Thermo Scientific
TX-200
Instruction Manual
50121026-d • 05 / 2020
Visit us online to register your warranty:
thermofisher.com/labwarranty

WEEE Conformity
This product is subject to the regulations of the EU Waste Electrical & Electronic
Equipment (WEEE) Directive 2012/19/EU. It is marked by the following symbol:

Thermo Scientific 75003658 TX-200 i
T
Preface .......................................................................................................................................iii
Scope of Supply ........................................................................................................................iii
Precautions ...............................................................................................................................iii
Chapter 1 Rotor Specifications ..............................................................................................................1-1
Technical Data ......................................................................................................1-2
230 V,50 / 60 Hz Round Bucket 75003659 .......................................................1-2
120 V,60 Hz Round Bucket 75003655 ..............................................................1-3
230 V,50 / 60 Hz Round Bucket 75003655 .......................................................1-4
120 V,60 Hz Round Bucket 75003655 ..............................................................1-5
100 V,50 / 60 Hz Round Bucket 75003655 ........................................................1-6
230 V,50 / 60 Hz Round Bucket 75003655 ..................................................1-7
120 V,60 Hz Round Bucket 75003655 ...........................................................1-8
Chapter 2 Accessories .............................................................................................................................2-1
Chapter 3 AutoLock™.............................................................................................................................3-1
Rotor Installation .....................................................................................................3-2
Removing the Rotor .................................................................................................3-3
Chapter 4 Rotor Loading ..........................................................................................................................4-1
Before a Run ............................................................................................................4-2
Proper Loading .........................................................................................................4-2
Improper Loading ....................................................................................................4-3
Maximum Loading ...................................................................................................4-3
Cycle Counter ..........................................................................................................4-4
Chapter 5 Aerosol-tight Applications ...................................................................................................5-1
Basic Principles .........................................................................................................5-2
Placing O-ring ..........................................................................................................5-2
Fill Level ...................................................................................................................5-2
Checking the Aerosol-Tightness ...............................................................................5-2
Chapter 6 Maintenance and Care ..........................................................................................................6-1
Cleaning intervals .....................................................................................................6-2
Cleaning ...................................................................................................................6-2
Disinfection ..............................................................................................................6-3
Decontamination .....................................................................................................6-4
Autoclaving ..............................................................................................................6-5
Service of Thermo Fisher Scientific ..........................................................................6-5
Table of Contents

Contents
ii 75003658 TX-200 Thermo Scientific
RCF Values ................................................................................................................A-1
Chemical Compatibility Chart ..............................................................................B-1

Thermo Scientific 75003658 TX-200 iii
P
Preface
Before starting to use the rotor, read through this instruction manual carefully and follow the
instructions.
The information contained in theinstruction manual is the property of Thermo Fisher Scientific; it is
forbidden to copy or pass on this information without explicit approval.
Failure to follow the instructions and safety information in this instruction manual will result in the
expiration of the seller’swarranty.
Scope of Supply
If any parts are missing, please contact the nearest Thermo Fisher Scientific representative.
Precautions
In order to ensure safe operation of the TX-200, the following general safety regulations must be
followed:
•Do not remove the magnet at the rotor bottom.
•Do not use rotors which show any signs of corrosion and / or cracks.
•Use only with rotors which have been loaded properly.
•Never overload the rotor.
Article Number Quantity Check
75003658 TX-200 1
76003500 Rubber seal grease 1
75003786 Bolt grease 1
50121026 Instruction Manual 1

Preface
iv 75003658 TX-200 Thermo Scientific
•Use only accessories which have been approved by Thermo Fisher Scientific. Exceptions to this
rule are commercially available glass or plastic centrifuge tubes, provided they have been approved
for the speed or the RCF value of the rotor.
•Please observe the safety instructions.
Please pay particular attention to the following aspects:
•Rotor installation: Check that the rotor is locked properly into place before operating the
centrifuge.
•Always balance the samples.
Maximum sample density at maximum speed: 1.2 g
cm3
-----------
This symbol refers to general hazards.
ATTENTION means that material damage could occur.
WARNING means that injuries or material damage or contamination could occur.
This symbol refers to biological hazards.
Observe the information contained in the instruction manual to keep yourself and your
environment safe.

Thermo Scientific 75003658 TX-200 1-1
1
Rotor Specifications
Contents
•“Technical Data” on page 1-2

1-2 75003658 TX-200 Thermo Scientific
1Rotor Specifications
Technical Data
Technical Data
Table 1-1. 230 V,50 / 60 Hz Round Bucket 75003659
Centrifuge Multifuge X1 Megafuge 16
Catalog # 75004210 75004230
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 30 / 35 30 / 35
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
60 minutes
10 10
Aerosol-tight *
* Tested byHPA, Porton-down, UK
yes yes
Permissible temperature range autoclavable
°C
121 121
Centrifuge Multifuge X1R Megafuge16R
Catalog # 75004250 75004270
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 30 / 35 30 / 35
Aerosol-tight *yes yes
Permissible temperature range autoclavable
°C
121 121
*Tested by HPA, Porton-down, UK

1 Rotor Specifications
Technical Data
Thermo Scientific 75003658 TX-200 1-3
Table1-2.120 V,60 Hz Round Bucket 75003655
Centrifuge Multifuge X1 Megafuge 16
Catalog # 75004211 75004231
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 35 / 40 35 / 40
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time 60
minutes
99
Aerosol-tight *yes yes
Permissible temperature range autoclavable °C 121 121
*Tested by HPA, Porton-down, UK
Centrifuge Multifuge X1R Megafuge 16R
Catalog # 75004251 75004271
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 35 / 40 35 / 40
Aerosol-tight *yes yes
Permissible temperature range autoclavable °C 121 121
*Tested by HPA, Porton-down, UK

1-4 75003658 TX-200 Thermo Scientific
1Rotor Specifications
Technical Data
Table 1-3. 230 V,50 / 60 Hz Round Bucket 75003655
Centrifuge Sorvall Legend X1 Sorvall ST 16
Catalog # 75004220 75004240
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 30 / 35 30 / 35
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
60 minutes
88
Aerosol-tight *
* Tested byHPA, Porton-down, UK
yes yes
Permissible temperature range autoclavable
°C
121 121
Centrifuge Sorvall Legend X1R Sorvall ST 16R
Catalog # 75004260 75004380
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 30 / 35 30 / 35
Aerosol-tight *yes yes
Permissible temperature range autoclavable
°C
121 121
*Tested by HPA, Porton-down, UK

1 Rotor Specifications
Technical Data
Thermo Scientific 75003658 TX-200 1-5
Table1-4. 120 V,60 Hz Round Bucket 75003655
Centrifuge Sorvall Legend X1 Sorvall ST 16
Catalog # 75004221 75004241
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 35 / 40 35 / 40
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
60 minutes
99
Aerosol-tight *
* Tested byHPA, Porton-down, UK
yes yes
Permissible temperature range autoclavable °C 121 121
Centrifuge Sorvall Legend X1R Sorvall ST 16R
Catalog # 75004261 75004381
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4x275 4x275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 35 / 40 35 / 40
Aerosol-tight *yes yes
Permissible temperature range autoclavable °C 121 121
* Tested byHPA, Porton-down, UK

1Rotor Specifications
Technical Data
1-6 75003658 TX-200 Thermo Scientific
Table 1-5. 100 V,50 / 60 Hz Round Bucket 75003655
Centrifuge Sorvall Legend X1 Sorvall ST 16
Catalog # 75004223 75004243
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 30 / 35 30 / 35
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
60 minutes
99
Aerosol-tight *
* Tested byHPA, Porton-down, UK
yes yes
Permissible temperature range autoclavable
°C
121 121
Centrifuge Sorvall Legend X1R Sorvall ST 16R
Catalog # 75004263 75004383
Weight of empty rotor [kg] 2.5 2.5
Max. cycle number 50,000 50,000
Maximum permissible load [g] 4 x 275 4 x 275
Maximum speed nmax [rpm] 5,500 5,500
Maximum RCF value at nmax 5,580 5,580
Max. / min. radius [cm] 16.5 / 6.4 16.5 / 6.4
Pitch angle [°] 90 90
Accel. / braking time [s] 35 / 40 35 / 40
Aerosol-tight *yes yes
Permissible temperature range autoclavable
°C
121 121
* Tested byHPA, Porton-down, UK

1 Rotor Specifications
Technical Data
Thermo Scientific 75003658 TX-200 1-7
Table1-6.230 V,50 / 60 Hz Round Bucket 75003655
Centrifuge SL 16
Catalog # 75004000
Weight of empty rotor [kg] 2.5
Max. cycle number 50,000
Maximum permissible load [g] 4 x 275
Maximum speed nmax [rpm] 5,500
Maximum RCF value at nmax 5,580
Max. / min. radius [cm] 16.5 / 6.4
Pitch angle [°] 90
Accel. / braking time [s] 30 / 35
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
60 minutes
8
Aerosol-tight *
* Tested byHPA, Porton-down, UK
yes
Permissible temperature range autoclavable °C 121
Centrifuge SL 16R
Catalog # 75004030
Weight of empty rotor [kg] 2.5
Max. cycle number 50,000
Maximum permissible load [g] 4 x 275
Maximum speed nmax [rpm] 5,500
Maximum RCF value at nmax 5,580
Max. / min. radius [cm] 16.5 / 6.4
Pitch angle [°] 90
Accel. / braking time [s] 30 / 35
Aerosol-tight *yes
Permissible temperature range autoclavable
°C
121
* Tested byHPA, Porton-down, UK

1Rotor Specifications
Technical Data
1-8 75003658 TX-200 Thermo Scientific
Table 1-7. 120 V,60 Hz Round Bucket 75003655
Centrifuge SL 16
Catalog # 75004001
Weight of empty rotor [kg] 2.5
Max. cycle number 50,000
Maximum permissible load [g] 4 x 275
Maximum speed nmax [rpm] 5,500
Maximum RCF value at nmax 5,580
Max. / min. radius [cm] 16.5 / 6.4
Pitch angle [°] 90
Accel. / braking time [s] 35 / 40
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
60 minutes
9
Aerosol-tight *
* Tested byHPA, Porton-down, UK
yes
Permissible temperature range autoclavable
°C
121
Centrifuge SL 16R
Catalog # 75004031
Weight of empty rotor [kg] 2.5
Max. cycle number 50,000
Maximum permissible load [g] 4 x 275
Maximum speed nmax [rpm] 5,500
Maximum RCF value at nmax 5,580
Max. / min. radius [cm] 16.5 / 6.4
Pitch angle [°] 90
Accel. / braking time [s] 35 / 40
Aerosol-tight *yes
Permissible temperature range autoclavable
°C
121
* Tested byHPA, Porton-down, UK

Thermo Scientific 75003658 TX-200 2-1
2
Accessories
Contents
•“Rotor data”on page 2-2
•“Accessories”on page 2-2

2Accessories
2-2 75003658 TX-200 Thermo Scientific
Rotor Specifications
* Maximum speed may vary by centrifuge model.
RCF/Radius
Maximum
Minimum
TX-200 Rotor Packages
Cat. No. Description
75003658 TX-200 Swing-Out Rotor without buckets
75003659 Round Buckets (set of 4)
75003660 Sealing Caps for Round Buckets (set of 4)
75003687 Replacement O-rings for 75003660 Sealing Caps (set of 4)
Tube Ordering Information
Cat. No. Qty
/Pkg Description Cat. No. Qty /Pkg
No. of
Places
75003800 180 180 PP Screw Cap Bottle 12 5500 56 x 123 Included 12 PP Sealing - - - - -
76009007 100 75 Glass Bottle 10 5500 45 x 123 - - - 75003801 4 1 - -
76009084 100 75 PP Bottle 1 5500 45 x 98 - - - 75003801 4 1 - -
76009095 100 75 PC Bottle 1 5500 45 x 98 - - - 75003801 4 1 - -
334959 50 50 Nunc Conical 25 5500 29.5 x 120 Included 25 PP Sealing 75003803 4 1
- 50 - Universal Tube - - 35 x 126 - - - 75003802 4 1 - -
3114-0050 50 50 Teflon Oak Ridge Tube 2 5000 32 x 126 Included 2 PP Sealing 75003815 4 1 - -
3139-0050 50 50 PP Oak Ridge Tube 10 5000 32 x 126 Included 10 PP Sealing 75003815 4 1 - -
3138-0050 50 50 PC Oak Ridge Tube 10 5500 32 x 126 Included 10 PP Sealing 75003815 4 1 - -
45500-30 30 25 KIMAX Glass Tube 6 25 x 118 - - - 75003805 4 2 - -
- 25 - Universal Tube - - 25.5 x 118 - - - 75003804 4 1 - -
- 25 - Round Bottom Tube - - 25 x 118 - - - 75003805 4 2 - -
366036 15 15 Nunc Conical 50 5500 17 x 120 Included 50 PP Sealing 75003771 4 5 - -
- 15 - Blood Collection - - 17 x 121 - - - 75003809 4 4 - -
45500-15 15 12 KIMAX Glass Tube 50 5500 17 x 102 - - - 75003809 4 4 - -
- 14 - Conical Urine Tube - - 17 x 114 - - - 75003807 4 2 - -
3139-0010 10 8 PP Oak Ridge Tube 10 5500 16 x 82 Included 10 PP Sealing 75003808 4 7 - -
3138-0010 10 8 PC Oak Ridge Tube 10 5500 16 x 82 Included 10 PP Sealing 75003808 4 7 - -
- 10 - Blood Collection - - 16 x 100 - - - 75003808 4 7 - -
- 7 - Blood Collection - - 13 x 100 - - - 75003785 4 8 - -
- 5 - Blood Collection - - 13 x 75 - - - 75003785 4 8 - -
- 5 - RIA Tubes - - 13 x 75 - - - 75003811 4 12 - -
- 1.5/2 - Conical Microtube - - 11 x 42 - - - 75003812 4 12 - -
Accessories Required:
Sealing Assembly Required: Adapters Required:
K Factor
Net Weight (kg)
Max.
Speed
(rpm)
RCF (x g)
5580
2162
Radius (cm)
16.5
6.4
Thermo Scientific General Purpose Rotors TX-200 Round Buckets
4 x 180
56 x 123
Capacity (ml)
Tube Dimensions (mm)
TX-200 Swinging Bucket Aluminium Rotor with Round Buckets
90
5500*
Angle
o
Maximum Speed (rpm)
Description Qty.Cat. No.
Tube
Vol.
(ml)
Vol.
Fill
(ml)
7920
2.5
Dims Ø x L
(mm)
-

Thermo Scientific 75003658 TX-200 3-1
3
AutoLock™
Contents
•“Rotor Installation” on page 3-2
•“Removing the Rotor” on page 3-3

3AutoLock™
Rotor Installation
3-2 75003658 TX-200 Thermo Scientific
Rotor Installation
This rotor is equipped with an AutoLock™-system.
This system is used to automatically lock the rotor to the centrifuge spindle. The rotor does not have
to be bolted onto the centrifuge spindle.
Proceed as follows:
1. Open the lid of the centrifuge and if necessary,remove any dust, foreign objects orresidue from
the chamber.
AutoLock™and O-ring must be clean and undamaged.
Figure 3-1. AutoLock™
2. Hold the rotor over the centrifuge spindle and let it slide slowly down the centrifuge spindle.
The rotor clicks automatically into place.
3. Check if the rotor is properly installed by lifting slightly on the handle. If the rotor can be pulled
up, then it must be reclamped to the centrifuge spindle.
CAUTION Unapproved or incorrectly combined accessories can cause serious damage to
the centrifuge.
CAUTION Do not force the rotor onto the centrifuge spindle.
If the rotor is very light, then it may benecessary to press it onto the centrifuge spindle
with a small amount of pressure.
WARNING If the rotor cannot be properly locked in place after several attempts, then the
AutoLock™is defective and you are not permitted to operate the
rotor. Check for any damage tothe rotor, damaged rotors must not be
used. Keep the hub area clear of objects.
AutoLock™
O-ring
