THORLABS vytran PTR406 User manual

PTR406 & PTR406B
Manual Fiber Recoaters
with Linear Proof Testers
User Guide
Mold Assembly Sold Separately

Fiber Recoaters with Linear Proof Testers
Table of Contents
Warning Symbol Definitions ............................................................................................. 1
Safety................................................................................................................................... 2
Description ......................................................................................................................... 3
3.1. Introduction................................................................................................................... 3
3.2. Parts Checklist.............................................................................................................. 3
Device Selection ................................................................................................................ 5
4.1. Automatic and Remote Manual Injection System....................................................... 5
4.2. Mold Assemblies .......................................................................................................... 5
4.3. Insert Selection............................................................................................................. 5
Setup ................................................................................................................................... 6
5.1. Removing the Shipping Fixture ................................................................................... 6
5.2. Attaching the Manual Recoat Injector ......................................................................... 6
5.3. Installing the Inserts..................................................................................................... 6
5.4. Attaching the Recoat Mold Assembly ......................................................................... 7
5.5. Connecting the Cables................................................................................................. 8
5.6. Priming the Mold........................................................................................................... 9
Controlling the PTR406/PTR406B .................................................................................. 10
6.1. Unit Control Buttons .................................................................................................. 10
6.2. Power Up..................................................................................................................... 11
6.3. A Quick Start Guide to Using the Handset Controller.............................................. 11
6.4. PTR406/PTR406B Parameters.................................................................................... 13
6.4.1. Inject Parameters (PTR406 Only).......................................................................................14
6.4.2. Cure Parameters.................................................................................................................14
6.4.3. Proof Test Parameters ........................................................................................................15
Handset Controller Reference ........................................................................................ 16
7.1. PTR406/406B Main Screen ......................................................................................... 16
7.2. File ............................................................................................................................... 18
7.2.1. Open File.............................................................................................................................19
7.2.2. Save File .............................................................................................................................19
7.2.3. Save File As ........................................................................................................................19
7.2.4. Delete File ...........................................................................................................................20
7.2.5. Export File ...........................................................................................................................20
7.2.6. Import File ...........................................................................................................................20
7.3. Edit .............................................................................................................................. 20
7.4. Tools............................................................................................................................ 21
7.4.1. Purge (PTR406 Only)..........................................................................................................22
7.4.2. Fill (PTR406 Only)...............................................................................................................22
7.4.3. Inject Calculator (PTR406 Only) .........................................................................................23

Fiber Recoaters with Linear Proof Testers
7.4.4. Material Usage (PTR406 Only) ...........................................................................................23
7.4.5. Process Counters................................................................................................................24
7.4.6. Terminal ..............................................................................................................................24
7.4.7. Version ................................................................................................................................25
7.4.8. Export Log File ....................................................................................................................25
7.4.9. User.....................................................................................................................................25
7.5. Accidental Reboot ...................................................................................................... 29
Priming the PTR406/PTR406B ........................................................................................ 30
8.1. Cleaning Recoat Mold ................................................................................................ 30
8.2. Priming the Injection System..................................................................................... 30
8.3. Remote Manual Injection System (PTR406B) ........................................................... 30
8.4. Automatic Injection System (PTR406)....................................................................... 32
8.5. Manual Injection System (Not Standard – Contact Factory for Information about
This Option) ................................................................................................................ 33
Recoat Process ................................................................................................................ 35
9.1. Loading the Fiber........................................................................................................ 35
9.2. Recoating (PTR406B) ................................................................................................. 36
9.3. Recoating (PTR406).................................................................................................... 36
9.3.1. Recoating Using the Manual Injection System (Not Standard – Contact Factory for
Information) .........................................................................................................................37
9.3.2. Curing the Coating ..............................................................................................................37
Proof Test Process .......................................................................................................... 39
10.1. Proof Testing .............................................................................................................. 39
Maintenance ..................................................................................................................... 40
11.1. Planned Maintenance ................................................................................................. 40
11.2. Cleaning ...................................................................................................................... 40
11.2.1. Clean Mold ..........................................................................................................................40
11.2.2. Check/Clean Fiber Holding Block Inserts ...........................................................................40
11.3. Recoat System Maintenance...................................................................................... 41
11.3.1. Recoat LEDs .......................................................................................................................41
11.3.2. Empty the Manual Injection System....................................................................................41
11.3.3. Flush the Manual Remote Injection System .......................................................................41
11.3.4. Purge the Automatic Injection System ................................................................................42
11.3.5. Flush Automatic Injection System .......................................................................................42
11.3.6. Replace Recoat Material.....................................................................................................43
11.3.7. Replace and Align Mold Assembly .....................................................................................43
11.4. Proof Test System Maintenance................................................................................ 44
11.4.1. Check Proof Test Calibration/Recalibration ........................................................................44
11.4.2. Replace Fiber Holding Block Inserts...................................................................................44
Specifications ................................................................................................................... 45
Trouble Shooting ............................................................................................................. 46
13.1. Recoat Diagnostics .................................................................................................... 46
13.2. Proof Test Diagnostics............................................................................................... 47

Fiber Recoaters with Linear Proof Testers
Appendix ........................................................................................................................... 48
14.1. Process Parameters ................................................................................................... 48
14.2. Material Data Safety Sheet ......................................................................................... 49
Compliance ....................................................................................................................... 57
Regulatory ........................................................................................................................ 58
Thorlabs Worldwide Contacts ........................................................................................ 59

Fiber Recoaters with Linear Proof Testers Chapter 1: Warning Symbol Definitions
Rev A, September 14, 2020 Page 1
Warning Symbol Definitions
Below is a list of warning symbols you may encounter in this manual or on your device.
Symbol Description
Direct Current
Alternating Current
Both Direct and Alternating Current
Earth Ground Terminal
Protective Conductor Terminal
Frame or Chassis Terminal
Equipotentiality
On (Supply)
Off (Supply)
In Position of a Bi-Stable Push Control
Out Position of a Bi-Stable Push Control
Caution: Risk of Electric Shock
Caution: Hot Surface
Caution: Risk of Danger
Warning: Laser Radiation
Caution: Spinning Blades May Cause Harm

Fiber Recoaters with Linear Proof Testers Chapter 2: Safety
Page 2 TTN176280-D02
Safety
All statements regarding safety of operation and technical data in this instruction manual will only apply when the
unit is operated correctly.
SHOCK WARNING
Unplug the power cord before servicing the unit. Do not operate the unit without all covers and
items properly installed.
CAUTION
Before connecting the AC power cord, make sure the source voltage is between 85 and 265 VAC,
47-63 Hz. Input voltages outside these ranges may result in damage to the unit.
CAUTION
The recoat material is a flammable, toxic, acrylate compound. Avoid contact with the skin and eyes.
WARNING
Argon is a chemically inert gas. It is colorless, odorless, tasteless, non-flammable, non-corrosive
and non-toxic. However, the work area should be well ventilated to ensure that the correct oxygen
level is maintained.
WARNING
Ensure that the operator is properly trained for the handling of compressed gases and regulators.
Small transparent fiber shards may be present in and around the work area, and as such, the
necessary measures should be taken to ensure the safety of the employee(s).
WARNING
This unit must not be operated in explosive environments. The equipment should be used in a
standard laboratory environment with temperature and humidity control.
WARNING
All materials (such as wipes and gloves) that have acrylate material on them should be disposed
with solid chemical waste.
Fuses can be replaced by twisting it to release and then pulling it out of the housing; it is replaced by pushing the
fuse into the housing and then twisting it to lock in place. The fuse is 6.4 A, 250 V.
!
!
!
!
!
!
!
!
!
!
!
!

Fiber Recoaters with Linear Proof Testers Chapter 3: Description
Rev A, September 14, 2020 Page 3
Description
3.1. Introduction
The PTR406 and PTR406B are optical fiber recoaters with have an integrated linear proof tester. The recoat mold
applies a flexible UV acrylate coating to a fusion spliced section of fiber, and the proof test function ensures that a
fiber or fusion splice meets a minimum strength requirement.
3.2. Parts Checklist
When unpacking the device for the first time, check to make sure that you have the following:
•PTR406 or PTR406B Manual Fiber Recoater with Linear Proof Tester
•Plastic Bag, Taped to Unit, Containing
oSix 4-40 x 3/16" Fillister-Head Screws
oPin with C-Clip
•12V Power Supply
•AC Line Cord
•Handset Controller
•Canvas Zipper Bag Containing:
oUSB Y- Cable
oLens Tissue
oEye Dropper
oQuartz Mold Cleaning Brush
o3/32" Hex Key
o0.035" Hex Key
oSmall Bottle with Cap
oMold Assembly (Purchased Separately)
oTop Inserts for Fiber Holding Blocks (Purchased Separately)
oBottom Inserts for Fiber Holding Block (Purchased Separately)
•UV-Curable Acrylate Recoat Material (Purchased Separately)
•For PTR406B Only: Manual Injector
•If Ordered Separately: Injection Syringes and Cap
If you are missing any of the above or need replacements, please contact Thorlabs.

Fiber Recoaters with Linear Proof Testers Chapter 3: Description
Page 4 TTN176280-D02
System Components

Fiber Recoaters with Linear Proof Testers Chapter 4: Device Selection
Rev A, September 14, 2020 Page 5
Device Selection
When purchasing a PTR406 or PTR406B, it is necessary to select a mold assembly and fiber holding block inserts
that best match the desired coating diameters of your fiber.
4.1. Automatic and Remote Manual Injection System
The PTR406 and PTR406B are both manual fiber Recoaters with an integrated linear Proof Tester. The major
difference between the two products is the type of injection system utilized by the device. The PTR406 comes with
the automatic recoat injection pump fitted inside the unit. This pump system can be activated either by the “Inject”
button on top of the unit or with the Handset Controller. An automatic injection system will inject a predetermined
volume of recoat material into the mold assembly. It is compatible with high-index recoat material only.
The PTR406B comes with a manual injection system. This pump system provides a method of manually dispensing
recoat material directly from the recoat bottle into the injection port. This system consists of a syringe with a knurled
dispensing screw, which is fitted to a distribution valve with a two-position selection lever. It is compatible with both
high- and low-index recoat material.
4.2. Mold Assemblies
The Mold Assemblies are composed of split quartz mold plates which, when closed, form the cylindrical mold cavity
around the exposed section of the fiber being recoated. When purchasing the Recoater for the first time, it is
necessary to choose a mold assembly that is appropriate for the desired fiber coating diameter. They are available
for Ø280 µm, Ø430 µm, or Ø600 µm fiber coatings. Custom mold sizes up to Ø900 µm are available; please contact
Thorlabs for more information. Additional mold assemblies may also be purchased and swapped out by the user.
The assembly simply screws to the top of the device, making the removal and installation simple and easy.
Item # Coating Diameter
RM280UVA
280 µm
RM430UVA
430 µm
RM600UVA
600 µm
4.3. Insert Selection
When purchasing a PTR406/PTR406B, the proper set of inserts need to be selected. A total of four inserts (two top
and two bottom) are required for a full unit. The inserts are seated in and secured to the fiber holding blocks. They
can easily be swapped out for different sizes, allowing our Recoaters to adapt quickly should different fiber coating
sizes be desired. The VHJ Series inserts (designed for Recoaters with linear Proof Testers) are compatible with
fiber coating sizes ranging from Ø80 µm to Ø1000 µm.
Item # Top or Bottom Nominal Diameter Min Diameter Max Diameter
VHJT
Top - 80 µm 700 µm
VHJT900
Top 900 µm 700 µm 1000 µm
VHJ250
Bottom 250 µm 80 µm 375 µm
VHJ500
Bottom 500 µm 375 µm 700 µm
VHJ900S
Bottom 900 µm 700 µm 1000 µm

Fiber Recoaters with Linear Proof Testers Chapter 5: Setup
Page 6 TTN176280-D02
Setup
5.1. Removing the Shipping Fixture
Loosen the eight set screws in the bases of the fiber holding blocks. Open the lids. Remove the shipping fixture.
Place it in a safe location. You may need it again, should you ever need to ship the unit back for service.
5.2. Attaching the Manual Recoat Injector
If your unit is a PTR406B, you will need to attach the manual recoat injector to the side of the unit. Place the injector
on the side of the unit and attach it to the unit using the two cap screws from the attached bag. Use the 3/32” hex
key to tighten the screws.
Attaching the Manual Recoat Injector
5.3. Installing the Inserts
Put the top inserts in place and capture them using the set screws in the lid. Use the 0.035" hex key to tighten the
set screws. Put the bottom inserts in place and capture them using the set screws in the base of the fiber holding
block, using the same Hex key. As you install the inserts, make sure they are fully seated as you tighten the set
screws.

Fiber Recoaters with Linear Proof Testers Chapter 5: Setup
Rev A, September 14, 2020 Page 7
Installing the Inserts
5.4. Attaching the Recoat Mold Assembly
Make sure that the base plate and bottom of the mold assembly are cleaned of any dirt particles. Insert the pin
assembly by inserting the long end into the recoat mold assembly. Verify that the pin assembly moves up and
down freely.
Placing the Recoat Mold
Plug the ribbon cable connector that emerges from the center slot into the bottom of the LED board on the
underside of the mold. Lower the assembly straight down, making sure the pin assembly enters through the
correct hole, and attach the recoat mold assembly using five of the screws from the attached bag. Lightly tighten
two diagonal screws; leave the rest loose. The screws need to be somewhat loose to allow for adjustment of the
recoat assembly. Open the recoat station top and the tops of the fiber holding blocks. Clamp a length of coated
fiber between the holding blocks so that the fiber is under slight tension. (A fiber nominally smaller than that of the
diameter of the recoat mold should be used.) Using a 10X magnifying loupe, view the fiber straight down at the
right-hand edge of recoat station, as shown below. Adjust the recoat assembly such that the fiber is centered in
the bottom recoat groove. Repeat this procedure while viewing the fiber at the left edge of the recoat station.
Tighten the recoat flange screws and re-check the fiber alignment.

Fiber Recoaters with Linear Proof Testers Chapter 5: Setup
Page 8 TTN176280-D02
Aligning the Recoat Mold
Connect the green recoat material tube to the inject port on the top of the lid.
5.5. Connecting the Cables
1. Plug in the AC power cord. The power supply
accepts an AC input of 100 - 240 VAC; 47 -
63 Hz.
2. Connect the AC power cord to the external
power supply.
3. Connect the DC power cable to the unit.

Fiber Recoaters with Linear Proof Testers Chapter 5: Setup
Rev A, September 14, 2020 Page 9
4. Locate the USB Y-cable that is included with the
unit. Locate the USB type A plug that is by itself
on a long pigtail.
5.
Plug this USB plug into the top USB socket of the
handset. Note that the USB socket on the side of
the handset is dedicated to connecting a USB
flash drive for importing/exporting fiber files and
updating software. Leave it unpopulated for now.
6. Plug the USB Type B plug of the Y-cable into its
socket on the back of the unit. This will provide
data to the handset controller.
7. Plug the remaining USB Type A plug of the Y-
cable into its socket on the back of the unit. This
will provide power to the handset controller.
5.6. Priming the Mold
Before dispensing recoat material, it is necessary to fill the recoat material bottle with recoat material and prime the
recoat mold. Priming the recoat mold will make it easier to dispense the exact right amount of acrylate material
when recoating a fiber, and it will eliminate air bubbles that may be trapped in the recoat material. Refer to Chapter
7 for instructions on performing these steps.

Fiber Recoaters with Linear Proof Testers Chapter 6: Controlling the PTR406/PTR406B
Page 10 TTN176280-D02
Controlling the PTR406/PTR406
This device can be operated using either the three (3)
buttons on the unit or with the Handset Controller.
6.1. Unit Control Buttons
The PTR406/PTR406B has three Unit Control Buttons that enable the user to inject and cure recoat material as
well as test the strength of a fusion splice. The inject button is only enabled on the PTR406, which comes with the
automatic injection system. All parameters are preset and cannot be changed without the Handset Controller in
conjunction with the Unit Control Buttons (see below for control options). The controller is also necessary for readout
of the proof test values, test history logging, and recoat material usage monitoring.
Unit Control Buttons
Inject Button: Inject a preset amount of recoat material into the mold (for the PTR406 only). The Inject Button
can be configured to inject recoat material while it is pressed (Momentary Injection).
Cure Button: If the recoat mold is closed, pressing the Cure Button turns on full power to the UV lamps for
the preset cure time. If the recoat mold is open, holding down the Cure Button will illuminate
the UV lamps at low power (no UV output). This allows for a visual inspection of the lamps.
Test Button: Activates a proof test with the current parameter settings stored within the main unit. The right-
hand fiber holding block will move linearly to the right to apply the set tension to the fiber. The
load will be held for a set “hold time,” after which the fiber holding block will move back left to
the home position.
Handset Controller

Fiber Recoaters with Linear Proof Testers Chapter 6: Controlling the PTR406/PTR406B
Rev A, September 14, 2020 Page 11
6.2. Power Up
With the Handset Controller properly connected to the unit, turn on the PTR406/PTR406B using the switch located
at the back of the unit.
The system will go through an initialization process that takes from 15 to 90 seconds, during which time it will home
and fill the internal recoat pump (if so equipped) and home the linear Proof Tester. During initialization, the handset
Controller will auto-detect the PTR406/PTR406B and display the main screen. From here the User can start
injecting, curing, testing, viewing, or editing Parameters and select items on the toolbar
The Handset Controller provides a simple, easy to use interface for configuring, controlling, and monitoring PTR
and LDC series machines. The following sections contain a quick start guide followed by a more detailed view of
the features and capabilities of the Handset Controller.
6.3. A Quick Start Guide to Using the Handset Controller
Once the Handset Controller has recognized a PTR406/PTR406B, the Main Screen is displayed.
A: Status Bar (currently blank)
B: Inject Button
C: Cure Button
D: Test Button
E: Stop
F: Toolbar
G: Inject Parameters
H: Cure Parameters
I: Proof test Parameters
PTR406 Main Screen and Edit Screen
(Note that the main screen differs slightly when the Handset Controller detects PTR406B; Inject functionality is
removed.)
This main screen will show the current file name (only if the parameters of the unit match the parameters of a saved
fiber file) in bold just below the Toolbar.
To start Injecting, press ‘Inject’ (B). This performs the same action as pressing the blue ‘Inject’ button on the
PTR406.
To start Curing, press ‘Cure’ (C). This performs the same action as pressing the blue ‘Cure’ button on the
PTR406/PTR406B.
To start Testing, press ‘Test’ (D). This performs the same action as pressing the blue ‘Test’ button on the
PTR406/PTR406B.
A
C
F
E
B
D
G
H
I

Fiber Recoaters with Linear Proof Testers Chapter 6: Controlling the PTR406/PTR406B
Page 12 TTN176280-D02
The main screen will also show the current status of any process that is running.
Main Screen Showing Status
To view and/or edit Inject, Cure, or Prooftest Parameters, touch “Edit” on the top toolbar (F) or swipe the screen to
the right. From the list of functions presented, select the function whose parameters you wish to view or edit. The
relevant parameters (along with the current value) will then be shown. Swipe the list to scroll up or down. Touch a
parameter to select it for editing.
Edit Screen

Fiber Recoaters with Linear Proof Testers Chapter 6: Controlling the PTR406/PTR406B
Rev A, September 14, 2020 Page 13
Cure Parameter, Prooftest Parameters, and Inject Parameter Screens
The On-Screen-Keyboard will allow entry of a new value
for the selected parameter.
Selecting “Ok” will close the Edit Screen and commit the
new value to the PTR406/PTR406B.
Parameter Edit Screen
6.4. PTR406/PTR406B Parameters
The following sections describe the parameters that control PTR406/PTR406B.

Fiber Recoaters with Linear Proof Testers Chapter 6: Controlling the PTR406/PTR406B
Page 14 TTN176280-D02
6.4.1. Inject Parameters (PTR406 Only)
The Inject parameters are defined as follows:
Inject Quantity: The volume of recoat material in microliters (µl) injected into the mold.
Inject Rate: The speed at which recoat material is injected into the mold in microliters per second
(µl/sec). The maximum inject rate is 1.8 µl/sec. The recommended inject rate for
recoating is 0.2 µl/sec.
Add Quantity: The percentage of Inject Quantity that can be manually injected to the mold after the
Inject sequence is complete. The Handset Controller displays the Add Button in the Inject
Screen once the Inject sequence is complete. The Add feature is especially useful in
situations where there is variability in the position of strip shoulders/length of recoat
required.
Fill Rate: The rate at which recoat material is filled into the auto-inject pump’s reservoir. The
maximum fill rate is 1.8 µl/sec.
Shrink Factor: The Shrink Factor is the amount of material injected into the recoat mold during the early
stages of curing. This is entered as a percentage of the initial Inject volume and is
intended to compensate for material shrinkage during cure. Typical values for Shrink
Factor are 3 to 6%.
Shrink Time: Shrink Time specifies the time period over which any additional material is injected into
the mold during cure. It is expressed as a percentage (%) of Cure Time.
Momentary Injection: This can be enabled or disabled. When enabled, pressing the Inject button on the
PTR406 causes the machine to inject recoat material for as long as the Inject button is
down. When disabled, pressing the Inject button causes the predefined Inject Quantity
to be injected. Note that pressing the Inject button on the Handset Controller will always
deliver the predetermined Inject Quantity.
Purge Cycles: This sets the number of purge cycles the unit will perform when the Purge command is
sent. Purge cycles are necessary to remove air from the injection system. It is
recommended to perform at least 5 purge cycles every time recoat material is replaced.
Purge Rate: The rate at which the pump will purge and fill material during a purge cycle. Maximum
purge rate is 1.8 µl/sec.
6.4.2. Cure Parameters
The Cure parameters are defined as follows:
Cure Time: The duration of the recoat material cure (1 to 480 seconds).
LED Set X Start: Specifies switch-on time of each pair of LEDs. The parameter is a percentage (%) of the
total cure time. The LEDs are numbered in pairs from 1 to 7 starting from the outside.
LED Set X Stop: Specifies the switch-off time of each pair of LEDs. The parameter is a percentage (%) of
the total cure time. The LEDs are numbered in pairs from 1 to 7 starting from the outside.
LED Set X Power: Sets the LED power as a percentage. The LEDs are numbered in pairs from 1 to 7
starting from the outside.

Fiber Recoaters with Linear Proof Testers Chapter 6: Controlling the PTR406/PTR406B
Rev A, September 14, 2020 Page 15
Warning
Do not look directly at the recoat assembly while the recoat LEDs are on. The recoat LEDs emit ultra-
violet radiation which can cause damage to the eyes. The mold must be closed during recoat LED
operation.
6.4.3. Proof Test Parameters
The proof test parameters are defined as follows:
Prooftest Level: The load or tension to which the fiber is to be proof tested in either grams, GPa, kpsi,
lb, or N.
Prooftest Units: The unit of measurement, this can be either grams (g), gigapascals (GPa),
Kilo-pounds per square inch (kpsi), pounds (lb) or Newtons (N).
Prooftest Hold Time: Also referred to as ‘Dwell Time,’ the amount of time in seconds that the Peak Tension
is held for.
Prooftest Ramp: The approximate time in seconds required to reach the Peak Tension.
Fiber Diameter: The diameter of the fiber in microns (µm). This diameter is required to calculate units
of tension (kpsi & GPa). Note: Make sure to enter the diameter of the fiber, not the
diameter of the coating.
!
!

Fiber Recoaters with Linear Proof Testers Chapter 7: Handset Controller Reference
Page 16 TTN176280-D02
Handset Controller Reference
The handset controller must be connected to a Vytran LDC/PTR module via the supplied Y-cable to function. Upon
switching on the power to the Vytran LDC/PTR unit, the handset controller will turn on and will require approximately
1 minute of boot up time. At this time, the screen will display the Thorlabs logo, which may flash a few times.
The Handset controller will automatically search for a connected Vytran LDC/PTR module and automatically
configure itself for that module, in this case the PTR406/PTR406B.
It is recommended that the Handset Controller remains connected to a single machine in order to benefit from
machine status monitoring built into the controller. The PTR406/PTR406B can, however, operate without the
Handset Controller attached, and through use of the blue buttons will carry out Inject and Cure using the last set of
parameters that were uploaded to it.
At startup, the Handset Controller will always read parameters from the PTR406/PTR406B, meaning that the
parameters that appear on the screen will always be the parameters that have been uploaded to the unit connected.
The Handset Controller provides a second USB port, labeled Program Port, to which fiber files can be imported and
exported via a flash drive. This port also allows the handset application to be updated via a flash drive.
7.1. PTR406/406B Main Screen
The PTR406/PTR406B Main Screen, much like the Main Screen for any other Vytran PTR or LDC module, shares
a common theme. It has a menu bar, one or more control (action) buttons, and a list of relevant current parameters.
During operation, runtime messages are displayed.
At the top of the screen, the handset shows the type of module detected (in this case PTR406 Manual Recoater –
Linear Proof Tester). The file currently opened (blank if none) is displayed just below the toolbar. The toolbar
provides access to the File menu, Edit menu to change parameters, and the Tools menu.
PTR406/PTR406B Top of Main Screen
