texet BlueFun TPA-2170 User manual

USER GUIDE
Руководство по эксплуатации
Пайдалану бойынша нұсқаулық
Керівництво з експлуатації
BLUETOOTH™ PORTABLE SPEAKER
Портативная колонка Bluetooth™
Шағын колонкасы Bluetooth™
Портативна колонка Bluetooth™
TPA-2170
BlueFun

2
Сontrols
Органы управления
Басқару жүйесі
Органи управління
1
5 9
2
7
3
6
4
8
DC 5V
AUX
ENG ............................3
RUS .........................11
KZ ............................21
UKR .........................24

3
BLUETOOTH™ PORTABLE SPEAKER
1 Power button. Receive and end a phone call.
2 AUX: Line-in jack for external devices, such as MP3 players, PC
tablets, artphones, and mobile telephones
3 LED light
4 DC 5V: Interface for charging and for connecting to a PC
5 Mic
6 Pause/resume playback button. Button to select main
functions
7 Volume-down/select previous le button
8 Volume-up/select next le button. Mute/unmute button in
eakerphone mode
9 microSD: MicroSD card slot
ENG

4
QUICK START GUIDE
Package contents
1. Bluetooth™ portable speaker BlueFun– 1 pc
2. microUSB cable – 1 pc
3. AUX cable – 1pc
4. Silicon cuff – 3 pcs
5. Handstrap – 3 pcs
6. User guide- 1 pc
7. Warranty certicate – 1 pc
Specications
Overall dimensions 52 x 52 x 50 mm
Weight 107,5 g
Battery Li-Ion 3,7 V, 600 mAh
Time of operation in playback mode Up to 8 hours1
External power source USB 5 V, 0,5-1 А2
Bluetooth™ Broadcom v. 3.0
Bluetooth™ proles A2DP, Headset
Simultaneous pairing of multiple
Bluetooth™ devices capability
4 external Bluetooth™
devices
Speakerphone Built-in microphone for
incoming/outgoing calls in
Hands-free mode
Speaker 45 mm, 4 Ohm
Output power 3 W
1 Depending on the level of the sound
2 The charging device is not included and must be purchased
separately.

5
Reproducible frequencies 150 Hz – 18 kHz
Line input response 420 mV
Signal-to-noise ratio > 80 dB
Nonlinear-distortions coefcient < 0.55%
MP3 player
Supported formats MP3
Bitrate 32 – 320 kBps
External media memory capacity
(microSD)
up to 32Gb
External media le system format FAT32
Working range -5 to + 40 °C
Press and hold the button to switch on the BlueFun portable
speaker. Wait for the «Welcome» prompt from the voice menu.
Choose the «BlueFun» external device from the search menu
to pair with an external Bluetooth device. If the external device
prompts you for a PIN, enter «0000» The LED light will turn blue
when the pairing process is complete.
Use the button to receive or end a telephone call. Press and hold
the buttons to adjust the volume.
Use the button to play/pause a le. Use the buttons to
select the previous/next le from external media.
To charge the battery, connect one end of the microUSB cable to
the DC 5V port. Plug the other end into a USB port on a computer
or into a USB wall charger.

6
USER GUIDE
Thank you for purchasing our Bluetooth™ portable speaker teXet
TPA-2170 BlueFun. Before you start operating the unit, please read
this manual to take full advantage of Bluetooth™ portable speaker
and extend its life. Save this manual to refer to it in the future if
the need arises.
This manual contains information on the technical characteristics
of the device, controls of the Bluetooth™ portable speaker, all
functions and modes of operation.
Note: Due to continuous product improvement, we reserve the right to
modify the software, hardware, and specications without prior notice
to the end user. Current information is always available on the website
www.texet.eu
1. Start of operation
Press and hold the button to switch on the BlueFun portable
speaker. Wait for the «Welcome» prompt from the voice menu.
When switched on, the LED light will rapidly ash blue.
The «Search for devices» prompt from the voice menu means
that the BlueFun portable speaker is ready to pair with external
Bluetooth devices.
Repeatedly press and hold the button to choose different modes
for the BlueFun portable speaker: Bluetooth™, MP3 player, or AUX.
If an audio cable or microSD card is connected when the BlueFun
is switched on, then the AUX or MP3 player mode will start, and the
«Welcome» prompt will be skipped. The voice menu is a function
of the Bluetooth™ mode.
2. Pairs with external Bluetooth™ devices
Attention! The distance between the BlueFun portable speaker and a
paired external device should not exceed 10 meters.
On the external device, enable Bluetooth™ and begin searching for
devices. When the list of discovered devices appears on the screen,
choose «BlueFun» If the external device prompts you for a PIN,

7
enter «0000» Wait for the «Pairing» prompt from the voice menu.
The LED light will turn blue when the pairing process is complete.
In most cases, when the connection is lost1 the BlueFun portable
speaker will automatically re-pair with your external device. If
pairing does not begin automatically, then switch the BlueFun
portable speaker off and then on. You can simultaneously pair
BlueFun with up to 4 external Bluetooth™ devices.
3. Plays music les from external Bluetooth™ devices
Play music on your external device. During playback, the BlueFun
portable speaker LED light will slowly ash blue. Use the button
to play and pause les. Use the button to select the
previous/next le. Files will be played sequentially by folder.
Press and hold the button to adjust the volume.
You can also adjust the volume and select les by using the menu
or the buttons on the external device.
4. Receives telephone calls. Hands-free
pability
The BlueFun portable speaker allows you to receive calls and provides
hands-free calling with a built-in loudspeaker and microphone.
When there is an incoming call, playback is paused, and the
BlueFun loudspeaker will either emit special beeps or play your
mobile device’s ringtone. Press the button to receive the call.
Press the button again to end the call and resume playback.
If you need to mute your microphone during a call, press the +
button. You will hear a «Mute on» conrmation. Repeatedly press
the + button to unmute the microphone. After the «Mute off»
conrmation, you will be able to continue your conversation.
If you do not want to take the call, you can reject it on your mobile
device.
Receiving calls is a Bluetooth™ function and is not possible when
in AUX or MP3 mode.
1 Depending on the model of the external device

8
5. MP3 player operation
Insert the microSD card in the microSD slot. Playback will start
automatically. Use the buttons to select the previous/next le.
Use the button to pause or resume playback. During playback,
the BlueFun portable speaker’s LED light will slowly ash blue.
Press and hold the button to adjust the volume.
When switched on, the BlueFun portable speaker recalls all
previous settings: volume level, current le.
Information about playing MP3 les from external media:
• File system format for external media: FAT32
• Maximum memory for external media: 32 Gb
6. Connects to external audio devices through the
AUX input
Connect your external device (MP3 player, PC tablet, smartphone,
notebook, or mobile phone) to the AUX port with an audio cable.
Start playback on your external device.
Use the button to adjust the volume. Press the button to
turn the sound off/on during playback.
7. Rechargable battery
Connect any USB wall charger (5V, 0.5-1A) to the DC 5V port using
a microUSB cable. The LED light will turn red, indicating that
charging has begun. After the battery is charged, the LED light
will turn off. You can speed up charging by turning off the BlueFun
portable speaker.
8. Troubleshooting guide
1. Fails to turn off
• Check the battery’s charge level.
• Plug the BlueFun into a power source to reboot.
2. Fails to charge
• Make sure the charging cable is connected.

9
3. No sound
• Check the volume level.
• Make sure there are MP3 les on the external media.
• Check the battery’s charge level.
• Check the BluetoothТМ connection.
4. The les on the external media are unreadable
• Check the le system format of the microSD card.
• Check the microSD card for viruses.
5. No sound for incoming/outgoing calls
• Make sure nothing is blocking the microphone; be sure not to
cover the microphone with your hand when talking.
• Check the volume level.
• Make sure the microphone is not muted.
6. The speaker emits static
• Make sure that mobile devices are no more than 30 cm away
from the BlueFun portable speaker.
7. Will not pair with external BluetoothТМ devices
• Make sure the BlueFun is completely charged.
• When pairing, position the mobile device as close as possible to
the BlueFun (not more than 1 meter away).
• Check your BluetoothТМ device’s menu to make sure that
«discoverable» mode is enabled.
• After pairing, some external BluetoothТМ devices require
additional conguration of the Bluetooth connection. To do this,
choose the BlueFun from the list of paired devices and select
«congure connection.»
• If the connection is lost because the external device is more
than 10m away or BluetoothТМ on the external mobile device
is disabled and re-pairing does not start automatically, then
switch the BlueFun portable speaker off and then on.
• The BlueFun is paired to 2 external mobile devices and the
connection to one of them is already established. If this is the
case, you must disconnect the rst device, then the connection
to the second device will automatically be established.
• After pairing your device with the BlueFun, four more external

10
BluetoothТМ devices were paired. The information for the rst
external BluetoothТМ device is erased. Re-pair and re-establish
the connection to your mobile device following steps 1 and 2
from the manual.
• Plug the BlueFun in and reboot.
