Toro TransPro 80 User manual

FormNo.3446-717RevA
TransportFrame
TransPro80Tow-BehindTrailer
ModelNo.04238—SerialNo.402900001andUp
InstallationInstructions
Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal98-8687
98-8687
1.Thetrailertiresshouldbeinatedto0.35bar(5psi);read
theOperator’sManual.
decal133-8061
133-8061
©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3446-717*

Installation
TheTranspro80machineisintendedforusewith
Greensmaster800,1000,1010,1600,1610,2000,
and2600machines,aswellasFlex18,21,1800,
1820,2100,2120machines,andeFlex1800,1820,
2100,2120WalkGreensmastermachines.
MountingtheTongue
Assembly
1.Insertthetongueassemblyintotheframe
assemblywhilealigningtherearmountingholes
(Figure1).
2.Securethetongueassemblyintotheframe
assemblywithaclevispin,2washersand2
cotterpins(Figure1).
g215365
Figure1
1.Tongueassembly4.Cotterpin
2.Frameassembly5.Washer
3.Clevispin
MountingtheAxleand
Ramp(Model04245)orRail
(Models04244and04247)
Assemblies
1.RefertoFigure2todeterminewhichmounting
holesthatyoushouldusetotthewidthofyour
greensmower.
g014662
Figure2
1.Greensmaster1600,
2600,1000withgroomer,
and2000machineswith
groomer
3.Greensmaster1000,Flex
21,2000,Flex2100,2120
andeFlex2100,and2120
machines
2.Greensmaster800,Flex
18,Flex1800,1820,and
eFlex1800,and1820
machines
Important:IfyourGreensmastermachine
hasagroomerattached,itwillbemounted
differentlythanabove;refertothefollowing
list:
•Greensmaster1000/2000or2100with
groomer:Theleftsideshouldbesetto
position#3andtherightsideshouldbeset
to#1.
•Greensmaster1800/eFlex1800with
groomer:Theleftsideshouldbesetto
position#2andtherightsideshouldbeset
to#3.
2.Mounttheaxleassemblyandarampassembly
(Figure3)orrailassembly(Figure4)toeach
endoftheframewith2bolts(3/8x3inches),
4washers,and2nuts.
2

g215364
Figure3
1.Axleassembly4.Washer
2.Rightrampassembly5.Nut
3.Bolt(3/8x3inches)
g215363
Figure4
1.Axleassembly4.Washer
2.Rightrailassembly5.Nut
3.Bolt(3/8x3inches)
3

MountingtheWheel
Assemblies
1.Mountawheelassemblytoeachaxlehubwith
4lugnuts(Figure5).Tightenthenutsto80ft-lb
(108N∙m).
2.Adjustthetirepressureto5psi(34kPa).
g014665
Figure5
1.Axle2.Wheelassembly
Important:Highertirepressuremay
damagethemachine.
Mounting/Adjustingthe
HitchStraps
Thehitchstrapsareshippedmountedinthestandard
position(Figure6).
Important:Thetrailertonguemustbeparallelto
thegroundwhenitisalignedwiththetowvehicle
hitch.
g014666
Figure6
Standardposition
Using1ofthecongurationsshowninFigure7or
Figure8,adjustandsecurethehitchstrapstothe
trailertongue.
g014667
Figure7
Lowhitchposition
4

g014668
Figure8
Highhitchposition
MountingtheGreensmower
WheelAssemblies
Models04244and04247only
Note:OnGreensmaster1000,1010,and2000
machinesequippedwithagroomer,removethewheel
shaftonthegroomerendandpurchaseandinstalla
newwheelshaft(PartNo.106-5385).Also,mountthe
railassemblyonthegroomerendtotheGreensmaster
1600and1610holelocations(Figure2).
Note:OnGreensmaster1800,1820,2100,and2120
machinesequippedwithagroomer,removethewheel
shaftonthegroomerendandpurchaseandinstalla
newwheelshaft(PartNo.136-7287).
1.Removetheexistingstandardtransportwheels
fromthewheelshaftsonthegreensmower(if
equipped).
2.OnGreensmasterFlex18or21machinesonly,
proceedasfollows:
A.Removetherightsidedrumcoverfromthe
machine(Figure9).
g017122
Figure9
1.Rightsidedrumdrive
cover
3.Rubbergrommet
2.Feltseal
B.Removeanddiscardtherubbergrommet
fromtheaxleholeinthedrumcover(Figure
9).
C.Afxthefeltsealtotheinsideofthecover
positioningitaroundtheaxlehole(Figure
9).
D.Installthecovertothemachine.
3.Insertawheelontoeachshaftandsecurewitha
wheelclip(Figure10).
Note:Flex1800,1820,and2100,2120series
machinesrequireadifferentwheeloffsetthan
allotherT orogreensmowers.Readandfollow
themountinginstructionsmoldedintothesides
ofthewheels.
g014669
Figure10
Leftsideshown
1.Wheelshaft3.Wheelclip
2.Wheel
5

LoadingtheTrailer
1.Whilemaintainingcontrolofthetrailerbedand
holdingontothehandle,pressdownonthelatch
assemblyandthelifthandle(Figure11).Lower
thetrailerbedtotheground.
g014670
Figure11
1.Latchassembly2.Handle
2.Onatramps,pivotthewheelrodsupward
(Figure13)andonrailramps,rotatethewheel
rodsparallel(open)totheramp(Figure14).
3.Removethebasketfromthegreensmower,
disengagethereeldrive,andmovethethrottle
totheslowestposition.Slowlydrivethegreens
mowerontothetraileruntilyoucontactthe
wheelstops(Figure12).
4.Iftherailwheelsarenotcenteredontherails,
loosenthefastenerssecuringtherailstothe
trailerandadjusttherailpositionsothattherail
wheelsarecentered,thentightenthefasteners.
5.Shutofftheengineandengagetheparking
brake.
6.Engagethewheelrodsasfollows:
•Onatramps,rotatethewheelrods
downwardoverthegreensmowertransport
wheels(Figure13).
•Onrailramps,liftthewheelrodandrotateit
behindthegreensmowertransportwheels
(Figure14).
g214902
Figure12
GreensmowerloadedonaTransPro80withRailKit
g014671
Figure13
1.Wheelrod(showninpivoteddownposition)
6

g014672
Figure14
1.Wheelrod(shownintheclosedposition)
7.Pushdownonthehandleuntilthetrailer
assemblylocksintothelatchassembly(Figure
11).
8.ForFlexGreensmastermachines,securethe
frontofthemachinebyhookingthebungee
strapstothebaskethoop.
Forxed-headGreensmastermachines,secure
thefrontofthemachinebyhookingthebungee
strapstothebaskethorns.
9.Storethebasketinthetowvehicle.
Operation
OperatingTips
•TheTransPro80trailerisintendedforusewith
Greensmaster800,1000,1600,2000,2600
machines,Flex18,21,1800,1820,2100,2120
machines,andeFlex1800,1820,2100,2120walk
Greensmastermachines.Thetowingofother
productsmaydamagetheaxlesandtransmissions
thatcontinuetorotatewhentowed.
•Useonlyavehiclewiththepropertowrating.
TheTransPro80trailerand1greensmowerweigh
approximately400lb(182kg).Ensurethatthe
towvehiclehasadequatebrakingandhandling
capacitybycheckingtherecommendationsofthe
vehiclemanufacturer.
•Ensurethatthetrailerisproperlyconnectedto
thetowvehiclebeforeloadingorunloadingthe
greensmowertopreventsuddenunintended
tonguemovementoripup.Usearetention
deviceonthehitchpintosecuretheconnection.
Important:Thetrailertongueshouldbe
paralleltothegroundwhenyoualignitwith
thetow-vehiclehitch.
•Duringtransport,usethebungeestraptosecure
thegreensmowertothetrailer(Figure15).You
canmovethebungeestraptodifferentmounting
holestoaccommodatedifferentmowers.
Note:Securethebungeestraptothegrass
baskethornsortothegrassbasketloopon
eFlex/Flex1800/2100machines.
g014673
Figure15
1.Bungeestrap
•TheTransPro80traileraddsextratowingweight
tothevehicle.Drivethevehiclesafely.
–Donotdriveonhighwayorpublicroads.
–Alwaysslowthetowvehiclewhenapproaching
andwhilemakingaturn.
–Alwaysslowthetowvehiclewhendrivingin
unfamiliarareasoroverroughterrain.
–Alwaysslowthetowvehiclegraduallywhen
changingdirectionoftravelorpreparingto
stop.
–Whenturningordrivingonslopes,alwaysslow
thetowvehicle,thenturntopreventlossof
controlandpossibleupset.
–Donotmakesuddenorsharpturns.Donot
suddenlychangedirectionoftravelonan
incline,ramp,grade,slopeorsimilarsurface.
–Themaximumtowingspeedis15mph(24
kmh).Alwaysadjustthetowvehiclespeedto
allowforexistinggroundconditions,suchas
wetslicksurfaces,loosesandorgraveland/or
lowvisibilityconditions,suchasdimorbright
lighting,fog,mistorrain.
–Beespeciallycarefulwhendrivingaheavily
loadedvehicledownaninclineorslope.Drive
thevehicleupanddownthefaceoftheslopes,
inclinesorgradeswheneverpossible.Donot
driveacrossthefaceifatallpossible.Thereis
ariskofupsettingthevehicle,whichcanresult
inseriousinjuryordeath.
7

•Beforebackingup,looktotherearandensurethat
nooneisbehindyou.Backupslowlyandwatch
thetrailermovementclosely.
•Useextremecautionandslowspeedwhen
backingupthetrailerandtowvehicle.
•Watchoutfortrafcwhennearorcrossingroads.
Alwaysyieldtherightofwaytopedestriansand
othervehicles
•Ifthetrailerbeginstovibrateabnormally,stop
immediately.Shutoffthetowvehicleengine.
Repairalldamagebeforetowing.
•Beforeservicingormakinganyadjustmentstothe
trailer,dothefollowing:
–Stopthetowvehicleandengagetheparking
brake.
–Shutoffthetowvehicleengineandremove
thekey.
•WhiletheTransPro80trailerisdisconnectedfrom
towvehicle:
–Storethetraileronlevelground.
–Chockthewheelstopreventthetrailerfrom
moving.
•Keepallnuts,boltsandotherfastenerstightened
securely.Replaceanypartsremovedduring
servicingoradjustments.
•T oensureoptimumperformanceandcontinued
safetyofthisproduct,alwaysusegenuineToro
replacementparts.Replacementpartsand
accessoriesmadebyothermanufacturersmay
affecttheproduct’soperation,performanceor
durability.Suchusecouldalsovoidthewarranty.
8

Maintenance
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst10hours•Checkthetorqueofthewheellugnuts.
Yearly•Servicethewheelhubandinspectfordamage.
•Lubricatethewheelhubassembly.
ServicingtheWheelHub
ServiceInterval:Yearly
1.Raisethetraileronjackstands.
2.Removethe4lugnutssecuringthewheeltothe
wheelhubandremovethewheel.
3.Removethedustcapfromthewheelhub(Figure
16).
4.Removethecotterpinandretainerlocknut
(Figure16).
5.Removethehubnut,spindlewasherandhub
assemblyfromtheaxle(Figure16).
6.Inspectallofthehubassemblyparts,including
thebearings,bearingcups,andoilseal.
Replaceanydamagedparts.
g265352
Figure16
1.Dustcap6.Bearingcup
2.Retainerlocknut7.Hubassembly
3.Hubnut8.Oilseal
4.Spindlewasher9.Cotterpin
5.Rollerbearing10.Axleassembly
LubricatingtheWheelHub
Assembly
ServiceInterval:Yearly
1.Wipeawaytheexistinggreasefromthe
bearings,bearingcups,andhubassemblywith
aclean,dryrag.
2.Packthebearingcupsandinteriorsurfacesof
thehubassemblywithhigh-temperaturegrease
sothatthebearingsrollerfacesarecompletely
coated.
3.Installthebearingcupsandbearingstothehub
assemblyasshowninFigure16.
4.Cleanupanyexcessgreasefromtheoutsideof
thehubassembly.
InstallingtheWheelHubAssembly
1.Installtheoilseal,hubassembly,andspindle
washerasshowninFigure16.
2.Tightenthehubnutwhileturningthewheelhub
assemblytoseatthebearingsandremoveall
endplay.
3.Whileturningthewheelhubassembly,torque
thehubnutto8.5to20.3N⋅m(75to180in-lb).
4.Loosenthehubnutuntilitdoesnotcontactthe
washerandthehubhasendplay.
5.Tightenthehubnutto1.7to2.3N⋅m(15to20
in-lb)whilerotatingthehub.
6.Placetheretainerlocknutoverthehubnutso
thatthecotterpinholeisalignedwithasloton
theretainerlocknut.
7.Installanewcotterpinthroughtheslotinthe
retainerlocknutandtheaxleandbendbothlegs
tosecurethepin.
8.Securethehubcap.
9

CheckingtheTorqueofthe
WheelLugNuts
ServiceInterval:Aftertherst10hours
Checkthetorqueofthewheellugnutsattheservice
intervalandeachtimeyouinstallthewheels.
WARNING
Failuretomaintainpropertorquecouldresult
infailureorlossofwheelandcouldresultin
personalinjury.
Torquethewheellugnutsto108N⋅ ⋅
⋅m(80
ft-lb).
10
