TOOL WAREHOUSE WT01Y0209 User manual

METAL TOOL CABINET WITH WOODEN WORKING BENCH
WT01Y0209

1.Please read instructions prior to assembly. 4. Recommend to use 2 people for assembly .
2. Verify that there are no missing parts. 5. Do not tighten any bolts until all bolts have been started.
3. Keep instructions for future reference. 6. For indoor use.
M A X I M U M L O A D C A P A C I T
FOR WOOD TOP (EVENLY DISTRIBUTED)
G E N E R A L I N F O R M AT I O N , T IPS & H E L P F U L H I N T S
1
IMUM LOAD 1,130 lb / 513.5 kg
MAX
A
A
B
C
D
E
A
B
C
F
A
B
C
D
E
F
MAXIMUM LOAD 25 lb / 11.3 kg
MAXIMUM LOAD 25 lb / 11.3 kg
MAXIMUM LOAD 66 lb / 30.0 kg
MAXIMUM LOAD 25 lb / 11.3 kg
MAXIMUM LOAD 25 lb / 11.3 kg
MAXIMUM LOAD 66 lb / 30.0 kg

Parts and Hardware List
Please read completely through the instructions and verify that all parts listed are included
before beginning assembly.
Tools required for assembly: Wrench (not included).
A- Tool Chest (1)
B- Side Handle (2) C- Small Bolt (8) D- Swivel Caster (2) E- Locking Caster (2)
F- Large Bolt (16+1 extra) G- Key (2)
2

Hardware required Sketch QTY
(B)- Side Handle (2)
(C)- (8)
Tools required for assembly: Wrench
Handle Assembly Instructions
Unpack the unit and confirm that you have all the hardware and required parts listed.
2 Stand the unit upright and attach Side Handle (B) to Tool Chest (A) securing with Small Bolts (C) as
shown below figure.
3 Repeat step for the other side handle.
Assemble the unit on a sturdy and level surface. Avoid assembling on carpet. You should place the
:
Note
unit on a protective su rface when assembling to the unit to prevent scratching or damage to any of the
surfaces.
Caster Assembly Instructions
Small Bolt
3

Hardware required Sketch QTY
( )- (2)
(E)- Locking Caster (2)
(F)- Large Bolt (16)
Tools required for assembly:
Wrench
CARE & MAINTENANCE
 Use a soft, clean cloth that will not scratch the surface when dusting.
 Using solvents of any kind on the wood top may damage the finish.
 Liquid spills should be removed immediately. Using a soft clean cloth, blot the spill gently. Avoid rubbing
4Attach Locking Casters (E) a nd Swivel Casters (D) to the bottom of Tool Chest with Large Bolts (F). Securely
tighten all the bolts with Wrench . Make sure the Locking Casters (E) locate at same side of the unit.
Note: Please adjust the bins and liners in the
drawers after finishing the casters.
E
D
Swivel Caster
4
E
D

9
Drawer
14
13
-
Drawer Liner Large
