Thermaltake W0116RU User manual

80 PLUS Verification and Testing Report
TYPICAL EFFICIENCY (50% Load):
AVERAGE EFFICIENCY :
80 PLUS COMPLIANT: YES
Value
Units
115-230 Volts
10 Amps
47-63 Hz
750
Watts
Note: All measurements were taken with input voltage at 115 V nominal and 60 Hz. Input AC Current Waveform (ITHD = 6.04%, 50% Load)
I
RMS
PF
A
-12V
3.3V
5V*
5VSB
1.65 0.99 7.1% 20% Light 187 12.2/0.2 3.3/3.6 5.1/3.4 4.9/0.6 151 80.78%
3.92 1.00 6.0% 50% Typical 449 12.2/0.4 3.3/9.1 4.9/8.5 4.9/1.5 375 83.60%
8.07 1.00 5.4% 100% Full 926 12.3/0.8 3.2/18.1 4.9/17 4.8/3 744 80.36%
Tested by Electric Power Research Institute, Knoxville, TN.
8/10/2007
Efficiency
%
Rated Output Power
Load
(%)
Rated Specifications
Input Voltage
Input Current
I
THD
(%) Input
Watts
Fraction
of Load DC Terminal Voltage (V)/ DC Load Current (A) Output
Watts
12V (cumulative of 12V1, 12V2, etc.)
12.1/9.7
12/24.3
11.9/48.4
Test Date
Input Frequency
337.3
Type
Ecos ID #
Model Number
Serial Number
Year ATX
NA
2007
Manufacturer
83.60%
81.58%
Thermaltake
W0116RU
Input and Output Power
Input Watts
Output Watts
0
100
200
300
400
500
600
700
800
900
1000
20% 50% 100%
Loading (% of Rated Output Power)
Power (Watts)
Efficiency of the Power Supply
30%
40%
50%
60%
70%
80%
90%
0% 25% 50% 75% 100% 125%
Loading (% of Rated Output Power)
Efficiency (%)
Efficiency %
These tests were conducted as a part of the 80 PLUS program. 80 PLUS is
a computer buy-down program to promote high-efficiency power supplies
(greater than 80% efficiency in the active mode) in desktop computers and
desktop-derived servers.
Input Current and Voltage Waveforms
-200
-150
-100
-50
0
50
100
150
200
0 0.003 0.006 0.009 0.012 0.015
Time (s)
Voltage (V)
-15
-10
-5
0
5
10
15
Current (A)
Voltage Current
