Titan TP-Cosmo User manual

Operation Instructions
MASSAGE CHAIR
SAVE THESE INSTRUCTIONS
TP- Cosmo

01
02
04
06
07
08
20
CONTENTS
Safety and Maintenance
Safety Warning
Name and Function of Components
Function
Method of Usage
Product Specification
Thank you for purchasing this product . Please read this manual instruction
carefully in order to know how to use this product correctly before operation .
Please pay more attention to some important safety warnings and keep this
manual book properly for future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warning.
·DO NOT allow children to touch this product.
·Please use a well-grounding power supply suited to this product.
·Please turn off and pull plug when not in use or before cleaning to avoid injury or
damage to the product.
·Please operate this product according to this manual instruction(s).
·Don’t use accessories which are not recommended.
·Don’t use this product outdoors.
·Please read this manual instruction carefully before operation.
·Any other usage that is not listed in this manual instruction is forbidden.
·20 minutes of usage each time is recommended.
·Please don’t use it if the leather is broken or damaged.
·Please don’t use it if the cover or leather is damaged.
·Please don’t use it if the radiator hole is covered or blocked.
·Please don’t drop anything into this product.
·Please don’t fall asleep while using this product.
·Please don’t use it if drunk or feel unwell.
·Please don’t use it within one hour after having meal.
·Please don’t make the massage function too strong to avoid Injury.
·Please do not carry fragile, explosive and combustible materials in your pocket
such as mobile phones, lighters, and etc when using massage chair.
2. Environment for usage.
·Please don’t use under high temperature and moist environment such as
bathroom and or near water.
·Please don’t use it immediately while the environmental temperature
changes sharply.
·Please don’t use it under heavy-dusty or caustic environment.
·Please don’t use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
·People who are suffering from osteoporosis are not suitable to use this product.
·People who are suffering from heart disease or carrying electronic medical
equipment such as heart pacemaker are not suitable to use this product.
·People who are suffering from fever are not suitable to use this product.
·Pregnant women must advise Physician before use, as it is not not allowed
otherwise
·People who are injured or have skin disease are not suitable to use this product.
·Children under 14-year old or people mentally unbalanced without
being supervised are not allowed to use this machine.
·People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product, unless otherwise said by the doctor.
·People whose bodies are wet are forbidden to use this product.
·The appliance has a heated surface. Persons insensitive to heat must be careful
when using the appliance.
4. Safety.
·Check the voltage if it is suitable to the specification of this product.
·Don’t use wet hand(s) to pull the plug.
·Don’t make water go inside this product to avoid electric shock or cause damage
to this product.
·Don’t damage the wires or change the circuit of this product.
·Don’t use wet cloth to clean the electric parts such as switch and plug.
·Be away from this product under power cut state to avoid injury if the power
comeback suddenly.
·Stop using this product if abnormal, and please consult local agent
immediately.
·Stop using this product if you feel unwell, and please consult health care doctor.
·This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
·Children should be supervised to ensure that they do not play with the appliance.
·If the supply cord is damaged, it must be replaced by the manufacturer, its Service
agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
·This product should be maintained by certain appointed agents, users are
prohibited to disassemble or maintain by themselves.
·Please don’t forget to cut the power after usage.
·Don’t use this product if the socket looses.
·If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
·Don’t reserve this product under high temperature or near fire and avoid long-
time direct sunshine.
·If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
Hazard.
·Please clean this product by dry cloth. Don’t use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and made, it is
not necessary to be specially maintained.
·Don’t use edged objects to thrust this product.
·Don’t roll or pull this product above uneven ground, it should be lifted before
moving.
·Please use it intermittently; don’t make this product work continuously for long
.6. Solution of ordinary malfunctions.
·It is natural if the motor makes sounds while in use.
·If the controller can’t work normally, please check the plug and socket if they are
connected strongly and make sure the switch is turned on.
·If the rated working time is over, the product will automatically activate the power-
off button; If this product works continuously for long, the temperature protector will
make the product automatically power-off, it should be used again after half an
hour's rest.

0504
Safety warning Safety warning
Warning
Warning
Warning
Warning
When the footrest is lifted, people should not apply pressure on the footrest to
avoid the massage chair falling forward to damage the product or cause personal
injuries.
Prohibit pressing
Before sitting on the massage chair, make sure that the massage rollers stay in
the seat cushion position to avoid damage to the rollers or discomfort to the
buttocks when the body is pressing down into the chair.
Do not strive to pull out the control cable or power cord during the standby or
power-on state to avoid product damaged or electrocution accidents. It is advised
that you unplug the controller cable and power cord and put away after use.
When starting the zero gravity lying function , be sure to check whether there are
children and pets under the bottom of the footrest and backrest . Please be extra
cautious as it may cause personal product damaged or personal injuries.

06 07
Name and function of components Function
1.Head cushion
2.3D digital audio
(right built-in voice-
controlled microphone)
3.Upper arm air
pressure component
4.Arm air pressure
component
5.Salient massage with
magnetic therapy
6.Manual controller
or mobile phone
placement slot
7.USB charging port
8.Seat cushion
9.Leg rest
10.Foot rest
11.Backrest
12.Armrest
13.Handrail shortcut key
14.Handrail decoration
15.Embedded lamp
16.Side cover
17.Back cover
18.Manual controller
19.Drive box cover
20.Move pulley
21.Power cord and plug
22.Safety box
23.Wire socket of
hand controller
24.Power switch
25.Power line socket
·This product has designed a set of automatic functions to help best aid your
relaxation.
·There are four simulative massage techniques: finger pressing, kneading, tapping
, tapping and kneading at same time.
·Equipped with shoulder automatic positioning detection.
·Automatic massage functions: automatic massage includes 12 kinds of automatic
massage functions, including comfortable massage, relaxing massage, traction
massage, shoulder and neck massage, back and waist massage, whole body
massage, Protection of vertebral massage, fatigue recovery, stretching muscles
and activating collaterals, buttock massage, soothing sleep and full air pressure.
·Equipped with upper body manual massage function (the whole body, fixed point
and local three massage parts are selected, and the speed of each massage
manipulation can be adjusted with five speed. In fixed point and local state, the
manipulator can adjust the position up and down; When tapping, pressing and
percussion massage, the width of the massage ball can be wide, medium or
narrow.
·Pneumatic massage function three modes and three levels of intensity selection;
Body pressure, arm pressure, leg pressure,.
·It is equipped with foot roller massage function.
·With leg frame with stepless adjustable function, suitable for different height use.
·With back heat treatment function: carbon fiber as far infrared heat source.
·Under the backrest frame, the backrest adopts slide rail technology to keep the
zero space against the deviation wall all the time, so as to save the space to the
greatest extent.
·Backrest frame guide adopts curve guide technology, which completely conforms
to the curve of human back, and can enjoy massage from head to thigh.
·Music playback system, 3D digital audio built into left and right upper arms. Use
the Bluetooth function of the smart device to play music wirelessly.
·Equipped with intelligent voice control recognition function.
·The left handrail is equipped with five kinds of handrail shortcut keys, such as open
key, calf frame lifting key, automatic mode key, linkage adjusting key and zero
gravity key.
·In the left and right palm air bags, there is a salient massage with a magnetic
massage function.
·The right handrail is equipped with USB charging function.
·The handrails on both sides are equipped with ice blue atmosphere lamp
·LCD Color screen controller.
·Shutdown automatic sitting function, manipulator automatic reset function.
18
17
22 23 24 25
19
21
FUSE:
T5AL 250V POWER INPUT
CONTROLLER JACK ON/ OFF
20
1
2
6
8
9
11
10 16
12
3
14
4
15
7
13
5

zero
0908
Method of Usage
Method of usage
LCD: Display all massage functions.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1.LCD:
·Display all massage functions.
2.Power switch:
·Turn on or off all massage functions.
3.Pause \ run button:
·Pause or run all massage functions.
4.Timing key:
·Timing time adjustment
5.Automatic reclining key:
·There are three automatic reclining modes, which can automatically switch
according to your own needs.
6.Footrest up key:
·Adjust footrest up.
7.Automatic massage button:
·Please refer to page 10 of this manual for details.
8.Air pressure mode key:
·Turn on/off air pressure massage function (please refer to page 11 of this manual
for details).
9.Manual massage key:
·Please refer to page 11 of this manual for details.
10.Foot roller key:
·Please refer to page 11 of this manual for details.
11.Shoulder adjustment key:
·Manual adjustment of human shoulder position massage, finger pressure
point.
12.Up key:
·Adjust backrest frame up and calf frame down.
13.Calf frame down key:
·Adjust calf frame down.
14.Lie down key:
·Adjust backrest frame down and calf frame up.
15.Air pressure intensity key:
·Adjust air pressure intensity.
16.Heating key:
·On/off heating massage function.

11
①、Press the power button to start the massage.
②、 leg frame and back frame will automatically lie down , waiting for the
selection of massage function (select an automatic function), sitting posture
adjustment more than 3 minutes without operation will cause automatic
shutdown.
③、After selecting the function of automatic mode, the automatic detection of
human shoulder position and massage finger pressure point shall be carried
out first, wait for the completion of the detection.
④、If the detected shoulder position is deviated from the actual shoulder position,
adjust the upper and lower keys of the shoulder position to the appropriate
position.The shoulder position has 10 positions. If no shoulder position is
selected within 10 seconds, it will automatically enter the massage function.
Method of usageMethod of usage
1.Switch power supply on
Diagram of plug in Diagram of the switch position of power supply
FUSE:
T5AL 250V POWER INPUT
CONTROLLER JACK ON/OF F
2.Start to massage
Button Description Display
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
10
Shoulder
adjust
High shoulder position
suitable shoulder position
Low shoulder position
F1 Auto
F2 Auto
F3 Auto
F4 Auto
F5 Auto
A1 Auto
A2 Auto
A3 Auto
A4 Auto
A5 Auto
A6 Auto
A7 Auto
·Automatic massage
Function Button Description Display
Comfort
Relax
Stretch
Shoulder&neck
Back&waist
More
Automatic
massage
Comfort: The most comfortable massage experience.
Easy, soft, and comfortable massage, relieve body
fatigue
Frame and backrest frame rise and fall, and air
pressure massage, and stretch or traction on the leg,
remove fatigue, restore vitality.
Shoulder & neck: focus on shoulder and neck massage.
Back & waist massage focus.
Full body massage: deep massage to rejuvenate
the body.
Chiropractic massage: Inspired by chiropractic style
of massage, relax body, and mind.
Fatigue recovery: improve the whole body fatigue pain,
for the back, limbs to achieve relaxation and improve
microcirculation, quickly relieve fatigue.
Meridians massage: dredge meridians, quickly improve
the body's microcirculation, enhance immunity.
Sleep massage: through the twelve major health
acupoints massage to help the body recuperate
balance, quickly improve sleep, improve sleep quality.
All pressure:, focusing on the whole body pressure
massage to fully relax the body, to the depth of the
body massage, fully relieve fatigue and pain of the body.
Glute Massage: Aimed at the buttock and thigh to
effectively massage to aid body in relaxation.
In shoulder massage and acupressure point detection process(manual device
screen displays shoulder position adjust icon. Key shoulder position can adjust
the position of shoulder), 12 automatic massage function keys (comfortable
massage, easy traction massage,massage neck, back, waist massage, whole body
massage, protecting vertebral massage, fatigue recovery, relaxes the muscles and
stimulate blood circulation, buttock, sleep, full pressure) in any key and enter the
massage function (skip step 5).
⑤、Select the massage function, massage.

12 13
Method of usageMethod of usage
H0
H1
H2
Function Button Display
·Upper body manual massage
Massage ball adjustment
Technique
Speed
Width
Back
stretch
Shiatsu: speed, width.
Knead: speed.
Beat: speed, width.
Knead pat: speed.
Knock: speed, width.
5 speed adjustable.
The width of the third gear can be adjusted.
Fixed position and spot massage.
Small area local round trip massage.
A round trip massage.
Massage position adjustment
(in fixed point and local mode,
massage position can
be adjusted).
Manipulator uplink
Manipulator descending
·Pneumatic massage
Function Button Description Display
Air
pressure
Mode
intensity
Full pressure: air pressure massage on arms,
legs and feet.
Arm: air pressure massage with the arm as the
focus.
Leg: barometric massage for leg, foot.
Adjustable in three levels.
·Foot roller massage
Function Button Description Display
Foot
roller min
·Heated massage
Function Button Description Display
Heat Press this button to turn on/off the back
infrared hyperthermia.
·Pause/start massage button
Function Button Description Display
Pause/start
·Adjust lying Angle
Function Button Description
Rise up
Lay
down
Calf
Rise up
Calf
down
Lie down
automatically
·Other manual functions
Function Button Description Display
Timing
Press this button in the process of massage and all
massage movements will be paused(the chair will
turn off after 20 mins paused), press this key to
resume all before it turns off..
Press button to turn the foot roller massage
on/off. There are three levels of intensity weak,
medium, and strong which can be adjusted to
close the four states of cycle switching.
Press key , the backrest frame will slowly rise and
the calf frame will slowly go down, a "beep" will be
heard when it reaches the top
Press key , the backrest frame will slowly go down, and
the calf frame will slowly go up, a "beep" will be heard
when it reaches the end.
Press key, the calf frame will slowly rise, a "beep" will be
issued to indicate the end. Release the key to stop
adjusting.
Press key, to lower the calf frame slowly, a "beep" will be
issued to indicate the end. Release the key to stop
adjusting
Press the button every time to switch the automatic
lying mode. There are three modes in total.
Press to add 5 minutes. Time adjustment can
not exceed 30mins, if more than 30 mins it
will return to the minimum time value.

14 15
AUTO
Zero
1
2
3
4
5
Method of usageMethod of usage
3.Introduction of handrail shortcut keys
The left arm
1. Press the "ON" key: Start the massage chair.
2. Calf Lift key: Adjust the calf up or down.
3. Automatic key: enable automatic massage function(s).
4. Linkage Adjustment key: Linkage to adjust backrest frame position.
5. Zero-gravity key: Adjust to the zero-gravity angle of the massage chair.
Function
Description
Power button: Press this button to turn on or off all massage functions.
Calf Up key: Lift the key up to move the calf slowly, release to stop
Calf Frame Down key: Press the key down to move the calf
frame down slowly, release to stop.
Automatic Mode: Press the key each time to switch and rotate
through the automatic massage functions.
Right arm
Manual controller
or cell phone placement slot
USB charging port
To move to an upright position: Press this button to move the
backrest up and footrest down slowly, it will stop once the button is
released.
Zero Gravity: Every time you press this key, it will automatically adjust
the position of the calf and backrest frame to zero gravity . There are
three kinds of zero-gravity lying mode(s), which can be rotated.
To move to a down position: Lift up the button, the backrest will go
down and footrest up slowly, it will stop once the button is released.

16 17
·When the massage chair is turned on or in standby mode, say “Alice Alice” to wake
up the voice control function.
·After the successful wake-up, the massage chair will reply “I am here”. At this time,
the voice control entry corresponding to the function is realized within 6 seconds.
After the massage chair responds, the corresponding voice control function can be
realized; if not correctly stating any voice entry for more than 6 seconds, the voice
control function automatically turns off and needs to be reawakened.
·Note: When using the voice control function, please use English, with amoderate
speech rate. Voice commands should follow the Voice entry as noted below.
4.Voice control operation
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Voice control enter
Awakening words: “hi Alice”. Answer: I am here.
Serial No Voice control entry
Massage on
Massage close
Comfort Massage.
Relax massage.
Full body massage.
Neck and shoulder massage.
Back and waist massage.
Stretch massage.
Fixed massage.
Change the other mode.
Go little down.
Go little up.
Open the air pressure.
Close the air pressure.
Up the seat position.
Down the seat position.
Stop adjustment.
Answer entry
Answer: Ok, massage on.
Answer: Ok, massage close
Answer: ok, comfort massage
Answer: ok, relax massage
Answer: ok,full body massage
Answer: ok,Neck and shoulder massage
Answer: Ok,back and waist massage
Answer: ok,stretch massage
Answer: ok,fixed massage
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Answer: OK, Open the air pressure
Answer: OK , Close the air pressure
Answer: Ok, Up the seat position
Answer: Ok, Down the seat position
Answer: Ok, stop adjustment
Method of usageMethod of usage
1.Enter your smart device settings and open the Bluetooth function to search the
new Bluetooth device(s) .
2.You will find the bluetooth named (IMCM-XXXX), choose it to pair with the
chair.
3.Turn on the Music Player in the smart device .
5.Bluetooth Player Operation
6.Turn Off the Power and Stop Massage.
·When pressing the power button during the massage, it will stop all the massage
functions immediately, the backrest and footrest will go back to the default posit
on.And when the massage time up, the massage hand will go back to the default
position, all the massage function will stop, the backrest and footrest will not go
back to the default position.
·Cut off the power of the whole machine. Figure (switch power off)
FUSE:
T5AL 250V POWER INPUT
CONTROLLER JACK O N/O FF
Diagram of the power switch position Unplug the power cord
7.The calf installation.
·After connecting the wires and the air hose between the chair seat and the leg
rest , unfasten the fixed pipe belt and insert the connecting part into the seat
frame(figure 1).
·Place the round tube from calf left and right sides to the legs brackets.(figure 2)
1 2

18 19
12
8. Head cushions and backrest pad's dismounting and use manual
·You can decide whether to use the head cushion(recommend). The head
cushion allows you to control the intensity of the neck and shoulder massage.
The backrest cushion and the backrest is connected by zipper (1); the head
cushion and the backrest cushion is connected by velcro as show in the
illustration (2).
Zipper Thread gluing
Method of Usage
·Please place the heavy massage chair on carpet, mat, or any soft object, for
it may cause damage to wooden floors. The object placed between the wood
and chair should serve as protection to the floor.
Caution: Do not move the chairs with its wheels on wood floor, rough ground or in
a narrow space. Two people are required to lift the chair. During the lifting period,
take the calf rest end sealing plate and backrest cover grooves as the force-bearing
point(Please do not lift armrest directly.)
9.Floor Protection
10. Method of Movement
·Make sure that all wires are far above the ground, tilt the backrest backward to
a certain degree (with the gravity center resting on the wheels), push the chair
forward or backward with your hands and finally resume the chair to the normal
position in a slow and gentle manner.
Note: Before movement you must turn off the power first and then unplug
the power cord, as well as the controller cord.
·Then turn the legs fixing cover over the round tube on both sides of the legs
(figure 3)
·Then use 2pcs M4 screws to fix the legs on the massage chair , turn up and
down to check if there are any problems to see if the wires and air hose get stuck
or not, then finish the installation. (figure 4)
3 4
Method of Usage

20
Product specification
Model: TP-Cosmo
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power input:120W
Rated time: 20Min
Safety structure: Class I
Material introduction: PVC, PA, steel parts and electric & electron parts
MATERIAL PU LEATHER CLOTH WOOD
