Topgreener Tgt06-jt User manual

WARNING

Voltage ...............................................................……...................120VAC,60Hz

Tungsten ...................................................................................1500W-120VAC

Electronic ballast/LED.......................................................................5A-120VAC

Resistive.........................................................................................10A-120VAC

Motor......................................................................................................…1/6HP

Time Delay.............................................................. 1, 5, 10, 20, 30, 60 minutes

Humidity..................................................................... 95% RH, non-condensing

Operation Temperature................................................................. 32° F--131° F

The TGT06-JT is a time switch that turns OFF the connected light

or fan when the selected time expires. The light under the ON/OFF button

blinks 15 seconds each time while the switch is OFF. One of the time

button indicators blinks 15 seconds each time to indicate the last used

timer.

While a timer is active, you can press the ON/OFF button to turn OFF,

the connected light or fan without delay.

The light under the ON/OFF button should be blink 15 seconds each time

when the switch is OFF. The indicator light beside one of the time selection

buttons is ON. Press the ON/OFF button.The connected light or fan comes

ON. The connected light or fan should turn OFF in the number of the minutes

indicated by the time selection indicator light.You can turn it OFF sooner

by pressing the ON/OFF button again.

If you decide that you need more or less time than you originally selected,

restart the time switch by pressing the button that matches the amount

of time you think you will need.

Press ON/OFF button. The connected light or fan should turn ON. If not:

•

Check the light bulb and/ or motor switch on the fan mechanism.

•

Turn OFF power to the circuit then check wire connections

•

Check the light bulb and/ or motor switch on the fan mechanism

•

Make certain that the circuit breaker is ON and functioning.Turn

OFF power to the circuit then check wire connections.

•

Press the ON/OFF button. If connected light or fan does not turn OFF,

please turn OFF power to the circuit then check wire connections.

For your safety:Connecting a proper ground to the time switch provides

protection against electrical shock in the event of certain fault conditions.

If a proper ground is not available, consult with a qualified electrician

before continuing installation.

•

Ground wire must be connected for unit to operate. Allow 2 mintues

for warm-up after connected.

•

Only connect the TGT06-JT to a Single Pole Circuit.If the

existing wiring does not match the description for a Single Pole

Circuit .You should consult with a qualified electrician.

Disconnect the power at the circuit breaker or fuse box

1.Remove the existing wall switch.

2.Connect the timer to the wall box as shown.See Figure 1.

Connect the line wire to the LINE terminal of the timer.

Connect the load wire to the LOAD terminal of the timer.

Connect the ground wire to the GROUND terminal of the timer.

Be sure that all the wire unts are light.

3.Tuck thee wires into the wall box and leave room for the timer.

4.Mount the timer to the wall box with the screws provided,And then install

the wall plate.

5.Restore power at the circuit breaker.

• Seven-button Preset Time Switch.

• Time Delay 1, 5, 10, 20, 30, 60 minutes.

• Replace a standard light or fan single pole switch.

• Work with most common lighting types.

• Ideal for closet, pantry, garage, laundry room, outdoor

lighting and spa.

FEATURES

INSTALLATION INSTRUCTIONS

Model: TGT06-JT

TIME SWITCH

Read and understand these instructions before installing. This device is intended for installation

in accordance with the National Electric Code and local regulations. It is recommended that a

qualified electrician performs this installation. Make sure to turn off the circuit breaker or fuse(s)

and make sure power is off before wiring the device.

Use copper wire only.

Turn the power off at the circuit breaker before installing

the receptacle.

6 time selection buttons with

activation indicator lights

ON/OFF Button

with hold on function

SPECIFICATIONS

DESCRIPTION AND OPERATION

INSTALLATION AND WIRING

TROUBLESHOTTING

Manual OFF

Light or fan will not turn ON (the indicator under the

ON/OFF button blinks 15 seconds each time)

Light or fan will not turn ON (the indicator under the

ON/OFF button is OFF)

Light or fan will not turn OFF

To test the time switch

CAUTION

Wire the time switch

Changing the selected time

Manual ON

Turn ON the connected light or fan by pressing the desired time button,

or the ON/OFF button. If you press the ON/OFF button, it activates the

timer that was last used.

-1- -2- -3-

Figure 1

TIMER WALL BOX

Line

Load

Ground

LINE

LOAD

60 Min30 Min

20 Min10 Min

5 Min1 Min

-4- -5- -6-

WARRANTY

This device is warranted to be free of material and workmanship defects for 1 years from the date of purchase. Original receipt or proof of purchase from an authorized retailer must be presented upon warranty claim. ALL claims

must be verified and approved by Top Greener, Inc. Warranties from other Top Greener products may vary. This warranty is nontransferable and does not cover normal wear and tear or any malfunction, failure, or defect resulting

from misuse, abuse, neglect, alteration, modification, or improper installation. To the fullest extent permitted by the applicable state law, Top Greener shall not be liable to the purchaser or end user customer of Top Greener products

for direct, indirect, incidental, or consequential damages even if Top Greener has been advised of the possibility of such damages. Top Greener’ total liability under this or any other warranty, express or implied, is limited to repair,
