Canvas MODENA LOVESEAT HUC23372 User manual

4
4. RIGHT LEG FRAME X 1
3. LEFT LEG FRAME X 1
5. FRONT BRACE RAIL X 1
6. BACK BRACE RAIL X 1
PARTS LIST
1. BACK x 1
2. BASE x 1
CANVAS LOGO
TM/MC

A
4
6
5
1
2
B
B
4
3
5
5
D
E
Requires 4, 5, 6, A and C
Insert screws (A) through the right leg frame (4) into brace rails (5 and 6).
Secure in place using the hex key (C).
Step 1:
Step 2:
Requires 3, 5, 6, A, and C
Insert screws (A) through the left leg frame (3) into brace rails (5 and 6).
Secure in place using the hex key (C).
Step 3:
Requires 1, 2, B, and C
Insert screw (B) up through the base (2) and into the back (1).
Secure in place by using the hex key (C).
Step 5:
Requires 3, 4, 5, D, E, and F
Place brackets (D) on leg frames (3 and 4) and brace rail (5).
Secure bracket (D) in place using screw (E) and screwdriver (F).
Step 4:
Requires 1, 2, 3, 4, A, and C
Insert screws (A) through leg frames (3 and 4) and into the back (1).
Secure in place using the hex key (C).
Position the back (1) and the base (2)
on the assembled frame as illustrated below.
Step 6:
Finished.
A
1
2
A
4
3
If any parts are missing, do not attempt to assemble the chair.
CAUTION
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
A
3
6
5
Note: do not fully tighten the screws at this stage.
Note: do not fully tighten the screws at this stage.
Note: fully tighten all the screws before use.

This product is covered by a one year manufacturer's limited
warranty. To ensure your complete satisfaction, this warranties
to the original purchaser that this furniture be free of manufacturing
defects. If you have a frame failure within the first year of ownership,
we will repair or replace at our option. We reserve the right to make
a substitution with similar merchandise if the model in question is
no longer in production. This warranty does not cover commercial
use, acts of nature, fire, freezing, or abusive use. In addition, faded
cushions and purchased parts are not covered in this warranty.
Proof of purchase (dated register receipt) is required for warranty
claims. It remains the customers responsibility for freight and packing
charges to and from our service centre.
