Themis RES-32XEL User manual

Themis Computer—Rest of World
5 Rue Irene Joliot-Curie
38320 Eybens, France
Phone [phone]
Fax [phone]
Themis Computer—Americas and Pacific Rim
3185 Laurelview Court
Fremont, CA 94538
Phone [phone]
Fax [phone]
World Wide Web http://www.themis.com
RES-32XEL Installation
Guide
Version 1.0— August 2004

Copyright © 2004 Themis Computer, Inc.
ALL RIGHTS RESERVED. No part of this publication may be reproduced in any form, by
photocopy, microfilm, retrieval system, or by any other means now known or hereafter invented without
the prior written permission of Themis Computer.
The information in this publication has been carefully checked and is believed to be accurate. However,
Themis Computer assumes no responsibility for inaccuracies. Themis Computer retains the right to
make changes to this publication at any time without prior notice. Themis Computer does not assume
any liability arising from the application or use of this publication or the product(s) described herein.
RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by the United States Government
is subject to the restrictions set forth in DFARS 252.227-7013 (c)(1)(ii) and FAR 52.227-19.
TRADEMARKS and SERVICEMARKS
THEMIS®is a registered trademark of Themis Computer, Inc.
Intel® is a registered trademark of Intel Corporation
Xeon™is a trademark of Intel Corporation
InfiniBand™ is a trademark and servicemark of the InfiniBand®Trade Association
All other trademarks, servicemarks, or registered trademarks used in this publication are the property of
their respective owners.
RES-32XEL Installation Guide, Version 1.0
August 2004
Part Number: 111600-020
Themis Customer Support
North America, South America, and Pacific Rim
Telephone: [phone]
Fax: [phone]
E-mail: [e-mail]
Web Site: http://www.themis.com

iii
Themis Computer
RES-32XEL Installation Guide
Version Revision History
Version 1.0........................................................................................ August 2004

iv Themis Computer
RES-32XEL Installation Guide

v
Themis Computer
Table of Contents
1. Overview and Specifications ........................................................................................ 1-1
1.1 Overview ................................................................................................................ 1-1
1.1.1 Special Features ......................................................................................... 1-6
1.1.1.1 BIOS Recovery ........................................................................... 1-6
1.1.1.2 Recovery from AC Power Loss .................................................. 1-6
1.1.1.3 Voltage Monitors ........................................................................ 1-6
1.1.1.4 Fan Status Monitor ...................................................................... 1-6
1.1.1.5 Environmental Temperature Control .......................................... 1-6
1.1.1.6 CPU Fan Auto-Off in Sleep (Doze) Mode ................................. 1-7
1.1.1.7 CPU Overheat LED and Control ................................................ 1-7
1.1.1.8 System Resource Alert (optional) ............................................... 1-7
1.1.1.9 Auto-Switching Voltage Regulator ............................................ 1-7
1.1.2 ACPI Features ............................................................................................ 1-7
1.1.2.1 Microsoft OnNow ....................................................................... 1-8
1.1.2.2 Suspend-State Indicator .............................................................. 1-8
1.1.2.3 Wake-Up Alarm .......................................................................... 1-8
1.1.2.4 Main Switch Override ................................................................. 1-8
1.1.2.5 External Modem Ring-On .......................................................... 1-8
1.1.2.6 Wake-On-LAN ........................................................................... 1-8
1.1.3 System LEDs and I/O Connectors ............................................................. 1-9
1.2 Specifications ....................................................................................................... 1-11
1.2.1 General ..................................................................................................... 1-11
1.2.2 Electrical .................................................................................................. 1-12
1.2.2.1 System Power ........................................................................... 1-12
1.2.2.2 Output Voltage .......................................................................... 1-12
1.2.3 Environmental .......................................................................................... 1-12
1.2.3.1 Shock ........................................................................................ 1-12
1.2.3.2 Vibration ................................................................................... 1-13
1.2.3.3 Electrostatic Discharge ............................................................. 1-13
1.2.3.4 Packaging and Shipping ............................................................ 1-13

vi Themis Computer
RES-32XEL Installation Guide
2. Installation and Operation ........................................................................................... 2-1
2.1 Installation Procedures ........................................................................................... 2-1
2.1.1 Remove Protective Top Cover ................................................................... 2-1
2.1.2 Memory Modules ....................................................................................... 2-3
2.1.2.1 Installation .................................................................................. 2-4
2.1.3 SCSI Hard-Disk Drive ............................................................................... 2-6
2.1.3.1 Removal ...................................................................................... 2-6
2.1.3.2 Installation .................................................................................. 2-7
2.1.4 AGP Graphics Card ................................................................................... 2-7
2.1.4.1 Installation .................................................................................. 2-8
2.1.5 PCI Cards ................................................................................................... 2-8
2.1.5.1 Installation .................................................................................. 2-9
2.1.6 Removable Dual-Fan Housing ................................................................. 2-10
2.1.6.1 Removal .................................................................................... 2-10
2.1.6.2 Installation ................................................................................ 2-11
2.1.7 Power Supply ........................................................................................... 2-12
2.1.7.1 Removal .................................................................................... 2-12
2.1.7.2 Installation ................................................................................ 2-12
2.1.8 Lithium Battery ........................................................................................ 2-13
2.1.8.1 Removal .................................................................................... 2-13
2.1.8.2 Installation ................................................................................ 2-13
2.2 Rack Mounts ........................................................................................................ 2-14
2.2.1 Mounting Brackets ................................................................................... 2-14
2.2.2 Mounting Slides ....................................................................................... 2-14
2.3 Operation ............................................................................................................. 2-16
2.3.1 Turning the System On ............................................................................ 2-16
2.3.2 Turning the System Off ........................................................................... 2-17
2.3.3 Getting Started ......................................................................................... 2-17
2.3.3.1 Configuration ............................................................................ 2-17
2.3.3.2 Linux Installation ...................................................................... 2-17
2.3.3.3 X Windows Configuration ........................................................ 2-18
Appendix A. Connector Pinouts ...................................................................................... A-1
A.1 PS/2 Keyboard and Mouse ................................................................................... A-1
A.2 USB Ports ............................................................................................................. A-2
A.3 Serial Ports ............................................................................................................ A-2

vii
Themis Computer
Table of Contents
A.4 Parallel Port ........................................................................................................... A-3
A.5 Gigabit Ethernet LAN Port ................................................................................... A-4
A.6 Audio Ports ........................................................................................................... A-4
Index ................................................................................................................ Index-1
Reader Comment Card

viii Themis Computer
RES-32XEL Installation Guide

ix
Themis Computer
Table of Contents
List of Figures
Figure 1-1 The RES-32XEL Server (with Rack Mounts) ................................................. 1-1
Figure 1-2 RES-32XEL System Block Diagram............................................................... 1-2
Figure 1-3 External Features of the RES-32XEL (Front and Rear) .................................. 1-3
Figure 1-4 Major Components of the RES-32XEL (Open Top View) ............................. 1-5
Figure 1-5 RES-32XEL LEDs and I/O Connectors .......................................................... 1-9
Figure 2-1 Remove the RES-32XEL Protective Access Cover ........................................ 2-2
Figure 2-2 Memory Module Slot Location (Hold-down Bracket Removed).................... 2-5
Figure 2-3 Memory Module Removal............................................................................... 2-5
Figure 2-4 RES-32XEL Hard-Disk Drive Removal.......................................................... 2-6
Figure 2-5 AGP Graphics Card Installation ...................................................................... 2-8
Figure 2-6 PCI Card Installation ....................................................................................... 2-9
Figure 2-7 The RES-32XEL Front and Rear Dual-Fan Housings................................... 2-10
Figure 2-8 Rear Dual-Fan Housing Partially Removed ................................................. 2-11
Figure 2-9 The RES-32XEL Power Supply Locking Mechanism .................................. 2-12
Figure 2-10 The RES-32XEL Lithium Battery and Socket .............................................. 2-13
Figure 2-11 Rack-Mount Bracket with (A) and without a Handle (B) ............................. 2-14
Figure 2-12 Screw Locations for Rack-Mount Slides ....................................................... 2-15
Figure 2-13 AC Power Socket and LED on the RES-32XEL Rear .................................. 2-16
Figure 2-14 System Power Switch and LED on the RES-32XEL Front........................... 2-16
Figure A-1 USB Connector ............................................................................................... A-2
Figure A-2 DB9 Serial Connector..................................................................................... A-2
Figure A-3 DB25 Parallel Connector ................................................................................ A-3
Figure A-4 Ethernet Connector, Type RJ45...................................................................... A-4

xThemis Computer
RES-32XEL Installation Guide
List of Tables
Table 1-1 Major Features of the RES-32XEL ................................................................ 1-4
Table 1-2 System LEDs ................................................................................................. 1-10
Table 1-3 I/O Connectors............................................................................................... 1-10
Table 1-4 RES-32XEL General Specifications.............................................................. 1-11
Table 1-5 RES-32XEL Electrical Specifications ........................................................... 1-12
Table 1-6 USPIIeVibration Parameters......................................................................... 1-13
Table 2-1 Typical Memory Module Distribution............................................................ 2-3
Table A-1 PS/2 Keyboard/Mouse Pinouts ...................................................................... A-1
Table A-2 USB Connector Pinouts ................................................................................. A-2
Table A-3 DB9 Serial Connector Pinout ........................................................................ A-2
Table A-4 Parallel Port Connector Pinout ...................................................................... A-3
Table A-5 RJ45 Ethernet Pinouts.................................................................................... A-4

1-1
Themis Computer
1
Overview and Specifications
1.1 Overview
The RES-32XEL SMP Server/Workstation (see Figure 1-1 and Figure 1-2, page
1-2) is a rack-mounted ruggedized system designed specifically for above-average
shock environments. The RES-32XEL supports single or dual Intel® 604/603
XeonTM processors (up to 3.06 GHz), and contains a combination of compute- and
graphics-intensive and diverse-I/O capabilities, ideal for a variety of military/aero-
space and commercial telecommunications applications.
Figure 1-1. The RES-32XEL Server (with Rack Mounts)
General
Section
Chapter

RES-32XEL Installation Guide
1-2 Themis Computer
The RES-32XEL is designed within a 3RU (5.25”) form-factor that is 20” deep and
fits into a 19” rack (with mounting brackets). I/O expansion includes one 64-bit/133-
MHz PCI-X slot, two 64-bit/100-MHz PCI-X slots (one that supports Ultra320-
SCSI RAID), two 32-bit/33-MHz PCI slots, and a single Pro8x/4x AGP graphics
slot to support a high-speed graphics card.
Figure 1-2. RES-32XEL System Block Diagram
100 MHz
1.5V
3.3V
5V
Memory
Controller
Hub*
(MCH)
I/O
Controller
Hub 4*
(ICH4)
AGP Pro/8x
64-bit PCI-X (2)
133 MHz
Ethernet (RJ45)
3.3V
64-bit PCI-X
33 MHz
32-bit PCI (2)
Ultra320
SCSI 0/1
Gigabit LAN
Primary M/S IDE
Secondary M/S IDE
PCI-X 64-bit
Hub 2.0*
(P64H2)
USB 2.0 0/1
Super I/O
Audio Interface
(AC97)
Integrated LAN
Controller
System
Management
Bus Controller
2-Channel ECC
DDR-266/200 SDRAM
Up to a total of 12 GB
Channel A
Channel B
266/200-MHz
Memory Bus
4.27 GB/sec
266 MB/sec
Dual-Channel
Ultra ATA/100 EIDE
Controller Ports
1 GB/sec
133-MHz PCI-X Bus
100-MHz PCI-X Bus
Up to 3.06 GHz each
533/400-MHz System Bus
Bank 1
Six 184-pin DIMM Sockets
Two 604/603-pin Sockets
Bank 2
Bank 3
Bank 1
Bank 2
Bank 3
Floppy Disk-Drive
Xeon CPU 1
TM
Xeon CPU 2
TM
Note:
* Intel E7505 chipset
®
1-Mb/sec Serial Ports (2)
EPP/ECP Parallel Port
Audio Line In
USB 0
USB 1
Audio Line Out
Microphone In

Overview and Specifications
Overview
1-3
Themis Computer
The RES-32XEL front panel provides access to two removable Ultra320 SCSI hard-
disk drives, one fixed Ultra320 SCSI hard-disk drive or 1.44-MB 3.5” floppy-disk
drive (mounts in the same location) a combination CD-RW/DVD-ROM slimline
drive, the system power switch and LEDs, and a reset switch (see Figure 1-3; rack-
mounting brackets are not shown). The rear panel contains the I/O faceplates for the
graphics, RAID, and PCI cards, two AC power supplies with power-cord sockets,
and all I/O connectors.
Major features are described in Table 1-1 on page 1-4. Major internal components
can be seen in the open top view (cover removed) of Figure 1-4 on page 1-5.
Figure 1-3. External Features of the RES-32XEL (Front and Rear)
Front View (Bezel Open)
AC Power Socket
(3-prong NEMA 15)
Power Supply with Twin-Fan Air Exhaust
System Power
Power Supply
Latch Lock
On/Off Switch
CD-RW/DVD-ROM
Combo Slimline Drive
Front LED Indicator Panel (see Figure 1-5)
Rear I/O Panel (see Figure 1-5)
17” (42.7 cm), 19” with Rack Mounts
5.25”
(3 RU)
20” (50.8 cm) deep
1.44-MB Floppy
Disk Drive
Rear View
ID 0
ID 1
Removable: (Boot)
DDS/DAT
Ta p e D r i v e
Ultra320 SCSI Disk Drives (3 total)
Fixed (optional)
Optional
(Replaces Floppy)
8x AGP Pro Graphics Slot
64-bit/133-MHz
PCI Slots (2), 32-bit/33-MHz
Reset
64-bit/100-MHz
PCI-X Slots (3)
64-bit/100-MHz
Blank

RES-32XEL Installation Guide
1-4 Themis Computer
Table 1-1. Major Features of the RES-32XEL
Feature Details
Processor (CPU) zSingle or dual Intel 604/603-pin Xeon CPUs @ up to 3.06 GHz
zDual ZIF sockets
z512-KB L2 cache
zOn-board Voltage-Regulator Module (VRM 9.1 spec)
zFront-side memory bus support for 400 MHz
Chipset zIntel E7505 chipset:
— Memory Controller Hub (MCH)
— P64H2 (PCI-X 64-bit Hub 2.0)
— ICH4 (I/O Controller Hub 4)
Memory zSix 184-pin DIMM sockets supporting up to 12 GB of registered
ECC DDR-266/200 (PC2100/1600) SDRAM
Expansion slots
zOne 3.3V, 64-bit, 133-MHz PCI-X (slot 1)
zTwo 3.3V, 64-bit, 100-MHz PCI-X (slots 2a& 3)
zTwo 5V, 32-bit, 33-Mhz PCI (slots 4 & 5)
zOne 1.5V 4x/8x AGP Pro Graphics Expansion Bus slot
Peripheral Support
z2 removable Ultra320 SCSI hard-disk drives
z1 fixed Ultra320 SCSI hard-disk or 1.44-MB 3.5” floppy drive
z1 combination CD-RW/DVD-ROM slimline drive (optional)
z1 DDS/DAT tape drive (optional)
Integrated SCSI
(no external I/O)
zDual-channel Ultra320 support
zSupports Adaptec zero-channel RAID (ZCR) in PCI-X slot 2
Integrated I/O
z2 serial ports (9-pin, 16550-based)
z1 parallel port (25-pin, EPP/ECP)
z6 USB 2.0 ports (2 from rear I/O panel, 4 from I/O slot 1)
z1 PS/2 keyboard port and 1 PS/2 mouse port
z1 Gigabit LAN (Intel 82545EM) Ethernet controller
z1 audio line in, 1 audio line out, 1 audio microphone in
z1 zero-channel SCSI RAID controller
Operating temperature z0°C to 50°C
Shock endurance z25G @ 40-msec duration
Dimensions z5.25” (3 RU) high, 17” (43.2 cm) wide (19”/48.3 cm with mount-
ing brackets), 20” (50.8 cm) deep
Rack-mount brackets and slides
zChoice of rack-mount brackets with or without handles
zOptional rack-mount slides
Dual power supplies
z460 watts each, auto-ranging (90–264 VAC)
zLoad-sharing N+1 redundant, hot-pluggable
zFiltered, fuse-protected AC socket
a—Slot 2 supports SCSI RAID.

Overview and Specifications
Overview
1-5
Themis Computer
Figure 1-4. Major Components of the RES-32XEL (Open Top View)
Front
Power
PCI-X Slot
SCSI Disk-Drives (up to 3)
CD-RW/DVD
Combo-Drive
Dual-Fans (Front)
DIMM Memory Modules (6)
& Floppy-Drive Housing
4x/8x AGP Graphics Slot (1.5V)
(64-bit/100-MHz, 3.3V)
2 PCI Slots (32-bit/33-MHz, 5V)
Housing
PCI-X Slot / SCSI RAID
PCI-X Slot
(64-bit/133-MHz, 3.3V)
CPU 2 (with Fan) CPU 1 (with Fan)
(64-bit/100-MHz, 3.3V)
Slot 1 2 3 4 5
Supply
Upper
Dual-Fans (Rear)
(under Hold-down Bracket)
Lithium Battery

1-6 Themis Computer
RES-32XEL Installation Guide
1.1.1 Special Features
1.1.1.1 BIOS Recovery
The BIOS recovery function allows the BIOS image file to be recovered if the BIOS
flash procedure fails.
1.1.1.2 Recovery from AC Power Loss
The BIOS setup can be configured to allow the system, whenever AC power is lost,
• to remain off (in which case, the power switch must be activated by the user) or
• return to a power-on state automatically when power is restored.
The system default is Always On.
1.1.1.3 Voltage Monitors
A built-in voltage monitor continually scans multiple voltages (CPU cores, chipset
voltage, +3.3V, +5V, +12V, and +3.3V standby) on the motherboard. If a voltage
becomes unstable, it issues a warning or sends an error message to the screen. Volt-
age thresholds can be adjusted through the PC health-monitor utility to define the
sensitivity of the voltage monitor.
1.1.1.4 Fan Status Monitor
The RES-32XEL has ten cooling fans, four at the frontof the motherboard, one on
each CPU, and two in the power supply. The PC health-monitor utility can be used to
check the RPM status of cooling fans with certain fans controlled by power-manage-
ment functions and overheat detection logic.
1.1.1.5 Environmental Temperature Control
The thermal control sensor monitors CPU temperature in real time and will activate
the thermal control fan when CPU temperature exceeds a user-defined threshold.
Overheat circuitry operates independently from the CPU, and can continue to moni-
tor overheat conditions even when the CPU is in sleep mode.
Once the thermal sensor detects a CPU temperature that is above the set threshold, it
automatically turns on the thermal control fan to prevent overheat damage to the
CPU. In addition, onboard chassis thermal circuitry can monitor overall system tem-
perature and alert users when chassis temperature exceeds a user-defined threshold.

1-7
Themis Computer
Overview and Specifications
Overview
1.1.1.6 CPU Fan Auto-Off in Sleep (Doze) Mode
The CPU fan activates whenever power is turned on. It continues to operate when
the system enters Standby mode. When in Sleep mode, the CPU will not run at
full power, hence generating less heat. Sleep settings are made through the PC
health-monitor utility.
1.1.1.7 CPU Overheat LED and Control
This feature is enabled by the user through the CPU overheat warning function in the
BIOS. With it, the user can define an overheat temperature that, when exceeded,
activates the overheat fan and the Overheat warning LED.
1.1.1.8 System Resource Alert (optional)
Available only through Intel’s LANDesk Client Manager (an optional third-party
product), this feature is used to notify the user of certain system events. For example,
if the system is running low on virtual memory and there is insufficient disk-drive
space for saving the data, an alert will be issued warning of the potential problem.
1.1.1.9 Auto-Switching Voltage Regulator
The auto-switching voltage regulator for the CPU core can support up to 20A of cur-
rent and auto-sense voltage IDs ranging from 1.4V to 3.5V. This allows the regulator
to run cooler, making the system more stable.
1.1.2 ACPI Features
Advanced Configuration and Power Interface or ACPI defines a flexible and abstract
hardware interface that provides a standard method of integrating power manage-
ment features throughout the system. This includes hardware, the operating system,
and application software. As a result, the system can automatically turn peripherals
(CD-ROMs, NICs, hard-disk drives, and printers, for example) on or off, including
any consumer devices that may be connected to the system (VCRs, TVs, telephones,
and stereo systems, for example).
In addition to providing operating-system power management, ACPI offers a generic
system event mechanism for Plug and Play and an operating-system-independent
interface for configuration control. Plug-and-Play BIOS data structures are lever-
aged, while the implementation is processor-architecture-independent and compati-
ble with both Windows 2000 and Windows NT 5.0.

RES-32XEL Installation Guide
1-8 Themis Computer
1.1.2.1 Microsoft OnNow
With OnNow, a comprehansive approach to system and device power control, a PC
is always ON but appears to be OFF and responds immediately to user requests.
1.1.2.2 Suspend-State Indicator
When the CPU enters a suspend state, the Power LED will start blinking to indicate
that the CPU is in suspend mode. Pressing any key on the keyboard will awaken the
CPU, at which time the power LED will stop blinking and remain on.
1.1.2.3 Wake-Up Alarm
Through the system BIOS settings, the user can configure a timer to awaken the sys-
tem at a predetermined time.
1.1.2.4 Main Switch Override
ATX 2.01-compliant power supply only. If enabled in the system setup, the RES-
32XEL power button on the front of the unit functions as a system suspend button to
enter a SoftOff state. The monitor will be suspended, and the hard drive will spin
down. Depressing the power button again will cause the system to awaken.
During the SoftOff state, the ATX power supply provides only enough power to
keep the minimum required circuitry alive. If you want to turn the power off com-
pletely, in the case of a system malfunction, for example, depress and hold the power
button for four (4) seconds. The system will turn off completely with no power to the
motherboard provided.
1.1.2.5 External Modem Ring-On
ATX 2.01-compliant power supply only. When the system is in the SoftOff state, it
can be awakened by the ringing of an external modem. This feature can only be pro-
vided if “External Modem Ring-On” is included in the installed modem card and the
corresponding setting is enabled in the system BIOS settings.
1.1.2.6 Wake-On-LAN
ATX 2.01-compliant power supply only. Wake-On-LAN (WOL) is the ability of a
remote management application to power up a computer that is powered off. To keep
daily LAN maintenance traffic to a minimum and avoid needless interruptions to
LAN users during work hours, remote PC setup, updates, and asset tracking can be
planned to occur during off-hours and weekends. To operate, WOL must be enabled
in the BIOS setup of the system.

Overview and Specifications
Overview
1-9
Themis Computer
1.1.3 System LEDs and I/O Connectors
All RES-32XEL system LEDs are located on the front panel and all I/O connectors
are located on the rear panel (see Figure 1-5). LEDs are described in Table 1-2 on
page 1-10; connectors are described in Table 1-3, page 1-10.
Figure 1-5. RES-32XEL LEDs and I/O Connectors
I/O Connectors
Front Panel (behind Lockable Hinged Bezel)
Rear Panel
PS/2 Keyboard
USB0 (top)
USB1 (bottom)
COM1
Port
COM2
Port
LAN Port
(Gigabit Ethernet)
MICLine In
Audio
Line Out
PS/2 Mouse
RESET
Parallel
Port
NIC Overheat
C
ENET
LEDs
01
SCSI
Drive 1
SCSI
Drive 0
Power Upper
Power
Fail
Lower
Power
Fail
Upper
Power
Supply
Lower
Power
Supply

RES-32XEL Installation Guide
1-10 Themis Computer
Table 1-2. System LEDs
Symbol LED Description
Power zIndicates that the system is turned on.
SCSI Drives 0/1 zIndicates SCSI hard-drive activity.
Left LED = drive 0; right LED = drive 1.
Ethernet NIC zIndicates network activity.
Upper Power Fail zWarns that there is a power failure in the upper
power supply.
Lower Power Fail zWarns that there is a power failure in the lower
power supply.
Overheat zWarns that the system is exceeding specified
temperature parameters.
ENET
C
Table 1-3. I/O Connectors
Connector Description
PS/2 Mouse z6-pin mini-DIN (female) connector to attach a PS/2
mouse device.
PS/2 Keyboard z6-pin mini-DIN (female) connector to attach a PS/2
keyboard device.
USB0 / USB1
Hi-Speed USB 2.0 Serial Ports
zTwo 4-pin USB connectors to attach serial devices
to USB port 0 and USB port 1.
COM1 / COM2 Serial Ports zTwo DB9 (male) connectors to attach serial devices
to COM1 and COM2 ports.
Parallel Port zDB25 (female) connector to attach a parallel port
device.
Ethernet LAN Port zStandard RJ45 connector to attach a
10/100NBase-T Ethernet LAN line.
Line In / Line Out / MIC zOne mini-jack to connect an audio line in, one mini-
jack for an audio line out, and one mini-jack for a
microphone input cable.
