Anova Wainwright RCPWT63 User manual

Assembly Instructions
RCPWT63 Wainwright 6’ Picnic Table and Benches Set
TOOLS NEEDED:
•9/16” Open-end or box-end wrench
•Ratchet with 9/16”socket
•18V (or more) driver with No. 3 Phillips head bit
•Rubber mallet
TABLE COMPONENTS:
(4) Bench Supports (4) Seat Braces (6) Seat Planks (2) Seat Channels (4) Seat End Caps
(2) Table Supports (2) Table End Caps (2) Table Braces
(1) Table Center Plank (6) Table Planks
(1) Table Channel
1
anovafurnishings.com
888.535.5005 tel

Assembly Instructions
RCPWT63 Wainwright 6’ Picnic Table and Benches Set
BENCH ASSEMBLY:
Assembly is a two-person operation.
1. Inspect the shipping contents for damage
and to determine that all of the components
and hardware are present.
2. Locate the two bench supports and place them
the approximate distance of the seat on the
packaging cardboard or other soft surface to
avoid scratching the product.
3. Locate the seat channel and position it
between the two bench supports. Orient the
seat channel with the open side facing
downward. Hold the channel so that the side
mounting holes in the channel match up with
the mounting holes in the bench support.
Place a flat washer on one of the 1.25” hex
head bolts and insert the bolt through the
bench support and the bench channel. Put a
flat washer and hex nut on the end of the bolt
and tighten finger tight. Repeat this step for
both sides of the seat. Leave the hardware
finger tight so adjustments can be made
during assembly.
4. Place the two seat braces on top of the seat
channel. Make sure the center hole in the seat
brace aligns with the mounting hole in the seat
channel.
2

Assembly Instructions
RCPWT63 Wainwright 6’ Picnic Table and Benches Set
BENCH ASSEMBLY:
5. Place three seat planks over the seat
supports and seat braces. NOTE: When
laying out the planks, make sure the surface
with the pre-drilled pilot holes face
downward. Place the seat end cap over each
end of the seat planks.
6. Secure the end caps and planks using a 3”
carriage bolt through the center seat plank
and a 2.5” carriage bolt through the
remaining seat planks. Install a flat washer
and flanged nut to each of the 3” carriage
bolts and install a flat washer, lock washer
and hex nut to each of the 2.5” carriage bolts.
Tighten the hardware finger tight so
adjustments can be made while installing the
Phillips head screws.
7. Using a driver with a No. 3 Phillips head bit,
drive a Phillips head screw through each of
the holes in the seat brace and seat supports
and into the matching pre-drilled holes in the
seat planks.
8. After the Phillips head screws are installed in
the seat planks, tighten the hardware on the
carriage bolts on the ends of the seat planks.
Tighten all of the hardware throughout the
seat. Move the assembled seat to the desired
location.
9. Repeat all of the steps for the second seat.
3

Assembly Instructions
RCPWT63 Wainwright 6’ Picnic Table and Benches Set
TABLE ASSEMBLY:
Assembly is a two-person operation.
1. Inspect the shipping contents for damage
and to determine that all of the components
and hardware are present.
2. Locate the two table supports and place them
the approximate distance of the table on the
packaging cardboard or other soft surface to
avoid scratching the product.
3. Locate the table channel and position it
between the two table supports. Orient the
table channel with the open side facing
downward. Hold the channel so that the side
mounting holes in the channel match up with
the mounting holes in the table support. Place
a flat washer on one of the 1.25” hex head bolts
and insert the bolt through the table support
and the table channel. Put a flat washer and
hex nut on the end of the bolt and tighten
finger tight. Repeat this step for both sides of
the table. Leave the hardware finger tight so
adjustments can be made during assembly.
4. Place the two table braces on top of the table
channel. Make sure the center hole in the
table brace aligns with the mounting hole in
the table channel.
5. Locate the 1.5” x 5.5” center table plank and
place it over the table channel. Place six of the
table planks over the table supports and table
braces. NOTE: When laying out the planks,
make sure the surface of the planks with the
pre-drilled pilot holes faces downward.
6. Place one of the table end caps over each end
of the table planks.
4

Assembly Instructions
RCPWT63 Wainwright 6’ Picnic Table and Benches Set
TABLE ASSEMBLY:
7. Locate the four 3” carriage bolts and insert
them through the two center mounting holes
on each of the table end caps, through the
center plank, and through the table support.
Insert 2.5” carriage bolts through the
remaining holes in the table end caps. Put a
flat washer and a flanged nut on the end of
each of the 3” carriage bolts. Put a flat
washer, lock washer, and hex nut on the end
of each of the 2.5” carriage bolts. Tighten
the hardware finger tight so adjustments can
be made while installing the Phillips head
screws.
NOTE: The 2.5” carriage bolts may need to
be set with the rubber mallet in order to
expose enough threads to install the
washers and hex nuts.
8. Using a driver with a No. 3 Phillips head bit,
drive a Phillips head screw through each of
the holes in the table brace and table
supports and into the matching pre-drilled
holes in the table planks.
5

Assembly Instructions
RCPWT63 Wainwright 6’ Picnic Table and Benches Set
TABLE ASSEMBLY:
9. After the Phillips head screws are installed in
the table planks, tighten the hardware on the
carriage bolts on the ends of the table planks.
Tighten all of the hardware throughout the
seat. Move the assembled table to the desired
location.
NOTE: After two weeks, retighten all of the
hardware.
7/6/2017 Copyright 2017 ANOVA®Made in USA
6
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
