Thermo Scientific RadEye SPRD User manual

Operating Instructions DB-100 E
RadEye SPRD
Spectroscopic Radiation Detector

RadEye SPRD DB-100 E 0-1
Pi/Ff 04.11.2014
REVISIONS SHEET:
Rev. Rev.
state
Dept.
resp.
Name Rev.
page
Cat.
*)
Explanation
23.07.14 RM&SI-EH Pijahn/
A 29.07.14 RM&SI-E Trost Cpl.
B 15.09.14 RM&SI-EH Pijahn Firmware V1.04
C 04.11.14 RM&SI-EH Pijahn Firmware V1.07
*) Category C: editorial correction
I: clearing improvement
A: substantial amendment
Explanations must be given, at least with Category A.

0-2 DB-100 E RadEye SPRD
Pi/Ff 04.11.2014
CONTENTS:
1. Introduction......................................1-1
2. Installation and start-up..................2-1
2.1 Scope of delivery ......................................................2-1
2.2 Inserting the battery ..................................................2-2
2.3 Mounting of the protection sleeve ............................2-4
2.4 Switching the unit on ................................................2-5
3. Configuration...................................3-1
3.1 Ratemeter..................................................................3-1
3.1.1 Basic display......................................................3-1
3.1.2 Information mode display..................................3-5
3.1.3 Channel mode display .......................................3-6
3.1.4 Cross-mode display ...........................................3-7
3.2 Scaler ........................................................................3-8
3.2.1 Mean value ........................................................3-9
3.2.2 Accumulated counts ........................................3-10
3.2.3 Wait time .........................................................3-10
3.2.4 Background measurement ...............................3-11

RadEye SPRD DB-100 E 0-3
Pi/Ff 04.11.2014
3.3 Nuclide identification .............................................3-13
3.3.1 “Home” Button................................................3-14
3.3.2 Measuring ........................................................3-14
3.3.3 Result...............................................................3-15
3.3.4 View saved spectrum.......................................3-18
3.3.5 Trigger list .......................................................3-18
3.4 Menu functions .......................................................3-18
3.4.1 Main menu.......................................................3-19
3.4.2 Sub menu “Nuc ID Settings”...........................3-22
3.4.3 Sub menu “Alarm indication” .........................3-23
3.4.4 Sub menu “Settings”........................................3-24
3.4.5 Sub menu “Edit alarm”....................................3-25
3.4.6 Sub menu “Scaler parameter”..........................3-26
3.4.7 Sub menu “Operation mode”...........................3-27
3.4.8 Sub menu “Measuring unit” (G / N)................3-27
3.4.9 Sub menu “Scaler Backgnd” ...........................3-28
3.5 Alarm thresholds.....................................................3-29
3.6 Gamma alarm threshold based on the relative
standard deviation (sigma threshold)......................3-30
3.7 Setting alarm thresholds..........................................3-31

0-4 DB-100 E RadEye SPRD
Pi/Ff 04.11.2014
4. Operation.......................................... 4-1
4.1 Audible single pulse indication and finder mode......4-1
4.2 Rated alarm...............................................................4-2
4.3 Alarm indication .......................................................4-3
4.4 Additional information .............................................4-4
4.5 Alarm latching ..........................................................4-5
4.6 Text Info ...................................................................4-7
4.7 Set date and time.......................................................4-7
4.8 Battery type...............................................................4-8
4.9 Lu-Adjust..................................................................4-9
5. Detection of gamma sources..........5-1
5.1 Background...............................................................5-2
5.2 NBR (natural background rejection).........................5-2
6. Indication of neutron sources........6-1

RadEye SPRD DB-100 E 0-5
Pi/Ff 04.11.2014
7. Functional test.................................7-1
7.1 Functional test...........................................................7-1
7.2 Failure indication ......................................................7-2
7.3 Overload indication...................................................7-3
7.4 Temperature warning................................................7-4
8. PC configuration..............................8-1
8.1 Ways to connect to a PC ...........................................8-1
8.1.1 Wireless connection via Bluetooth ....................8-1
8.1.2 Cable connection ...............................................8-2
8.2 Installation of the optional RadEye.EXE software ...8-3
8.3 Start RadEye.EXE ....................................................8-3
8.3.1 RadEye SPRD Device Parameters.....................8-4
8.3.2 Measurements....................................................8-4
8.3.3 Creating a Measurement File.............................8-6
8.3.4 Select serial interface.........................................8-7
8.4 Configuration............................................................8-8
8.4.1 General configuration ........................................8-8
8.4.2 User defined text..............................................8-10
8.4.3 Mode configuration .........................................8-11
8.4.4 Trigger list .......................................................8-12

0-6 DB-100 E RadEye SPRD
Pi/Ff 04.11.2014
8.4.5 Alarm configuration ........................................8-14
8.4.6 Bluetooth configuration...................................8-15
8.4.7 Menu configuration .........................................8-16
8.5 History ....................................................................8-17
8.6 Logbook..................................................................8-19
8.7 RadEye Spectra.......................................................8-20
8.7.1 Storing spectra to another location ..................8-21
8.7.2 Loading spectra from file ................................8-21
8.7.3 Export spectra data ..........................................8-21
9. Trouble Shooting.............................9-1
9.1 RadEye SPRD doesn’t power on ..............................9-1
9.1.1 Press “On” for at least one second.....................9-1
9.1.2 Check battery.....................................................9-1
9.2 Reading data from the start up screen.......................9-2
9.3 The RadEye doesn’t show the menu items as
described in the manual ............................................9-2
9.4 The RadEye shows an error message in the
display’s top line.......................................................9-3
9.5 The RadEye is not found in the software..................9-3

RadEye SPRD DB-100 E 0-7
Pi/Ff 04.11.2014
9.6 RadEye lost date and time settings ...........................9-5
9.7 RadEye’s battery status is lower than expected ........9-6
9.8 History data shows the wrong time and date ............9-6
10. Maintenance ................................10-1
10.1 Recommended maintenance................................10-1
10.1.1 Lu-Adjust.........................................................10-1
10.1.2 Cleaning the instrument...................................10-1
10.1.3 Remove batteries for storage ...........................10-1
11. Spare Parts..................................11-1
11.1 Available spare parts ...........................................11-1
11.2 Recommended spare parts...................................11-1
12. Optional Accessories ................. 12-1
12.1 RadEye Holster (425067046)..............................12-1
12.2 Earphone for RadEye series (425067037)...........12-1
12.3 Lutetium Test-Adapter for RadEye (425067071)12-2
12.4 Desktop holder (425067060)...............................12-2
12.5 IR connection cable serial (4254029)..................12-3

0-8 DB-100 E RadEye SPRD
Pi/Ff 04.11.2014
12.6 IR connection cable USB (4254026) ..................12-3
12.7 Bluetooth battery cover (425067087) .................12-4
12.8 RadEye car- and wall holder with accumulator
charging circuit....................................................12-4
12.8.1 Accessories for dash board mounting of
car holder 42506/7065
(including charging function)
holder 42506/7060 (mechanical holder only)..12-8
12.8.2 Accessories for data transmission using the
car adaptor .....................................................12-10
12.8.3 Accessories for AC – operation of the
car adaptor .....................................................12-10
12.9 RadEye Area Monitor with alarm
contacts (4250680) .........................................12-11
12.10 Foodmonitor (425069015) ................................12-12
13. Technical data............................. 13-1
13.1 RadEye SPRD .....................................................13-1
13.2 RadEye car holder ...............................................13-7

RadEye SPRD DB-100 E 0-9
Pi/Ff 04.11.2014
13.3 Firmware version ................................................13-8
V 1.00.............................................................................13-8
V 1.03.............................................................................13-8
V 1.04.............................................................................13-9
V 1.07...........................................................................13-10
14. Annex...........................................14-1
14.1 Interrelationship between false alarm
probability and sigma value ................................14-1
14.2 Flow Diagram Background Learning & Alarming14-2
14.3 Factory Settings RadEye SPRD ..........................14-3
15. Service contact............................15-1
TABLE OF FIGURES:
Diagram 12-1: Gamma dose rate linearity of
RadEye SPRD .......................................... 13-5
Diagram 12-2: Ambient equivalent dose rate response...... 13-6
Diagram 12-3: Energy response in main direction
count rate .................................................. 13-6

0-10 DB-100 E RadEye SPRD
Pi/Ff 04.11.2014
SAFETY INSTRUCTIONS
Do not use the unit if error messages appear on the screen.
The earphone connector at the bottom side of the instrument
must be exclusively used by equipment that is specified for
use with RadEye SPRD.
The instrument must not be used in explosive atmosphere.
The RadEye SPRD is not intended to be used as a personal
dosimeter. No neutron dose rate or dose calculation is per-
formed. Due to the high detector sensitivity the gamma dose
rate measuring range of the RadEye SPRD is limited to
250 µSv/h (25 mrem/h). For higher dose rates (indicated by
“Overload”) an underestimation of the integrated gamma dose
can be expected.
The RadEye SPRD shall not be used for measurements in
pulsed fields.

RadEye SPRD DB-100 E 0-11
Pi/Ff 04.11.2014
WEEE Compliance:
This product is required to comply with the European Union’s
Waste Electrical & Electronic Equipment (WEEE) Directive
2002/96/EC. It is marked with the following symbol:
Thermo Fisher Scientific has contracted with one or more re-
cycling/disposal companies in each EU Member State, and this
product should be disposed of or recycled through them. Fur-
ther information on Thermo Fisher Scientific compliance with
these Directives, the recyclers in your country, and informa-
tion on Thermo Fisher Scientific products which may assist
the detection of substances subject to the RoHS Directive are
available at www.thermo.com/WEEERoHS

RadEye SPRD DB-100 E 1-1
Pi/Ff 04.11.2014
1. Introduction
The RadEye SPRD radiation pagers are highly sensitive and
rugged measuring devices to detect and localize gamma and
neutron radiation sources.
Furthermore, by virtue of the so called NBR-technique (natu-
ral Background Rejection) the RadEye SPRD pagers separate
man-made (non-NORM1) gamma radiation from natural back-
ground fluctuations. As well, the energy compensated dose
rate of gamma radiation (Sv/h) can be measured. In this con-
text it is important to note, that users may select “R/h” as a
display unit, with the understanding that the energy response
characteristic is not altered by this selection. Within the Rad-
Eye SPRD the relation 1 R = 1 rem = 10 mSv is used.
The instrument is designed to meet the requirements in the
ANSI standard 42.48 in respect to gamma radiation.
1
Natural Occurring Radioactive Material (NORM).

1-2 DB-100 E RadEye SPRD
Pi/Ff 04.11.2014
The RadEye SPRD incorporates a single CsI (Tl) Cesium Io-
dide Scintillator which is equipped with a miniature silicon
photo-multiplier (SiPM) allowing the detection of very low
radiation levels.
While the RadEye SPRD does not contain a specific thermal
neutron detector, it does analyze specific characteristic fea-
tures of the measured gamma spectrum to indicate the pres-
ence of a neutron source.
The RadEye SPRD pager identifies to the user whether the
alarms are due to gamma or neutron by a different colored
alarm LED, different tones and flashing the count rate / dose
rate display readings with an inverted display background of
the alarming channels or both channels as appropriate. The
RadEye SPRD also has different audible alarms discriminating
between elevated background/NORM and any artificial iso-
tope alarm also the gamma and neutron audible alarms are
clearly different. This gives the RadEye SPRD audible and
visual identification using NBR of the type of material de-
tected.
The last 1600 mean and maximum values of gamma count
rate, neutron count rate and gamma dose rate data points are
recorded internally and can be read out via serial interface.
Additionally the last 250 alarms, errors and changes of the
configuration are logged. All events can be read out via serial
interface.

RadEye SPRD DB-100 E 1-3
Pi/Ff 04.11.2014
A real time clock is provided to add a time stamp to all buffer
data.
The RadEye SPRD enables measurement of detector pulse
rates and energy compensated dose and dose rates.
All menu functions described in 3.4 can be configured to be
invisible.
Thus the instrument can be configured to both, an extremely
simple mode allowing just LCD-illumination and alarm ac-
knowledgment to a very versatile mode for the more experi-
enced user.
Key on top side to acknowl-
edge alarms if worn in a
holster
Powerful graphical display.
Units in cps, Roentgen,
Rem or Sievert.
Easy to use, four key,
menu driven user interface
Orange LED: gamma
alarm / blue LED:
neutron alarm
LEDs are showing
radiation exceeding
thresholds. Visible
from top if
worn in a holster
and from display side
Rugged plastic enclosure
Earphone connector

RadEye SPRD DB-100 E 2-1
Pi/Ff 04.11.2014
2. Installation and start-up
2.1 Scope of delivery
The RadEye is delivered in a folding paper box together with
two AAA cells, a rubber protection sleeve and an operating
manual.
For optional accessories see chapter 12.

2-2 DB-100 E RadEye SPRD
Pi/Ff 04.11.2014
2.2 Inserting the battery
The two AAA-Alkaline cells as delivered with the instrument
allow est. 170 h of normal operation.
AAA size rechargeable batteries can be used as well.
•Switch off the measuring instrument and wait about 5s for
complete shutdown.
•Remove rubber boot.
•Open the cover of the battery compartment.
Use of a coin is recommended.
•Exchange the batteries according to the shown polarity.
•Close the compartment cover hooks first, care for the rub-
ber seal being in its groove.
•Switch on the unit again. (see chapter 2.4)
The instrument continues working in the operating mode set
last (see chapter 3.2).
