Using the UCC28742EVM-001 10-W Converter
User's Guide
Literature Number: SLUUBU4B
March 2018–Revised June 2018

WARNING
www.ti.com
2SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
General Texas Instruments High Voltage Evaluation (TI HV EVM) User Safety Guidelines
Always follow TI’s setup and application instructions, including use of all interface components within their
recommended electrical rated voltage and power limits. Always use electrical safety precautions to help
ensure your personal safety and those working around you. Contact TI's Product Information Center
http://support/ti./com for further information.
Save all warnings and instructions for future reference.
Failure to follow warnings and instructions may result in personal injury, property damage, or
death due to electrical shock and burn hazards.
The term TI HV EVM refers to an electronic device typically provided as an open framed, unenclosed
printed circuit board assembly. It is intended strictly for use in development laboratory environments,
solely for qualified professional users having training, expertise and knowledge of electrical safety
risks in development and application of high voltage electrical circuits. Any other use and/or
application are strictly prohibited by Texas Instruments. If you are not suitable qualified, you should
immediately stop from further use of the HV EVM.
1. Work Area Safety
1. Keep work area clean and orderly.
2. Qualified observer(s) must be present anytime circuits are energized.
3. Effective barriers and signage must be present in the area where the TI HV EVM and its interface
electronics are energized, indicating operation of accessible high voltages may be present, for the
purpose of protecting inadvertent access.
4. All interface circuits, power supplies, evaluation modules, instruments, meters, scopes and other
related apparatus used in a development environment exceeding 50Vrms/75VDC must be
electrically located within a protected Emergency Power Off EPO protected power strip.
5. Use stable and nonconductive work surface.
6. Use adequately insulated clamps and wires to attach measurement probes and instruments. No
freehand testing whenever possible.
2. Electrical Safety
As a precautionary measure, it is always a good engineering practice to assume that the entire EVM
may have fully accessible and active high voltages.
1. De-energize the TI HV EVM and all its inputs, outputs and electrical loads before performing any
electrical or other diagnostic measurements. Revalidate that TI HV EVM power has been safely
de-energized.
2. With the EVM confirmed de-energized, proceed with required electrical circuit configurations,
wiring, measurement equipment connection, and other application needs, while still assuming the
EVM circuit and measuring instruments are electrically live.
3. After EVM readiness is complete, energize the EVM as intended.
WARNING: WHILE THE EVM IS ENERGIZED, NEVER TOUCH THE EVM OR ITS ELECTRICAL
CIRCUITS AS THEY COULD BE AT HIGH VOLTAGES CAPABLE OF CAUSING ELECTRICAL
SHOCK HAZARD.
3. Personal Safety
1. Wear personal protective equipment (for example, latex gloves or safety glasses with side shields)
or protect EVM in an adequate lucent plastic box with interlocks to protect from accidental touch.
Limitation for safe use:
EVMs are not to be used as all or part of a production unit.

3
SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
User's Guide
SLUUBU4B–March 2018–Revised June 2018
Using the UCC28742EVM-001 10-W Converter
1 Description
The UCC28742EVM-001 is a 10-W evaluation module for evaluating an off-line power converter
applications. The EVM meets CoC tier 2 and DoE Level 6 efficiency and standby power requirements. It is
intended for evaluation purposes and is not intended to be an end product. The UCC28742EVM-001
converters 85-VRMS to 265-VRMS input voltage down to 5-VDC, with a 2.1-A current limit.
Figure 1. UCC28742EVM-001

Electrical Performance Specifications www.ti.com
4SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
2 Electrical Performance Specifications
Table 1. UCC28742EVM-001 Electrical Performance Specifications
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
INPUT CHARACTERISTICS
VIN Input voltage (RMS) 85 115/230 265 V
fLINE Line frequency 47 50/60 63 Hz
PSTBY No load input power VIN = 115 V / 230 V RMS, IOUT = 0 A 75 mW
OUTPUT CHARACTERISTICS
VOUT Output voltage VIN = nom, IOUT = nom 4.75 5.25 V
VOUT Output ripple voltage VIN = nom, IOUT = max, 50 mVpp
IOUT Output current VIN = min to max 2 2.05 A
Over Current Shut Down VIN = min to max 2.1 A
Load step 0 A to 0.5 A 4.1 6 V
SYSTEMS CHARACTERISTICS
η4-point average efficiency 25%, 50%, 75% and 100% load, 115-V / 230-V
RMS input 82%
η10% Efficiency 115-V / 230-V RMS input 78
Operating temperature
range VIN = min to max, IOUT = min to max 25 °C

www.ti.com Schematic
5
SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
3 Schematic
Figure 2. UCC28742EVM-001 Schematic

AC Line
AC Neutral
VOUT +
VOUT -
Isolated
Variable AC
Source
1 ohm
Precision Shunt
Current
Measurement
Voltage
Measurement
Power Analyzer
Load
UCC28742EVM-001
TP1
TP2
TP3
TP4
Volt Meter
Oscilloscope
100nF
Scope
Probe
Test Setup www.ti.com
6SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
4 Test Setup
4.1 Test Setup Requirements
Safety: This evaluation module is not encapsulated and there are voltages that are much greater than 50
VDC.
WARNING
If you are not trained in the proper safety of handling and testing
power electronics please do not test this evaluation module.
Voltage Source: Isolated AC source or variable AC transformer capable of 265 VAC cable of handling 10
W
Voltmeter: Digital voltage meter
Power Analyzer: Capable of measuring 1 mW to 10 W of input power and capable of handling 265-V
RMS input voltage. Some power analyzers may require a precision shunt resistor for measuring input
current to measure input power of 5 W or less. Please read the power analyzer’s user manual for proper
setup.
Oscilloscope:
• 4 Channel 100 MHz.
• Probes capable of handling 600 V.
Output Load: Resistive or electronic load capable handling 15 W at 5 V.
Recommended Wire Gauge: Insulated 22 AWG.
4.2 Test Setup Diagram
Figure 3. UCC28742EVM-001 Test Setup Diagram

Output Power
Efficiency (%)
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
60%
65%
70%
75%
80%
85%
D001D001
115 V RMS
230 V RMS
www.ti.com Test Points
7
SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
5 Test Points
Table 2. Test Point Functions
TEST POINTS NAME DESCRIPTION
TP1 L AC line voltage input
TP2 N AC neutral input
TP3 VOUT + Output supply
TP4 VOUT – Output return
6 Performance Data and Typical Characteristic Curves
6.1 Efficiency
Table 3. Efficiency Test Data
VIN RMS VOUT IOUT PIN EFFICIENCY
115 V 5.018 V 0.000 A 0.055 W N/A
115 V 5.017 V 0.201 A 1.268 W 79.5%
115 V 5.015 V 0.501 A 3.072 W 81.8%
115 V 5.014 V 1.002 A 6.124 W 82.0%
115 V 5.013 V 1.500 A 9.183 W 81.9%
115 V 5.011 V 2.004 A 12.244 W 82.0%
230 V 5.019 V 0.000 A 0.072 W N/A
230 V 5.017 V 0.201 A 1.317 W 76.6%
230 V 5.015 V 0.501 A 3.086 W 81.4%
230 V 5.015 V 1.002 A 6.097 W 82.4%
230 V 5.013 V 1.500 A 9.121 W 82.5%
230 V 5.011 V 2.004 A 12.157 W 82.6%
Figure 4. Efficiency

VIN = 230V RMS
RLOAD = 2.5 Ohm
VIN = 230V RMS
RLOAD = Unloaded
VIN = 115V RMS
RLOAD = Unloaded
VIN = 115V RMS
RLOAD = 2.5 Ohm
VIN
VOUT
VAUX
VCS
VIN = 85V RMS
RLOAD = Unloaded
VIN = 85V RMS
RLOAD = 2.5 ohm
Performance Data and Typical Characteristic Curves www.ti.com
8SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
6.2 Startup
CH1 = Aux (D4 Anode), CH2 = VOUT, CH3 = VRCS (R16) , CH4 = VIN (C1)
Figure 5. Figure 6.
Figure 7. Figure 8.
Figure 9. Figure 10.

VIN = 230V RMS
VIN = 265V RMS
VIN = 115V RMS
IOUT
VOUT
VAUX
VCS
VIN = 85V RMS
VIN = 265V RMS
RLOAD = Unloaded
VIN = 265V RMS
RLOAD = 2.5 Ohm
www.ti.com Performance Data and Typical Characteristic Curves
9
SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
Figure 11. Figure 12.
6.3 Load Transients
CH1 = Aux (D4 Anode), CH2 = VOUT, CH3 = VRCS (R16), CH4 = IOUT
Load = 0.100A to 2 A, 50 Hz, 50% Duty Cycle
Figure 13. Figure 14.
Figure 15. Figure 16.

VIN = 265V RMS
VQ1d, 100 X Probe
VAUX
VCS
VIN = 85V RMS
VOUT
VAUX
VCS
VIN = 265V RMS
Performance Data and Typical Characteristic Curves www.ti.com
10 SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
6.4 Output Ripple Voltage at Full Load
Figure 17. IOUT = 2A Figure 18. IOUT = 2 A
6.5 Q1 Drain Voltage Evaluation
Figure 19. IOUT = 2A

www.ti.com Performance Data and Typical Characteristic Curves
11
SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
6.6 Conducted EMI
Figure 20. VIN = 115 VRMS, Load = 2.5 ΩFigure 21. VIN = 230 VRMS, Load = 2.5 Ω
NOTE: Please note this was evaluated on an unqualified EMI station. It is recommended that all
final designs be verified by agency qualified EMI test house.

1
2
6
Np/2
Np/2
4
3
Na1 Na2
5
Nc1 Nc2
Ns1 Ns2FL1
FL2
Flying Leads (FL)
Transformer Details www.ti.com
12 SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
7 Transformer Details
Wurth Elektronik transformer part number 750315841 is used on this design and wound on an RM6 core.
Figure 22. Transformer Schematic
Table 4. Transformer Specifications
PARAMETER PINS/LEADS TEST CONDITIONS VALUE
D.C. resistance 1 – 2 At 20ºC 0.56 Ω, ±10%
D.C. resistance 3 – 4 At 20ºC 0.157 Ω, ±10%
D.C. resistance FL1 – FL2 At 20ºC 0.012 Ω, ±20%
D.C. resistance 3 – 5 At 20ºC 0.142 Ω, ±10%
D.C. resistance 2 – 6 At 20ºC 0.845 Ω, ±10%
Inductance 1 – 6 10 kHz, 100 mV, Ls 750 µH, ±10%
Saturation current 1 – 6 20% rolloff from initial 800 mA
Leakage inductance 1 – 6 tie (FL1 + FL2, 3 + 4 + 5),100
kHz, 100 mV, Ls 4.0 µH typical, 6.0 µH maximum
Dielectric 6vFL1 tie (5 + 6), 3750 VAC, 1 second
Turns ratio (1 – 6):(FL1 – FL2) 13:1, ±1%
Turns ratio (1 – 6):(3 – 4) 4:1, ±1%
Turns ratio (1 – 6):(5 – 3) 5.78:1, ±1%
Turns ratio (1 – 2):(2 – 6) 1:1, ±1%

1
2
Tape
Nc1 = 9 turns, 34 AWG
Nc2 = 9 turns, 34 AWG
Wound Bifilar Single Layer 5
Tape
Tape
Na1 = 13 turns, 34 AWG
Na2 = 13 turns 34 AWG
Wound Bifilar Single Layer
34
Tape
Np/2 = 26 Turns, 34 AWG, Single Layer 2
Bobbin Surface
Transformer Inner Core
Clockwise
Clockwise
Ns1 = 4 turns, 25 AWG Triple Insulated
Ns2 = 4 turns, 25 AWG Triple Insulated
Wound Bifilar Single Layer
FL1 FL2 Clockwise
3Counter
Clockwise
Np/2 = 26 Turns, 34 AWG
20 Turns on one layer and 6 on the next 6 Clockwise
PinPin
Start Winding Finish Winding
Winding Direction
Transformer Outer Core
www.ti.com Transformer Details
13
SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
Figure 23. Transformer Winding Structure

EVM Assembly and Layout www.ti.com
14 SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
8 EVM Assembly and Layout
Figure 24. EVM Assembly (Top View)
Figure 25. EVM Assembly/Layout (Bottom View)

www.ti.com List of Materials
15
SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Using the UCC28742EVM-001 10-W Converter
9 List of Materials
UCC28742EVM-001 list of materials as shown in Figure 2.
Table 5. UCC28742EVM-001 List of Materials
QTY DES DESCRIPTION PART NUMBER MANUFACTURER
2 C1, C2 Capacitor, aluminum, 10 µF, 400 V, ±20%, TH UCS2G100MPD1TD Nichicon
1 C3 Capacitor, ceramic, 470 pF, 630 V, ±5%, U2J, 1206 GRM31A7U2J471JW31
DMuRata
2 C5, C6 Capacitor, aluminum, 470 µF, 16 V, +±20%, 0.009 ohm,
TH PLF1C471MDO1 Nichicon
1 C7 Capacitor, ceramic, 1 µF, 25 V, +±10%, X7R, 0603 C1608X7R1E105K080A
BTDK
1 C8 Capacitor, ceramic, 0.33 µF, 50 V, ±10%, X7R, 1206 GRM319R71H334KA01
DMuRata
1 C10 Capacitor, ceramic, 100 pF, X1 VAC/Y1 VAC, ±10%, B,
6.5 mm x 6 mm CD45-B2GA101K-NKA TDK
1 C11 Capacitor, ceramic, 6.8 uF, 25 V, X7R, ±5%, 0603 GRM155R71E682KA01
DAVX
0 C12 Capacitor, ceramic, 270 nF, 16 V, ±5%, X7R, 0603 C0603C274K4RACTU Kemit
1 C13 Capacitor, ceramic, 220 nF, 50 V, ±5%, X7R, 0603 GCM188R71H224KA64
DMuRata
0 C14 Capacitor, ceramic, 2.2 nF, 100 V, X7R, ±5%, 0603 06031C222JAT2A AVX
1 D1 Diode, switching-bridge, 600 V, 0.8 A, MiniDIP HD06-T Diodes Inc.
2 D2, D4 Diode, l, 600 V, 1 A, SMB MURS160-13-F Diodes Inc.
1 D3 Diode, super barrier rectifier, 50 V, 15 A, AEC-Q101,
PowerDI5 SBRT15U50SP5-13 Diodes Inc.
1 F1 Fuse, 0.5 A, 250 VAC/VDC, TH RST 500 Bel Fuse
2 J2, J3 Terminal block, 5.08 mm, 2x1, TH 1715721 Phoenix Contact
2 JAUX,
JPGND Jumper wire, 500mil spacing, green, pkg of 200 923345-05-C 3M
1 JPGND2 Jumper wire, 400 mil spacing, yellow, pkg of 200 923345-04-C 3M
1 L1 Inductor, wirewound, ferrite, 470 µH, 0.5 A, 1.3 ohm, TH RLB0914-471KL Bourns
2 L2, L3 Ferrite bead, 300 Ωat 100 MHz, 3 A, 1206 742792121 Wurth Elektronik
1 Q1 MOSFET, N-channel, 600 V, 5 A, IPAK STU7NM60N STMicroelectronics
1 R1 Resistor, 1.00 kΩ, 1%, 0.25 W, 1206 CRCW12061K00FKEA Vishay-Dale
3 R2, R3,
R4 Resistor, 5.11 MΩ, 1%, 0.125 W, 0805 CRCW08055M11FKEA Vishay-Dale
1 R5 Resistor, 511 kΩ, 1%, 0.25 W, 1206 CRCW1206511KFKEA Vishay-Dale
1 R6 Resistor, 51.1 Ω, 1%, 0.125 W, 0805 CRCW080551R1FKEA Vishay-Dale
1 R8 Resistor, 1.0 kΩ, 5%, 0.1 W, 0603 CRCW06031K00JNEA Yageo America
1 R10 Resistor, 20 kΩ, 5%, 0.125 W, 0805 CRCW080520R0JNEA Vishay-Dale
1 R11 Resistor, 115 kΩ, 1%, 0.125 W, 0805 CRCW0805115KFKEA Vishay-Dale
1 R12 Resistor, 36.5 kΩ, 1%, 0.1 W, 0603 CRCW060336K5FKEA Vishay-Dale
1 R13 Resistor, 715 Ω, 1%, 0.1 W, 0603 RC0603FR-07715RL Yageo America
2 R14, R18 Resistor, 0 Ω, 5%, 0.25 W, 1206 RC1206JR-070RL Yageo America
2 R15, R16 Resistor, 2.15 Ω, 1%, 0.125 W, 0805 CRCW08052R15FKEA Vishay-Dale
1 R17 Resistor, 10 Ω, 5%, 0.25 W, 1/4 W axial resistor FRM-25JR-52-10R Yageo America
1 R21 Resistor, 4.02 kΩ, ±1%, 0.1 W, 0603 CRCW06034K02FKEA Vishay-Dale
1 R23 Resistor, 32.4 kΩ, ±1%, 0.1 W, 0603 RT0603BRD0732K4L Yageo America
1 R25 Resistor, 680 Ω, 5%, 0.1 W, 0603 RC0603JR-07680RL Yageo America
0 R26 Resistor, 249 Ω, ±1%, 0.1 W, 0603 P249DBTR-ND Panasonic Electronic
Components
1 R27 Resistor, 49.9 Ω, ±1%, 0.1 W, 0603 RC0603FR-0749R9L Yageo America

Revision History www.ti.com
16 SLUUBU4B–March 2018–Revised June 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Revision History
Table 5. UCC28742EVM-001 List of Materials (continued)
QTY DES DESCRIPTION PART NUMBER MANUFACTURER
2 R28, R29 Resistor, 42.2 kΩ, ±1%, 0.1 W, 0603 CRCW060342K2FKEA Vishay-Dale
1 R30 Resistor, 0 Ω, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 RMCF0603ZT0R00 Stackpole Electronics
Inc
1 RHVJ Resistor, 0 Ω, 5%, 0.125 W, 0805 CRCW08050000Z0EA Vishay-Dale
1 RT1 Thermistor NTC, 5 Ω, 20%, MF72D5 TH MF72-005D5 Cantherm
1 T1 Transformer, 750 µH, TH 750315841 Wurth Elektronik
2 TP1, TP3 Test point, multipurpose, red, TH 5010 Keystone
2 TP2, TP4 Test point, multipurpose, black, TH 5011 Keystone
1 U1 High-Efficiency Low-Cost Flyback Controller with
Secondary-Side Regulation, DBV0006A (SOT-23-6) UCC28742DBVR Texas Instruments
1 U2 Optocoupler, 5 kV, 50-600% CTR, TH LTV-817 Lite-On
1 U3 Precision programmable reference, DBZ0003A TL431AIDBZ Texas Instruments
0 C4 Capacitor, ceramic, 100 pF, 50 V, ±5%, C0G/NP0, 0805 08055A101JAT2A AVX
0 C9 Capacitor, ceramic, 27 pF, 50 V, ±5%, C0G/NP0, 0603 06035A270JAT2A AVX
0 R9 Resistor, 1.00 kΩ, 1%, 0.1 W, 0603 CRCW06031K00FKEA Vishay-Dale
0 R7 Resistor, 510 kΩ, 5%, 0.125 W, 0805 CRCW0805510KJNEA Vishay-Dale
Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from A Revision (May 2018) to B Revision ...................................................................................................... Page
• Changed Removed USB from title and text and replaced USB with converter and power converter where necessary. ... 3
Changes from Original (March 2018) to A Revision ....................................................................................................... Page
• Changed Efficiency image................................................................................................................ 7

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.

FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.

【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.

6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2018, Texas Instruments Incorporated
