Time4Sleep MARLOW User manual

Parts Identification
Page 1 of 18
210410
1
2
3
5
4
5
5
6
7
7
8
8
9
10
11
12
13
14
15
X4
MARLOW
4 DRAWER CHEST
PLEASE READ this guide prior to installation, to familiarise
yourself with the various stages of construction required.
Carefully open the pack and check the contents against the
parts and fittings check list.
Do not destroy any of the packaging until you are certain that
you have all the necessary parts.
Please ensure that the packaging is disposed of in a safe and
environmentally friendly way.
In the unlikely event of missing or damaged parts, please
email [email protected]
Please have this guide close at hand, quoting the part code
reference numbers shown, when requesting spare or
replacement parts.
Warnings
This product should only be used on a firm and level floor with the anti-tilt devices (p) fitted, see
Stage 13. Make sure the legs/base always remains in contact with the floor.
Keep small parts out of the reach of children during assembly to prevent choking.
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
use power tools to construct this product.
tighten screws until parts are assembled or as advised in this guide.
over tighten screws or bolts.
use this product if parts are missing, damaged or worn.
sit or stand on the product.
To clean, wipe with a damp cloth.
Never use scourers, abrasives or chemical cleaners.
Do not use solvent based cleaners or detergents as they can bleach or damage the product.
Care Information

8
1
PACK
Qty
PACK 2/2
7
Qty
1
4
5
1
1
1
Parts Checklist
1/2
6
1
Page 2 of 18
3
Top Panel
Left Side Panel
Right Side Panel
Upper Cross Rail
Drawer Cross Rail
Bottom Panel
Base Frame - Long Plinth
Base Frame - Short Plinth
9
10
14
4
13
11
1
4
12
4
Drawer Left Side Panel
Drawer Right Side Panel
Drawer Back Panel
Drawer Base
Drawer Base Support Bar
15
4
Fittings Checklist
QtyCode Description
a x20
c
x20
d
Qty
Code Description
b
x20
x2
p
HARDWARE NEEDED FOR CABINET ASSEMBLY
x20
x16
x4
x22
x8
x48
x2
x6
x8
e
x10
x10
r
m
x4
n
q
x2
Metal Cam Dowel
(Ø 7 x 40mm )
f
g
s
h
j
k
l
Cam Lock ( Ø 15 x 12mm )
Thin Thread Metal Cam Dowel
(Ø 5 x 34mm )
Cam Lock ( Ø 12 x 10mm )
Wooden Dowel ( Ø 8 x 30mm )
Screw ( Ø 5 x 60 mm )
Screw ( Ø 4 x 35 mm )
Screw ( Ø 3.5 x 12 mm )
Screw ( Ø 4 x 14 mm )
Screw ( Ø 4 x 12 mm )
Foot pad ( Ø 12 x 5 mm )
Screw ( Ø 3 x 16 mm )
Plastic bracket
Two part drawer slide
m1 & m2
Metal anti-tilt L bracket
Back panel support fitting
Expanding wall plug
Drawer Front Panel
2
3
4
2
2
Back Panel
1
1

Page 3 of 18
Bed Assembly
Additional Tools Required
Care & Maintenance
Please retain your assembly instruction and
tools provided for future use.
Periodically check that all bolts are still tight.
General Hints & Tips
A ssembly requires two persons.
Approximate time to
assemble this product
In the unlikely event of missing or damaged parts,
please contact your retailer. Please have this guide at
hand quoting the part code reference numbers shown
when requesting spare or replacement parts.
This product is designed to hold 25Kg in
total, spread evenly over the whole unit.
Do not exceed this weight.
We recommend that this unit is assembled in
the room intended for use.
When you are ready to start, make sure that
you have the right tools, plenty of space and
a clean, dry area for assembly.
Unwrap all packaging materials and place
the components on top of the carton box or
on a clean floor to prevent them from
scratching.
Check the pack and make sure you have all
the parts listed.
Ensure that this product is fully assembled as
illustrated before use.
Check all screws or bolts are tightened and
inspect regularly
Tools not included unless they are specified
in the parts list.
General Information

Stage
1
Page 4 of 18
Cabinet Assembly
m-1 = outer drawer slide
fixed to cabinet side
panels (2 & 3)
m-2 - inner drawer slide
fixed to drawer sides
(11 & 12)
x8
Separate the inner & outer
drawer slides and carefully
follow the diagram
Two part drawer slide (m)
m-1
m-2

hh
h
outer drawer slide (m-1)
a
a
a
a
a 3
h8
m-1 4
Stage
2
Page 5 of 18
Cabinet Assembly
2
2

a
a
a
hh
m-1
a 3
h8
m-1 4
Stage
3
Page 6 of 18
Cabinet Assembly
h
a
3
3

a*6
a*8
e
ee
e
a 14
e 8
Stage
4
Page 7 of 18
Cabinet Assembly
a
x3
1
4
5
6

j
n
b8
j
n 4
j 8
Stage
5
Stage
6
Page 8 of 18
Cabinet Assembly
bx8
6
6
7
8
8
7
7
7
8
8

b6
Stage
7
Page 9 of 18
Cabinet Assembly
bx6
2
3
4
5
5
5

e*4
f*4
f 4
e 4
Stage
8
Page 10 of 18
Cabinet Assembly
2
3
6

l*6
l6
Stage
9
Page 11 of 18
Cabinet Assembly
I
II
l
2
3
6

Stage
10
Page 12 of 18
Cabinet Assembly
2
3
4
5
5
5
Back panel (9).
Place the coloured side on
the back of the cabinet and
plain side on the inside of
the cabinet.

e*4
b6
e 4
Stage
11
Page 13 of 18
Cabinet Assembly
bx6
1
2
3

step1 step2
step3 step4
Ø6mm
p
k
r*10
s*10
g
p
q
r 10
s 10
g 2
k2
q2
p 2
Stage
12
Stage
13
Page 14 of 18
Cabinet Assembly

g*5
Stage
15
Stage
14
Page 15 of 18
Cabinet Assembly
g20
11
12
13
15
x4
x4
Drawer base panel (14)
Place the coloured side on
the inside of the drawer
and the plain side
underneath the drawer.

c*5
h
inner drawer slide (m-2)
h
h
h
h
h
m-2
m-2
c 20
d20
Stage
17
Stage
16
Page 16 of 18
Cabinet Assembly
dx5
m-2
h16
8
10
10
x4
x4

Stage
18
Page 17 of 18
Cabinet Assembly

m-1
m-2
h16
h*8
h*8
Stage
19
Page 18 of 18
Cabinet Assembly
Stage
20
800mm
390mm
906mm
