Timex INTELLIGENT QUARTZ User manual

W273 NA 355-095016
Perpetual Calendar • Fly-back Chronograph
• Fly-back Chrono Compass • Linear Chronograph • World Time
• Compass • Tide Temp and Compass • Altimeter • Depth
• Yacht Racer • Yacht Racer Pro • Chrono Timer • 3GMT
Calendrier Perpétuel • Chronographe avec Fly-back
• Boussole Chrono avec Fly-back • Chronographe Linéaire
• Heure Mondiale • Boussole • Marée Température et Boussole
• Altimètre • Profondeur • Yacht Racer • Yacht Racer Pro
• Minuterie Chrono • 3 GMT
Calendario Perpetuo • Cronógrafo Fly-back
• Brújula y Cronógrafo Fly-back • Cronógrafo lineal
• Hora mundial • Brújula • Marea temperatura y brújula
• Altímetro • Profundidad • Yacht Racer • Yacht Racer
• Cronógrafo temporizador • 3GMT
™

English.............................. Page 1
Français............................ page 125
Español............................. página 259

1
TIMEX®WATCHES
Congratulations on purchasing your TIMEX®INTELLIGENT
QUARTZ™watch. Please read these instructions carefully
to understand how to operate your Timex watch.
Your watch may not have all of the features described in
this booklet.
For more information, and to register your
product please visit:
www.timex.com

23
TABLE OF CONTENTS
How to Start Your Watch................................................... 5
Water and Shock Resistance ............................................. 6
Indiglo®Night-Light ............................................................ 8
Date and Time Setting........................................................ 9
Perpetual Calendar .......................................................... 11
Fly-Back Chronograph...................................................... 14
Fly-back Chronograph Compass...................................... 20
Linear Chronograph ........................................................ 32
World time ....................................................................... 38
Compass........................................................................... 45
Tide Temp and Compass.................................................. 52
Altimeter .......................................................................... 61
Depth................................................................................ 69
Yacht Racer...................................................................... 74
Chrono Timer ................................................................... 85
3GMT .............................................................................. 101
Tachymeter Function..................................................... 108
Slide-Rule Bezel Function .............................................. 109
How to Adjust Bracelet.................................................. 114
Bracelet Link Removal.................................................... 116
Battery............................................................................ 117
Warranty......................................................................... 119

45
HOW TO START YOUR WATCH
(Does not apply to Perpetual Calendar models.) To start
your watch remove the plastic guard from under the
crown, then press the crown in against the case.
Some watches require the setting crown to be screwed
in. If your watch case has a protrusion with screw
threads, the crown must be screwed in after setting the
watch.
To screw in, push the crown firmly against the threaded
protrusion and hold in while turning the crown clockwise.
Continue to screw in the crown until it is tight. You will
need to unscrew the crown (counter-clockwise) before
pulling it out the next time you want to set your watch.
Welcome to the world of Timex®watches with
Intelligent Quartz™ technology, the future of quartz
analogue technology. Intelligent Quartz technology
brings the power of a micro-processor to the reliability
and accuracy of quartz analogue timekeeping. With Timex
Intelligent Quartz watches, the technology is written into
the design, delivering a new level of dial complication.
Uses up to three additional independent hands to display
an array of information, normally only available in digital
watches, in a traditional analogue format.

67
WARNING: TO MAINTAIN WATER-RESISTANCE, DO
NOT PRESS ANY BUTTONS UNDER WATER UNLESS
YOUR WATCH IS INDICATED AS 200 METER WATER-
RESISTANT. NEVER PULL OUT THE CROWN WHILE
UNDER WATER.
1. Watch is water-resistant only as long as crystal, crown
and case remain intact.
2. Watch is not a certified Diver’s watch.
3. Rinse watch with fresh water after exposure to salt
water.
4. Shock-resistance will be indicated on the watch face
or caseback. Watches are designed to pass ISO test for
shock-resistance. However, care should be taken to
avoid damaging the crystal.
WATER AND SHOCK RESISTANCE
If your watch is water-resistant, meter marking (WR_M)
is indicated.
Water-Resistance Depth p.s.i.a.* Water Pressure
Below Surface
30m/98ft 60
50m/164ft 86
100m/328ft 160
200m/656ft 284

89
DATE AND TIME SETTING
NOTE: The watch crown has three positions: closed,
middle and outer. To familiarize yourself with the
difference between the various positions extend the
crown to its outer position and then push the crown very
lightly until you feel it click into the middle position.
To set the date and time:
Time
Pull the crown to its outer position and turn it until the
correct time is shown. Ensure AM/PM setting is correct by
verifying that the date changes at midnight, not noon.
Date (Does not apply to Perpetual Calendar)
Pull the crown to its middle position and turn it until the
correct date appears in the date window. Note: The date
changes between 10 pm and 2 am. Do not change the
INDIGLO®NIGHT-LIGHT
Press button or crown to activate light.
Electroluminescent technology used in the INDIGLO®
night-light illuminates the watch face at night and in low
light conditions.
OR

10 11
date during this timeframe. Doing so could damage the
watch movement.
Push crown to closed position after setting date/time. The
second hand will begin moving.
NOTE: For months with fewer than 31 days, the date will
need to be adjusted.
PERPETUAL CALENDAR
OVERVIEW
A
B
1 2 3
1 2 3
HOUR HAND
DAY HAND
DATE HAND
SECOND HAND
MINUTE HAND CROWN
MONTH HAND
BUTTON A
(RECESSED)
BUTTON B
(RECESSED)
CLOSED
POSITION
MIDDLE
POSITION
OUTER
POSITION

12 13
LEAP YEAR OFFSET
To maintain the correct date, the watch includes a setting
for the current leap year offset. This setting is made at the
Timex factory or after battery replacement and cannot be
changed, only viewed.
To view the offset, pull the crown to its middle position.
The date hand shows the offset: 1 = 1 year after leap
year; 2 = 2 years after leap year; 3 = 3 years after leap
year; 4 = leap year. Push the crown in when done and
the hands resume their normal display of day, month,
and date.
INTRODUCTION
With your watch’s perpetual calendar feature, the
date does not need adjustment until 2100. The watch
automatically accounts for short months and leap years,
always showing the correct day and date. The day and date
were preset at the Timex factory. You only need to adjust
the time. The watch has two recessed push buttons for
use by Timex Service Center to set the day and date after
battery replacement. They have no use otherwise.

14 15
4TH CENTER HAND ADJUSTMENT
To readjust a misaligned 4th center hand:
1. Pull the crown to its outer position. The upper and
lower hands reset to the ends of their sweeps
automatically.
2. 4th center hand should point to 12 o’clock. If within
5 seconds of pulling the crown to its outer position the
4th center hand does not point to 12 o’clock, press
Button A or B to move the hand counterclockwise or
clockwise until it points to 12 o’clock.
3. Push crown to closed position when finished.
FLY-BACK CHRONOGRAPH
OVERVIEW
AA
B
23
1 2 3
1 2 3
UPPER HAND
CHRONO HOURS
2ND TIME ZONE
4TH CENTER HAND
SECOND HAND
DATE WINDOW
CROWN
CHRONO MINUTES SCALE
LOWER HAND
BUTTON A
BUTTON B
MINUTE HAND
HOUR HAND
CLOSED
POSITION
MIDDLE
POSITION
OUTER
POSITION
