Time4Sleep IRIS TV BED User manual

IRIS TV BED
DOUBLE, KING & SUPER KING SIZE
Parts Identification
Page 1 of 14
PLEASE READ
this sheet prior to assembly to familiarise
yourself with the various stages of construction. Carefully
open the pack supplied and check the contents against the
parts and fittings check list.
Do not destroy any of the packaging until you are certain
that you have all the necessary parts for the assembly.
Please ensure that the packaging is disposed of in
a safe environmentally friendly way.
CAUTION: There are small components used in the
construction of this unit. These loose items should be
kept away from young children during assembly, to avoid
the danger of choking.
IMPORTANT: BEFORE STARTING TO ASSEMBLE THE BED - PLEASE READ THESE INSTRUCTIONS CAREFULLY.
211014
17
DOUBLE & KING
SUPER KING
1
7
2
3
4
5
5
6
12
11
11
10
10
13
8
14
9
15
15
12
12
12
13
13
13
13
16
19
18

Page 2 of 14
11 1/2
Double&King/Super King
Double&King/Super King
Double&King/Super King
Double/King/Super King
Double/King&Super King
Double/King/Super King
12 2/4
13
28/30/45
Ref. Qty
Ref. Description
5
Qty
1
2
3
1
1
1
Parts Checklist
Description
41
2
19 1
14
15 28/30
14/15/30
16
2/4
17 1
9
6
7
1
1
81
1
10 2
Headboard
Footboard
Side Rail - with Media Tray
Side Rail - Plain, no tray
‘L’ Bracket for Media Tray
Media Tray Base Panel
Media Tray Side Panel - RH
Media Tray Side Panel - LH
Media Tray Back Panel
Media Tray Support Legs
18 1
Centre Support Rail
Holster for Remote Control
Mains Power Lead - 3 mt
Bentwood Slats
Centre Support Rail Legs
Single Plastic Caps
Double Plastic Caps
Metal ‘L’ Bracket
TV Lift Remote Control
C x2
Bolt (Large head)
(M8x25mm)
Bolt (M6x30mm)
AEx10Screw (M5x50mm)
Bolt (Large head)
(M8x16mm)
B
x14
Double & King
Super King
x20
x12
Double & King
Super King
x16
x10
x1
DAllen Key
Fittings Checklist
Ref. Qty
Ref. Description
Qty
Description
F
Additional Tools Required
Care & Maintenance
General Hints & Tips
Please retain your assembly instruction and
tools provided for future use.
Periodically check that all bolts are still tight.
Approximate time to
assemble this product
1 1/2 Hrs
In the unlikely event of missing or damaged parts,
please contact your retailer. Please have this guide at
hand quoting the part code reference numbers shown
when requesting spare or replacement parts.
Cross-head Screwdriver Tape Measure
Plastic Barrel Nuts
Gx3
x3
H
x2
x2
a
TV INSTALLATION KIT - Inside main hardware pack
x1
b
x2
Bolt Sets (M8x25mm)
(M6x12mm)
Counter-Sunk Screws
Counter-Sunk Screws
(M4x12mm)
Allen Key (2.5mm)
Cable Clips
Cable Ties

Page 3 of 14
Stage
1
Stage
2
D
x1
90%
Ax8
D
x1
Bx4
F
x2
Ex2
Ax2
Media Tray on Right
Media Tray on Left
Bx2
Bx2
Ex2
Fx2
7
8
6
9
F
IMPORTANT:
MAKE SURE WHEN FITTING
THE BARREL NUTS THAT
THE HOLE IS IN CORRECT
ALIGNMENT WITH THE
HOLE IN THE PANEL EDGE.
1
1
2
2
3
3
4
4

D
x1
Bx4
D
x1
Cx2
F
x8
Ex8
Media Tray on Right
Media Tray on Left
Bx4
Ex8
Cx2
Fx8
7
8
Page 4 of 14
Stage
3
Stage
4
10
10

D
A
x1
D
x1
B
Page 5 of 14
Stage
5
Stage
6
Bx4
Double & King Size x1
Super King Size x2 Double & King Size x6
Super King Size x12
Double & King Size x4
Double & King Size
Super King Size
Super King Size x8
Bx2
Ax2
12
12
11
11
11
13
11
12
12
&

Page 6 of 14
Stage
7
Stage
8
Connect Main Power Lead (17)
to your wall socket - for safety,
this must be an earthed supply.
17
Press the “UP”
button to raise
the TV lift.
18

Page 7 of 14
Stage
9
Stage
10
TV Power Lead
supplied with your TV
TIP:
BEFORE FITTING THE TV, PUSH
CABLES THROUGH EACH DUCT
FROM THE TOP. CHOOSE THE
BEST SIDE TO USE DEPENDING
ON WHERE THE CONNECTION
PORTS ARE, ON BACK OF YOUR
TV. NEVER CROSS CABLES
FROM ONE SIDE TO THE OTHER.
Note: For illustration purposes
only, TV connections may vary.
Media Cable are
not supplied
a
a
LoosenTighten
IF SCREWS ARE SUPPLIED WITH TV, PLEASE USE THOSE IN PREFERENCE
TV Installation - Normal Vesa Fixing
a x2
b x2
M8 x 25mm
Bolt sets Counter-sunk screw
sets (M6x12mm)
Counter-sunk screw
sets (M4x12mm)
Allen Key (4mm) Allen Key (2.5mm)

Stage
11a
Stage
11b
Page 8 of 14
aa
b
100mm
100mm
IF SCREWS ARE SUPPLIED WITH TV, PLEASE USE THOSE IN PREFERENCE
REMOVE CROSS-BRACKET
AND FIX IT DIRECTLY TO BACK OF TV
TV Installation - 100x100 Vesa Fixing
a x2
b x2
M8 x 25mm
Bolt sets Counter-sunk screw
sets (M6x12mm)
Counter-sunk screw
sets (M4x12mm)
Allen Key (4mm)
Allen Key (2.5mm)

Stage
11c
Page 9 of 14
Loosen Tighten
i.
ii.

Stage
12
Page 10 of 14
90º ADAPTOR
TV Power Lead
supplied with your TV
PLUG IN - KEEP ALL CABLES TIGHT
- USE CLIPS & TIES PROVIDED.
Keep wires tight - peel
off cover from cable clips
& adhere to back of TV.
Note: For illustration purposes
only, TV connections may vary.
GH

Stage
13
Stage
14a
Page 11 of 14
TV Power Lead
supplied with your TV
Press the “DOWN”
button to lower the
TV lift.
18
18
19
Press
down
Press
down
Fit RC holster (19) to
left or right side.
14 14
14 14
15 15
16
For Double & King Size

Page 12 of 14
Press
down
Press
down
18
19
Fit RC holster (19) to
left or right side.
Stage
14b
14 14
14 14
15 15
16 14
14
16
For Super King Size
Overall Dimensions (LWH mm)
Double: 2210 x 1445 x 1140
2310 x 1595 x 1140
2310 x 1895 x 1140
1930 x 1380
2030 x 1530
2030 x 1830
685 x 53 x 9
760 x 53 x 9
King:
Super King:
Super King:
605 x 53 x 9
Super King:
Internal Dimensions (LW mm)
Double:
King:
Distance between slats (mm)
Double, King & Super King: 70
Slat Dimensions (LWH mm)
Double:
King:
200
20
95
810
L
25
H
W
275
Floor to top
of slat
45
Top of side rail
to top of slat

Page 13 of 14
TV BED SAFETY INFORMATION
GENERAL INFORMATION
It is very important not to place any vessel containing liquids, e.g. drinks or vase of flowers, on top of the TV footboard
which may accidentally spill and enter the TV compartment as this could cause damage to the TV and/or the TV lifting
equipment.
If this happens, please contact your retailer.
Do not expose the bed to an undue level of heat - keep away from radiators.
Never allow anyone to sit on the foot end of the bed - keep children well away from moving parts.
To keep bed clean, we recommend that it be wiped over with a slightly dampened cloth or if fabric, use a light vacuum
cleaner; disconnect power before cleaning.
Supplied with the bed is a remote control to operate the TVlift and when you fit your own TV there is a remote control to
operate it as well. Both these remotes use batteries - there are no batteries inthe rest of the equipment.
There are strict controls for disposal of batteries - your local council can advise on how to safely dispose of them.
Never burn batteries on an open fire as they could explode.
IMPORTANT POWER INFORMATION
It is essential that the Mains Power Lead is connected to an earthed socket be it a wall socket or extension lead - otherwise
there is risk of damage or even electric-shock.
The socket providing the power must be accessible at all times in case you need to switch off the power quickly.
During an electrical or lightening storm - disconnect the powercompletely as a precaution.
Always un-plug the power when going on holiday or when the bed is not used for an extended period.
If you have young children in the home always disconnect the power at the wall socket for extra safety.
Power outlets, extension leads or adapters must not be overloaded beyond their limit - this can result in fire or electric shock.
Leads supplied with this bed, or other approved mains powered extension leads used to power the equipment, must not be
placed where they can be walked on - this is dangerous and could lead to accidents.
Do not interfere with or modify any cables already fitted and do not add any extra media leads unless they are routed through
the ducts as shown. All leads must be tightly connected to back of TV, never hanging loose.
Never touch moving parts or any part of the equipment - if something needs to be checked, disconnect the power first.
Do not insert anything into the footboard as this could seriously damage the TVand/or the TV lifting equipment and could, if
done carelessly, cause serious damage or injury.
If the equipment doesn't operate normally or if there is an unusual noises, disconnect the power.
TELEVISION INSTALLATION
Before fixing the mattress base boards to the bed, please follow the television installation instructions. below.
Raise the TV lift by pressing the top UP button of the remote control.
Connect TV to the mounting bracket using the TV installation kit packed with the main hardware in the accessory box inside
carton 2. If screws are supplied with your TV, use those in preference.
If necessary mounting plate can easily be adjusted to move up or down to align with VESA holes in the TV.
Connect the TV power lead (supplied with TV) by passing plug down one of the ducts, plugging it into the TV power adapter
if supplied with your TV, then into the TV power socket which is on the face of footboard.This socket is only to be used for
the TV as the supply is not permanent.
If required, connect your own aerial & HDMI cable by passing down the appropriate duct.
If required, connect your own media cables through either of the ducts - connecting your media equipment when ready.
Please use the cable clips & cable ties to make certain there are no loose wires to snag or get trapped .
The TV can now be operated following the TV operation guide supplied with your TV.
When finished viewing, lower the TV back into the footboard by pressing DOWN button of the remote control.
The TV will retract into the footboard automatically - for safety, power shall be turned off to the TV when it reaches the
bottom rest position.
Note that when the TV is operating and Bluetooth is selected, the TV picture will stay on screen - either turn off TV or press
down button to lower to the resting position, TV is turned off but music will still play.
When the up button is pressed - the TV lifting column rises and power to the TV turns back on automatically.
TROUBLE SHOOTING
If your equipment does not operate please check all the power connections, to the wall and to the socket in the footboard.
Make sure TV is switched on. (Note: TV will only work when it is in the up position).
Follow instruction at the top of Page 14to make certain pairing of the remote control & TV lift has not been lost.
If the television or TV Lift still fails to operate contact your retailer.
IMPORTANT
: Care should be taken when connecting electrical items. If in any doubt please consult an approved
electrician to advise you on the electrical supply to achieve safe connections, to the electrical equipment of the TV Bed.

Page 14 of 14
①. Disconnect all mains electric power to the bed, for at least 60 seconds.
②. Press UP or DOWN Button on Remote Control and keep holding button down,
simultaneously re-connect mains electric power to bed keeping button down for at least
a further 5 seconds. TV Lift unit receives signal from Remote Control and lift will begin
to move UP or DOWN whichever direction is appropriate.
③. Re-connection is now completed.
We cannot be held responsible for any damage caused to the TV, TV cabling or the TV Bed itself due to
incompatibility of anyequipment installed by the end-user or due to loose and poorly installed cables.
Please read this Assembly Instruction carefully and follow the recommendations.
TV LIFT REF: LA08 CONFORMS TO STANDARD FOR UK & LED CONFORMS TO STD FOR UK (EMC, LVD & ROHS)
TV LIFT: EN 60335-1:2012+A11: 2014
EN 60950-1:2006+A11:2009+A1:2010
+A12:2011+A2: 2013
EN 301 489-1 V2.2.0: 2017
EN 301 489-3 V2.1.1: 2017
EN 55014-1:2006+A1:2009+A2:2011
EN 61000-3-2: 2014
EN 62233: 2008
EN 300 440 V2.1.1: 2017 EN 301 489-3
V2.1.1: 2017 EN 62479: 2010
EN 55014-2: 2015
EN 61000-3-3: 2013
EMC CERT NO. HTT170911240E DIRECTIVE: 2014/30/EU
LVD CERT NO. HTT170911240L DIRECTIVE: 2014/35/EU
ROHS CERT NO. HTT170911240R DIRECTIVE: 2011/65/EU
POWER SUPPLY: FDD-009
EMC CERT NO. BST14010531Y-1EC-1 DIRECTIVE: 2004/108/EC
LVD CERT NO. BST14010531Y-1SC-2 DIRECTIVE: 2006/95/EC
ROHS CERT NO. BST14010531Y-1RC-4 DIRECTIVE: 2011/65/EU
Periodically remove dust by using a light vacuum cleaner or if your bed is PU, use a soft damp cloth.
Occasionally you may find the radio wave connection between remote control and TV Lift is lost,
probably due to atmospheric conditions. In that case please follow these simple instructions:
c
of 14 Kg
W98 x H58 x D8.5 cm
up to a maximum of 42"
