Titan TTB876PLN User manual

Original Instructions_MNL_TTB876PLN_GB_V1_220119
TTB876PLN
900W Planer
EAN: 5059340252247
WARNING: Read the instructions before using the product!
EN

EN
02
35
36
37
34
28
25
24
In more detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
EC declaration of conformity
23
02
03
16
17
19
Getting started...
Technical and legal information
Your product
Technical
Before you start
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...

Getting started...
03
EN
Safety information
Safety warnings
General power tool safety warnings
WARNING! Read all safety warnings, instructions,
power tool. Failure to follow all instructions listed
serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
of electric shock.
TTB876PLN by TITAN

04
Getting started...
EN Safety information
Safety warnings
b) Avoid body contact with earthed or grounded
surfaces, as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Donotexposepowertoolstorainorwetconditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
TTB876PLN by TITAN

Getting started...
05
EN
Safety information
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool.
switch or energising power tools that have the switch
on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
TTB876PLN by TITAN

06
Getting started...
EN Safety information
Safety warnings
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect
the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
TTB876PLN by TITAN

Getting started...
07
EN
Safety information
5) Service
a) repair person using only identical replacement
parts. This will ensure that safety of the power tool is
maintained.
Safety instructions for planers
a) Wait for the cutter to stop before setting the tool
down. An exposed rotating cutter may engage the
surface leading to possible loss of control and serious
injury.
b) Hold the power tool by insulated gripping surfaces,
because the cutter may contact its own cord.
Cutting a “live” wire may make exposed metal parts
of the power tool “live” and could give the operator an
electric shock.
c) Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding
the workpiece by your hand or against the body leaves
it unstable and may lead to loss of control.
d) Only bring the power tool into contact with the
workpiece when switched on. Otherwise there
is danger of kickback if the cutting tool jams in the
workpiece.
e) Do not allow the roller and blades to come into
contact with your hands. Contact with these
rotating parts will cause serious injury.
f) Never plane over metal objects, nails or screws.
Blades and roller will be damaged and cause
increased vibration and a hazard to the user.
g) While working, always hold the planer in such a
workpiece. Otherwise the planer could slip and cause
injury.
TTB876PLN by TITAN

08
Safety information
Getting started...
EN
Safety warnings
h) Always ensure that the power cable trails out
behind the tool to prevent the risk of it becoming
snagged by the rotating roller and blades. Risk of
injury or electrocution.
Additional safety warnings
a) Be aware of kickback.
b) Turn the product off immediately if the cutting blade
gets jammed.
c) Never slow down the application tool yourself
mechanically. Always allow the product to come to
complete stop on its own.
d) Never touch the workpiece with your hand when you
are working on it.
e) Do not work overhead.
f) Ensure that the workpiece is free of foreign objects
such as screws or nails.
WARNING! Contact with or inhalation of harmful
/ toxic dusts arising from sanding lead-based
painted surfaces, woods and metals can endanger
the health of operator and bystanders!
g) Take special care to guard against these dusts,
including the following:
- All persons entering the work area must wear
an appropriate dust mask specially designed for
protection against harmful / toxic dusts, in addition
to using the dust extraction facility, and keeping
work area well ventilated.
- Children and pregnant women must not enter the
work area.
- Do not eat, drink or smoke in the work area.
TTB876PLN by TITAN

Getting started...
Safety information EN
9
- Any pre 1960 building may have paint containing
lead on wood or metal surfaces. If you suspect
workpiece contains lead seek professional advice.
h) Some wood and wood type products especially MDF
(Medium Density Fibreboard) can produce dust that
can be hazardous to your health. We recommend the
this product in addition to using the dust extraction
facility.
The following information applies to professional
users only but is good practice for all users:
ADDITIONAL SAFETY WARNING FOR
CONSTRUCTION DUST
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce
the risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at- risk groups within
this because of the dust that they breathe: silica dust is
not just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts
in things like sand, sandstone and granite. It is also
commonly found in many construction materials such as
dust (also known as Respirable Crystalline Silica or RCS)
during many common tasks such as cutting, drilling and
silica can lead to the development of:
•Lung cancer
•Silicosis
•Chronic Obstructive Pulmonary Disorder / Chronic
obstructive pulmonary disease (COPD)
the development of Asthma. The risk of lung disease is
linked to people who regularly breathe construction dust
over a period of time, not on the odd occasion.
TTB876PLN by TITAN

Getting started...
EN
10
Safety information
Safety warnings
To protect the lung, the COSHH Regulations sets a limit
on the amount of these dusts that you can breathe (called
a Workplace Exposure Limit or WEL) when averaged
over a normal working day. These limits are not a large
amount of dust: when compared to a penny it is tiny – like
a small pinch of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
HOW TO REDUCE THE AMOUNT OF DUST?
a) Reduce the amount of cutting by using the best sizes
of building products.
b) Use a less powerful tool e.g. a block cutter instead of
angle grinder.
c) Using a different method of work altogether – e.g.
using a nail gun to direct fasten cable trays instead of
Please always work with approved safety equipment,
out microscopic particles and use the dust extraction
facility at all time.
For more information please see the HSE website:
http://www.hse.gov.uk/construction or http://www.hse.gov.
uk/pubns/cis69.pdf
TTB876PLN by TITAN

Getting started...
EN
11
Safety information
WARNING! Some dust particles created by power
sanding, sawing, grinding, drilling and other
construction jobs contain chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
•Lead from lead-based paints.
•Crystalline silica from bricks and cement and
other masonry products.
•Arsenic and chromium from chemically treated
timber.
Your risk from these exposures varies, depending
upon how often you do this type of work. To reduce
your exposure to these chemicals:
•Work in a well-ventilated area.
•Work with approved safety equipment, such as
those dust masks that are specially designed to
VIBRATION
The European Physical Agents (Vibration) Directive
has been brought in to help reduce hand arm vibration
syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to
provide indicative vibration test results to enable users to
make informed decisions as to the period of time a power
tool can be used safely on a daily basis and the choice of
tool.
SEE TECHNICAL SPECIFICATIONS IN THE
INSTRUCTION MANUAL FOR THE VIBRATION
LEVELS OF YOUR TOOL.
The declared vibration emission value should be used
as a minimum level and should be used with the current
guidance on vibration.
the HSE website has further information.
TTB876PLN by TITAN

Getting started...
EN
12
Safety warnings
The declared vibration emission value has been measured
in accordance EN 62841-1 and EN 62841-2-14 and may
be used to compare one tool with another.
The declared vibration emission value may also be used
in a preliminary assessment of exposure.
WARNING! The vibration emission value during
actual use of the power tool can differ from the
declared value depending on the ways in which
the tool is used:
•How the materials are grinded, cut or drilled.
•If the tool is in good condition and well maintained.
•Use correct accessory for the tool and ensure it
is sharp and in good condition.
•The tightness of the gripping handles.
•The tool is being used as intended by its design
and these instructions.
While working with this power tool, hand/arm
vibrationsoccur.Adoptthecorrectworkingpractices
in order to reduce the exposure to vibration. This
tool may cause hand-arm vibration syndrome if its
use is not adequately managed.
Safety information TTB876PLN by TITAN

Getting started...
EN
13
WARNING! Identify safety measures to protect
the operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
Note:
•The use of other tools will reduce the users’ total
working period on this tool.
•Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
•Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
•Avoid using tools in temperatures of 10 ºC or
less. Plan your work schedule to spread any
high vibration tool use across a number of days.
Health surveillance
All employees should be part of an employer’s health
surveillance scheme to help identity any vibration related
diseases at an early stage, prevent disease progression
and help employees stay in work.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
a) Only use the product as intended by its design and
these instructions.
b) Ensure that the product is in good condition and well
maintained.
Safety information
TTB876PLN by TITAN

Getting started...
EN
14
Safety warnings
c) Use correct attachments for the product and ensure
they are in good condition.
d) Keep tight grip on the handles/grip surface.
e) Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
f) Plan your work schedule to spread any high vibration
tool use across a longer period of time.
g) Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
a) Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage to
property.
b) Switch off and disconnect from the power supply
if there are malfunctions. Have the product checked
before you operate it again.
Safety information TTB876PLN by TITAN

Getting started...
EN
15
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
a) Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
b) Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects
during use.
c)
objects or poor power tool accessories.
WARNING! This product produces an
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Safety information
TTB876PLN by TITAN

Getting started...
EN
16
Your product
Your product
1 2 3
5
4
6
7
8
9
10
11
12
13
14
15
9
18
17
29
26
25
28
20 19
21
22
24
23
27
30
TTB876PLN by TITAN

Getting started...
EN
17
1. Lock-off button
2. On/off switch
3. Handle
4. Dust extraction
crossover lever
5. Power cord with plug
6. Dust extraction outlet
(both sides)
7. Air vents
8. Mounting bolt
9. Wing screw (x2)
10. Parallel guide
11. Wing nut
12. Angle bracket
13. Mounting thread
(parallel guide)
14. Mounting thread
(rebate depth gauge)
15. Rebate depth gauge
16. Scale
17. Cutting depth
adjustment knob
18. Dust bag
19. Blade (x2)
20. Hex bolts (x6)
21. Roller
22. Grub screws (x4)
23.
(x2)
24. Guard
25. Back plate
26. Foot
27. V-groove
28. Front plate
29. Hex key
30. Wrench
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
General
> Rated voltage, frequency : 220-240 V~, 50 Hz
> Rated input power : 900 W
> Rated no load speed n0:16000 min-1
> Cutting head type : 57002
> Planing width : 82 mm
> Cutting depth : 0-3 mm
> Rebating depth : 0-12 mm
> Protection class : Il
> Weight : approx. 3.6 kg
Sound values
> Sound pressure level LpA :84.9 dB (A)
> Sound power level LWA :95.9 dB (A)
> Uncertainty KpA, KWA :3 dB (A)
Hand arm vibration values
> Handle ah,W :1.542 m/s²
> Uncertainty K : 1.5 m/s²
The sound values have been determined according to noise test code given in
EN 62841-1 and EN 62841-2-14, using the basic standards EN ISO 3744 and
EN ISO 11203.
TTB876PLN by TITAN

Getting started...
EN
18
The sound intensity level for the operator may exceed 80 dB(A) and ear protection
measures are necessary.
The declared vibration value has been measured in accordance with a standard
test method (according to EN 62841-1 and EN 62841-2-14) and may be used for
comparing one product with another. The declared vibration value may also be
used in a preliminary assessment of exposure.
WARNING! Depending on the actual use of the product the vibration
values can differ from the declared total. Adopt proper measures to
protect yourself against vibration exposures. Take the whole work
process including times the product is running under no load or
switched off into consideration.
Proper measures include among others regular maintenance and
care of the product and accessories, keeping hands warm, periodical
breaks and proper planning of work processes.
Rating label explanation
Symbols
others the following symbols and abbreviations. Familiarise yourself with them to
reduce hazards like personal injuries and damage to property.
V ~ Volt, (alternating voltage) Hz Hertz
W Watt /min or
min-1
Per minute
g Gram kg Kilogram
mm Millimetre m Metre
dB(A) Decibel (A-rated) m/s² Metres per second squared
Lock / to tighten or secure. Unlock / to loosen.
Note / Remark. Caution / Warning.
TTB876PLN by TITAN
TTB876PLN = Model Number
TT = TITAN
B = 220 - 240V ~
876 = Sequential Code
PLN = Planer

Getting started...
EN
19
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
Read the instruction manual. Wear hearing protection.
Wear eye protection. Wear a dust mask.
Wear protective gloves. Wear protective, slip-resistant
footwear.
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage and
transportation.
Do not smoke in the work area, around the product and in the vicinity of
This product is of protection class II. That means it is equipped with
enhanced or double insulation.
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
UK Conformity Assessed.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check with
your Local Authority or local store for recycling advice.
Unpacking
1.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
TTB876PLN by TITAN

Before you start
Getting started...
EN
20
You will need
(items not supplied)
Suitable personal protective equipment
(items supplied)
Mounting bolt (8), wing screws (9)
& wing nut (11)
Parallel guide (10)
Angle bracket (12)
Rebate depth guide (15)
Dust bag (18)
Hex key (29)
Wrench (30)
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
Setup
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to the power supply before it is completely
assembled!
Dust extraction
WARNING! Always attach a dust extraction device or the dust bag
when using this product in order to keep the working area clean! Wear
a dust mask when operating this product! Dust can be harmful to
health! Especially dust and chips of wood that has been treated, e.g.
with wood preservative or a stain!
Dust bag
1. Align the connector of the dust bag (18) to the dust extraction outlet (6) on
either side of the product (depending on application) and insert it all the way
to the stop (Fig. 1).
2.
depending on the side that is chosen.
3. Pull the connector out in a twisting motion to remove the dust bag (18).
TTB876PLN by TITAN
