Timex iConnect Pro User manual

iConnect Pro By Timex™
00725b-Pro Womens
USER GUIDE…..……..……..……..……..…….. 1
05K096001 5.18.20
Register your product at https://www.timex.com/product-registration.html
Register your product at https://www.timex.ca/product-registration.html

1
iConnect Pro
User Manual
Important Safety Instructions And Warnings
1. To prevent risk of fire, chemical burn, electrolyte leak, and/or injury from the unit’s
internal Lithium-polymer battery:
a. Do not attempt to remove the case back or exterior shell of the unit, or to remove
its non-user-replaceable battery.
b. Do not leave the unit exposed to a heat source or in a high-temperature location
(such as in the sun or in an unattended vehicle). To prevent damage, store the unit
out of direct sunlight.
c. Do not puncture or incinerate the unit.
d. When storing the unit for an extended time, keep it in the 32°F to 77°F (0°C to 25°C)
temperature range.
e. Charge the unit only within the 50°F to 113°F (10°C to 45°C) temperature range.

2
f. Do not operate the unit outside the -14 to 104°F (-10°C to 40°C) temperature range.
g. Contact your local waste disposal department to properly recycle or dispose of the
unit or its battery.
2. Use only the charging cable supplied with this product.
3. This unit is not a medical device and is not recommended for use by persons with
serious heart conditions. Always consult your physician before beginning or modifying
an exercise program.
4. Do not attempt to read the unit’s display while moving: this is unsafe and distracting,
and could result in an accident or collision. Read the display only when you can safely do
so. See instructions for details.
1. Product specifications
➢Model: M05K
➢Memory: RAM 256KB+ ROM 128Mb
➢Capacitive touch screen 1.3”360*360 pixel AMOLED IPS
➢Bluetooth: version 5.0
➢Function: Heart Rate, Anti-lost, Pedometer, Sleep monitor, Notification
➢Battery: Lithium-ion 3.8V/310mAh
2. Product Details
Side Button Function:
(1) HOME button: Press and hold the button for 5 seconds to turn on or shut down the watch.
After the watch is on, short press the button on time of day screen to turn off the screen.
Short press the button in menu or sub-menu to return to the time of day screen.
HOME button

3
3. Features and Functions
3.1 Basic Operations
(1) From the time of day screen, swipe the screen left to select different dial faces. Stay idle
for 2 second after choosing the desired dial face to confirm the selection.
(2) From the time of day screen, swipe the screen right to enter the menu. Different function
in menu are shown below.
•Daily activity –Record the activity data of current date.
•Heart rate –Measure heart rate
•Message –Check message pushed from phone.
•Sleep –Record the sleep of last night
•Weather –Weather information
•Sports mode –Different workout modes including Walking, Running, Hiking, Biking.
•Timer - Stopwatch
•Find phone –Find the connected phone.
•Setting –Allow manually adjusting the screen brightness, enabling vibration and
showing system information.
•Shutdown –Shut down the watch
(3) From TOD (time of day) screen, swipe the screen down to show short cut icon of menu
item Setting, Always ON Mode, Fine Phone, Shutdown and Timer.
(4) From TOD screen, swipe the screen up to show new pushed messages.
(5) The screen will be off after being idle for about 10sec. Simply pushing the HOME button
to light up the screen.
3.2 Watch Faces
4. Getting Connected
4.1 The iConnect By Timex 2 App

4
Download and install the "iConnect By Timex 2" App from APP Store or Google Play Store;
iPhone with IOS 10.0 or higher and Android phone with Android 6.0 or higher is
recommended.
4.2 Connection and Synchronize data
4.2.1 Bluetooth connection
4.2.1.1 For Android:
Open iConnect By Timex 2 - left slide menu bar –Pair my watch - select the corresponding
device icon - search for the corresponding Bluetooth address pairing.
Click OK and Click Pair to bind watch as below.
4.2.1.2 For IOS:
Connect Step 1:
Open “iConnect By Timex 2”- left slide menu bar –Pair my watch - select the corresponding
device icon - search for the corresponding Bluetooth address pairing
Connect Step 2: Now the Bluetooth menu interface displays iConnect Pro connected
successfully as shown below:

5
There will be “Connected”and icon shown on the right of the Bluetooth name of the
watch after connected successfully.
4.2.2 Synchronizing Data
Pair your watch with " iConnect By Timex 2 " App, Press " " to sync data. Your
data will be shown on App accordingly.

6
Notice：
Turning off the Bluetooth function on your phone will interrupt synchronization features
between your phone and watch. Please keep Bluetooth turned on.
It is recommended to allow the “Location Services”on your phone to the iConnect by Timex
2 App. This will enable the Weather feature as well other functions.
4.3 Main Features
4.3.1 Daily Activity
(1) Function introduction: The watch will display the user's total number of steps on the day,
walking distance, calories burned on the same day, and the data will be cleared at 0 o'clock
every day.
(2) Operation instructions: the main interface slides left and right, clicks the motion data to
switch to the step counter interface, and automatically stops the screen after 5S without
operation.
4.3.2 Heart Rate
(1) Function introduction:
Heart rate measurement: The watch will measure the user's heart rate under the heart rate
measurement interface. After the test is completed, the vibration will display the result.
After no operation, the screen will automatically go out.
(2) Operating instructions:
Heart rate measurement: slide to the left on the main interface and click the heart rate static
icon to switch to the heart rate measurement interface. Once the interface is entered, the

7
measurement will start. "- -" is shown on screen when the watch starts the measurement.
The measurement will take about 40sec to come up with a stable value to be displayed on
the screen, which will be indicated with vibration on the watch. If no value is displayed,
please return to menu and re-enter the heart rate measurement interface and try again.
4.3.3 Message
After pairing the watch to the phone, notifications from your phone will be sent to your
watch. It is necessary to switch on the supported message sending software in the App in
advance in the “Notification Settings”page.
Please note that the notifications are shown in characters but not in word. Emojis are not
supported on notifications.
4.3.4 Sleep
(1) Function introduction: The watch will display the user's sleep time of the previous night.
The default sleep measuring period is from 21:30 of current day to 12:00 of next day.
(2) Check measured Sleeping time: Drag the TOD screen to the right side. Tap on the Sleep
icon to enter the sleep interface. “Monitoring……” on the screen indicating the watch is still
measuring the sleeping time. Once the watch detects valid activity after sleep, the sleeping
time counting will stop and the measured sleep time of the previous night will be displayed
on the screen.
4.3.5 Weather
After connected with iConnect By Timex 2, the watch will show the local weather and
temperature.
4.3.6 Sports Mode
Single tapping the “Sports Mode” in the menu allows you to enter sports mode which

8
includes Walking, Running, Hiking, Biking.
Please note that it is NOT allowed to turn off the watch during tracking the activity in Sports
Mode. Once the activity in sport mode is paused, the heart rate measured value will be reset
to zero. Please also note that the watch supports 4 hours of sport mode tracking.
4.3.7 Timer
Single tapping the Timer icon enter the stopwatch interface. Tap the icon to start time
counting. The counting can be paused by single tapping the icon and be reset by single
tapping the icon. Drag the screen to the right in the Timer interface to return to the
menu page. The watch supports time couting to 99hrs 59mins 59sec.
4.3.8 Find phone
Single tapping the “Find phone”icon to attempt finding the paired phone. The phone
vibrates and rings indicating the phone is found. A “Disconnect”icon being shown on watch
screen indicates the watch has not been connected successfully to any phone.
4.3.9 Setting
You can manually adjust the screen brightness, enabling vibration and getting system
information in the Setting page.
4.3.10 Shutdown
Single tapping the green icon to confirm shutting down the watch or tapping the red icon to
return to menu page.

9
5. Features in the iConnect By Timex 2 App
5.1 Sleep Monitor.
Wearing the watch at night will allow you to monitor your sleep schedule and analyze
the quality of your sleep according to your nocturnal movements.
5.2 Heart Rate Monitoring.
The watch will automatically monitor your heart rate in 5 minute intervals and the measured
HR value will be synced to the App automatically. The measured value will be shown on the
Heart Rate block in the Dashboard of the App
In the App, you can initiate real-time measurement of heart rate. Tap on “Start” to start
heart rate monitoring and the measured heart rate will be shown in graphical manner. Tap
Close to end monitoring.
