Gunite/Brunner/Bendix
Automatic Slack Adjuster Puller
10409
•
Stay Alert! Watch what you are doing and use common sense when
operating this tool.
•
Inspect product for damage prior to using; do not use if product is
in unsafe condition.
• Do not operate tool while under the influence of drugs, alcohol
or medication.
•
Always use safety equipment to prevent injuries. Approved face
and eye protection must always be worn by the operator, as well
as others in the work area.
•
Do not overreach. Keep proper footing and balance at all times.
•
Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving parts.
•
Keep hands clear of all pressurized hydraulic components.
•
Always ensure hoses are free from sharp bends and kinks.
• Keep your work area clean and well lit.
Safety Warning
Read all instructions and safety warnings prior to operation. Failure to do so could
result in equipment damage, personal injury or even death.
Operating Instructions
Threads must be clean and well lubricated at all times. Do not
use over a 1⁄2" impact wrench—doing so will void warranty.
1 Remove clevis pin from the end of the slack adjuster
with the Tiger Tool 10501 Brake Clevis Pin Press.
Remove the slack adjuster rod from the slack adjuster
with the Tiger Tool 10502 Slack Adjuster Rod Pin Press.
2 Back out the forcing screw, slip the puller onto the
slack adjuster. Align the tip of the forcing screw with
the center of the s-cam.
3 Attach the tool to the slack adjuster through the clevis
hole using the supplied hardware.
4 Turn the forcing screw by hand or with an
impact wrench.
5 Hold the puller and slack adjuster to keep it
from falling to the ground.
Here at Tiger Tool, your satisfaction is our number one
priority. Should you have any questions about this or any
of our products, please call us at 1.800.661.4661.

Item No.
1
2
3
4
5
Part Number
10409-1
10407-2
10409-2
10407-4
10407-5
Qty.
1
1
1
2
1
Description
Body
Forcing Screw
Bolt
Washer
Nut
Parts Breakdown
1.800.661.4661
View demonstration videos and a
complete product list at tigertool.com
Technical Support
Have What It Takes
Gunite/Brunner/Bendix
Automatic Slack Adjuster Puller
10409
1
2
3
4
5
