FormNo.3434-151RevA
WeatherProtectionKit
Groundsmaster®4300orReelmaster®5010SeriesTractionUnit
withSecurityCage
ModelNo.03626
InstallationInstructions
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
Clasp4
Claspmount8
Screw8
2Nut8
Installtheclasps.
Leftdoorcover1
3Rightdoorcover1Installthelargecovers.
Rightcover1
Leftcover1
Lowerleftcover1
Lowerrightcover1
4
Rearcagecover1
Installthesmallcovers.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
PreparingtheMachine
NoPartsRequired
Procedure
Performthefollowingproceduretopreparethemower
forattachingtheblowerandnishingkit.
1.Parkthemachineonalevelsurface,disengage
thePTO,andengagetheparkingbrake.
2.Shutoffthemachine,removethekey,andwait
forallmovementtostopbeforeleavingthe
operatingposition.
3.Cleanthesurfacesofthecagewherethehoop
andhookclosurewilladheredtowithalcohol
wipes.
©2019—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3434-151*A

2
InstallingtheClasps
Partsneededforthisprocedure:
4Clasp
8Claspmount
8Screw
8Nut
Procedure
1.Measurethelocationtoinstalltheclaspson
eachdoorasshowninFigure1.
g295828
Figure1
1.Installedclasp3.27.13cm(10-21/32
inches)
2.Installtheclaspsonthe
rstrowof“X”onthedoor.
4.58.72cm(23-1/8inches)
2.InstalltheclaspsasshowninFigure2.
g295829
Figure2
1.Bolt3.Claspmount
2.Clasp4.Nut
3
InstallingtheLargeCovers
Partsneededforthisprocedure:
1Leftdoorcover
1Rightdoorcover
Procedure
Note:Thisprocedureisforeachdoorandrearopening.
2

1.Removehalfofthehoopandhookclosurestraps,withtheadhesive,fromeachdoorcover(Figure3).
2.Pealthelmoffoftheadhesiveandplaceitinthepositionforeachdoor(Figure3).
3.Installthecoversforthedoorsbyaligningtheholeswiththeclaspsandpressthehoopandhookclosure
strapstogetheraroundeachdoor.
g295830
Figure3
1.Rightdoorcover3.Leftdoorcover
2.Removethehoopandhookstrapsfromthecovers.
3

4
InstallingtheSmallCovers
Partsneededforthisprocedure:
1Rightcover
1Leftcover
1Lowerleftcover
1Lowerrightcover
1Rearcagecover
Procedure
Note:Forthesmallcovers,donotseparatethehoopandhookclosurestraps.Usethewholecoverfor
positioning.
1.Positionandensurethelocationofthecoverbeforepeelingoffthelmfortheadhesive(Figure4).
2.Peelthelmoffoftheadhesiveandplacethecoverinposition(Figure4).
3.Repeatthisforallofthesmallcovers.
g295831
Figure4
1.Rightcover4.Lowerleftcover
2.Rearcagecover5.Lowerrightcover
3.Leftcover
