Titan TTB892MLT User manual

Original Instructions_MNL_TTB892MLT_GB_V01_220308
TTB892MLT
WARNING: Read the instructions before using the product!

EN
02
37
38
39
36
33
30
29
In more detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Declaration of conformity
28
02
03
17
19
Getting started...
Safety information
Your product
Before you start
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...

TTB892MLT
Getting started...
EN
03
Safety information
Safety warnings
General power tool safety warnings
Work area safety
Electrical safety
>
>
>
>
>
WARNING! Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool.Failure to follow all
instructions listed below may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future
reference.The term "power tool" in the warnings
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.

04
TTB892MLT
Getting started...
EN Safety information
Safety warnings
>
>
>
>
Personal safety
>
>
>
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric
shock.
Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites
accidents.

TTB892MLT
Getting started...
EN
05
Safety information
Power tool use and care
>
>
>
>
>
>
>
>
>
Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power tool in
unexpected situations.
Dress properly. Do not wear loose clothing or jewellery.
Keep your hair and clothing away from moving parts.
Loose clothes, jewellery or long hair can be caught in moving
parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within a
fraction of a second.
Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the job
better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on
and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or
remove the battery pack, if detachable, from the power
tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.

06
TTB892MLT
Getting started...
EN Safety information
Service
Safety warnings
>
>
>
>
>
Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free
from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the tool
in unexpected situations.
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.

TTB892MLT
Getting started...
EN
07
Safety information
Safety instructions for multi tool
>Take special care to protect yourself and people around
against dusts, including the following:
• All persons entering the work area must wear an
appropriate dust mask specially designed for protection
against harmful / toxic dusts, in addition to using the
dust extraction facility and keeping work area well
ventilated.
• Children and pregnant women must not enter the work
area.
• Do not eat, drink or smoke in the work area.
>Some wood and wood type products especially MDF
(Medium Density Fibreboard) can produce dust that can
be hazardous to your health. We recommend the use
product in addition to using the dust extraction facility.
>Hold the product correctly on its gripping surface and
adopt a stable stance, make sure that the power cord is
prevented from coming into contact with the product or
getting caught up on other objects preventing completion
of the operating pass.
>Ensure that you have removed foreign objects such as
nails and screws from the workpiece before commencing
operation.
>Do not use product for wet sanding, for dry sanding only.
>Do not force the product. Let the product do the work at
a reasonable speed. Overloading will occur if too much
pressure is applied and the motor slows resulting in
>Do not continue to use worn, torn or heavily clogged tool
attachments.
Safety warnings

08
TTB892MLT
Safety information
Getting started...
EN
Safety warnings
>Do not touch the moving tool attachment.
>Do not scrape wet or dampened materials (e. g.
wallpaper) or on moist surfaces. Penetration of water
into the product increases the risk of an electric shock.
>Where possible, secure smaller workpieces to prevent
them from moving under the product.
>Only use tool attachments in good condition. Do not use
them if they are torn or worn.
>Exercise extreme caution when handling the scraper.
The scraper is sharp; danger of injury.
>Keep your hands away from the cutting area. Do not
reach under the material being cut.
>Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory may
contact hidden wiring or its own cord. Cutting accessory
contacting a “live” wire may make exposed metal parts
of the power tool “live” and could give the operator an
electric shock.
>Clamping surfaces shall be cleaned to remove dirt,
grease, oil and water.
>Longer period using may lead overheating blade tips.
Therefore take breaks of approx. 15 minutes on a regular
basis to let the blade tips cool down.
>The power tool shall not be wet or applied in wet
environment.
>The voltage of the power source must agree with the
>Check the product, its power cord and plug as well as
accessories for damage before each use. Do not use the
product if it is damaged or shows wear.
>Double check that the accessories and attachments are
condition will be helpful to identify the problems.

TTB892MLT
Getting started...
EN
09
Safety information
>Secure the workpiece. A workpiece clamped with
clamping devices or in a vice is held more secure than
by hand.
>Keep the handles dry to ensure safe control. Grip the
product securely with two hands so you have full control
at all times.
>Ensure that the air vents are always unobstructed and
clear. Clean them if necessary with a soft brush. Blocked
air vents may lead to overheating and damage the
product.
>Switch the product off immediately if you are disturbed
while working by other people entering the working area.
Always let the product come to complete stop before
putting it down.
>Do not overwork yourself. Take regular breaks to ensure
you can concentrate on the work and have full control
over the product.
>Always keep the power cord behind the power tool.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
>Only use the product as intended by its design and these
instructions.
>Ensure that the product is in good condition and well
maintained.
>Use correct cutting attachments for the product and
ensure they are in good condition.
>Keep tight grip on the handles / gripping surface.
>Maintainthisproductinaccordancewiththeseinstructions
and keep it well lubricated (where appropriate).

TTB892MLT
Safety information
Getting
started...
EN
10
Safety warnings
>Plan your work schedule to spread any high vibration
tool use across a longer period of time.
>Prolonged use of the product exposes the user to
vibrations that can cause a range of conditions collectively
known as hand-arm vibration syndrome (HAVS) e.g.
carpal tunnel syndrome. To reduce this risk when using
the product, always wear protective gloves and keep
your hands warm.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
>Always be alert when using this product, so that you
can recognise and handle risks early. Fast intervention
can prevent serious injury and damage to property.
>Switch off and disconnect from the power supply if
there are malfunctions. Have the product checked by a
you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
>Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.

TTB892MLT
Getting started...
EN
Safety information
11
>Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects
during use.
>
objects.
WARNING! This product produces an
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
The following information applies to professional users
only but is good practice for all users:
Additional safety warnings for construction dust
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce
the risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at-risk groups within
this because of the dust that they breathe: silica dust is
not just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts in things
like sand, sandstone and granite. It is also commonly
found in many construction materials such as concrete
known as Respirable Crystalline Silica or RCS) during
many common tasks such as cutting, drilling and grinding.
to the development of:

TTB892MLT
Getting started...
EN
12
Safety information
Safety warnings
• Lung cancer
• Silicosis
• Chronic Obstructive Pulmonary Disorder (Chronic
obstructive pulmonary disease (COPD))
the development of Asthma. The risk of lung disease is
linked to people who regularly breathe construction dust
over a period of time, not on the odd occasion.
To protect the lung, the COSHH Regulations sets a limit
on the amount of these dusts that you can breathe (called
a Workplace Exposure Limit or WEL) when averaged over
a normal working day. These limits are not a large amount
of dust: when compared to a penny it is tiny – like a small
pinch of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
How to reduce the amount of dust?
1. Reduce the amount of cutting by using the best sizes of
building products.
2. Use a less powerful tool e.g. a block cutter instead of
angle grinder.
3. Using a different method of work altogether – e.g. using
a nail gun to direct fasten cable trays instead of drilling
Please always work with approved safety equipment, such
microscopic particles and use the dust extraction facility
at all time.
For more information, please see the HSE website:
http://www.hse.gov.uk/construction or http://www.hse.gov.
uk/pubns/cis69.pdf

TTB892MLT
Getting started...
EN
13
noitamrofniytefaS
WARNING! Some dust created by power sanding,
sawing, grinding, drilling and other construction
activities contains chemicals known to cause
cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paint
• Crystalline silica from bricks and cement and
other masonry products
• Arsenic and chromium from chemically treated
timber
Your risk from these exposures varies, depending
upon how often you do this type of work. To reduce
your exposure to these chemicals:
• Work in a well-ventilated area.
• Work with approved protective equipment,
such as those dust masks that are specially
Vibration
The European Physical Agents (Vibration) Directive has
beenbroughtintohelpreducehandarmvibrationsyndrome
injuries to power tool users. The directive requires power
tool manufacturers and suppliers to provide indicative
vibration test results to enable users to make informed
decisions as to the period of time a power tool can be
used safely on a daily basis and the choice of tool.
SEE TECHNICAL SPECIFICATIONS IN THE
INSTRUCTION MANUAL FOR THE VIBRATION LEVELS
OF YOUR TOOL.
The declared vibration emission value should be used
as a minimum level and should be used with the current
guidance on vibration.

TTB892MLT
Getting started...
EN
14
Safety information
Safety warnings
the HSE website has further information.
The declared vibration total value has been measured in
accordance with EN 62841-1 and EN 62841-2-4 and may
be used for compare one tool with another.
The declared vibration total value may also be used in a
preliminary assessment of exposure.
WARNING! the vibration and noise emissions
during actual use of the power tool can differ
from the declared value depending on the ways
in which the tool is used dependant on the
following examples and other variations on
how the tool is used:
• How the tool is used and the materials being
cut or drilled.
• The tool being in good condition and well
maintained.
• The use of the correct accessory for the tool
and ensuring it is sharp and in good condition.
• The tightness of the grip on the handles.
• And the tool is being used as intended by its
design and these instructions.
While working with this power tool, hand/arm
vibrations occur. Adopt the correct working
practices in order to reduce the exposure
to vibration. This tool may cause hand-arm
vibration syndrome if its use is not adequately
managed.

TTB892MLT
Getting started...
EN
15
Safety information
WARNING! Identify safety measures to protect
the operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
Note:
• The use of other tools will reduce the users’
total working period on this tool.
• Helping to minimise your vibration exposure
risk. ALWAYS use sharp chisels, drills and
blades.
• Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
• Avoid using tools in temperatures of 10ºC or
less. Plan your work schedule to spread any
high vibration tool use across a number of
days.
Health surveillance
All employees should be part of an employer’s health
surveillance scheme to help identity any vibration related
diseases at an early stage, prevent disease progression
and help employees stay in work.

TTB892MLT
Safety information
Getting started...
EN
16
Symbols
others the following symbols and abbreviations. Familiarise yourself with them to
reduce hazards like personal injuries and damage to property.
V~ Volt (alternating voltage) kg Kilogram
Hz Hertz °C Degree Celsius
W Watt dB(A) Decibel (A-rated)
/min or
min-1
Per minute m/s² Metres per second
squared
mm Millimetre
Lock / to tighten or
secure.
Unlock / to loosen.
Note / Remark. Caution / Warning.
Read the instruction
manual.
Wear hearing protection.
Wear eye protection. Wear a dust mask.
Wear protective
gloves (for assembly,
adjustments and
maintenance).
Wear protective, slip-
resistant footwear.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week
of manufacturing (Wxx)
For use in dry indoor rooms only.
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage
and transportation.
This product is of protection class II. That means it is equipped
with enhanced or double insulation.
The product complies with the applicable European directives and
an evaluation method of conformity for these directives was done.
WEEE symbol. Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.
UK Conformity Assessed.

TTB892MLT
Getting started...
EN
17
Your product
Your product
1. SDS clamping lever
2. On/Off switch
3. Hand grip
4. Speed dial*
5. Hex key
a. Hex key holder
6. SDS tool holder
a. Pin* (x12)
7. Sanding base plate
8. Plunge saw blade for wood
9. Segment saw blade
10. Plunge saw blade for metal
11. Sanding paper
(60# x3, 120# x3, 240# x3)
12. Scraper
13. Bolt
a.
14. Tool holder adaptor
(for popular brand accessories)
a. Pin* (x12)
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective section in the instruction manual.
7 8 9 10
5a
11 12 13 13a 14
4
321
5
6

TTB892MLT
Getting
started...
EN
18
Your product
General
> Rated voltage, frequency : 220 - 240 V~, 50 Hz
> Rated power input : 300 W
> Rated no load speed n0:10000 - 19000 min-1
> Oscillation angle : 2.8º
> Protection class : ||
> Weight : approx. 1.65 kg
Sanding base plate/paper
> :Hook & loop
> Base plate dimension : Delta 80 mm
Sound values
> Sound pressure level LpA :82.8 dB(A)
> Sound power level LWA :93.8 dB(A)
> Uncertainty KpA, KWA :3 dB(A)
Hand arm vibration values
> Hand arm vibration ah:2.633 m/s2
> Uncertainty K :1.5 m/s2
The sound values have been determined according to noise test code given in
EN 62841-1 and EN 62841-2-4.
The sound intensity level for the operator may exceed 80 dB(A) and ear protection
measures are necessary.
RATING LABEL EXPLANATION
TTB892MLT = Model number
TT = TITAN B = 220-240V ~ 892 = Serial Number MLT = Multi Tool
WARNING! The vibration and noise emissions during actual use of the
power tool can differ from the declared values depending on the ways
in which the tool is used especially what kind of workpiece is
processed; and need to identify safety measures to protect the operator
that are based on an estimation of exposure in the actual conditions of
use (taking account of all parts of the operating cycle such as the times
when the tool is switched off and when it is running idle in addition to
the trigger time).
The declared vibration total values and the declared noise emission values
have been measured in accordance with a standardised test method (according
to in EN 62841-1 and EN 62841-2-4) and may be used to compare one tool with
another tool. The declared vibration emission value and noise emission value
may also be used in a preliminary assessment of exposure.

TTB892MLT
Getting started...
EN
19
Before you start
Unpacking
>
> Remove all packing materials and shipping devices, if applicable.
> Make sure the delivery contents are complete and free of any damage. If you
your dealer. Using an incomplete or damaged product represents a hazard to
people and property.
> Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
You will need
(items not supplied)
Suitable personal protective equipment
(items supplied)
Hex key (5)
Sanding base plate (7)
Plunge saw blade for wood (8)
Segment saw blade (9)
Plunge saw blade for metal (10)
Sanding paper (11) (60# x3, 120# x3,
240# x3)
Scraper (12)
Bolt for compatible accessories (13)
accessories (13a)
Tool holder adaptor(14)
Setup
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!

TTB892MLT
Getting started...
EN
20
Before you start
Setup
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid lost.
Tool attachments
Different tool attachments can be used with this product depending on the material
being worked. Select a suitable tool attachment according to the intended use, by
referring to the following table.
WARNING! Always use tool attachments according to the intended
use!
Observe the technical requirements of this product (see section
Some tool attachments are very sharp and become hot during use!
Handle them carefully! Wear protective gloves when handling tool
attachments in order to avoid injuries like burns and cuts!
WARNING! Ensure the tool attachments are correctly attached.
Incorrect or insecurely fastened tool attachments can come loose
during operation and cause a hazard.
NOTE: Tool attachments are available in various shapes and sizes.
Below is only an overview of the supplied tool attachments. Ask in
store for more choices.
Tool attachment Material Application
Sanding base
plate (7) &
sanding paper
(11)
Bare or painted
wood, plaster,
and other surface,
depending on
grain size (grit) of
sanding paper
Flat sanding and
reaching into
corners and along
edges
