Time4Sleep LUCILLE User manual

LUCILLE TV BED
Double, King & Super King Size
Parts Identification
Page 1 of 12
Double & King Size
Super King Size
IMPORTANT: BEFORE STARTING TO ASSEMBLE THE BED - PLEASE READ THESE INSTRUCTIONS CAREFULLY.
23040
1
2
3
3
4
7
8
8
910 11 12
5
6
6
4
PLEASE READ this sheet prior to assembly to familiarise
yourself with the various stages of construction. Carefully
open the pack supplied and check the contents against the
parts and fittings check list.
Do not destroy any of the packaging until you are certain
that you have all the necessary parts for the assembly.
Please ensure that the packaging is disposed of in
a safe environmentally friendly way.
CAUTION: There are small components used in the
construction of this unit. These loose items should be
kept away from young children during assembly, to avoid
the danger of choking.
Ref. Qty Box Box
Parts Checklist
Description Ref. Qty
Description
2/4
6
7
8
14/15/30
28/30
91
10
Double Slat Caps
Single Slat Caps
MainsPower Lead - 3mt
11 3
12
Remote Control for TV Lift
Cable Clips
Cable Ties
3
Double / King / Super King
Double & King / Super King
Double & King / Super King
Headboard
Footboard
Side Rails
Wooden Slats
Centre Support Bar
Legs for Centre Support
5
1
2
3
1 1
2
3
1
2
428/30/45
1/2
3
2
2
2
2
2
Double / King / Super King
Double / King & Super King
3
1
2
2

Page 2 of 12
A D
x32Double & King
x40Super King
x32Double & King
x40Super King
x32Double & King
x40Super King
C
Spring Washer for M8 bolts
Flat Washer for M8 bolts
B
x2
x2
Bolts (M8x25mm) Allen key for M8 Bolts
Ea
Hook Bracket
Eb
Hook Bracket
HARDWARE NEEDED FOR BED ASSEMBLY (PACK A)
a
x1
x2
x2
TV INSTALLATION KIT - Inside Hardware pack (B)
x1
x1
b
x2
Allen Key (4mm)
Allen Key (2.5mm)
Ref. Qty
Ref. Description
Qty
Description
Counter-Sunk Screws (M4x12mm
Counter-Sunk Screws (M6x12mm)
Screw-Washer sets (M8x25mm) -
Use 5mm Allen Key (D)
Fittings Checklist
Additional Tools Required
Care & Maintenance
General Hints & Tips
Please retain your assembly
instruction and tools provided for
future use. Periodically check that
all bolts are still tight.
Approximate time to
assemble this product
2 1/2 Hrs
In the unlikely event of missing or damaged parts,
please contact your retailer. Please have this guide at
hand quoting the part code reference numbers shown
when requesting spare or replacement parts.
Cross-head Screwdriver Tape Measure
Press once and TV will rise to it's upper working position. Power to the TV will
be connected automatically
Press once and TV Lift will stop.
Torch
Code Matching
Code Matching (pairing): occasionally pairing is lost, perhaps due to atmospheric conditions,
To re-pair - press and hold the code matching button whilst connecting the power by plugging
the mains cable into the control box of the TV lift on the base of the footboard.
Continue to press the button for another 5 seconds then press the up or down button to
successfully match the code.
Regularly check the batteries and if necessary re-place them - x3 pcs AAA size.
Press once and TV will go down - as soon as the lower resting position is
reached power to the TV is switched off to prevent it overheating.
Choose a suitable sets of bolts & Allen key
IF BOLTS ARE SUPPLIED WITH YOUR TV, USE THOSE IN PREFERENCE

Page 3 of 12
Stage
1
Stage
2
ylbmessAdeB
Ax12 Bx12
C x12
D
x1
Ax12 Bx12 Cx12
D
x1
Ea x1 Eb x1
B
C
A
B
C
A
Ea
Ea
B
C
A
BC
A
Eb
Eb
1
2
3ii
3i
3i
3ii
90%
90%

Page 4 of 12
Stage
3
A B C
D
x1
Double & King x8
Super King x16
Double & King x2
Super King x4
Double & King x2
Super King x4
Double & King x8
Super King x16
Double & King x8
Super King x16
A
B
C
A
B
C
5
1 2
&
5
6
6
5
6
100%

Page 5 of 12
Stage
4
Stage
5
Press the "UP" button
to raise the TV lift.
9
Electrical & Cable Connections
10
Connect mains power lead (9)
to your wall socket - for safety,
this must be an earthed supply.

Page 6 of 12
Stage
6
TV Power Lead supplied
with your own TV
Leads for
HDMI or Aerial
If required, please
purchase yourself -
HDMI about 3mt
long and length of
aerial lead to suit
the position of your
wall socket.
TIP:
BEFORE FITTING THE TV,
PUSH CABLES THROUGH
EACH DUCT FROM THE TOP.
CHOOSE THE BEST SIDE TO
USE DEPENDING ON WHERE
THE CONNECTION PORTS
ARE ON BACK OF YOUR TV.
NEVER CROSS CABLES FROM
ONE SIDE TO THE OTHER.
Note: For illustration purposes only, TV connections may vary.

Page 7 of 12
Stage
7
x2
TIKNOITALLATSNIVT
a
Screw-Washer set (M8/M6/M4)
a
a
Loosen
Tighten
x1
Allen Key (5mm/4mm/2.5mm)b
TV INSTALLATION

Page 8 of 12
Stage
8
TV power lead supplied
with your own TV
PLUG IN - KEEP ALL CABLES TIGHT
- USE CLIPS & TIES PROVIDED.
Keep wires tight - peel
off cover from cable clips
& adhere to back of TV.
Note: For illustration purposes only, TV connections may vary.
11
12

Page 9 of 12
Stage
9
TV power lead
supplied with your
own TV
Press the “DOWN” button
to lower the TV lift.
10
Aerial lead supplied
by yourself if required

Page 10 of 12
Stage
10
Bed Assembly
8
84
4
4
47
8
84
4
4
47
4
4
7
3
5
3
5
Double & King Size
Super King Size
On either Double, King or Super King slat
frames - fit the slats to the frame as follows:
Slide slats (4) into the double plastic caps (7).
Slide single plastic caps (8) onto each end.
Connect each set one by one onto the centre
support bar(s) (5) & the metal support rail on
each side rail (3) - align the lugs & tap gently
with a light hammer.

Page 11 of 12
30
280
Floor to top
of slat
80
205
25
W
H
L
830
40
Top of slat to
top of side rail
Overall Dimensions (LWH mm)
Double:
2200 x 1430 x 1155
King: 2300 x 1580 x 1155
Super King: 2300 x 1880 x 1155
Internal Dimensions (LW mm)
Double:
King:
Super King:
Technical Specifications
Maximum TV Dims (WHD mm)
975 x 575 x 85
2020 x 1830
2020 x 1530
1920 x 1380
Distance Between Slats (mm)
Double:
King & Super King: 73
75
Slat Dimension (mm)
Double:
King:
Super King: 610 x 53 x 9
765 x 53 x 9
690 x 53 x 9

Page 12 of 12
TV BED SAFETY INFORMATION
IMPORTANT: Care should be taken when connecting electrical items. If you are in any doubt about the connections
please consult an approved electrician. If you still have a problem please contact your retailer for advice.
GENERAL INFORMATION
It is very important not to place any vessel containing liquids, e.g. drinks or vase of flowers on top of the TV footboard that may
accidentally spill and enter the TV compartment as this could cause damage to the TV and/or the TV lifting equipment. If this happens
turn off the power and contact your retailer.
Do not expose the bed to an undue level of heat - keep away from radiators.
Never allow anyone to sit on the foot end of the bed - keep children well away from moving parts.
To keep your bed clean, we recommend that it be wiped over with a slightly dampened cloth, or if fabric, use a light vacuum cleaner;
disconnect power before cleaning.
Supplied with the bed is a remote control to operate the TV Lift and there will be one to operate the television itself. Both these
remotes will be supplied with batteries - there are no batteries in the rest of the equipment.
When it is time to change the batteries there are strict controls for disposal of the old ones - your local council can advise
on how to safely dispose of them. Never burn batteries on an open fire as they could explode.
IMPORTANT POWER INFORMATION
Before fixing the mattress baseboards to the bed, please follow the instructions below:
Plug in the main power supply lead supplied with your bed; this is packedi inside the TV footend pack
It is essential that this power lead is connected to an earthed socket be it a wall socket or extension lead - otherwise there is risk of
damage or even electric-shock.
The wall socket providing the power must be accessible at all times in case you need to switch off the electric supply.
Power cable supplied with this bed or other approved mains powered extension leads used to power your equipment must not be
placed where they can be walked on - this is dangerous and could lead to accidents.
Power outlets, extension leads or adapters must not be overloaded beyond their limit - this can result in fire or electric shock.
During an electrical or lightening storm - disconnect the power completely as a precaution.
Always un-plug the power when going on holiday or when the bed is not used for an extended period.
If you have young children in the home always disconnect the power at the wall socket for extra safety.
Do not interfere with or modify any cables already fitted and do not add any media cables unless they are routed through the ducts as
shown. All leads must be tightly connected to back of TV, never hanging loose where they can get trapped.
Never touch moving parts or any part of the equipment - if something needs to be checked, disconnect the power first.
Do not insert anything into the footboard as this could seriously damage the TVand/or the TV lifting equipment and could, if done
carelessly, cause serious damage or injury.
If the equipment doesn't operate normally or if there is any unusual noises, disconnect the powerand contact your retailer for advice.
TELEVISION INFORMATION
Please follow the assembly steps for initial operation of the TV Lift, your TV and any media cables required.
Push the television power plug (supplied with your own TV), into it's own special socket which is on the face of the
footboard clearly shown in the instructions. For safety and to prevent overheating, this socket is only to be used for the
television as it does not have a constant power supply.
Raise the TV Lift by pressing the UP button of the remote control.
If required you can connect media cables the television ports.
Please use the cable clips & cable ties to make certain there are no loose wires to snag or get trapped.
The television can now be operated following the TV User Guide.
When finished viewing, lower the television back into the footboard by pressing the DOWN button of the remote contro,l.
For safety and to stop any overheating, power to the television is switched off when lift reaches the bottom rest position.
When the UP button is pressed - the TV Lifting Column rises and power is turned back on automatically.
TROUBLE SHOOTING
oIf your equipment does not operate please check all the electrical connections to the wall socket and check that
electricity is reaching the main power input plug bringing power to the footboard.
oMake sure that the TV is switched on -but note that the television will only work when it is in the up position.
oCheck that the remote control has not lost its connection with the TV Lift - please see pairing instructions on Page (2).
