Toro REELMASTER 5010 Series User manual

FormNo.3360-637RevA
CombandScraperKit
ForReelmaster®5010SeriesCuttingUnit
ModelNo.110–1735
InstallationInstructions
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
Combbracket1
Combscraper1
Combplate1
Comb1
Carriagebolt(1/4x1inch)4
Locknut(1/4inch)4
1
Flatwashers(ifrequired)8
Installingthecombandscraperkit.
InstallationInstructions1
2PartsCatalog1
Readthedocumentationandstoreitin
asafelocation.
1
InstallingtheComband
ScraperKit
Partsneededforthisprocedure:
1Combbracket
1Combscraper
1Combplate
1Comb
4Carriagebolt(1/4x1inch)
4Locknut(1/4inch)
8Flatwashers(ifrequired)
Procedure
1.Placethemoweronalevelsurface.
2.Removetheboltandangenutsecuringeachendof
frontrollertorollerbrackets.Discardtheboltsand
angenuts.
3.Threadaangenutontoeachboltasshownin
Figure1.
Note:Thecomb/scraperassemblyisloosely
assembledatthefactory.Donottightenthelocknuts
atthistime.
4.Mounteachendofthecombbrackettothetop
ofeachrollerbracketwithaangenutandboltas
showninFigure1.
Note:Ifthescraperisnotrequired,removeitfrom
theassembly.Whenreassemblingthecomponents,
insert2washersontoeachboltsotheyactasspacers
betweenthecombbracketandcombplate(Figure1).
Thewashersareshippedloose.
5.Makesuretherollerandcombassemblyaresecure
andcenteredintherollerbrackets,thentightenthe
angenutsonthebolts.
6.Usingagaugebarandruler,setthecomb
aggressivenesstomeetyourturfconditions.Secure
thelocknuts.
•Recommendedheightofcutrangeis0.375inch
to0.75inch.
•Lessaggressivesetting=HeightofCutSetting
•Moreaggressivesetting=1/8inchBelowHeight
ofCutSetting
Note:Itmayrequireafewweeksofoperationto
removeexcessgraininturf.
©2008—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved

9
10
8
7
6
5
4
3
2
1
G009081
Figure1
1.Locknut(1/4inch)4.Flangenut7.Combplate10.Carriagebolt(1/4x1inch)
2.Flatwashers(ifrequired)5.Bolt8.Comb
3.Combbracket6.Combscraper9.Comb&scraperassembly
2
Reading/Storingthe
Documentation
Partsneededforthisprocedure:
1InstallationInstructions
1PartsCatalog
Procedure
1.Readthedocumentation.
2.Storethedocumentationinasafeplace.
