Time4Sleep ANCONA OTTOMAN User manual

6a&6b 2 Prs
17
8
9
Headboard
Footboard
Side Rail - Left
Side Rail - Right
Metal Slat Frame
Angle Brackets with Leg
2
Cross Bar
Mattress Stoppers
1
10 4
11
Slat Frame Support Rail (wood)
Base Boards
Base Board Support Rails (wood) 5
Ref. Qty
Ref. Description
5
ANCONA OTTOMAN
LIFT UP BED
Parts Identification
Qty
1
2
3
1
1
1
Parts Checklist
Description
4 1
Page 1 of 8
5
1
2
6a
6b
9
7
PLEASE READ
this sheet prior to assembly to familiarise
yourself with the various stages of construction. Carefully
open the pack supplied and check the contents against the
parts and fittings check list.
Do not destroy any of the packaging until you are certain
that you have all the necessary parts for the assembly.
Please ensure that the packaging is disposed of in
a safe environmentally friendly way.
CAUTION: There are small components used in the
construction of this unit. These loose items should be
diovaot,ylbmessagnirudnerdlihcgnuoymorfyawatpek
the danger of choking.
IMPORTANT: BEFORE STARTING TO ASSEMBLE THE BED - PLEASE READ THESE INSTRUCTIONS CAREFULLY.
1
FABRIC
HANDLE
10
10 10
10
11
3
4
HEADEND
FOOTEND
8
180511
An instructional video of the Operation of the Ottoman Lift Up system is available via YouTube using
the following address: https://youtu.be/hyq4zm7h_yU

Fittings Checklist
Page 2 of 8
QtyCode Description
Ax24
C
x24
Spring Washers (for M8 bolts)
D
Qty
Code Description
B
Spring Washers (for M8 bolts)
B
Allen Key (for M8 bolt) x1
Bolts (M8x30mm) for
fitting side rails (3&4) and to
headboard & footboard (1&2)
Flat Washers (for M8 bolts)
E
x1
Spanner (for M8 nut)
Metal Plates for Slat Frame
x6
GNuts (for M8 slat frame bolts)
x6
x6 F
HARDWARE NEEDED FOR BED ASSEMBLY (PACK A)
x26
CFlat Washers (for M8 bolts)
x18
HARDWARE FOR FITTING METAL SLAT FRAME (PACK B)
Bolts (M8x50mm) for fitting
Metal Slat Frame (5) to
slat frame support bars
x2
F
Bolts (M8x50mm) for fitting
Slat Frame Support Rail (9) to
Footboard (2)
x6
J
Bolts (M8x20mm) for fitting
Metal Plates (K) and Cross
Bar (7) to Metal Slat Frame (5)
x2
K
QtyCode Description Qty Code Description
HFlange Lock-Nuts (M8) for
gas-lift pistons x2
Additional Tools Required Care & Maintenance
Please retain your assembly instruction and
tools provided for future use.
Periodically check that all bolts are still tight.
General Hints & Tips
When they are supplied and are
part of the assembly of this bed,
ensure that the barrel nuts are
fitted the correct way so the
hole in the nut is facing towards
the intersecting hole in the panel.
Intersecting
Hole
We recommend the bed is
assembled in
the room it shall be
located in.
A ssembly requires two persons.
Approximate time to
assemble this product
1.5 Hrs
No Additional Tools Required
In the unlikely event of missing or damaged parts,
please contact your retailer. Please have this guide at
hand quoting the part code reference numbers shown
when requesting spare or replacement parts.

Stage
1
Page 3 of 8
Bed Assembly - Use Pack 'A'
A x8 B x8 C x8
D
x1
2
1
Fit two sets of bolts (A), spring washers (B), and flat washers (C) to the holes in the headboard (1) as shown.
Note: Do not tighten fully but leave 10mm protruding as in the diagram.
Fit the side panels (3 & 4) to the headboard locating the brackets behind the flat washers.
Fit the other two sets of bolts through the brackets into the central pair of holes.
Loosely screw in the bolts but do not tighten them 100% yet.
A
B
C
10mm
3
&
4
1
&
2
3
4

6a
A
B
Between headboard (1)
and right side rail (4)
Between footboard (2)
and left side rail(3)
C
Fit the two angle brackets with leg (6a&6b) loosley screwing the
bolts (A), spring washers (B) & flat washers (C) into the threaded
inserts in the corners of headboard & footboard (1&2) and the
side rails (3&4).
Stage
2
Page 4 of 8
Bed Assembly - Use Pack 'A'
A x16 B x16 C x16
D
x1
Stage
3
11
3
34
&
11
4
Fit the base board support rails (11) to both side panels.
IMPORTANT: Be careful not to scratch the PU or fabric when
slotting the wooden supports into the side rail brackets.
Make certain the bed is squared up
as shown in the diagram then tighten
all bed assembly bolts 100%.
44
3
2
100%
6b
A
B
C
Between headboard (1)
and left side rail (3)
Between footboard (2)
and right side rail (4)

4
Page 5 of 8
10
Stage
5
i) Carefully fit Base Boards (10).
9
2
ii)
Using four sets of bolts (J) & flat washers (C) fit
two pieces of the metal plate (K) into threaded
inserts on top of the frame.
Using Allen key (D), tighten all six bolts 100%.
iii)
ii)
x2
F
Fit base boards - Use Pack 'A'
C x6
D
x1 x6
J
x2
K
2
5
7
Assembling Slat Frame - Use Pack ‘B’
Stage
Fit slat frame support rail (9) to
baseboard using two bolts (F) & flat
washers (C).
Using Allen Key (D) tighten 100%.
Fitting position for cross Bar (7) is clearly
labeled. Pass bar through Metal Slat Frame
(5) between first & second slat.
Carefully open the frame.
C
K
J
C
F
x2
C
J
7
Ease the plates on top of the cross bar (7) onto
top of the slat frame sides and loosely fit two sets
of bolts (J) & flat washers (C) through the plates
into the threaded inserts.
Do not tighten yet.
C x2
D
x1
F
I
T
C
R
O
S
S
B
A
R
H
E
R
E
i)

Page 6 of 8
6
E x1
B x6 C x12
D
x1
x6
G
x6
F
Fitting Slat Frame - Use Pack ‘B’
Stage
F
C
B
C
EG
Bolt into centre of long holes
4
iii) With help from your assistant, lift slat
frame (5) onto slat frame support bars
aligning first set of holes on slat frame with
first set of holes in support bars (nearest to
headboard).
iv) Using three bolt sets on each side (F),
(C), (B) & (G), fix slat frame to the support
bars but do not tighten fully.
HOLD THEM
FORWARD
ii)
i) UN-TIE THE ONE MECHANISM,
AND TAKE OUT THE BLOCK
3
3
Slat Frame Support Bar

Page 7 of 8
7
Stage
8mm
Carefully lay frame down making sure there
is an even gap all round as in the sketch.
Hold frame securely then tighten all six
bolt sets 100% using spanner (E) &
Allen key (D).
Fitting Slat Frame - Use Pack 'B'
E x1
D
x1
Stage
8
H x2
Ex1
During this next step, the assistant should hold up the
slat frame.
On side panels (3&4) slide gas-lift piston stems (X)
onto the axles (Y) then fit the flange lock-nuts (H).
Tighten nuts with spanner (E) - BUT DO NOT
over-tighten. A small gap is left so stems can
move freely - this is important - see sketch below.
Note: Be very careful what
you store under the bed -
the top of an item, like a
suitcase or a box must not
touch the slats or they may
be damaged. Maximum
storage height is 185mm.
SMALL GAP
E
H
(X)
(Y)
3
H

Page 8 of 8
Stage
9
Push x2 Mattress Stoppers (8) into metal frame, they should go all the
way through the upper & lower metal sections.
8
NOTE: Before moving the slat frame, place the mattress on the slats. Without a mattress in place, the speed of movement
is quick and may cause injury. Carefully lower the frame with the hand-strap ensuring the frame sides are aligned with the
side panels; there should be an even gap on each side. If not aligned, check bed is still square (see Stage 2) and if it is, but
gaps are still not even, re-align as in Stage 7.
Depending on the weight of the mattress, the rising speed will vary so be careful until you get used to the speed. Always
use the strap to lift or lower the frame - keep fingers well away from the moving parts.
When fully assembled and the mattress in position, please raise & lower the ottoman 4/5 times to
ensure the gas pistons are fully lubricated.
