Titan TRS05RX User manual

TITANALARM PANEL
INTRODUCTION
TheTITANAlarmPanelispart ofauniquelighting/ securitysystemfor homeor
business use. Theunit isdesigned toprotect yourproperty, servingasabasic
alarmsystemandalsowiththeadditionofaTITANBell PushTransmitter adoor
chimeunit. Inadditiontothebell pushtheTITANalarmpaneliscompatiblewith
theTITANwireless PIRDetector andwireless MagneticContact Detector. In
alarmmode whentriggered bythelatter twotransmittersthe110 decibelsirenwill
sound. TheBell Pushwill trigger achimealert wheninchimemode.
Note:Please readthisentiremanual beforeyoustarttoinstall thesystem.
LOADINGTHEBATTERIES
Theunit requiresfourAA sizebatteries. Toinstall thebatteries:
1.Openthebatterycover. (FIGURE1)
2.Insert fourAA batteriesensuringcorrect polarity.
3.Refit thebatterycover.
If duringusetheLowBatteryLED flasheseverythree seconds,the batteriesneed tobe
replaced.Average batterylifefor typicalusage issixmonths,subjecttoalkalinebatteries
beingused.
CHOOSINGAMOUNTINGLOCATION
l DONOTfixtheunitontometalworkor within1mof metalwork(i.e.radiator,water pipesetc)asthiscouldaffectthereceipt
ofsignalsfromTITANtransmitters.
l DO NOTlocatetheunit directlyaboveaheat source(e.g. fire, radiator, boiler etc).
l DO NOTexposetheunit totheweather or liquids. Theunit isnot weather proof.
Consider thefollowingpointswhenchoosingamountinglocation. Locatetheunit:
1) Withinaprotected area whenthesystemisset, i.e.anintruder shouldnotbe abletoreachtheunitwithoutatransmitter
detector beingtriggered.
2) Inapositionwhere it isnot visiblefromexternaldoorsor windows.
3) Inaneasilyaccessiblepositionbetween1.5mand2.0mabovefloor level.
Theunit shouldbe fixed usingtwoscrews50mm apart. Thescrewheadsshouldbe left proudtoallowtheunit tobe attached
usingthetwokeyholeslotsat therear oftheunit.
FIRST TIMEPOWERUP
Theunit iscapableofholdinguptotwelveTITANtransmitter
codes. Onfirst timepower upnocodeswill be stored. To
indicatethistheStatusLEDwill flashonandoff everythree
seconds.
Thefactorydefault 4-digit securitycode isset to1234 (Notethat
ifthebatteriesare removed or allowed torun flat theunit will
default back tothefactory4-digit securitycode of1234).
It isimportant tochange thefactory4-digit securitycode of1234
toyourownpersonalcode. Todo thisproceed asfollows:
1) Keyinthefactory4-digit securitycode 1234
2) Press key6
3) Enter yournewpersonal4-digit code (usinganycombinationofkeys 0to9)
4) Press key6again
Yourpersonal4-digit code isnowset andshouldbe used for anyfurther actions. (Notethisprocess must be completed within
15 seconds. Ifyoumakeamistakeor run out oftimetheunit will revert back tothefactory4-digit securitycode 1234).
CODELEARNING
ToenabletheTITANAlarmPaneltomemorisecompatibleTITANtransmitter codesproceed asfollows:
a) Keyinyour4-digit securitycode
b) Presskey Ý(theunitisnowinlearningmode andwillremainsofor thirtyseconds, theStatusandLowBatteryLEDs
will flashtoindicatethis)
c)Oncetheunitisinlearningmode activatethelearning mode for theTITANtransmitter youwishtheTITANAlarm
Paneltolearnfrom. Refer totheinstructionsfor eachtype oftransmitter inorder todo this. Duringlearningmode the
Page 1of2
Default Setting
(4-digit securitycode)
Mode Key Mode Status
1234 1 Instant Arm
1234 2 Delayed Arm
1234 3 Chime
1234 4 Disarm
1234 6 SecurityCode
1234 8 KeyTone
1234 ÝIDCode LearnMode
1234 # IDCode Clearance
KeyCombinationQuick ReferenceGuide
StatusLED LowBattery
LED
Siren
FIGURE1
KeyCombinationQuick ReferenceGuide

CODELEARNING(Continued)
TITANtransmitter shouldbe nolessthan30cmandnomore thanthemaximumrange of70mfromtheTITANAlarm
Panel.
d) TheTITANAlarmPanelwill emit alongbeep toindicatethat thecode hasbeenlearnt.
· IftheTITANAlarmPanelfailstolearnthetransmitter code repeat stepsa), b), c)andd).
Alsorepeatstepsa),b),c)andd) for eachTITANtransmitter youwishtheTITANAlarmPaneltolearnfrom.Uptothe
maximumoftwelveseparatetransmitters.
· Ifyoumakeanerror duringthecode learningsequence, or youwishtoclear theentire memoryoftheTITANAlarmPanel
for another reasonproceed asfollows:
1) Keyinyour4-digit securitycode
2) Press key#(theunit will nowaccept code clearance, theStatusandLowBatteryLED’swill flashtoindicatethis)
3) Keyinyour4-digit securitycode again
4) Press key#again
ARMING/DISARMINGALARMPANEL
Twoarmingmodesare availableinstantandentrydelay.Ifsettoinstantthealarmwillsoundthesirenimmediatelyacoded
TITANtransmitter istriggered. Ifset toentrydelaythealarm will soundthesirenfifteensecondsafter acoded TITANtransmitter
istriggered. Theentrydelaymode isthemost commonused. Bothmodeshaveafifteensecondexit delay.
Ifyoudo wishtoarm thealarm ininstantmodeproceedas follows:
1) Keyinyour4-digit securitycode
2) Press key1(after thefifteensecondexitdelaythealarmwill be armed) duringtheexitdelaythealarmwillbleep andthe
statusLEDwill flash.
To arm thealarm inentrydelay modeproceedas follows:
1) Keyinyour4-digit securitycode
2) Presskey2(after thefifteen-second-exitdelaythealarmwill be armed) duringtheexitdelaythealarmwillbleep andthe
statusLEDwill flash.
To disarm thealarm proceedas follows:
1) Keyinyour4-digit securitycode
2) Press key4.
· Ifthealarmistriggered thesirenwillsoundfor thirtyseconds,be silentfor tenseconds,repeated for tencyclesor untilthe
alarmisdisarmed.
· Ifacode entryerrorismade theLowBatteryLEDwillflashandthealarmwillemitthreebeeps.Ifthreeconsecutivecode
entryerrorsare made thekeypad will be disabled for thirtysecondsor until thesirensequencehasended.
OTHERFEATURES
1) Thedefault keypad toneison. Toturnthekeypad toneoff, or back on, keyinyour4-digit securitycode thenpress key8.
2) Thealarmcanbe used asadoor chime.Thisfunctionwillonlyworkwhenthealarmisdisarmed.Toturnthechimeonkeyin
your4-digit securitycode thenpress key3. Toturnthechimeoff keyinyour4-digit securitycode thenpress key4.
Inchimemode thealarmwillemitatwo-tonesoundwhenaTITANtransmitter triggersthealarmincludingtheTITANBell Push
Transmitter.
TROUBLESHOOTING
Unit will not learncodesor doesnot respondtoTITAN
transmitters:
l Check polarityofbatteries.
l Batterieslowor flat.
l Ensure transmitter isworkingandwithinrange.
Unit sirenvolumeweak:
l Batterieslow.
Environmental Concerns:
PleaseDONOTdisposeofelectricalappliancesasunsorted waste,usetherecyclingfacilitiesprovided byyour local
authorities.
PleaseDO NOTdisposeofpackagingasunsorted waste, usetherecyclingfacilitiesprovided byyourlocalauthorities.
Page 2of2
SPECIFICATIONS
Power Requirement 4x1.5vAA Batteries
Receiver Frequency 433MHz
MountingHeight Recommended 1.5-2.0m
SolidWall Mount
Keypad 10 digitsand# Ý
OperatingMode Chime: 2tone for2cycles
Alarm: Siren30 seconds, silent
10 seconds, 10 cycles
WarmUpTime Approximately10 seconds
IndexofProtection IP21 Indoor UseOnly
Specificationssubject tochangewithoutnotice.
