Topgreener TGT09 User manual

©2018 Top Greener, Inc. • CA, USA • www.topgreener.com • 0208180129-01
WARRANTY
Voltage......................................................................................... 120VAC, 60Hz
Resistive………......................…...…….…………..........................…15A, 1800W
Tungsten....................................................................................................1200W
Standard Ballast.......................................................................................1200VA
LED..............................................................................................................150W
Motor ……...........………................……..........................……….………......1/2Hp
• Astronomical feature: Automatically adjusts dusk to dawn times
• Total of 7 on, 7 off programmable settings
• Random On/Off operation for security
• Manual override
• Battery backup: Progams will be saved during power outages
• Daylight Savings: Auto adjusts for daylight savings time
• Works with CFL, LED and incandescent bulbs
FEATURES
INSTALLATION INSTRUCTIONS
Model: TGT09
ASTRONOMIC PROGRAMMABLE
HEAVY DUTY DIGITAL PLUG-IN TIMER
MAIN SCREEN BUTTONS AND INDICATORS
SETTING THE CLOCK
M/D
R
1. Indicates the day of the week.
2. CLOCK
3. AM/ PM indicator
4. MODE button. Press the button to switch between Manual, Automatic, and
Random operation mode.
• Automatic Mode: The timer will run the programs that you have scheduled. It will
automatically turn the lights ON or OFF based on all your programs.
• Manual Mode: The timer WILL NOT run the programs that you have scheduled.
You will only be able to operate the lights using the MAN button.
• Random Mode: Randomly turns the lights ON/OFF within 30 minutes before or
after the programmed times.
5. TIMER and MANUAL ON/OFF button. Hold down for 3 seconds to enter timer
or press and release to manually turn the light(s)/ load(s) ON/ OFF.
6. DAYLIGHT SAVINGS TIME indicator.
• DST displayed = ON
• DST not displayed = OFF
7. Dusk to Dawn Button. Press once to set dusk time, 2 times to set Dawn time.
8. Timer indicator
9. HOME button. Does not have function on home screen.
10. AUTO/ MANUAL/ RANDOM indicator. Indicates Manual operation mode,
Automatic timer controlled mode, and Random mode
11. PROGRAMMING button. Press to scroll through program On/ Off schedules.
12. RESET button: Push to reset all settings to Factory Default. Press and
immediately release.
13. SET button. Press:
1 time to set the clock
2 times to set the year
3 times to set the month
4 times to set the day
5 times to select the region
6 times to turn Daylight Savings (DST) On/Off
14. Indicates dusk and dawn selections.
15. Indicates the status of connected light(s) or load(s): ON/ OFF.
1. Press and release the button once.
2. Press the or buttton to change the time. Make sure the am/pm
indicator displays the correct “morning/ afternoon” indicator.
3. Press to exit and return to home screen.
This device is warranted to be free of material and workmanship defects for 1 year from the date of purchase. Original receipt or proof of purchase from an authorized retailer must be presented upon warranty claim.
ALL claims must be verified and approved by Top Greener, Inc. Warranties from other Top Greener products may vary. This warranty is nontransferable and does not cover normal wear and tear or any malfunction,
failure, or defect resulting from misuse, abuse, neglect, alteration, modification, or improper installation. To the fullest extent permitted by the applicable state law, Top Greener shall not be liable to the purchaser or
end user customer of Top Greener products for direct, indirect, incidental, or consequential damages even if Top Greener has been advised of the possibility of such damages. Top Greener’ total liability under this
or any other warranty, express or implied, is limited to repair, replacement or refund. Repair, replacement or refund are the sole and exclusive remedies for breach of warranty or any other legal theory.
RPRG HOME
MAN
P
ON
WE
AUTOMANURND DST
M/D
1. 2. 3.
4.
5.
7.
9.
11.
12.
13.
15.
6.
10.
DOWN
UP
SET
DOWN
UP
SET
14.
PRG
8.
MAN
MAN
SET
DOWN
UP
SETTING THE DATE
1. Press and release the button twice.
2. Press the or butttons to select the year.
3. Press and release the button again to view the month and use the
or buttons to change the month.
4. Press and release the button again to view the day and use the
or buttons to change the day.
3. Press to exit and return to home screen.
SET
DOWN
UP
SET
DOWN
UP
SET
DOWN
UP
HOME
HOME
P
ON
WE
AUTOMANURND DST

ON
MO TU WE TH FR SA SU
OFF
FR
A
COUNTDOWN
INDICATOR
ON
ADJUSTING THE DUSK/DAWN TIME
PROGRAMMING ON/OFF TIMES
COUNTDOWN TIMER
SETTING THE REGION
1. Press and release the button 5 times.
2. Press the or butttons to change the region.
Choices are: NOR = North United States
CENT = Central United States
SOU = South United States
MEX = Mexico
PRI = Puerto Rico
HAW = Hawaii
3. Press to exit and return to home screen.
SET
DOWN
UP
HOME
SETTING THE DAYLIGHT SAVINGS TIME (DST)
1. Press and release the button 6 times.
2. Press the or buttton to toggle the DST on/off.
3. Press to exit and return to home screen.
SET
DOWN
UP
HOME
1. Press and release the button once to adjust the Dusk time.
2. Press the or buttton to adjust the time.
3. Press and release the button again to adjust the Dawn time.
4. Press the or buttton to adjust the time.
5. Press to exit and return to home screen.
RPRG HOME
MAN
P
ON
WE
AUTOMANURND DST
M/D
DOWN
UP
SET
DOWN
UP
DOWN
UP
HOME
1. Press the button to program times into the schedule. The display will show "ON
PG 1" as illustrated.
2. Press to scroll through the remaining On/Off programs until you reach an
available program. There are 7 On/Off programs total. Press when you are on the
program number you want to change.
3. Use the or buttons to set the time, taking note of the AM/PM on the display.
• To use the astronomic feature, press the button to select the preset
Dusk or Dawn times.
4. Once you have the desired time, press again to set the day
5. Press the button to program times into the schedule. The display will show "OFF
PG 1". Then repeat steps 3 and 4 to program the desired time and day.
6. Press to exit and return to home screen.
PRG
PRG
SET
DOWN
UP
SET
PRG
HOME
1. Press and hold the button for 3 seconds to enter countdown timer mode.
2. Press the or buttton to adjust the run time.
3. Wait 8 seconds and the countdown will start.
MAN
DOWN
UP
OTHER PROGRAMMING
REVIEWING PROGRAMS
• Press the button to scroll through all On/Off programs.
DELETING PROGRAMS
• Press the button to scroll to the program to be deleted and press
button to delete. The screen will show the program has been deleted.
SETTING AUTO, MANUAL OR RANDOM MODE
Press button to scroll through the available modes:
• AUTO – (Automatic) Timer is in Automatic mode and will operate by
the programmed times
• MANU – (Manual) This overrides the programmed times an the lights
can only be turned On and Off by pressing the ON/OFF button
• RND – (Random) The timer will randomly turn ON/OFF times within 30
minutes of the programmed times
RESET DEVICE TO FACTORY DEFAULTS
• Press and release the button
PRG
PRG
M/D
M/D
R
