK3_STARTUP_DELAY 0 ms Yes
Shutdown Delay BUCK3_SHUTDOWN_DELAY 1 ms Yes
Table 9 lists the device settings for GPIOs.
Table 9. EN, CLKIN and GPIO Pin Settings
Description Bit Name LP87524J-Q1 Configurable
EN1 (GPIO1) pin EN1 (GPIO1) pin pulldown resistor enable
or disable EN1_PD Enabled Yes
EN2 (GPIO2) pin EN2 (GPIO2) pin pulldown resistor enable
or disable EN2_PD Disabled Yes
EN3 (GPIO3) pin EN3 (GPIO3) pin pulldown resistor enable
or disable EN3_PD Disabled Yes
CLKIN pin
CLKIN pin pull-down resistor enable or
disable CLKIN_PD Enabled Yes
Frequency of external clock when
connected to CLKIN EXT_CLK_FREQ 2 MHz Yes
Mode for the internal PLL. When PLL
disabled, internal RC OSC is used PLL_MODE[1:0] Enabled Yes
EN1 (GPIO) control
Enable or GPIO GPIO1_SEL Enable Yes
Input or output in GPIO mode GPIO1_DIR Input Yes
Output type open drain or push-pull GPIO1_OD Push-pull Yes
EN2 (GPIO) control
Enable or GPIO GPIO2_SEL GPIO Yes
Input or output in GPIO mode GPIO2_DIR Output Yes
Output type open drain or push-pull GPIO2_OD Open drain Yes
Pin control of GPIO, EN1 or EN3 EN_PIN_CTRL_GPIO2,
EN_PIN_SELECT_GPIO2 EN1 Yes
Startup Delay GPIO2_STARTUP_DELAY 5 ms Yes
Shutdown Delay GPIO2_SHUTDOWN_DELAY 0 ms Yes
EN3 (GPIO) control
Enable or GPIO GPIO3_SEL GPIO Yes
Input or output in GPIO mode GPIO3_DIR Output Yes
Output type open drain or push-pull GPIO3_OD Open drain Yes
Pin control of GPIO, EN1 or EN2 EN_PIN_CTRL_GPIO3,
EN_PIN_SELECT_GPIO3 EN1 Yes
Startup Delay GPIO3_ STARTUP_ DELAY 3 ms Yes
Shutdown Delay GPIO3_ SHUTDOWN_ DELAY 0 ms Yes
Table 10 shows device settings for PGOOD.

Configuration www.ti.com
10 SNVU663–June 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Table 10. PGOOD OTP Settings
Description Bit Name LP87524J-Q1 Configurable
Signals monitored
by PGOOD BUCKx output voltage / voltage and current (master bucks) PGx_SEL Voltage Yes
PGOOD mode
selections
PGOOD thresholds for BUCKx
(Undervoltage / Window (undervoltage
and overvoltage)) PGOOD_WINDOW Window Yes
PGOOD valid debounce time PGOOD_SET_DELAY 11 ms Yes
PGOOD signal mode (status / latched
until fault source read) EN_PGFLT_STAT Status Yes
PGOOD output mode (push-pull or open
drain) PGOOD_OD Open drain Yes
PGOOD polarity (active high / active low) PGOOD_POL Active high (power
valid) Yes
Table 11 lists the device settings for thermal warning. Also refer to Table 13 for interrupt settings.
Table 11. Protections OTP Settings
Description Bit Name LP87524J-Q1 Configurable
Protections Thermal warning level (125°C or 137°C) TDIE_WARN_LEVEL 137°C Yes
Input over-voltage protection N/A Enabled No
Table 12 shows device settings for I2C and OTP revision ID values.
Table 12. Device Identification and I2C Settings
Description Bit Name LP87524J-Q1 Configurable
I2C slave ID (7-bit) Slave address N/A 0x60 No
Table 13 lists device settings for interrupts. When interrupt from an event is unmasked, an interrupt is
generated to nINT pin.
Table 13. Interrupt Mask Settings
Interrupt event Bit Name LP87524J-Q1 Configurable
General
Sync clock appears or disappears SYNC_CLK_MASK Unmasked Yes
Thermal warning TDIE_WARN_MASK Unmasked Yes
Load measurement ready I_LOAD_READY_MASK Masked Yes
Register reset RESET_REG_MASK Masked Yes
BUCK0 Buck0 PGOOD has reached threshold
level BUCK0_PG_MASK Masked Yes
Buck0 current limit triggered BUCK0_ILIM_MASK Masked Yes
BUCK1 Buck1 PGOOD has reached threshold
level BUCK1_PG_MASK Masked Yes
Buck1 current limit triggered BUCK1_ILIM_MASK Masked Yes
BUCK2 Buck2 PGOOD has reached threshold
level BUCK2_PG_MASK Masked Yes
Buck2 current limit triggered BUCK2_ILIM_MASK Masked Yes
BUCK3 Buck3 PGOOD has reached threshold
level BUCK3_PG_MASK Masked Yes
Buck3 current limit triggered BUCK3_ILIM_MASK Masked Yes
3.1.2.1 Startup and Shutdown Sequence
Figure 5 shows default startup and shutdown sequence programmed to OTP, in this case with EN1 signal.
Refer to the datasheet for a full description of all registers and their settings.

BUCK2
BUCK1
BUCK0
EN1
BUCK3
GPIO2
DOUBLE_DELAY = 0 HALF_DELAY = 0
GPIO3
5 ms
5 ms
5 ms
2 ms
3 ms
1 ms
www.ti.com Configuration
11
SNVU663–June 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Figure 5. LP87524J-Q1 Startup and Shutdown Sequence Timing Diagram
3.1.3 LP87524P-Q1 OTP Configuration
Table 14. BUCK0, BUCK1, BUCK2, BUCK3 OTP Settings
Description Bit Name LP87524P-Q1 Configurable
General settings
Buck phase configuration (e.g. four single
phase denoted as 1+1+1+1, four phase
single output denoted as 4 ph). N/A 1+1+1+1 No
Switching frequency N/A 4 MHz No
Spread spectrum EN_SPREAD_SPEC No Yes
Startup and shutdown delay range,
0...4.8 ms / 0... 9.6 ms / 0...15 ms / 0...30
ms DOUBLE_DELAY, HALF_DELAY 0...4.8 ms Yes
BUCK0
Output voltage BUCK0_VSET 1000 mV Yes
Enable, ENx-pin or I2C register EN_BUCK0, EN_PIN_CTRL0,
BUCK0_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK0_FPWM Force PWM Yes
Force multiphase mode or auto mode BUCK0_FPWM_MP auto Yes
Peak current limit ILIM0 4 A Yes
Slew rate SLEW_RATE0 3.8 mV/µs Yes
Startup Delay BUCK0_STARTUP_DELAY 0.96 ms Yes
Shutdown Delay BUCK0_SHUTDOWN_DELAY 0.32 ms Yes
BUCK1
Output voltage BUCK1_VSET 1200 mV Yes
Enable, EN-pin or I2C register EN_BUCK1, EN_PIN_CTRL1,
BUCK1_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK1_FPWM Force PWM Yes
Peak current limit ILIM1 2.5 A Yes
Slew rate SLEW_RATE1 3.8 mV/µs Yes
Startup Delay BUCK1_STARTUP_DELAY 2.24 ms Yes
Shutdown Delay BUCK1_SHUTDOWN_DELAY 0.32 ms Yes

Configuration www.ti.com
12 SNVU663–June 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Table 14. BUCK0, BUCK1, BUCK2, BUCK3 OTP Settings (continued)
Description Bit Name LP87524P-Q1 Configurable
BUCK2
Output voltage BUCK2_VSET 1000 mV Yes
Enable, ENx-pin or I2C register EN_BUCK2, EN_PIN_CTRL2,
BUCK2_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK2_FPWM Force PWM Yes
Force multiphase mode or auto mode BUCK2_FPWM_MP auto Yes
Peak current limit ILIM2 4 A Yes
Slew rate SLEW_RATE2 3.8 mV/µs Yes
Startup Delay BUCK2_STARTUP_DELAY 1.6 ms Yes
Shutdown Delay BUCK2_SHUTDOWN_DELAY 0.32 ms Yes
BUCK3
Output voltage BUCK3_VSET 1800 mV Yes
Enable, EN-pin or I2C register EN_BUCK3, EN_PIN_CTRL3,
BUCK3_EN_PIN_SELECT I2C and EN1 Yes
Force PWM mode or auto mode BUCK3_FPWM Force PWM Yes
Peak current limit ILIM3 3.5 A Yes
Slew rate SLEW_RATE3 3.8 mV/µs Yes
Startup Delay BUCK3_STARTUP_DELAY 0 ms Yes
Shutdown Delay BUCK3_SHUTDOWN_DELAY 0.32 ms Yes
Table 15 lists the device settings for GPIOs.
Table 15. EN, CLKIN and GPIO Pin Settings
Description Bit Name LP87524P-Q1 Configurable
EN1 (GPIO1) pin EN1 (GPIO1) pin pulldown resistor enable
or disable EN1_PD Enabled Yes
EN2 (GPIO2) pin EN2 (GPIO2) pin pulldown resistor enable
or disable EN2_PD Disabled Yes
EN3 (GPIO3) pin EN3 (GPIO3) pin pulldown resistor enable
or disable EN3_PD Disabled Yes
CLKIN pin
CLKIN pin pull-down resistor enable or
disable CLKIN_PD Enabled Yes
Frequency of external clock when
connected to CLKIN EXT_CLK_FREQ 2 MHz Yes
Mode for the internal PLL. When PLL
disabled, internal RC OSC is used PLL_MODE[1:0] Enabled Yes
EN1 (GPIO) control
Enable or GPIO GPIO1_SEL Enable Yes
Input or output in GPIO mode GPIO1_DIR Output Yes
Output type open drain or push-pull GPIO1_OD Open drain Yes
EN2 (GPIO) control
Enable or GPIO GPIO2_SEL GPIO Yes
Input or output in GPIO mode GPIO2_DIR Output Yes
Output type open drain or push-pull GPIO2_OD Open drain Yes
Pin control of GPIO, EN1 or EN3 EN_PIN_CTRL_GPIO2,
EN_PIN_SELECT_GPIO2 EN1 Yes
Startup Delay GPIO2_STARTUP_DELAY 2.88 ms Yes
Shutdown Delay GPIO2_SHUTDOWN_DELAY 0.32 ms Yes
EN3 (GPIO) control
Enable or GPIO GPIO3_SEL GPIO Yes
Input or output in GPIO mode GPIO3_DIR Output Yes
Output type open drain or push-pull GPIO3_OD Open drain Yes
Pin control of GPIO, EN1 or EN2 EN_PIN_CTRL_GPIO3,
EN_PIN_SELECT_GPIO3 EN1 Yes
Startup Delay GPIO3_ STARTUP_ DELAY 4.16 ms Yes
Shutdown Delay GPIO3_ SHUTDOWN_ DELAY 0 ms Yes
Table 16 shows device settings for PGOOD.

www.ti.com Configuration
13
SNVU663–June 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
Table 16. PGOOD OTP Settings
Description Bit Name LP87524P-Q1 Configurable
Signals monitored
by PGOOD BUCKx output voltage / voltage and current (master bucks) PGx_SEL Voltage Yes
PGOOD mode
selections
PGOOD thresholds for BUCKx
(Undervoltage / Window (undervoltage
and overvoltage)) PGOOD_WINDOW Window Yes
PGOOD valid debounce time PGOOD_SET_DELAY 11 ms Yes
PGOOD signal mode (status / latched
until fault source read) EN_PGFLT_STAT Status Yes
PGOOD output mode (push-pull or open
drain) PGOOD_OD Open drain Yes
PGOOD polarity (active high / active low) PGOOD_POL Active high (power
valid) Yes
Table 17 lists the device settings for thermal warning. Also refer to Table 19 for interrupt settings.
Table 17. Protections OTP Settings
Description Bit Name LP87524P-Q1 Configurable
Protections Thermal warning level (125°C or 137°C) TDIE_WARN_LEVEL 125°C Yes
Input over-voltage protection N/A Enabled No
Table 18 shows device settings for I2C and OTP revision ID values.
Table 18. Device Identification and I2C Settings
Description Bit Name LP87524P-Q1 Configurable
I2C slave ID (7-bit) Slave address N/A 0x60 No
Table 19 lists device settings for interrupts. When interrupt from an event is unmasked, an interrupt is
generated to nINT pin.
Table 19. Interrupt Mask Settings
Interrupt event Bit Name LP87524P-Q1 Configurable
General
Sync clock appears or disappears SYNC_CLK_MASK Unmasked Yes
Thermal warning TDIE_WARN_MASK Unmasked Yes
Load measurement ready I_LOAD_READY_MASK Masked Yes
Register reset RESET_REG_MASK Masked Yes
BUCK0 Buck0 PGOOD has reached threshold
level BUCK0_PG_MASK Masked Yes
Buck0 current limit triggered BUCK0_ILIM_MASK Masked Yes
BUCK1 Buck1 PGOOD has reached threshold
level BUCK1_PG_MASK Masked Yes
Buck1 current limit triggered BUCK1_ILIM_MASK Masked Yes
BUCK2 Buck2 PGOOD has reached threshold
level BUCK2_PG_MASK Masked Yes
Buck2 current limit triggered BUCK2_ILIM_MASK Masked Yes
BUCK3 Buck3 PGOOD has reached threshold
level BUCK3_PG_MASK Masked Yes
Buck3 current limit triggered BUCK3_ILIM_MASK Masked Yes

BUCK2
BUCK1
BUCK0
EN1
BUCK3
GPIO2
DOUBLE_DELAY = 0 HALF_DELAY = 1
GPIO3
2.24 ms
2.88 ms
4.16 ms
0.32 ms
0.96 ms
1.6 ms 0.32 ms
0.32 ms
0.32 ms
0.32 ms
References www.ti.com
14 SNVU663–June 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
LP87524B/J/P-Q1 Technical Reference Manual
3.1.3.1 Startup and Shutdown Sequence
Figure 6 shows default startup and shutdown sequence programmed to OTP, in this case with EN1 signal.
Refer to the datasheet for a full description of all registers and their settings.
Figure 6. LP87524P-Q1 Startup and Shutdown Sequence Timing Diagram
4 References
See these references for additional information:
1. Texas Instruments, LP87524B/J/P-Q1 Four 4-MHz Buck Converters for AWR and IWR MMICs
datasheet
2. Texas Instruments, XWR1xxx Power Management Optimizations – Low Cost LC Filter Solution
application report

IMPORTANT NOTICE AND DISCLAIMER
TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATASHEETS), DESIGN RESOURCES (INCLUDING REFERENCE
DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”
AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD
PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate
TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable
standards, and any other safety, security, or other requirements. These resources are subject to change without notice. TI grants you
permission to use these resources only for development of an application that uses the TI products described in the resource. Other
reproduction and display of these resources is prohibited. No license is granted to any other TI intellectual property right or to any third
party intellectual property right. TI disclaims responsibility for, and you will fully indemnify TI and its representatives against, any claims,
damages, costs, losses, and liabilities arising out of your use of these resources.
TI’s products are provided subject to TI’s Terms of Sale (www.ti.com/legal/termsofsale.html) or other applicable terms available either on
ti.com or provided in conjunction with such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable
warranties or warranty disclaimers for TI products.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2019, Texas Instruments Incorporated
