SERVICE MANUAL
FILE No. A10-023
AIR CONDITIONER (SPLIT TYPE)
Model name:
RAS-M10PKVP-E
RAS-M13PKVP-E
RAS-M16PKVP-E
RAS-M18PKVP-E
RAS-4M27UAV-E
PRINTED IN JAPAN, Apr, 2011, TDOC
+00COV.fm Page 1 Wednesday, April 20, 2011 8:27 AM

–2–
CONTENTS
1. Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3. Refrigerant R410A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
4. Construction Views. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
5. Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
6. Specifications of Electrical Parts . . . . . . . . . . . . . . . . . . . . .44
7. Refrigerant Cycle Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . .45
8. Control Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
9. Operation Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
10. Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
11. How to Diagnose the Trouble . . . . . . . . . . . . . . . . . . . . . . . .99
12. How to Replace the Main Parts . . . . . . . . . . . . . . . . . . . . . .127
13. Exploded Views and Parts List . . . . . . . . . . . . . . . . . . . . . .147
+00A10-023_01EN.book Page 2 Wednesday, April 6, 2011 2:43 PM

–3–
1. Safety Precautions
The important contents concerned to the safety are described on the product itself and on this Service Manual.
Please read this Service Manual after understanding the described items thoroughly in the following contents
(Indications / Illustrated marks), and keep them.
[Explanation of indications]
∗Property damage: Enlarged damage concerned to property, furniture, and domestic animal / pet
[Explanation of illustrated marks]
For general public use
Power supply cord of outdoor unit shall be more than 2.5 mm² (H07RN-F or 60245IEC66) polychloroprene
sheathed flexible cord.
• Read this “SAFETY PRECAUTIONS” carefully before servicing.
• The precautions described below include the important items regarding safety. Observe them without fail.
• After the servicing work, perform a trial operation to check for any problem.
• Turn off the main power supply switch (or breaker) before the unit maintenance.
CAU TI ON
New Refrigerant Air Conditioner Installation
• THIS AIR CONDITIONER ADOPTS THE NEW HFC REFRIGERANT (R410A) WHICH DOES NOT DESTROY
OZONE LAYER.
R410A refrigerant is apt to be affected by impurities such as water, oxidizing membrane, and oils because the
working pressure of R410A refrigerant is approx. 1.6 times of refrigerant R22. Accompanied with the adoption
of the new refrigerant, the refrigeration machine oil has also been changed. Therefore, during installation work,
be sure that water, dust, former refrigerant, or refrigeration machine oil does not enter into the new type
refrigerant R410A air conditioner circuit.
To prevent mixing of refrigerant or refrigerating machine oil, the sizes of connecting sections of charging port on
main unit and installation tools are different from those used for the conventional refrigerant units.
Accordingly, special tools are required for the new refrigerant (R410A) units. For connecting pipes, use new and
clean piping materials with high pressure fittings made for R410A only, so that water and / or dust does not
enter. Moreover, do not use the existing piping because there are some problems with pressure fittings and
possible impurities in existing piping.
Indication Explanation
DANGER Indicates contents assumed that an imminent danger causing a death or serious injury of
the repair engineers and the third parties when an incorrect work has been executed.
WARNING Indicates possibilities assumed that a danger causing a death or serious injury of the
repair engineers, the third parties, and the users due to troubles of the product after work
when an incorrect work has been executed.
CAUTION Indicates contents assumed that an injury or property damage (∗) may be caused on the
repair engineers, the third parties, and the users due to troubles of the product after work
when an incorrect work has been executed.
Mark Explanation
Indicates prohibited items (Forbidden items to do)
The sentences near an illustrated mark describe the concrete prohibited contents.
Indicates mandatory items (Compulsory items to do)
The sentences near an illustrated mark describe the concrete mandatory contents.
Indicates cautions (Including danger / warning)
The sentences or illustration near or in an illustrated mark describe the concrete cautious contents.
+00A10-023_01EN.book Page 3 Wednesday, April 6, 2011 2:43 PM

–4–
CAU TI ON
TO DISCONNECT THE APPLIANCE FROM THE MAIN POWER SUPPLY
A switch or circuit breaker that can disconnect all poles must be included in the fixed wiring.
Be sure to use an approved circuit breaker or switch.
DANGER
• The manufacturer shall not assume any liability for the damage caused by not observing the description
of this manual.
• Ask an authorized dealer or qualified installation professional to install / maintain the air conditioner.
INAPPROPRIATE SERVICING MAY RESULT IN WATER LEAKAGE, ELECTRIC SHOCK OR FIRE.
• TURN OFF MAIN POWER SUPPLY BEFORE ATTEMPTING ANY ELECTRICAL WORK.
MAKE SURE ALL POWER SWITCHES ARE OFF. FAILURE TO DO SO MAY CAUSE ELECTRIC SHOCK.
DANGER: HIGH VOLTAGE
The high voltage circuit is incorporated. Be careful to do the check service, as the electric shock may be
caused in case of touching parts on the P.C. board by hand.
• CORRECTLY CONNECT THE CONNECTING CABLE. IF THE CONNECTING CABLE IS INCORRECTLY
CONNECTED, ELECTRICAL CONTROL MAY BE DAMAGED.
• CHECK THAT THE EARTH WIRE IS NOT BROKEN OR DISCONNECTED BEFORE SERVICE AND
INSTALLATION. FAILURE TO DO SO MAY CAUSE ELECTRIC SHOCK.
• DO NOT INSTALL NEAR CONCENTRATIONS OF COMBUSTIBLE GAS OR GAS VAPORS. FAILURE TO
FOLLOW THIS INSTRUCTION CAN RESULT IN FIRE OR EXPLOSION.
• TO PREVENT THE INDOOR UNIT FROM OVERHEATING AND CAUSING A FIRE HAZARD, PLACE THE
UNIT WELL AWAY (MORE THAN 2 M) FROM HEAT SOURCES SUCH AS RADIATORS, HEAT RESISTORS,
FURNACE, STOVES, ETC.
• WHEN MOVING THE AIR-CONDITIONER FOR INSTALLATION IN ANOTHER PLACE, BE VERY CAREFUL
NOT TO ALLOW THE SPECIFIED REFRIGERANT (R410A) TO BECOME MIXED WITH ANY OTHER
GASEOUS BODY INTO THE REFRIGERATION CIRCUIT. IF AIR OR ANY OTHER GAS IS MIXED IN THE
REFRIGERANT, THE GAS PRESSURE IN THE REFRIGERATION CIRCUIT WILL BECOME ABNORMALLY
HIGH AND IT MAY RESULT IN THE PIPE BURSTING AND POSSIBLE PERSONNEL INJURIES.
• IN THE EVENT THAT THE REFRIGERANT GAS LEAKS OUT OF THE PIPE DURING THE SERVICE WORK
ANDTHEINSTALLATION WORK,IMMEDIATELY LET FRESHAIR INTOTHEROOM. IF THEREFRIGERANT
GAS IS HEATED, SUCH AS BY FIRE, GENERATION OF POISONOUS GAS MAY RESULT.
WARNING
• Do not use any refrigerant different from the one specified for complement or replacement.
Otherwise, abnormally high pressure may be generated in the refrigeration cycle, which may result in a failure
or explosion of the product or an injury to your body.
• Never modify this unit by removing any of the safety guards or bypass any of the safety interlock switches.
• Do not install in a place which cannot bear the weight of the unit.
Personal injury and property damage can result if the unit falls.
• After the installation work, confirm that refrigerant gas does not leak.
If refrigerant gas leaks into the room and flows near a fire source such as a cooking range, noxious gas may
generate.
• The electrical work must be performed by a qualified electrician in accordance with the Installation
Manual. Make sure the air conditioner uses an exclusive circuit.
An insufficient circuit capacity or inappropriate installation may cause fire.
• When wiring, use the specified cables and connect the terminals securely to prevent external forces
applied to the cable from affecting the terminals.
• Be sure to provide grounding.
Do not connect ground wires to gas pipes, water pipes, lightning rods or ground wires for telephone cables.
• Conform to the regulations of the local electric company when wiring the power supply.
Inappropriate grounding may cause electric shock.
+00A10-023_01EN.book Page 4 Wednesday, April 6, 2011 2:43 PM

–5–
CAU TI ON
• Exposure of unit to water or other moisture before installation may result in an electrical short.
Do not store in a wet basement or expose to rain or water.
• Do not install in a place that can increase the vibration of the unit. Do not install in a place that can amplify the
noise level of the unit or where noise or discharged air might disturb neighbors.
• To avoid personal injury, be careful when handling parts with sharp edges.
• Perform the specified installation work to guard against an earthquake.
If the air conditioner is not installed appropriately, accidents may occur due to the falling unit.
2. Specifications
The indoor and outdoor units that can be used in combination are shown in the tables below.
Table of models that can be connected
Table of models that can be used in combination
NOTES
A 1-room connection is not an option for the indoor units (you cannot connect only one indoor unit).
Be sure to connect indoor units in two or more.
The contents noted in this service manual limit the indoor units to the RAS-M10PKVP-E, RAS-M13PKVP-E,
RAS-M16PKVP-E, RAS-M18PKVP-E.
For other indoor units that can also be used in combination, see the Service Manual of each indoor unit.
Type Outdoor unit Indoor unit
Heat pump RAS-4M27UAV-E
RAS-M10PKVP-E RAS-M13PKVP-E RAS-M16PKVP-E RAS-M18PKVP-E
RAS-M10PKVP-ND RAS-M13PKVP-ND RAS-M16PKVP-ND RAS-M18PKVP-ND
RAS-B10UFV-E RAS-B13UFV-E RAS-B18UFV-E
RAS-M07SKV-E RAS-M10SKV-E RAS-M13SKV-E RAS-M16SKV-E
RAS-M22SKV-E RAS-M24SKV-E
RAS-M10GDV-E RAS-M13GDV-E RAS-M16GDV-E
RAS-M10SMUV-E RAS-M13SMUV-E RAS-M16SMUV-E
Type Outdoor unit Combinations of indoor unit models that can be connected
Heat pump RAS-4M27UAV-E Refer to page 7 to 36
Indoor unit File No.
RAS-M07SKV-E
RAS-M10SKV-E
RAS-M13SKV-E RAS-M16SKV-E SVM-07034
RAS-M22SKV-E
RAS-M24SKV-E SVM-10070
RAS-M10GDV-E
RAS-M13GDV-E
RAS-M16GDV-E A05-010
RAS-B10UFV-E
RAS-B13UFV-E
RAS-B18UFV-E SVM-10044
RAS-M10SMUV-E
RAS-M13SMUV-E
RAS-M16SMUV-E A06-015
+00A10-023_01EN.book Page 5 Wednesday, April 6, 2011 2:43 PM

–6–
2-1. Specifications
RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E / RAS-4M27UAV-E
• For performance when each indoor unit is combined with other unit, refer to the separate table.
• The specifications may be subject to change without notice for purpose of improvement.
Unit model Indoor RAS- M10PKVP-E, M13PKVP-E, M16PKVP-E, M18PKVP-E
Outdoor RAS- 4M27UAV-E
Cooling Capacity (kW) 8.0
Cooling Capacity range (kW) 9.3
Heating Capacity (kW) 9.0
Heating Capacity range (kW) 11.7
Power supply 220-240 V 1 Ph 50 Hz / 220 V 1 Ph 60 Hz
Electric
characteristics
Indoor
Unit model RAS- M10PKVP-E M13PKVP-E M16PKVP-E M18PKVP-E
Running current (A) 0.21 / 0.20 / 0.19 0.24 / 0.23 / 0.22 0.27 / 0.26 / 0.25 0.30 / 0.29 / 0.28
Power consumption (W) 25 30 35 40
Powerfactor (%) 54 / 54 / 55 57 / 57 / 57 59 / 59 / 58 61 / 60 / 60
Total
Unit model RAS- 4M27UAV-E
Operation mode Cooling Heating
Runningcurrent (A) 10.94 / 10.46 / 10.03 9.22 / 8.82 / 8.45
Power consumption (W) 2286 1927
Power factor (%) 95 95
Starting current (A) 10.94 / 10.46 / 10.03
COP (Cooling / Heating) 3.50 / 4.67
Operating noise
Indoor
(Cooling / Heating)
Unit model RAS- M10PKVP-E M13PKVP-E M16PKVP-E M18PKVP-E
High dB (A) 43 / 43 45 / 45 47 / 47 49 / 49
Medium dB (A) 37 / 35 38 / 36 40 / 38 41 / 41
Low dB (A) 31 / 27 31 / 27 34 / 30 34 / 31
Outdoor
(Cooling / Heating) Unit model RAS- 4M27UAV-E
Full indoor units operating 48 / 49
Indoor unit
Unit model RAS- M10PKVP-E M13PKVP-E M16PKVP-E M18PKVP-E
Dimension High (mm) 295 295 295 295
Width (mm) 790 790 790 790
Depth (mm) 242 242 242 242
Net weight (kg) 12 12 12 12
Fan motor output (W) 30 30 30 30
Air flow rate (Cooling /Heating) (m³/h) 640 / 640 690 / 690 750 / 750 800 / 800
Outdoor unit
Unit model RAS- 4M27UAV-E
Dimension High (mm) 890
Width (mm) 900
Depth (mm) 320
Net weight (kg) 69
Compressor Motor output (W) 2000
Type Twin rotary type with DC-inverter variable speed control
Model DA220A2F-22L
Fan motor output (W) 60
Air flow rate (m³/h) High: 2507, Medium: 2268
Type Flare connection
Piping connection
Indoor unit Unit model RAS- M10PKVP-E M13PKVP-E M16PKVP-E M18PKVP-E
Liquid side Ø6.35 Ø6.35 Ø6.35 Ø6.35
Gas side Ø9.52 Ø9.52 Ø12.7 Ø12.7
Outdoor unit
Unit model RAS- 4M27UAV-E
A unit liquid side / gas side Ø6.35 / Ø12.7
B unit liquid side / gas side Ø6.35 / Ø12.7
C unit liquid side / gas side Ø6.35 / Ø9.52
D unit liquid side / gas side Ø6.35 / Ø9.52
Maximum length (per unit) (m) 25
Maximum length (total) (m) 70
Maximum chargeless length (m) 40
Maximum height difference (m) 15
Name of refrigerant R410A
Weight (kg) 2.40
Wiring connection Power supply interconnection 3 Wires : includes earth, 4 Wires : includes earth
Usable temperature range Indoor (Cooling / Heating) (°C) 21 - 32 / 0 - 28
Outdoor (Cooling / Heating) (°C) 10 - 43 / -15 - 22
Accessory Indoor unit
Unit model RAS- M10PKVP-E M13PKVP-E M16PKVP-E M18PKVP-E
Installation plate 1 1 1 1
Wireless remote controller 1 1 1 1
Batteries 2 2 2 2
Remote controller holder 1 1 1 1
Remote controller holder mounting screw 2 (Ø3.1 × 16L) 2 (Ø3.1 × 16L) 2 (Ø3.1 × 16L) 2 (Ø3.1 × 16L)
Owner's manual 1 1 1 1
Mounting screw 7 (Ø4 × 25L) 7 (Ø4 × 25L) 7 (Ø4 × 25L) 7 (Ø4 × 25L)
Installation manual 1 1 1 1
Outdoor
unit Unit model RAS- 4M27UAV-E
Installation manual 1
+00A10-023_01EN.book Page 6 Wednesday, April 6, 2011 2:43 PM

–7–
2-2. Specifications of Performance When Each Indoor Unit is Combined with Other Unit
Outdoor Unit: RAS-4M27UAV-E
<Cooling / 220 V>
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
220 1 unit 07 - - - 2.0 - - - 2.0 650 3.84 77 3.08 48 63
( 1.4 - 2.5 ) ( 640 - 700 ) ( 3.83 - 3.74 ) ( 76 - 85 )
10 - - - 2.7 - - - 2.7 750 4.43 77 3.60 48 63
( 1.4 - 3.2 ) ( 640 - 950 ) ( 3.83 - 4.64 ) ( 76 - 93 )
13 - - - 3.7 - - - 3.7 1200 6.20 88 3.08 48 63
( 1.4 - 4.4 ) ( 640 - 1520 ) ( 3.68 - 7.20 ) ( 79 - 96 )
16 - - - 4.5 - - - 4.5 1650 7.98 94 2.73 48 63
( 1.4 - 5.0 ) ( 640 - 2000 ) ( 3.68 - 9.28 ) ( 79 - 98 )
18 - - - 5.0 - - - 5.0 1950 9.33 95 2.56 48 63
( 1.4 - 5.2 ) ( 640 - 2100 ) ( 3.68 - 9.74 ) ( 79 - 98 )
22 - - - 6.0 - - - 6.0 2020 9.56 96 2.97 48 63
( 2.4 - 6.8 ) ( 640 - 2500 ) ( 3.68 - 11.60 ) ( 79 - 98 )
24 - - - 7.1 - - - 7.1 2390 11.32 96 2.97 48 63
( 2.4 - 7.2 ) ( 660 - 2960 ) ( 3.80 - 13.73 ) ( 79 - 98 )
2 units 07 07 - - 2.00 2.00 - - 4.0 1520 7.27 95 2.63 48 63
( 2.5 - 5.0 ) ( 640 - 1770 ) ( 3.64 - 8.21 ) ( 80 - 98 )
10 07 - - 2.70 2.00 - - 4.7 1530 7.32 95 3.07 48 63
( 2.5 - 5.7 ) ( 640 - 1910 ) ( 3.64 - 8.86 ) ( 80 - 98 )
13 07 - - 3.70 2.00 - - 5.7 1810 8.66 95 3.15 48 63
( 2.6 - 6.5 ) ( 660 - 2130 ) ( 3.75 - 9.88 ) ( 80 - 98 )
16 07 - - 4.08 1.82 - - 5.9 1810 8.66 95 3.26 48 63
( 2.7 - 6.6 ) ( 660 - 2220 ) ( 3.75 - 10.30 ) ( 80 - 98 )
18 07 - - 4.50 1.80 - - 6.3 2040 9.76 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.81 - 11.13 ) ( 80 - 98 )
22 07 - - 4.73 1.58 - - 6.3 2040 9.76 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.81 - 11.13 ) ( 80 - 98 )
24 07 - - 5.31 1.49 - - 6.8 2320 11.10 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.92 - 11.92 ) ( 80 - 98 )
10 10 - - 2.70 2.70 - - 5.4 1530 7.32 95 3.53 48 63
( 2.5 - 6.3 ) ( 640 - 2040 ) ( 3.64 - 9.46 ) ( 80 - 98 )
13 10 - - 3.41 2.49 - - 5.9 1810 8.66 95 3.26 48 63
( 2.7 - 6.6 ) ( 660 - 2220 ) ( 3.75 - 10.30 ) ( 80 - 98 )
16 10 - - 3.94 2.36 - - 6.3 2040 9.76 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.81 - 11.13 ) ( 80 - 98 )
18 10 - - 4.09 2.21 - - 6.3 2040 9.76 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.81 - 11.13 ) ( 80 - 98 )
22 10 - - 4.69 2.11 - - 6.8 2320 11.10 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.92 - 11.92 ) ( 80 - 98 )
24 10 - - 5.22 1.98 - - 7.2 2550 12.20 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
13 13 - - 3.15 3.15 - - 6.3 2040 9.76 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.81 - 11.13 ) ( 80 - 98 )
16 13 - - 3.73 3.07 - - 6.8 2320 11.10 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.92 - 11.92 ) ( 80 - 98 )
18 13 - - 3.91 2.89 - - 6.8 2320 11.10 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.92 - 11.92 ) ( 80 - 98 )
22 13 - - 4.45 2.75 - - 7.2 2550 12.20 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
24 13 - - 4.73 2.47 - - 7.2 2550 12.20 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
16 16 - - 3.60 3.60 - - 7.2 2550 12.20 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
18 16 - - 3.79 3.41 - - 7.2 2550 12.20 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
22 16 - - 4.17 3.13 - - 7.3 2550 12.20 95 2.86 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
24 16 - - 4.47 2.83 - - 7.3 2550 12.20 95 2.86 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
18 18 - - 3.60 3.60 - - 7.2 2550 12.20 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
22 18 - - 4.04 3.36 - - 7.4 2550 12.20 95 2.90 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
24 18 - - 4.34 3.06 - - 7.4 2550 12.20 95 2.90 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.98 - 12.76 ) ( 80 - 98 )
3 units 07 07 07 - 2.00 2.00 2.00 - 6.0 2400 11.48 95
2.50 48 63
( 3.8 - 7.5 ) ( 950 - 2720 ) ( 4.80 - 12.62 ) ( 90 - 98 )
10 07 07 - 2.70 2.00 2.00 - 6.7 2400 11.48 95 2.79 48 63
( 3.8 - 8.2 ) ( 950 - 2720 ) ( 4.80 - 12.62 ) ( 90 - 98 )
13 07 07 - 3.65 1.97 1.97 - 7.6 2410 11.53 95 3.15 48 63
( 3.9 - 8.3 ) ( 960 - 2740 ) ( 4.85 - 12.71 ) ( 90 - 98 )
+00A10-023_01EN.book Page 7 Wednesday, April 6, 2011 2:43 PM

–8–
220 3 units 16 07 07 - 4.08 1.81 1.81 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
18 07 07 - 4.28 1.71 1.71 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
22 07 07 - 4.68 1.56 1.56 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
24 07 07 - 4.99 1.41 1.41 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
10 10 07 - 2.70 2.70 2.00 - 7.4 2400 11.48 95 3.08 48 63
( 3.8 - 8.2 ) ( 950 - 2720 ) ( 4.80 - 12.62 ) ( 90 - 98 )
13 10 07 - 3.39 2.48 1.83 - 7.7 2410 11.53 95 3.20 48 63
( 3.9 - 8.3 ) ( 960 - 2740 ) ( 4.85 - 12.71 ) ( 90 - 98 )
16 10 07 - 3.77 2.26 1.67 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
18 10 07 - 3.97 2.14 1.59 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
22 10 07 - 4.37 1.97 1.46 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
24 10 07 - 4.69 1.78 1.32 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
13 13 07 - 3.03 3.03 1.64 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
16 13 07 - 3.44 2.83 1.53 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
18 13 07 - 3.64 2.70 1.46 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
22 13 07 - 4.00 2.47 1.33 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
24 13 07 - 4.38 2.28 1.23 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
16 16 07 - 3.19 3.19 1.42 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
18 16 07 - 3.39 3.05 1.36 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
22 16 07 - 3.79 2.84 1.26 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
24 16 07 - 4.12 2.61 1.16 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
18 18 07 - 3.29 3.29 1.32 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
22 18 07 - 3.65 3.04 1.22 - 7.9 2440 11.67 95
3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
24 18 07 - 3.98 2.80 1.12 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
10 10 10 - 2.53 2.53 2.53 - 7.6 2400 11.48 95 3.17 48 63
( 3.8 - 8.2 ) ( 950 - 2720 ) ( 4.80 - 12.62 ) ( 90 - 98 )
13 10 10 - 3.13 2.28 2.28 - 7.7 2410 11.53 95 3.20 48 63
( 3.9 - 8.3 ) ( 960 - 2740 ) ( 4.85 - 12.71 ) ( 90 - 98 )
16 10 10 - 3.50 2.10 2.10 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
18 10 10 - 3.70 2.00 2.00 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
22 10 10 - 4.16 1.87 1.87 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
24 10 10 - 4.49 1.71 1.71 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
13 13 10 - 2.82 2.82 2.06 - 7.7 2410 11.53 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.85 - 12.94 ) ( 90 - 98 )
16 13 10 - 3.22 2.65 1.93 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
18 13 10 - 3.42 2.53 1.85 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
22 13 10 - 3.82 2.36 1.72 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
24 13 10 - 4.15 2.17 1.58 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
16 16 10 - 3.04 3.04 1.82 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
18 16 10 - 3.20 2.88 1.73 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
22 16 10 - 3.64 2.73 1.64 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
24 16 10 - 3.97 2.52 1.51 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Cooling / 220 V> (Continued)
+00A10-023_01EN.book Page 8 Wednesday, April 6, 2011 2:43 PM

–9–
220 3 units 18 18 10 - 3.11 3.11 1.68 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
22 18 10 - 3.50 2.92 1.58 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
24 18 10 - 3.84 2.70 1.46 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
13 13 13 - 2.60 2.60 2.60 - 7.8 2430 11.63 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.90 - 13.03 ) ( 90 - 98 )
16 13 13 - 2.99 2.46 2.46 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
18 13 13 - 3.19 2.36 2.36 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
22 13 13 - 3.58 2.21 2.21 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
24 13 13 - 3.92 2.04 2.04 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
16 16 13 - 2.80 2.80 2.30 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
18 16 13 - 2.99 2.69 2.21 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
22 16 13 - 3.38 2.54 2.08 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
24 16 13 - 3.71 2.35 1.93 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
18 18 13 - 2.88 2.88 2.13 - 7.9 2440 11.67 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.90 - 13.13 ) ( 90 - 98 )
22 18 13 - 3.27 2.72 2.01 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
16 16 16 - 2.67 2.67 2.67 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
22 16 16 - 3.20 2.40 2.40 - 8.0 2450 11.72 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.95 - 13.45 ) ( 90 - 98 )
4 units 07 07 07 07 1.78 1.78 1.78 1.78 7.1 2029 9.71 95
3.50 48 63
( 4.0 - 8.6 ) ( 850 - 2620 ) ( 4.29 - 12.15 ) ( 90 - 98 )
10 07 07 07 2.33 1.72 1.72 1.72 7.5 2143 10.25 95 3.50 48 63
( 4.0 - 8.7 ) ( 890 - 2640 ) ( 4.49 - 12.24 ) ( 90 - 98 )
13 07 07 07 2.90 1.57 1.57 1.57 7.6 2171 10.39 95 3.50 48 63
( 4.1 - 8.9 ) ( 900 - 2700 ) ( 4.55 - 12.52 ) ( 90 - 98 )
16 07 07 07 3.30 1.47 1.47 1.47 7.7 2200 10.53 95 3.50 48 63
( 4.1 - 9.0 ) ( 930 - 2730 ) ( 4.70 - 12.66 ) ( 90 - 98 )
1807 07 07 3.55 1.42 1.42 1.42 7.8 2229 10.67 95
3.50 48 63
( 4.1 - 9.1 ) ( 930 - 2760 ) ( 4.70 - 12.80 ) ( 90 - 98 )
22 07 07 07 4.00 1.33 1.33 1.33 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
24 07 07 07 4.34 1.22 1.22 1.22 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
10 10 07 07 2.18 2.18 1.62 1.62 7.6 2171 10.39 95 3.50 48 63
( 4.1 - 8.9 ) ( 900 - 2700 ) ( 4.55 - 12.52 ) ( 90 - 98 )
13 10 07 07 2.74 2.00 1.48 1.48 7.7 2200 10.53 95 3.50 48 63
( 4.1 - 9.0 ) ( 930 - 2730 ) ( 4.70 - 12.66 ) ( 90 - 98 )
16 10 07 07 3.13 1.88 1.39 1.39 7.8 2229 10.67 95 3.50 48 63
( 4.1 - 9.1 ) ( 930 - 2760 ) ( 4.70 - 12.80 ) ( 90 - 98 )
18 10 07 07 3.38 1.82 1.35 1.35 7.9 2257 10.80 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.75 - 12.94 ) ( 90 - 98 )
22 10 07 07 3.78 1.70 1.26 1.26 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
24 10 07 07 4.12 1.57 1.16 1.16 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
13 13 07 07 2.56 2.56 1.39 1.39 7.9 2257 10.80 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.75 - 12.94 ) ( 90 - 98 )
16 13 07 07 2.95 2.43 1.31 1.31 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 13 07 07 3.15 2.33 1.26 1.26 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
22 13 07 07 3.50 2.16 1.17 1.17 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
24 13 07 07 3.84 2.00 1.08 1.08 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 16 07 07 2.77 2.77 1.23 1.23 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 16 07 07 2.96 2.67 1.19 1.19 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 18 07 07 2.86 2.86 1.14 1.14 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Cooling / 220 V> (Continued)
+00A10-023_01EN.book Page 9 Wednesday, April 6, 2011 2:43 PM

–10–
220 4 units 10 10 10 07 2.03 2.03 2.03 1.50 7.6 2171 10.39 95 3.50 48 63
( 4.1 - 8.9 ) ( 900 - 2700 ) ( 4.55 - 12.52 ) ( 90 - 98 )
13 10 10 07 2.60 1.90 1.90 1.41 7.8 2229 10.67 95 3.50 48 63
( 4.1 - 9.1 ) ( 930 - 2760 ) ( 4.70 - 12.80 ) ( 90 - 98 )
16 10 10 07 2.99 1.79 1.79 1.33 7.9 2257 10.80 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.75 - 12.94 ) ( 90 - 98 )
18 10 10 07 3.23 1.74 1.74 1.29 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
22 10 10 07 3.58 1.61 1.61 1.19 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
24 10 10 07 3.92 1.49 1.49 1.10 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
13 13 10 07 2.45 2.45 1.79 1.32 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 13 10 07 2.79 2.29 1.67 1.24 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 13 10 07 2.99 2.21 1.61 1.19 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
22 13 10 07 3.33 2.06 1.50 1.11 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
24 13 10 07 3.66 1.91 1.39 1.03 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 16 10 07 2.63 2.63 1.58 1.17 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 16 10 07 2.82 2.54 1.52 1.13 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 18 10 07 2.72 2.72 1.47 1.09 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
13 13 13 07 2.26 2.26 2.26 1.22 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 13 13 07 2.59 2.13 2.13 1.15 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 13 13 07 2.78 2.06 2.06 1.11 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 16 13 07 2.45 2.45 2.01 1.09 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 16 13 07 2.63 2.37 1.95 1.05 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
10 10 10 10 1.98 1.98 1.98 1.98 7.9 2257 10.80 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.75 - 12.94 ) ( 90 - 98 )
13 10 10 10 2.48 1.81 1.81 1.81 7.9 2257 10.80 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.75 - 12.94 ) ( 90 - 98 )
16 10 10 10 2.86 1.71 1.71 1.71 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 10 10 10 3.05 1.65 1.65 1.65 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
22 10 10 10 3.40 1.53 1.53 1.53 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
24 10 10 10 3.74 1.42 1.42 1.42 8.0 2286 10.94 95 3.50 48 63
Only SKV series allowed
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
13 13 10 10 2.31 2.31 1.69 1.69 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 13 10 10 2.65 2.18 1.59 1.59 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 16 10 10 2.50 2.50 1.50 1.50 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 13 10 10 2.84 2.10 1.53 1.53 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 16 10 10 2.68 2.42 1.45 1.45 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
13 13 13 10 2.14 2.14 2.14 1.57 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
16 13 13 10 2.47 2.03 2.03 1.48 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
18 13 13 10 2.65 1.96 1.96 1.43 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
13 13 13 13 2.00 2.00 2.00 2.00 8.0 2286 10.94 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.80 - 13.08 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Cooling / 220 V> (Continued)
+00A10-023_01EN.book Page 10 Wednesday, April 6, 2011 2:43 PM

–11–
Outdoor Unit: RAS-4M27UAV-E
<Heating / 220 V>
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Heating capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
220 1 unit 07 - - - 2.7 - - - 2.7 900 4.70 87 3.00 49 64
( 0.8 - 4.8 ) ( 300 - 1980 ) ( 1.87 - 9.18 ) ( 73 - 98 )
10 - - - 4.0 - - - 4.0 1450 6.94 95 2.76 49 64
( 0.8 - 5.2 ) ( 300 - 1980 ) ( 1.87 - 9.18 ) ( 73 - 98 )
13 - - - 5.0 - - - 5.0 2050 9.81 95 2.44 49 64
( 0.8 - 6.5 ) ( 310 - 2750 ) ( 1.93 - 12.76 ) ( 73 - 98 )
16 - - - 5.5 - - - 5.5 2400 11.48 95 2.29 49 64
( 0.8 - 6.9 ) ( 310 - 3000 ) ( 1.93 - 13.91 ) ( 73 - 98 )
18 - - - 6.0 - - - 6.0 2630 12.58 95 2.28 49 64
( 0.8 - 7.1 ) ( 310 - 3200 ) ( 1.93 - 14.84 ) ( 73 - 98 )
22 - - - 7.0 - - - 7.0 2700 12.78 96 2.59 49 64
( 1.8 - 8.2 ) ( 330 - 3600 ) ( 2.05 - 16.70 ) ( 73 - 98 )
24 - - - 8.1 - - - 8.1 3300 15.63 96 2.45 49 64
( 1.8 - 8.6 ) ( 330 - 3700 ) ( 2.05 - 17.16 ) ( 73 - 98 )
2 units 07 07 - - 2.70 2.70 - - 5.4 2050 9.81 95 2.63 49 64
( 1.5 - 7.4 ) ( 320 - 3200 ) ( 1.94 - 14.84 ) ( 75 - 98 )
10 07 - - 4.00 2.70 - - 6.7 2080 9.95 95 3.22 49 64
( 1.5 - 8.9 ) ( 320 - 3200 ) ( 1.94 - 14.84 ) ( 75 - 98 )
13 07 - - 4.81 2.59 - - 7.4 2320 11.10 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3210 ) ( 1.94 - 14.89 ) ( 75 - 98 )
16 07 - - 5.10 2.50 - - 7.6 2480 11.87 95 3.06 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.94 - 14.98 ) ( 75 - 98 )
18 07 - - 5.45 2.45 - - 7.9 2480 11.87 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.94 - 14.98 ) ( 75 - 98 )
22 07 - - 5.70 2.20 - - 7.9 2480 11.87 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.94 - 14.98 ) ( 75 - 98 )
24 07 - - 6.23 2.08 - - 8.3 2700 12.92 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.94 - 15.03 ) ( 75 - 98 )
10 10 - - 3.60 3.60 - - 7.2 2100 10.05 95 3.43 49 64
( 1.5 - 10.0 ) ( 320 - 3200 ) ( 1.94 - 14.84 ) ( 75 - 98 )
13 10 - - 4.22 3.38 - - 7.6 2320 11.10 95 3.28 49 64
( 1.5 - 10.1 ) ( 320 - 3210 ) ( 1.94 - 14.89 ) ( 75 - 98 )
16 10 - - 4.57 3.33 - - 7.9 2480 11.87 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.94 - 14.98 ) ( 75 - 98 )
18 10 - - 4.74 3.16 - - 7.9 2480 11.87 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.94 - 14.98 ) ( 75 - 98 )
22 10 - - 5.28 3.02 - - 8.3 2700 12.92 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.94 - 15.03 ) ( 75 - 98 )
24 10 - - 5.76 2.84 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
13 13 - - 3.95 3.95 - - 7.9 2480 11.87 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.94 - 14.98 ) ( 75 - 98 )
16 13 - - 4.35 3.95 - - 8.3 2700 12.92 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.94 - 15.03 ) ( 75 - 98 )
18 13 - - 4.53 3.77 - - 8.3 2700 12.92 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.94 - 15.03 ) ( 75 - 98 )
22 13 - - 5.02 3.58 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
24 13 - - 5.32 3.28 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
16 16 - - 4.30 4.30 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
18 16 - - 4.49 4.11 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
22 16 - - 4.82 3.78 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
24 16 - - 5.12 3.48 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
18 18 - - 4.30 4.30 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
22 18 - - 4.63 3.97 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
24 18 - - 4.94 3.66 - - 8.6 2860 13.68 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.94 - 15.07 ) ( 75 - 98 )
3 units 07 07 07 - 2.70 2.70 2.70 - 8.1 2290 10.96 95 3.54 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.16 - 12.76 ) ( 80 - 98 )
10 07 07 - 3.53 2.38 2.38 - 8.3 2300 11.00 95 3.61 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.16 - 12.76 ) ( 80 - 98 )
13 07 07 - 4.13 2.23 2.23 - 8.6 2300 11.00 95 3.74 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.16 - 12.76 ) ( 80 - 98 )
16 07 07 - 4.39 2.16 2.16 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
+00A10-023_01EN.book Page 11 Wednesday, April 6, 2011 2:43 PM

–12–
220 3 units 18 07 07 - 4.58 2.06 2.06 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
22 07 07 - 4.91 1.89 1.89 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
24 07 07 - 5.22 1.74 1.74 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
10 10 07 - 3.18 3.18 2.14 - 8.5 2300 11.00 95 3.70 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.16 - 12.76 ) ( 80 - 98 )
13 10 07 - 3.72 2.97 2.01 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
16 10 07 - 3.92 2.85 1.93 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
18 10 07 - 4.11 2.74 1.85 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
22 10 07 - 4.50 2.57 1.73 - 8.8 2400 11.48 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.16 - 12.89 ) ( 80 - 98 )
24 10 07 - 4.82 2.38 1.61 - 8.8 2400 11.48 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.16 - 12.89 ) ( 80 - 98 )
13 13 07 - 3.43 3.43 1.85 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
16 13 07 - 3.67 3.33 1.80 - 8.8 2400 11.48 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.16 - 12.89 ) ( 80 - 98 )
18 13 07 - 3.85 3.21 1.73 - 8.8 2400 11.48 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.16 - 12.89 ) ( 80 - 98 )
22 13 07 - 4.24 3.03 1.63 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 13 07 - 4.56 2.82 1.52 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
16 16 07 - 3.57 3.57 1.75 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
18 16 07 - 3.76 3.45 1.69 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 16 07 - 4.10 3.22 1.58 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 16 07 - 4.42 3.00 1.47 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
18 18 07 - 3.63 3.63 1.63 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 18 07 - 3.97 3.40 1.53 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 18 07 - 4.29 3.18 1.43 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
10 10 10 - 2.87 2.87 2.87 - 8.6 2300 11.00 95 3.74 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.16 - 12.76 ) ( 80 - 98 )
13 10 10 - 3.35 2.68 2.68 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
16 10 10 - 3.54 2.58 2.58 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
18 10 10 - 3.73 2.49 2.49 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
22 10 10 - 4.15 2.37 2.37 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 10 10 - 4.48 2.21 2.21 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
13 13 10 - 3.11 3.11 2.49 - 8.7 2350 11.24 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.16 - 12.80 ) ( 80 - 98 )
16 13 10 - 3.34 3.03 2.43 - 8.8 2400 11.48 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.16 - 12.89 ) ( 80 - 98 )
18 13 10 - 3.56 2.97 2.37 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 13 10 - 3.89 2.78 2.23 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 13 10 - 4.22 2.60 2.08 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
16 16 10 - 3.26 3.26 2.37 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
18 16 10 - 3.45 3.16 2.30 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 16 10 - 3.78 2.97 2.16 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 16 10 - 4.10 2.78 2.02 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
18 18 10 - 3.34 3.34 2.23 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Heating capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Heating / 220 V> (Continued)
+00A10-023_01EN.book Page 12 Wednesday, April 6, 2011 2:43 PM

–13–
220 3 units 22 18 10 - 3.66 3.14 2.09 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 18 10 - 3.98 2.95 1.97 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
13 13 13 - 2.93 2.93 2.93 - 8.8 2400 11.48 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.16 - 12.89 ) ( 80 - 98 )
16 13 13 - 3.16 2.87 2.87 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
18 13 13 - 3.34 2.78 2.78 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 13 13 - 3.66 2.62 2.62 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 13 13 - 3.98 2.46 2.46 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
16 16 13 - 3.06 3.06 2.78 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
18 16 13 - 3.24 2.97 2.70 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 16 13 - 3.56 2.80 2.54 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
24 16 13 - 3.88 2.63 2.39 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
18 18 13 - 3.14 3.14 2.62 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 18 13 - 3.46 2.97 2.47 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
16 16 16 - 2.97 2.97 2.97 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
22 16 16 - 3.46 2.72 2.72 - 8.9 2450 11.72 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.16 - 12.94 ) ( 80 - 98 )
4 units 07 07 07 07 2.09 2.09 2.09 2.09 8.4 1792 8.57 95 4.67 49 64
( 3.0 - 11.5 ) ( 470 - 2560 ) ( 2.37 - 11.87 ) ( 90 - 98 )
10 07 07 07 2.80 1.89 1.89 1.89 8.5 1812 8.67 95 4.67 49 64
( 3.0 - 11.5 ) ( 470 - 2560 ) ( 2.37 - 11.87 ) ( 90 - 98 )
13 07 07 07 3.30 1.78 1.78 1.78 8.6 1850 8.85 95 4.67 49 64
( 3.0 - 11.6 ) ( 480 - 2580 ) ( 2.42 - 11.97 ) ( 90 - 98 )
16 07 07 07 3.53 1.73 1.73 1.73 8.7 1869 8.94 95 4.67 49 64
( 3.0 - 11.6 ) ( 490 - 2580 ) ( 2.47 - 11.97 ) ( 90 - 98 )
18 07 07 07 3.75 1.69 1.69 1.69 8.8 1889 9.04 95 4.67 49 64
( 3.0 - 11.6 ) ( 490 - 2580 ) ( 2.47 - 11.97 ) ( 90 - 98 )
22 07 07 07 4.17 1.61 1.61 1.61 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
24 07 07 07 4.50 1.50 1.50 1.50 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
10 10 07 07 2.58 2.58 1.74 1.74 8.6 1850 8.85 95 4.67 49 64
( 3.0 - 11.6 ) ( 480 - 2580 ) ( 2.42 - 11.97 ) ( 90 - 98 )
13 10 07 07 3.03 2.43 1.64 1.64 8.7 1869 8.94 95 4.67 49 64
( 3.0 - 11.6 ) ( 490 - 2580 ) ( 2.47 - 11.97 ) ( 90 - 98 )
16 10 07 07 3.26 2.37 1.60 1.60 8.8 1889 9.04 95 4.67 49 64
( 3.0 - 11.6 ) ( 490 - 2580 ) ( 2.47 - 11.97 ) ( 90 - 98 )
18 10 07 07 3.47 2.31 1.56 1.56 8.9 1908 9.13 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
22 10 07 07 3.84 2.20 1.48 1.48 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
24 10 07 07 4.17 2.06 1.39 1.39 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
13 13 07 07 2.89 2.89 1.56 1.56 8.9 1908 9.13 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 13 07 07 3.11 2.83 1.53 1.53 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 13 07 07 3.29 2.74 1.48 1.48 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
22 13 07 07 3.62 2.59 1.40 1.40 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
24 13 07 07 3.94 2.43 1.31 1.31 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 16 07 07 3.02 3.02 1.48 1.48 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 16 07 07 3.20 2.93 1.44 1.44 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 18 07 07 3.10 3.10 1.40 1.40 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
10 10 10 07 2.35 2.35 2.35 1.59 8.6 1850 8.85 95 4.67 49 64
( 3.0 - 11.6 ) ( 480 - 2580 ) ( 2.42 - 11.97 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Heating capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Heating / 220 V> (Continued)
+00A10-023_01EN.book Page 13 Wednesday, April 6, 2011 2:43 PM

–14–
220 4 units 13 10 10 07 2.81 2.25 2.25 1.52 8.8 1889 9.04 95 4.67 49 64
( 3.0 - 11.6 ) ( 490 - 2580 ) ( 2.47 - 11.97 ) ( 90 - 98 )
16 10 10 07 3.03 2.20 2.20 1.49 8.9 1908 9.13 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 10 10 07 3.23 2.16 2.16 1.46 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
22 10 10 07 3.56 2.03 2.03 1.37 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
24 10 10 07 3.88 1.91 1.91 1.29 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
13 13 10 07 2.69 2.69 2.16 1.46 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 13 10 07 2.88 2.62 2.09 1.41 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 13 10 07 3.05 2.54 2.03 1.37 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
22 13 10 07 3.37 2.41 1.93 1.30 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
24 13 10 07 3.68 2.27 1.82 1.23 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 16 10 07 2.80 2.80 2.03 1.37 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 16 10 07 2.97 2.72 1.98 1.34 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 18 10 07 2.89 2.89 1.93 1.30 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
13 13 13 07 2.54 2.54 2.54 1.37 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 13 13 07 2.72 2.47 2.47 1.34 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 13 13 07 2.89 2.41 2.41 1.30 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 16 13 07 2.65 2.65 2.41 1.30 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 16 13 07 2.81 2.58 2.34 1.27 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
10 10 10 10 2.18 2.18 2.18 2.18 8.7 1869 8.94 95 4.67 49 64
( 3.0 - 11.6 ) ( 490 - 2580 ) ( 2.47 - 11.97 ) ( 90 - 98 )
13 10 10 10 2.62 2.10 2.10 2.10 8.9 1908 9.13 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 10 10 10 2.83 2.06 2.06 2.06 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 10 10 10 3.00 2.00 2.00 2.00 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
22 10 10 10 3.32 1.89 1.89 1.89 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
24 10 10 10 3.63 1.79 1.79 1.79 9.0 1927 9.22 95 4.67 49 64
Only SKV series allowed ( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
13 13 10 10 2.50 2.50 2.00 2.00 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 13 10 10 2.68 2.43 1.95 1.95 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 16 10 10 2.61 2.61 1.89 1.89 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 13 10 10 2.84 2.37 1.89 1.89 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 16 10 10 2.77 2.54 1.85 1.85 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
13 13 13 10 2.37 2.37 2.37 1.89 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
16 13 13 10 2.54 2.31 2.31 1.85 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
18 13 13 10 2.70 2.25 2.25 1.80 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
13 13 13 13 2.25 2.25 2.25 2.25 9.0 1927 9.22 95 4.67 49 64
( 3.0 - 11.7 ) ( 500 - 2600 ) ( 2.53 - 12.06 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Heating capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Heating / 220 V> (Continued)
+00A10-023_01EN.book Page 14 Wednesday, April 6, 2011 2:43 PM

–15–
<Cooling / 230 V>
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
230 1 unit 07 - - - 2.0 - - - 2.0 650 3.67 77 3.08 48 63
( 1.4 - 2.5 ) ( 640 - 700 ) ( 3.66 - 3.58 ) ( 76 - 85 )
10 - - - 2.7 - - - 2.7 750 4.23 77 3.60 48 63
( 1.4 - 3.2 ) ( 640 - 950 ) ( 3.66 - 4.44 ) ( 76 - 93 )
13 - - - 3.7 - - - 3.7 1200 5.93 88 3.08 48 63
( 1.4 - 4.4 ) ( 640 - 1520 ) ( 3.52 - 6.88 ) ( 79 - 96 )
16 - - - 4.5 - - - 4.5 1650 7.63 94 2.73 48 63
( 1.4 - 5.0 ) ( 640 - 2000 ) ( 3.52 - 8.87 ) ( 79 - 98 )
18 - - - 5.0 - - - 5.0 1950 8.92 95 2.56 48 63
( 1.4 - 5.2 ) ( 640 - 2100 ) ( 3.52 - 9.32 ) ( 79 - 98 )
22 - - - 6.0 - - - 6.0 2020 9.15 96 2.97 48 63
( 2.4 - 6.8 ) ( 640 - 2500 ) ( 3.52 - 11.09 ) ( 79 - 98 )
24 - - - 7.1 - - - 7.1 2390 10.82 96 2.97 48 63
( 2.4 - 7.2 ) ( 660 - 2960 ) ( 3.63 - 13.13 ) ( 79 - 98 )
2 units 07 07 - - 2.00 2.00 - - 4.0 1520 6.96 95 2.63 48 63
( 2.5 - 5.0 ) ( 640 - 1770 ) ( 3.48 - 7.85 ) ( 80 - 98 )
10 07 - - 2.70 2.00 - - 4.7 1530 7.00 95 3.07 48 63
( 2.5 - 5.7 ) ( 640 - 1910 ) ( 3.48 - 8.47 ) ( 80 - 98 )
13 07 - - 3.70 2.00 - - 5.7 1810 8.28 95 3.15 48 63
( 2.6 - 6.5 ) ( 660 - 2130 ) ( 3.59 - 9.45 ) ( 80 - 98 )
16 07 - - 4.08 1.82 - - 5.9 1810 8.28 95 3.26 48 63
( 2.7 - 6.6 ) ( 660 - 2220 ) ( 3.59 - 9.85 ) ( 80 - 98 )
18 07 - - 4.50 1.80 - - 6.3 2040 9.34 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.64 - 10.65 ) ( 80 - 98 )
22 07 - - 4.73 1.58 - - 6.3 2040 9.34 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.64 - 10.65 ) ( 80 - 98 )
24 07 - - 5.31 1.49 - - 6.8 2320 10.62 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.75 - 11.40 ) ( 80 - 98 )
10 10 - - 2.70 2.70 - - 5.4 1530 7.00 95 3.53 48 63
( 2.5 - 6.3 ) ( 640 - 2040 ) ( 3.48 - 9.05 ) ( 80 - 98 )
13 10 - - 3.41 2.49 - - 5.9 1810 8.28 95 3.26 48 63
( 2.7 - 6.6 ) ( 660 - 2220 ) ( 3.59 - 9.85 ) ( 80 - 98 )
16 10 - - 3.94 2.36 - - 6.3 2040 9.34 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.64 - 10.65 ) ( 80 - 98 )
18 10 - - 4.09 2.21 - - 6.3 2040 9.34 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.64 - 10.65 ) ( 80 - 98 )
22 10 - - 4.69 2.11 - - 6.8 2320 10.62 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.75 - 11.40 ) ( 80 - 98 )
24 10 - - 5.22 1.98 - - 7.2 2550 11.67 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
13 13 - - 3.15 3.15 - - 6.3 2040 9.34 95 3.09 48 63
( 2.9 - 6.9 ) ( 670 - 2400 ) ( 3.64 - 10.65 ) ( 80 - 98 )
16 13 - - 3.73 3.07 - - 6.8 2320 10.62 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.75 - 11.40 ) ( 80 - 98 )
18 13 - - 3.91 2.89 - - 6.8 2320 10.62 95 2.93 48 63
( 3.0 - 7.2 ) ( 690 - 2570 ) ( 3.75 - 11.40 ) ( 80 - 98 )
22 13 - - 4.45 2.75 - - 7.2 2550 11.67 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
24 13 - - 4.73 2.47 - - 7.2 2550 11.67 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
16 16 - - 3.60 3.60 - - 7.2 2550 11.67 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
18 16 - - 3.79 3.41 - - 7.2 2550 11.67 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
22 16 - - 4.17 3.13 - - 7.3 2550 11.67 95 2.86 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
24 16 - - 4.47 2.83 - - 7.3 2550 11.67 95 2.86 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
18 18 - - 3.60 3.60 - - 7.2 2550 11.67 95 2.82 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
22 18 - - 4.04 3.36 - - 7.4 2550 11.67 95 2.90 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
24 18 - - 4.34 3.06 - - 7.4 2550 11.67 95 2.90 48 63
( 3.2 - 7.5 ) ( 700 - 2750 ) ( 3.80 - 12.20 ) ( 80 - 98 )
3 units 07 07 07 - 2.00 2.00 2.00 - 6.0 2400 10.98 95 2.50 48 63
( 3.8 - 7.5 ) ( 950 - 2720 ) ( 4.59 - 12.07 ) ( 90 - 98 )
10 07 07 - 2.70 2.00 2.00 - 6.7 2400 10.98 95 2.79 48 63
( 3.8 - 8.2 ) ( 950 - 2720 ) ( 4.59 - 12.07 ) ( 90 - 98 )
13 07 07 - 3.65 1.97 1.97 - 7.6 2410 11.03 95 3.15 48 63
( 3.9 - 8.3 ) ( 960 - 2740 ) ( 4.64 - 12.16 ) ( 90 - 98 )
16 07 07 - 4.08 1.81 1.81 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
18 07 07 - 4.28 1.71 1.71 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
+00A10-023_01EN.book Page 15 Wednesday, April 6, 2011 2:43 PM

–16–
230 3 units 22 07 07 - 4.68 1.56 1.56 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
24 07 07 - 4.99 1.41 1.41 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
10 10 07 - 2.70 2.70 2.00 - 7.4 2400 10.98 95 3.08 48 63
( 3.8 - 8.2 ) ( 950 - 2720 ) ( 4.59 - 12.07 ) ( 90 - 98 )
13 10 07 - 3.39 2.48 1.83 - 7.7 2410 11.03 95 3.20 48 63
( 3.9 - 8.3 ) ( 960 - 2740 ) ( 4.64 - 12.16 ) ( 90 - 98 )
16 10 07 - 3.77 2.26 1.67 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
18 10 07 - 3.97 2.14 1.59 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
22 10 07 - 4.37 1.97 1.46 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
24 10 07 - 4.69 1.78 1.32 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
13 13 07 - 3.03 3.03 1.64 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
16 13 07 - 3.44 2.83 1.53 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
18 13 07 - 3.64 2.70 1.46 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
22 13 07 - 4.00 2.47 1.33 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
24 13 07 - 4.38 2.28 1.23 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
16 16 07 - 3.19 3.19 1.42 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
18 16 07 - 3.39 3.05 1.36 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
22 16 07 - 3.79 2.84 1.26 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
24 16 07 - 4.12 2.61 1.16 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
18 18 07 - 3.29 3.29 1.32 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
22 18 07 - 3.65 3.04 1.22 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
24 18 07 - 3.98 2.80 1.12 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
10 10 10 - 2.53 2.53 2.53 - 7.6 2400 10.98 95 3.17 48 63
( 3.8 - 8.2 ) ( 950 - 2720 ) ( 4.59 - 12.07 ) ( 90 - 98 )
13 10 10 - 3.13 2.28 2.28 - 7.7 2410 11.03 95 3.20 48 63
( 3.9 - 8.3 ) ( 960 - 2740 ) ( 4.64 - 12.16 ) ( 90 - 98 )
16 10 10 - 3.50 2.10 2.10 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
18 10 10 - 3.70 2.00 2.00 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
22 10 10 - 4.16 1.87 1.87 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
24 10 10 - 4.49 1.71 1.71 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
13 13 10 - 2.82 2.82 2.06 - 7.7 2410 11.03 95 3.20 48 63
( 4.0 - 8.5 ) ( 960 - 2790 ) ( 4.64 - 12.38 ) ( 90 - 98 )
16 13 10 - 3.22 2.65 1.93 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
18 13 10 - 3.42 2.53 1.85 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
22 13 10 - 3.82 2.36 1.72 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
24 13 10 - 4.15 2.17 1.58 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
16 16 10 - 3.04 3.04 1.82 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
18 16 10 - 3.20 2.88 1.73 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
22 16 10 - 3.64 2.73 1.64 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
24 16 10 - 3.97 2.52 1.51 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
18 18 10 - 3.11 3.11 1.68 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
22 18 10 - 3.50 2.92 1.58 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Cooling / 230 V> (Continued)
+00A10-023_01EN.book Page 16 Wednesday, April 6, 2011 2:43 PM

–17–
230 3 units 24 18 10 - 3.84 2.70 1.46 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
13 13 13 - 2.60 2.60 2.60 - 7.8 2430 11.12 95 3.21 48 63
( 4.1 - 8.6 ) ( 970 - 2810 ) ( 4.69 - 12.47 ) ( 90 - 98 )
16 13 13 - 2.99 2.46 2.46 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
18 13 13 - 3.19 2.36 2.36 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
22 13 13 - 3.58 2.21 2.21 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
24 13 13 - 3.92 2.04 2.04 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
16 16 13 - 2.80 2.80 2.30 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
18 16 13 - 2.99 2.69 2.21 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
22 16 13 - 3.38 2.54 2.08 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
24 16 13 - 3.71 2.35 1.93 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
18 18 13 - 2.88 2.88 2.13 - 7.9 2440 11.17 95 3.24 48 63
( 4.1 - 8.7 ) ( 970 - 2830 ) ( 4.69 - 12.56 ) ( 90 - 98 )
22 18 13 - 3.27 2.72 2.01 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
16 16 16 - 2.67 2.67 2.67 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
22 16 16 - 3.20 2.40 2.40 - 8.0 2450 11.21 95 3.27 48 63
( 4.3 - 9.0 ) ( 980 - 2900 ) ( 4.73 - 12.87 ) ( 90 - 98 )
4 units 07 07 07 07 1.78 1.78 1.78 1.78 7.1 2029 9.29 95 3.50 48 63
( 4.0 - 8.6 ) ( 850 - 2620 ) ( 4.11 - 11.62 ) ( 90 - 98 )
10 07 07 07 2.33 1.72 1.72 1.72 7.5 2143 9.81 95 3.50 48 63
( 4.0 - 8.7 ) ( 890 - 2640 ) ( 4.30 - 11.71 ) ( 90 - 98 )
13 07 07 07 2.90 1.57 1.57 1.57 7.6 2171 9.94 95 3.50 48 63
( 4.1 - 8.9 ) ( 900 - 2700 ) ( 4.35 - 11.98 ) ( 90 - 98 )
16 07 07 07 3.30 1.47 1.47 1.47 7.7 2200 10.07 95 3.50 48 63
( 4.1 - 9.0 ) ( 930 - 2730 ) ( 4.49 - 12.11 ) ( 90 - 98 )
18 07 07 07 3.55 1.42 1.42 1.42 7.8 2229 10.20 95 3.50 48 63
( 4.1 - 9.1 ) ( 930 - 2760 ) ( 4.49 - 12.24 ) ( 90 - 98 )
22 07 07 07 4.00 1.33 1.33 1.33 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
24 07 07 07 4.34 1.22 1.22 1.22 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
10 10 07 07 2.18 2.18 1.62 1.62 7.6 2171 9.94 95 3.50 48 63
( 4.1 - 8.9 ) ( 900 - 2700 ) ( 4.35 - 11.98 ) ( 90 - 98 )
13 10 07 07 2.74 2.00 1.48 1.48 7.7 2200 10.07 95 3.50 48 63
( 4.1 - 9.0 ) ( 930 - 2730 ) ( 4.49 - 12.11 ) ( 90 - 98 )
16 10 07 07 3.13 1.88 1.39 1.39 7.8 2229 10.20 95 3.50 48 63
( 4.1 - 9.1 ) ( 930 - 2760 ) ( 4.49 - 12.24 ) ( 90 - 98 )
18 10 07 07 3.38 1.82 1.35 1.35 7.9 2257 10.33 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.54 - 12.38 ) ( 90 - 98 )
22 10 07 07 3.78 1.70 1.26 1.26 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
24 10 07 07 4.12 1.57 1.16 1.16 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
13 13 07 07 2.56 2.56 1.39 1.39 7.9 2257 10.33 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.54 - 12.38 ) ( 90 - 98 )
16 13 07 07 2.95 2.43 1.31 1.31 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 13 07 07 3.15 2.33 1.26 1.26 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
22 13 07 07 3.50 2.16 1.17 1.17 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
24 13 07 07 3.84 2.00 1.08 1.08 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 16 07 07 2.77 2.77 1.23 1.23 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 16 07 07 2.96 2.67 1.19 1.19 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 18 07 07 2.86 2.86 1.14 1.14 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
10 10 10 07 2.03 2.03 2.03 1.50 7.6 2171 9.94 95 3.50 48 63
( 4.1 - 8.9 ) ( 900 - 2700 ) ( 4.35 - 11.98 ) ( 90 - 98 )
13 10 10 07 2.60 1.90 1.90 1.41 7.8 2229 10.20 95 3.50 48 63
( 4.1 - 9.1 ) ( 930 - 2760 ) ( 4.49 - 12.24 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Cooling / 230 V> (Continued)
+00A10-023_01EN.book Page 17 Wednesday, April 6, 2011 2:43 PM

–18–
230 4 units 16 10 10 07 2.99 1.79 1.79 1.33 7.9 2257 10.33 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.54 - 12.38 ) ( 90 - 98 )
18 10 10 07 3.23 1.74 1.74 1.29 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
22 10 10 07 3.58 1.61 1.61 1.19 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
24 10 10 07 3.92 1.49 1.49 1.10 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
13 13 10 07 2.45 2.45 1.79 1.32 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 13 10 07 2.79 2.29 1.67 1.24 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 13 10 07 2.99 2.21 1.61 1.19 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
22 13 10 07 3.33 2.06 1.50 1.11 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
24 13 10 07 3.66 1.91 1.39 1.03 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 16 10 07 2.63 2.63 1.58 1.17 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 16 10 07 2.82 2.54 1.52 1.13 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 18 10 07 2.72 2.72 1.47 1.09 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
13 13 13 07 2.26 2.26 2.26 1.22 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 13 13 07 2.59 2.13 2.13 1.15 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 13 13 07 2.78 2.06 2.06 1.11 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 16 13 07 2.45 2.45 2.01 1.09 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 16 13 07 2.63 2.37 1.95 1.05 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
10 10 10 10 1.98 1.98 1.98 1.98 7.9 2257 10.33 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.54 - 12.38 ) ( 90 - 98 )
13 10 10 10 2.48 1.81 1.81 1.81 7.9 2257 10.33 95 3.50 48 63
( 4.1 - 9.2 ) ( 940 - 2790 ) ( 4.54 - 12.38 ) ( 90 - 98 )
16 10 10 10 2.86 1.71 1.71 1.71 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 10 10 10 3.05 1.65 1.65 1.65 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
22 10 10 10 3.40 1.53 1.53 1.53 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
24 10 10 10 3.74 1.42 1.42 1.42 8.0 2286 10.46 95 3.50 48 63
Only SKV series allowed ( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
13 13 10 10 2.31 2.31 1.69 1.69 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 13 10 10 2.65 2.18 1.59 1.59 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 16 10 10 2.50 2.50 1.50 1.50 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 13 10 10 2.84 2.10 1.53 1.53 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 16 10 10 2.68 2.42 1.45 1.45 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
13 13 13 10 2.14 2.14 2.14 1.57 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
16 13 13 10 2.47 2.03 2.03 1.48 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
18 13 13 10 2.65 1.96 1.96 1.43 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
13 13 13 13 2.00 2.00 2.00 2.00 8.0 2286 10.46 95 3.50 48 63
( 4.2 - 9.3 ) ( 950 - 2820 ) ( 4.59 - 12.51 ) ( 90 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Cooling capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Cooling / 230 V> (Continued)
+00A10-023_01EN.book Page 18 Wednesday, April 6, 2011 2:43 PM

–19–
<Heating / 230 V>
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Heating capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
230 1 unit 07 - - - 2.7 - - - 2.7 900 4.50 87 3.00 49 64
( 0.8 - 4.8 ) ( 300 - 1980 ) ( 1.79 - 8.78 ) ( 73 - 98 )
10 - - - 4.0 - - - 4.0 1450 6.64 95 2.76 49 64
( 0.8 - 5.2 ) ( 300 - 1980 ) ( 1.79 - 8.78 ) ( 73 - 98 )
13 - - - 5.0 - - - 5.0 2050 9.38 95 2.44 49 64
( 0.8 - 6.5 ) ( 310 - 2750 ) ( 1.85 - 12.20 ) ( 73 - 98 )
16 - - - 5.5 - - - 5.5 2400 10.98 95 2.29 49 64
( 0.8 - 6.9 ) ( 310 - 3000 ) ( 1.85 - 13.31 ) ( 73 - 98 )
18 - - - 6.0 - - - 6.0 2630 12.04 95 2.28 49 64
( 0.8 - 7.1 ) ( 310 - 3200 ) ( 1.85 - 14.20 ) ( 73 - 98 )
22 - - - 7.0 - - - 7.0 2700 12.23 96 2.59 49 64
( 1.8 - 8.2 ) ( 330 - 3600 ) ( 1.97 - 15.97 ) ( 73 - 98 )
24 - - - 8.1 - - - 8.1 3300 14.95 96 2.45 49 64
( 1.8 - 8.6 ) ( 330 - 3700 ) ( 1.97 - 16.42 ) ( 73 - 98 )
2 units 07 07 - - 2.70 2.70 - - 5.4 2050 9.38 95 2.63 49 64
( 1.5 - 7.4 ) ( 320 - 3200 ) ( 1.86 - 14.20 ) ( 75 - 98 )
10 07 - - 4.00 2.70 - - 6.7 2080 9.52 95 3.22 49 64
( 1.5 - 8.9 ) ( 320 - 3200 ) ( 1.86 - 14.20 ) ( 75 - 98 )
13 07 - - 4.81 2.59 - - 7.4 2320 10.62 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3210 ) ( 1.86 - 14.24 ) ( 75 - 98 )
16 07 - - 5.10 2.50 - - 7.6 2480 11.35 95 3.06 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.86 - 14.33 ) ( 75 - 98 )
18 07 - - 5.45 2.45 - - 7.9 2480 11.35 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.86 - 14.33 ) ( 75 - 98 )
22 07 - - 5.70 2.20 - - 7.9 2480 11.35 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.86 - 14.33 ) ( 75 - 98 )
24 07 - - 6.23 2.08 - - 8.3 2700 12.36 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.86 - 14.37 ) ( 75 - 98 )
10 10 - - 3.60 3.60 - - 7.2 2100 9.61 95 3.43 49 64
( 1.5 - 10.0 ) ( 320 - 3200 ) ( 1.86 - 14.20 ) ( 75 - 98 )
13 10 - - 4.22 3.38 - - 7.6 2320 10.62 95 3.28 49 64
( 1.5 - 10.1 ) ( 320 - 3210 ) ( 1.86 - 14.24 ) ( 75 - 98 )
16 10 - - 4.57 3.33 - - 7.9 2480 11.35 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.86 - 14.33 ) ( 75 - 98 )
18 10 - - 4.74 3.16 - - 7.9 2480 11.35 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.86 - 14.33 ) ( 75 - 98 )
22 10 - - 5.28 3.02 - - 8.3 2700 12.36 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.86 - 14.37 ) ( 75 - 98 )
24 10 - - 5.76 2.84 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
13 13 - - 3.95 3.95 - - 7.9 2480 11.35 95 3.19 49 64
( 1.5 - 10.1 ) ( 320 - 3230 ) ( 1.86 - 14.33 ) ( 75 - 98 )
16 13 - - 4.35 3.95 - - 8.3 2700 12.36 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.86 - 14.37 ) ( 75 - 98 )
18 13 - - 4.53 3.77 - - 8.3 2700 12.36 95 3.07 49 64
( 1.5 - 10.2 ) ( 320 - 3240 ) ( 1.86 - 14.37 ) ( 75 - 98 )
22 13 - - 5.02 3.58 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
24 13 - - 5.32 3.28 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
16 16 - - 4.30 4.30 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
18 16 - - 4.49 4.11 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
22 16 - - 4.82 3.78 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
24 16 - - 5.12 3.48 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
18 18 - - 4.30 4.30 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
22 18 - - 4.63 3.97 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
24 18 - - 4.94 3.66 - - 8.6 2860 13.09 95 3.01 49 64
( 1.5 - 10.2 ) ( 320 - 3250 ) ( 1.86 - 14.42 ) ( 75 - 98 )
3 units 07 07 07 - 2.70 2.70 2.70 - 8.1 2290 10.48 95 3.54 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.07 - 12.20 ) ( 80 - 98 )
10 07 07 - 3.53 2.38 2.38 - 8.3 2300 10.53 95 3.61 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.07 - 12.20 ) ( 80 - 98 )
13 07 07 - 4.13 2.23 2.23 - 8.6 2300 10.53 95 3.74 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.07 - 12.20 ) ( 80 - 98 )
16 07 07 - 4.39 2.16 2.16 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
18 07 07 - 4.58 2.06 2.06 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
+00A10-023_01EN.book Page 19 Wednesday, April 6, 2011 2:43 PM

–20–
230 3 units 22 07 07 - 4.91 1.89 1.89 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
24 07 07 - 5.22 1.74 1.74 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
10 10 07 - 3.18 3.18 2.14 - 8.5 2300 10.53 95 3.70 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.07 - 12.20 ) ( 80 - 98 )
13 10 07 - 3.72 2.97 2.01 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
16 10 07 - 3.92 2.85 1.93 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
18 10 07 - 4.11 2.74 1.85 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
22 10 07 - 4.50 2.57 1.73 - 8.8 2400 10.98 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.07 - 12.33 ) ( 80 - 98 )
24 10 07 - 4.82 2.38 1.61 - 8.8 2400 10.98 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.07 - 12.33 ) ( 80 - 98 )
13 13 07 - 3.43 3.43 1.85 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
16 13 07 - 3.67 3.33 1.80 - 8.8 2400 10.98 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.07 - 12.33 ) ( 80 - 98 )
18 13 07 - 3.85 3.21 1.73 - 8.8 2400 10.98 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.07 - 12.33 ) ( 80 - 98 )
22 13 07 - 4.24 3.03 1.63 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
24 13 07 - 4.56 2.82 1.52 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
16 16 07 - 3.57 3.57 1.75 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
18 16 07 - 3.76 3.45 1.69 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
22 16 07 - 4.10 3.22 1.58 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
24 16 07 - 4.42 3.00 1.47 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
18 18 07 - 3.63 3.63 1.63 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
22 18 07 - 3.97 3.40 1.53 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
24 18 07 - 4.29 3.18 1.43 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
10 10 10 - 2.87 2.87 2.87 - 8.6 2300 10.53 95 3.74 49 64
( 2.0 - 10.4 ) ( 380 - 2750 ) ( 2.07 - 12.20 ) ( 80 - 98 )
13 10 10 - 3.35 2.68 2.68 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
16 10 10 - 3.54 2.58 2.58 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
18 10 10 - 3.73 2.49 2.49 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
22 10 10 - 4.15 2.37 2.37 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
24 10 10 - 4.48 2.21 2.21 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
13 13 10 - 3.11 3.11 2.49 - 8.7 2350 10.76 95 3.70 49 64
( 2.0 - 10.5 ) ( 380 - 2760 ) ( 2.07 - 12.24 ) ( 80 - 98 )
16 13 10 - 3.34 3.03 2.43 - 8.8 2400 10.98 95 3.67 49 64
( 2.0 - 10.6 ) ( 380 - 2780 ) ( 2.07 - 12.33 ) ( 80 - 98 )
18 13 10 - 3.56 2.97 2.37 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
22 13 10 - 3.89 2.78 2.23 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
24 13 10 - 4.22 2.60 2.08 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
16 16 10 - 3.26 3.26 2.37 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
18 16 10 - 3.45 3.16 2.30 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
22 16 10 - 3.78 2.97 2.16 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
24 16 10 - 4.10 2.78 2.02 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
18 18 10 - 3.34 3.34 2.23 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
22 18 10 - 3.66 3.14 2.09 - 8.9 2450 11.21 95 3.63 49 64
( 2.0 - 10.7 ) ( 380 - 2790 ) ( 2.07 - 12.38 ) ( 80 - 98 )
Power
supply
(V) Operating
Statu
Indoor unit Unit Capacity Total Outdoor noise (dB)
ABCDABCD
Heating capacity
(kW) Power consumption (W) Operation current (A) Power Factor (%)
Energy Efficiency
Ratio EER
Sound
Pressure Sound Power
<Heating / 230 V> (Continued)
+00A10-023_01EN.book Page 20 Wednesday, April 6, 2011 2:43 PM
