ThermoFisher Scientific SL 40 F User manual

Thermo Scientific
SL 40 F
SL 40 FR
Instruction manual
50122832-e • 04 / 2020
Visit us online to register your warranty:
thermofisher.com/labwarranty

WEEE Conformity
This product is subject to the regulations of the EU Waste Electrical & Electronic Equipment
(WEEE) Directive 2012/19/EU. It is marked by the following symbol:

Thermo Scientific SL 40 F / SL 40 FR i
T
Preface .......................................................................................................................................iii
Scope of Supply ........................................................................................................................iii
Intended Use .............................................................................................................................iii
Accident Prevention ................................................................................................................ iv
Precautions ............................................................................................................................... iv
Chapter 1 Introduction and Description ...............................................................................................1-1
Characteristics of the Thermo Scientific SL 40 F/ SL 40 FR ....................................1-2
Technical Data .........................................................................................................1-3
Directives, Standards and Guidelines ............................................................................1-4
Functions and Features ............................................................................................................. 1-5
Mains Supply ...........................................................................................................1-5
Rotor Selection .........................................................................................................1-6
Chapter 2 Before use ................................................................................................................................2-1
Before Setting up ......................................................................................................2-2
Setting up .................................................................................................................2-2
Transporting the Centrifuge .....................................................................................2-4
Location ...................................................................................................................2-4
Aligning the Centrifuge ............................................................................................2-4
Mains Connection ....................................................................................................2-5
Storage .....................................................................................................................2-6
Chapter 3 Control Panel ...........................................................................................................................3-1
Control Panel ...........................................................................................................3-2
Keys .........................................................................................................................3-2
Chapter 4 Operation .................................................................................................................................4-1
Switch on Centrifuge ................................................................................................4-2
Lid Opening .............................................................................................................4-2
Close Lid ..................................................................................................................4-2
Rotor Installation .....................................................................................................4-2
Entering Parameters .................................................................................................4-4
Centrifugation ........................................................................................................4-10
Temperature Adaptation during Standstill ..............................................................4-11
Short-term Centrifugation ......................................................................................4-11
Removing the Rotor ...............................................................................................4-12
Aerosol-tight Rotors ...............................................................................................4-12
Aligning the Centrifuge ..........................................................................................4-13
Table of Contents

T Table of Contents
ii SL 40 F / SL 40 FR Thermo Scientific
Chapter 5 System Menu .......................................................................................................................... 5-1
Description .............................................................................................................. 5-3
Chapter 6 Maintenance and Care ......................................................................................................... 6-1
Cleaning Intervals .................................................................................................... 6-2
Cleaning .................................................................................................................. 6-2
Disinfection ............................................................................................................. 6-3
Decontamination ..................................................................................................... 6-4
Autoclaving .............................................................................................................. 6-5
Service of Thermo Fisher Scientific .......................................................................... 6-5
Chapter 7 Trouble Shooting .................................................................................................................... 7-1
Mechanical Emergency Door Release ...................................................................... 7-2
Troubleshooting by User ......................................................................................... 7-3
When to contact Customer Service .......................................................................... 7-5
Chemical Compatibility Chart ...............................................................................A-1

Thermo Scientific SL 40 F / SL 40 FR iii
P
Preface
Before starting to use the centrifuge, read through this instruction manual carefully and follow the
instructions.
The information contained in this instruction manual is the property of Thermo Fisher Scientific; it is
forbidden to copy or pass on this information without explicit approval.
Failure to follow the instructions and safety information in this instruction manual will result in the
expiration of the sellers warranty.
Scope of Supply
If any parts are missing, please contact your nearest Thermo Fisher Scientific representative.
Intended Use
•This centrifuge is an IVD accessory, and therefore subject to the Directive 98/79/EC of the
European Parliament and the Council of October 27, 1998 on in vitro diagnostic medical devices.
•This centrifuge is a laboratory product designed to separate components by generation of Relative
Centrifugal Force. It separates human samples (e.g. blood, urine and other body fluids) collected
in appropriate containers, either alone or after addition of reagents or other additives.
•As general-purpose centrifuge, it is designed to also run other containers filled with chemicals,
environmental samples and other non-human body samples.
•This centrifuge should be operated by trained specialists only.
Article Number Quantity Check
Centrifuge Thermo Scientific SL 40 F 1
Power supply cable 1
50122832 Instruction manual 1
70009824 Anti-corrosion oil 1

P Preface
iv SL 40 F / SL 40 FR Thermo Scientific
Accident Prevention
Prerequisite for the safe operation of the Thermo Scientific SL 40 F / SL 40 FR is a work
environment in compliance with standards, directives and trade association safety regulations and
proper instruction of the user.
The safety regulations contain the following basic recommendations:
•Maintain a radius of at least 30 cm around the centrifuge.
•Implementation of special measures which ensure that no one can approach the centrifuge for
longer than absolutely necessary while it is running.
•The mains plug must be freely accessible at all times. Pull out the power supply plug or
disconnect the power supply in an emergency.
Precautions
In order to ensure safe operation of the Thermo Scientific SL 40 F / SL 40 FR, the following
general safety regulations must be followed:
•The centrifuge should be operated by trained specialists only.
•The centrifuge is to be used for its intended use only.
•Plug the centrifuge only into sockets which have been properly grounded.
•Do not move the centrifuge while it is running.
•Do not lean on the centrifuge.
•Use only rotors and accessories for this centrifuge which have been approved by Thermo Fisher
Scientific. Exceptions to this rule are commercially available glass or plastic centrifuge tubes,
provided they have been approved for the speed or the RCF value of the rotor.
•Do not use rotors which show any signs of corrosion and/or cracks.
•Do not touch the mechanical components of the rotor and do not make any changes to the
mechanical components.
•Use only with rotors which have been properly installed. Follow the instructions on the Autolock
in section “Rotor Installation” on page 4-2.
•Use only with rotors which have been loaded properly. Follow the instructions given in the rotor
manual.
•Never overload the rotor. Follow the instructions given in the rotor manual.
•Never start the centrifuge when the lid is open.
•Never open the lid until the rotor has come to a complete stop and this has been confirmed in
the display.

P Preface
Thermo Scientific SL 40 F / SL 40 FR v
•The lid emergency release may be used in emergencies only to recover the samples from the
centrifuge, e.g. during a power failure (see section “Mechanical Emergency Door Release” on
page 7-2).
•Never use the centrifuge if parts of its cover panels are damaged or missing.
•Do not touch the electronic components of the centrifuge or alter any electronic or mechanical
components.
•Please observe the safety instructions.
Please pay particular attention to the following aspects:
•Location: well-ventilated environment, set-up on a level and rigid surface with adequate
load-bearing capacity.
•Rotor installation: make sure the rotor is locked properly into place before operating the
centrifuge.
•Especially when working with corrosive samples (salt solutions, acids, bases), the accessory parts
and vessel have to be cleaned carefully.
•Always balance the samples.
Centrifuging hazardous substances:
•Do not centrifuge explosive or flammable materials or substances which could react violently with
one another.
•The centrifuge is neither inert nor protected against explosion. Never use the centrifuge in an
explosion-prone environment.
•Do not centrifuge inflammable substances.
•Do not centrifuge toxic or radioactive materials or any pathogenic micro-organisms without
suitable safety precautions.
When centrifuging microbiological samples from the Risk Group II (according to the “Bio-safety
Manual”of the World Health Organization WHO), aerosol-tight biological seals have to be used.
For materials in a higher risk group,extra safety measures have to be taken.
•If toxins or pathogenic substances have gotten into the centrifuge or its parts, appropriate
disinfection measures have to be taken (see “Disinfection” on page 6-3).
•Highly corrosive substances which can cause material damage and impair the mechanical stability
of the rotor,should only be centrifuged in corresponding protective tubes.
IF A HAZARDOUS SITUATION OCCURS, TURN OFF THE POWER SUPPLY TO THE
CENTRIFUGE AND LEAVE THE AREA IMMEDIATELY.
Intended Use
The centrifuge is to be used for separating materials of different density or particle size suspended in a
liquid.
Maximum sample density at maximum speed: 1,2 g
cm3
-----------

P Preface
vi SL 40 F / SL 40 FR Thermo Scientific
This symbol refers to general hazards.
CAUTION means that material damage could occur.
WARNING means that injuries or material damage or contamination could occur.
This symbol refers to biological hazards.
Observe the information contained in the instruction manual to keep yourself and your
environment safe.

Thermo Scientific SL 40 F / SL 40 FR 1-1
1
Introduction and Description
Contents
•“Characteristics of the Thermo Scientific SL 40 F / SL 40 FR” on page 1-2
•“Technical Data” on page 1-3
•“Directives, Standards and Guidelines” on page 1-4
•“Functions and Features” on page 1-5
•“Mains Supply” on page 1-5
•“Rotor Selection” on page 1-6

1Introduction and Description
Characteristics of the Thermo Scientific SL 40 / SL 40 FR
1-2 SL 40 F / SL 40 FR Thermo Scientific
Characteristics of the Thermo Scientific SL 40 / SL 40 FR
The Thermo Scientific SL 40 / SL 40 FR is an in-vitro diagnostics device according to the In-Vitro
Diagnostics Directive 98/79/EC.
Several rotors with a wide range of tubes can be used.
The set speed is reached within seconds. The maintenance-free induction motor ensures quiet and
low-vibration operation even at high speeds, and guarantees a very long lifetime.
The user-friendly control panel makes it easy to pre-set the speed, RCF value, running time,
temperature, and running profile (acceleration and braking curves). You can choose between the
display of speed and RCF or the entry mode.
These settings can be changed even while the centrifuge is running.
With the help of the PULSE key , you can also centrifuge a sample for justa few seconds, if called
for.
The Thermo Scientific SL 40 / SL 40 FR is equipped with various safety features:
•The housing and rotor chamber consist of steel plate, the interior of armour steel, while the front
panel is made of high-impact resistant plastic.
•The lid is equipped with a view port and a lock.
•The lid of the centrifuge can only be opened while the centrifuge is switched on and the rotor
has come to a complete stop. The centrifuge cannot be started until the lid has been closed
properly.
•The integrated rotor detection systems ensures that no inadmissible speed settings can be
preselected.
•Electronic imbalance recognition
•Lid emergency release: For emergencies only, e.g. during power failures (see “Mechanical
Emergency Door Release” on page 7-2)

1 Introduction and Description
Technical Data
Thermo Scientific SL 40 F / SL 40 FR 1-3
Technical Data
The technical data of the Thermo Scientific SL 40 F / SL 40 FR is listed in the following table.
Table1-1.Technical Data Thermo Scientific SL 40 F / SL 40 FR
Feature Value
Environmental conditions -Use in interior spaces
-Altitudes of up to 2,000 m above sea level
-Max. relative humidity 80 % up to 31 °C; decreasing linearly up to 50 %
relative humidity at 40 °C.
Permissible ambient temperature +2 °C to +35 °C +2 °C to +35 °C
Overvoltage category II II
Pollution degree 2 2
Heat dissipation Ventilated Refrigerated
230 V 120 V 230 V 120 V
6653 BTU/h 4776 BTU/h 5800 BTU/h 4776 BTU/h
IP 20 20
Running time Unlimited Unlimited
Max Speed nmax 15200 rpm (depending on the rotor) 15200 rpm (depending on the rotor)
Min Speed nmin 300 rpm 300 rpm
Maximum RCF value at nmax 25314 x g 25314 x g
Maximum kinetic energy < 62.5 kJ < 62.5 kJ
Noise level at maximum speed < 64 dB (A) < 64 dB (A)
Temperature setting range -10 ? to +40 ?
Dimensions Ventilated Refrigerated
Height
Width
Depth
Table top height
840 mm
550 mm
670 mm
790 mm
840 mm
550 mm
670 mm
790 mm
Weight without rotor 152.5 kg 142.5 kg

1Introduction and Description
Directives, Standards and Guidelines
1-4 SL 40 F / SL 40 FR Thermo Scientific
Directives, Standards and Guidelines
Table 1-2. Directives, Standards and Guidelines
Tension /
Frequency
Produced and inspected according to the following
standards and guidelines
230 V,50 / 60 Hz 2006/95/EC Low Voltage Directive:
2006/42/EC & 98/37/EC Machine Directive:
2004/108/EC EMC Directive
98/79/EC In-vitro-Diagnostika (IvD)
EN 61010-1, 2nd Edition
EN 61010-2-020, 2nd Edition
EN 61010-2-101
EN 61326-1
EN 61326-2-6
EN 55011B
EN 61000-6-2
EN ISO 13485
230 V,60 Hz
120 V,60 Hz
100 V,60 Hz
UL 61010-1, 2nd Edition
CAN/CSA-C22.2 No. 61010-1, 2nd Edition
IEC 61010-2-20, 2nd Edition
(Pollution degree 2, Overvoltage category II)
IEC 61010-2-101
Emitted interference FCC Part 15 CLASS A
NOTE: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated in
a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.
100 V,50 Hz IEC 61010-1 2nd Edition
IEC 61010-2-020 2nd Edition
IEC 61010-2-101
EN 61326-1
EN 61326-2-6
EN 55011A
EN 61000-6-2
EN ISO 13485

1 Introduction and Description
Functions and Features
Thermo Scientific SL 40 F / SL 40 FR 1-5
Mains Supply
Functions and Features
The following table gives an overview of the important functional and performance characteristics
of the Thermo Scientific SL 40 F / SL 40 FR.
Table1-3.Functions and Features
Component / Function Description / Features
Structure / Housing Galvanized steel chassis with armoured plating
Chamber Stainless steel / varnished steel
Drive Induction drive without carbon brushes
Keys and display Easy-to-clean keypad and display surface
Controls Microprocessor-controlled
Internal memory The most recent data is saved
Functions RCF-selection, temperature control, pretemp with cooling equipped
devices
Acceleration / braking profiles 9 acceleration and 10 braking curves
Rotor recognition Automatic
Imbalance recognition Electronic, contingent on rotor and speed
Lid lock Automatic lid closing and locking starting from an initial hold position
The following table contains an overview of the electrical connection data for the Thermo Scientific
SL 40 F / SL 40 FR. This data is to be taken into consideration when selecting the mains connection
socket.
Table1-4.Electrical connection data of the Thermo Scientific SL 40 F / SL 40 FR
Cat. Ma
volt
ins
age Frequency Rated
current
Power
consumption
Equipment
fuse
Building
fuse
75004543 Refrigerated 230 V ±10 %50 / 60 Hz 10,5 A 1950 W 15 AT 16 AT
75004542 Ventilated 230 V ±10 % 50 / 60 Hz 11 A 1700 W 15 AT 16 AT

1Introduction and Description
Rotor Selection
1-6 SL 40 F / SL 40 FR Thermo Scientific
Rotor Selection
The Thermo Scientific SL 40 F / SL 40 FR is supplied without a rotor.
Various rotors are available to choose from.
The technical data of the rotors and the corresponding adapters and reduction sleeves for various
commercially available containers can be found in the corresponding rotor operating manuals.
For more information visit our website at: http://www.thermofisher.com
TX-750 75003607
with round buckets 75003608
with rectangular buckets 75003614
incl. Microtiter carrier 75003617
incl. ABI-bucket 75003618
BIOshieldTM 1000A 75003603
BIOLinerTM 75003667
HIGHPlateTM 6000 75003606
FIBERLiteTM H3LV 75003665
FIBERLiteTM F14S-6 x 250 LE 75003662
FIBERLiteTM F15-6 x 100 75003698
FIBERLiteTM F13S-14 x 50c 75003661
FIBERLiteTM F15-8 x 50c 75003663
FIBERLiteTM F21-48 x 2 75003664
Microliter 48 x 2 75003602
HIGHConicTM 6 x 100 75003620
M-20 75003624

Thermo Scientific SL 40 F / SL 40 FR 2-1
2
Before use
Contents
•“Before Setting up” on page 2-2
•“Transporting the Centrifuge” on page 2-4
•“Location” on page 2-4
•“Aligning the Centrifuge” on page 2-4
•“Mains Connection” on page 2-5
•“Storage” on page 2-6

2Before use
Before Setting up
2-2 SL 40 F / SL 40 FR Thermo Scientific
Before Setting up
1. Check the centrifuge and the packaging for any shipping damage.
Inform the shipping company and Thermo Fisher Scientific immediately if any damage is
discovered.
2. Remove the packaging.
3. Check the order for completeness (see “Scope of Supply” on page iii).
If the order is incomplete, please contact Thermo Fisher Scientific.
Setting up
1. Place the pallet with the centrifuge so that you have at leased 1.5 m room in front of the pallet.
2. Release the rails from the pallet.

2 Before use
Setting up
Thermo Scientific SL 40 F / SL 40 FR 2-3
3. Screw the rails onto the pallet in front of the centrifuge.
4. Remove the protectors that locate the centrifuge on the pallet. Release the castors. Use several
people in order to roll the centrifuge off the pallet.
5. Fix the castors once the centrifuge is in its final position.

2Before use
Transporting the Centrifuge
2-4 SL 40 F / SL 40 FR Thermo Scientific
Transporting the Centrifuge
•Due to its weight (see “Technical Data” on page 1-3), the centrifuge should be carried by several
people.
•The centrifuge can be damaged by impacts.
•Transport the centrifuge upright and if at all possible in its packaging.
Location
The centrifuge should only be operated indoors.
The set-up location must fulfil the following requirements:
•A safety zone of at least 30 cm must be maintained around the centrifuge.
People and hazardous substances must be kept out of the safety zone while centrifuging.
•The supporting structure must be stable and free of resonance, for example a level laboratory
bench.
•The supporting structure must be suitable for horizontal setup of the centrifuge.
•The centrifuge should not be exposed to heat and strong sunlight.
•The set-up location must be well-ventilated at all times.
Aligning the Centrifuge
The horizontal alignment of the centrifuge must be checked every time after moving it to a different
location.
The supporting structure must be suitable for horizontal setup of the centrifuge.
CAUTION Fix the castors.
WARNING Always remove the rotor before moving the centrifuge.
WARNING UV rays reduce the stability of plastics.
Do not subject the centrifuge, rotors and plastic accessories to direct sunlight.
CAUTION If the centrifuge isn’tlevel, imbalances can occur and the centrifuge can be
damaged.
Do not place anything under the feet to level the centrifuge.

2 Before use
Mains Connection
Thermo Scientific SL 40 F / SL 40 FR 2-5
Mains Connection
Figure 2-1. Mains Connection
1. Turn off the power supply switch on the back (press “0”).
2. Plug the centrifuge into grounded electrical sockets only.
3. Check whether the cable complies with the safety standards of your country.
4. Make sure that the voltage and frequency correspond to the figures on the rating plate.
5. Establish the connection to the power supply with the connecting cable.
Main Power
Mains plug

2Before use
Storage
2-6 SL 40 F / SL 40 FR Thermo Scientific
Storage
•Before storing the centrifuge and the accesories it must be cleanedand if necessary desinfected
and decontaminated.
•Store the centrifuge in a clean, dust-free location.
•Be sure to place the centrifuge on its feet.
•Avoid direct sunlight.
•Fix the castors.
