Loop Controller L3 User’s Manual Basic Hardware

Important Information
No patent liability is assumed by TOSHIBA Corporation with respect to use of information, illustrations,
circuits, equipment or examples of application in this publication.
TOSHIBA Corporation reserves the right to make changes and improvements to this publication and/or
related products at any time without notice. No obligation shall be incurred other than as noted in this
publication.
This publication is copyrighted and contains proprietary material. No part of this book may be reproduced,
stored in a retrieval system, or transmitted, in any form or by any means —electrical, mechanical,
photocopying, recording, or otherwise —without obtaining prior written permission from TOSHIBA
Corporation.
PROSEC, TOSLINE and TOSDIC are trademarks or registered trademarks of TOSHIBA Corporation.
IBM is a registered trademark of International Business Machines Corporation.
Microsoft, MS-DOS, Windows and Windows NT are registered trademarks of Microsoft Corporation in the
U.S.A. and other countries.
Ethernet is a registered trademark of Xerox Corporation.
DeviceNet is a trademark of the Open DeviceNet Vender Association, Inc.
TOSHIBA CORPORATION 2000. All rights reserved

6F8C0882 i
Safety Precautions
This manual contains important information for the operator to operate this product safely and correctly
and avoid bodily injury and property damage.
Grasp the meanings of the following marks and their descriptions before reading this manual.
Hazard Classifications
Note: 1. Serious injury means loss of sight, injury, burns (high temperature, low temperature), electrical
shock, fracture, or intoxication which leaves aftereffects or requires hospitalization or need to
go to the hospital for a long time.
2. Injury means hurt, burn, or electrical shock which does not require hospitalization or going to
the hospital for a long time.
3. Property damage means extended breakdown of assets and materials.
Notation of Markings
Note: The description of forbiddance, mandatory, and caution marks are subject to change, depending
on the labels on the main unit.
WARNING Indicates a potentially hazardous situation which, if not avoided,
could result in serious injury or death.
CAUTION Indicates a potentially hazardous situation which, if not a avoided,
can result in minor or moderate injury, or property damage. It can
also be used to alert against unsafe practices.
Prohibited Indicates a "may not" mark.
The concrete forbiddance is indicated with a pictograph or wording.
Mandatory Indicate a mandatory action that you should never fail to do.
The concrete content is indicated inside or near the circle with a
pictograph or wording.
Caution Indicates a caution.
The concrete content is indicated inside or near the triangle.

ii model 3000 Loop Controller L3 User’s Manual - Basic Hardware -
WARNING
CAUTION
1. Checking the Warning Labels on the Main Unit
Make sure warning markings are attached on the main unit.
If any of them are missing or the wording is illegible, contact Toshiba's Service Department.
2. Precautions on Installation
Be sure to ground the equipment.
Operation without grounding may cause
accidental fire or shock.
Mandatory
Mandatory
Avoid the following locations when
installing or storaging the equipment.
•Locations where there is dust, salinity, or ion
particles
•Locations where there are corrosive gases
(SO2, H2S) or flammable gases
•Locations where vibration or shock occurs
beyond the allowance
•Locations where there is condensation due
to sharp temperature variations
•Locations where the ambient temperature
exceeds the allowance range
•Locations where the relative humidity
exceeds the allowance range
•Locations where the equipment is exposed
to direct sunlight
•Locations where strong electric radiation or
magnetic field is generated
Improper the installation or writing of the
system can cause not only insufficient
performance but also malfunction and
failure of the equipment
Do not cover the hole of the equipment, and the
ventilator/air inlet of the system.
Otherwise, overheating, etc. can cause fire
or malfunction.
Mandatory
Install the equipment at a place where
maintenance and inspection are easy to do.
Otherwise, recovery from failure may take
much more time, leading to a serious
accidents.
Mandatory
Forbidden

6F8C0882 iii
WARNING
CAUTION
3. Safety Precautions on Maintenance and inspection
Turn off power removing or connecting any
modules, boards, or devices.
Otherwise, it can cause electrical shock, or
machine damage.
Mandatory
Be careful not to hit or fall off the equipment by
accident.
Excess shock can cause failure.
Touch a grounded metal part to discharge the
static electricity on your body before touching
the equipment.
Otherwise, charged static electricity on your
body can cause malfunction or failure.
Mandatory
Forbidden
Use soft cloth to clean the equipment.
Use water-dipped and squeezed cloth to
clean it if dirty.
Leaving the equipment dirty can cause
mistaken or malfunction.
Mandatory
Turn off power removing any modules after
installing.
Otherwise, exposed conductive parts of wire
or on the rear of terminal blocks can cause
electrical shock.
Mandatory
Do not apply benzene and thinner when clean-
ing the equipment.
Otherwise, it can cause deformity or discolora-
tion the panel or case of the equipment.
Place any modules or boards removed from
the unit on a conductive mat or conductive bag
(containing a spare board, etc.) on an
grounded desk.
Otherwise, static electricity can damage
components of the module.
Mandatory
Forbidden

iv model 3000 Loop Controller L3 User’s Manual - Basic Hardware -
WARNING
WARNING
CAUTION
4. Precautions During Parts Replacement
Turn off power of the equipment before
replacing the power fuse or warning fuse.
Otherwise, it can cause electrical shock or fire.
Mandatory
5. Precautions During Daily Use
Apply power of the specified ratings (voltage
fluctuation range, frequency, output rating,
etc.) in User's manual.
Otherwise, it can cause malfunction, machine
damage or fire due to overheat.
Mandatory
Do not touch any components, terminals,
connectors, or printed circuit boards in the
module.
Otherwise, it can cause the IC or LSI or the
like to be broken by static electricity, resulting
in failure or malfunction.
Also, the edge of components can cause
injury.
Forbidden
Do not forcibly bend or pull or distort the power
cord and other cables. Otherwise, they can be
cut off or cause overheat.
Forbidden
Turn off power immediately if the ambient
temperature or internal temperature exceeds
beyond normal range or if failure is occurred
in the equipment.
Contact Toshiba for repairing.
Operation under such situation can cause fire
or electrical shock.
Mandatory

6F8C0882 v
WARNING CAUTION
Do not disassemble or modify the equipment.
Otherwise, it can cause malfunction or failure.
Forbidden Do not enter wire scrapes or other foreign
debris into the equipment.
Also, do not insert metal parts into them.
They can cause fire or accidents.
Forbidden
6. Safety Precautions on Disposal
Do not throw lithium batteries into fire.
Otherwise, they can explode.
Forbidden Observe local regulations for disposal of the
lithium batteries or the product (Base unit
and modules).
Mandatory

vi model 3000 Loop Controller L3 User’s Manual - Basic Hardware -
Limitation of Applications
The equipment has been designed and manufactured for use in an industrial environment.
However, the equipment is not intended to be used for systems which can endanger human life
(Note 1).
Consult Toshiba if you intend to use the equipment for a special application which involves human
life and has great influence on the maintenance of the public function (Note 2). This is why such
application requires special care on the operation, maintenance, and control of the system (Note 3).
(Note 1) The systems which can endanger human life are life maintenance systems, equipment
installed in the surgery, and other medical equipment.
(Note 2) The systems which involve human life and have great influence on the maintenance of the
public function mean the main control system of a nuclear power plant, safety and
protection system of a nuclear power facility, transport operation and control systems for
mass transportation, control systems of aviation and space systems, and other systems
and subsystems where safety is critical.
(Note 3) "Special care" means to build a safety system (foolproof design, fail safe design,
redundancy design, etc.) in full consultation with Toshiba's engineers.
Immunity
Toshiba is not liable for any loss caused by fire, earthquake, action by a third party, or other
accidents, or the operator's intentional or accidental misuse, incorrect use, or use under abnormal
condition.
Toshiba is not liable for any incidental loss caused by the use or non-use of this product, such as
loss of business profits, suspension of business, or loss or change of data on memory.
Toshiba is not liable for the loss caused by an operation contradictory to any of the instructions
stated in this manual.
Toshiba is not liable for the loss caused by an incorrect operation in combination with other
equipment.
Toshiba is not liable for the loss caused by a malfunction in combination with an application program
made by the customer.
NOTE:
Use cellular phones and PHSs at least one meter away from the working equipment, transmission
cables, and I/O bus cable. Otherwise, the system can malfunction.

6F8C0882 vii
Preface
The Toshiba Integrated Controller V series is a new integrated control system
suitable for the age of open and light-sizing. Based on the control and computer
technologies long accumulated, it implements an easy-to-use open system by
applying a standard multi-vendor network and simplified engineering package
software.
This manual describes the handling requirements, functions, and troubleshooting of
the V series model 3000 loop controller (L3 controller).
Be sure to read "Safety Precautions" before use, to ensure correct and safe
operation.
Note that the expenses for repair/replacement of worn or consumed products will be
charged even if request for the repair/replacement is made within the product
guarantee period.
For thorough understanding of the L3 controller, also refer to the following manuals:
•model 2000/3000 Loop Controller L2/L3 User's Manual - Functions (6F8C0885)
•model 3000 Ethernet Module User's Manual (6F8C0878)
•model 2000/3000 Serial Bus I/O Module User's Manual (6F8C0887)
•model 3000 Direct I/O Module User's Manual (6F8C0867)
•Engineering Tool - Basics (6F8C0875)
•OIS1200 User's Manual (6F8C0886)
This manual consists of the following chapters:
Chapter 1 Overview of Loop Controller L3
Describes the L3 controller system configuration, the module configuration of the
main unit, and the name and function of each module.
Chapter 2 Mounting, Dismounting & Cable Connection
Describes the methods for mounting/dismounting a basic base unit/fan unit, and
various modules, as well as for cable connection.
Chapter 3 Installation & Wiring
Describes the methods for grounding the L3 controller, and presents some example
grounding works.
Chapter 4 Startup & Shutdown
Describes the startup and shutdown procedures for L3 controller.
Chapter 5 Troubleshooting
Describes the troubleshooting functions of the L3 controller, such as trace function.
Chapter 6 Maintenance & Inspection
Describes the maintenance/inspection procedures for the L3 controller, such as
routine inspection and periodical inspection.

viii model 3000 Loop Controller L3 User’s Manual - Basic Hardware -
Be Sure to Observe the Following
Observe the following to ensure the safety of the operator in using the equipment and to
keep it in normal operating condition.
1. Carefully read the Operation Manual before use.
2. Avoid installing or keeping the equipment at any of the places or in the environment
mentioned below.
(1) Very dusty place
(2) Place where corrosive gases (SO2, H2S, etc.) are generated
(3) Place where the product may be exposed to vibration or shock
(4) Environment of low or high temperature deviating from the conditions for instal-
lation specified herein.
(5) Very humid place
3. If the ambient temperature or the internal temperature of the equipment has arisen
too high, or if the equipment has developed a fault, stop using it, switch power off,
and contact the nearest Toshiba service station.
4. Do not open the case of the equipment while it is in operation except when setting
the switches.
5. Do not attempt to modify the equipment.
6. Take care not to drop the EN7 module during transit.

CONTENTS
6F8C0882 ix
1 Overview of Loop Controller L3 . . . . . . . 1
1.1 L3 System Configuration . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Configuration of Main Unit . . . . . . . . . . . . . . . . . . . . . . 3
1.2.1 Single Configuration . . . . . . . . . . . . . . . . . . . . . . . . .3
1.2.2 Duplex Configuration . . . . . . . . . . . . . . . . . . . . . . . .4
1.3 Connection with Intelligent PI/O System . . . . . . . . . . . 5
1.4 Connection with G3 I/O System . . . . . . . . . . . . . . . . . 8
1.5 Connection with Engineering Tool . . . . . . . . . . . . . . . 10
1.6 Names and Functions of Modules . . . . . . . . . . . . . . . 11
1.6.1 L3 CPU module . . . . . . . . . . . . . . . . . . . . . . . . . . .13
1.6.2 Power Supply Module . . . . . . . . . . . . . . . . . . . . . .16
1.6.3 Expansion Interface Module . . . . . . . . . . . . . . . . .20
1.6.4 Basic Base Unit . . . . . . . . . . . . . . . . . . . . . . . . . . .27
1.6.5 Fan Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
2 Mounting, Dismounting & Cable
Connection . . . . . . . . . . . . . . . . . . . . . . . 29
2.1 Mounting/Dismounting of Base Unit and Fan Unit . . . 30
2.1.1 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
2.1.2 Dismounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
2.2 Mounting/Dismounting of Modules . . . . . . . . . . . . . . 32
2.2.1 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
2.2.2 Dismounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
2.3 Mounting/Dismounting of Line I/O Terminal Unit . . . . 35
2.3.1 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
2.3.2 Dismounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
2.4 Connection of External Cables to Line I/O
Terminal Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.5 Connection with Serial Bus . . . . . . . . . . . . . . . . . . . . 38
2.6 Connection with Engineering Tool . . . . . . . . . . . . . . . 39
3 Installation & Wiring . . . . . . . . . . . . . . . . 41
3.1 Installation Environment . . . . . . . . . . . . . . . . . . . . . . 42
3.1.1 Control Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
3.1.2 Environmental Conditions . . . . . . . . . . . . . . . . . . .43
3.1.3 Power Supply Equipment . . . . . . . . . . . . . . . . . . . .43
3.2 Carrying-in & Installation . . . . . . . . . . . . . . . . . . . . . . 45
3.2.1 Transportation Passage and Parking Space for
Trucks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
3.2.2 Unloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

CONTENTS
xmodel 3000 Loop Controller L3 User’s Manual - Basic Hardware -
3.2.3 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
3.2.4 Carry-in Entrance and Passage . . . . . . . . . . . . . . .46
3.2.5 Carrying-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
3.2.6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
3.3 Example of Console-mounted L3 . . . . . . . . . . . . . . . .50
3.3.1 Cautionary Requirements in Mounting
L3 Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
3.3.2 Mounting of External Power Supply Unit and
I/O System Power Supply Unit . . . . . . . . . . . . . . .51
3.4 Grounding of L3 Controller . . . . . . . . . . . . . . . . . . . . .52
3.4.1 Cautionary Requirements in Grounding the
L3 Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
3.4.2 Grounding Electrode . . . . . . . . . . . . . . . . . . . . . . .54
3.4.3 Ground Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
3.4.4 Example Grounding Work . . . . . . . . . . . . . . . . . . .56
3.5 After Wiring Work . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
4 Startup & Shutdown . . . . . . . . . . . . . . . . 59
4.1 Confirmation of Switch Settings . . . . . . . . . . . . . . . . .60
4.1.1 L3 CPU Module . . . . . . . . . . . . . . . . . . . . . . . . . . .60
4.1.2 Duplexing Interface Module (IF719/IF728/IF748) . .61
4.2 Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
4.3 Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
4.4 Confirmation of LED Status . . . . . . . . . . . . . . . . . . . .66
4.4.1 LED Status on L3 CPU Module in Single
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
4.4.2 LED Status on L3 CPU Module in duplex
configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
5 Troubleshooting . . . . . . . . . . . . . . . . . . . 69
5.1 Status LED Indication . . . . . . . . . . . . . . . . . . . . . . . . .70
5.2 Trace Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
5.3 Memory Clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
5.4 Formatting of E2PROM . . . . . . . . . . . . . . . . . . . . . . .73
5.5 Error Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
5.6 Forced Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
6 Maintenance & Inspection . . . . . . . . . . . 77
6.1 Routine Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . .78
6.2 Periodical Inspection . . . . . . . . . . . . . . . . . . . . . . . . . .79

CONTENTS
6F8C0882 xi
6.3 Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
6.3.1 Replacement of Battery . . . . . . . . . . . . . . . . . . . . .82
6.3.2 Checking and Adjustment of Output Voltage . . . . .83
A Table of Specifications . . . . . . . . . . . . . 85
A.1 General Specifications . . . . . . . . . . . . . . . . . . . . . . . 86
A.2 Functional Specifications . . . . . . . . . . . . . . . . . . . . . 87
A.3 Hardware Specifications . . . . . . . . . . . . . . . . . . . . . . 89
A.3.1 L3 CPU Module (L3PU11/L3PU21) . . . . . . . . . . . .89
A.3.2 Serial I/O Expansion Module (IF735) . . . . . . . . . .89
A.3.3 Duplexing Interface Module (IF719) . . . . . . . . . . .90
A.3.4 Power Module (PS791/PS791S) . . . . . . . . . . . . . .90
A.4 Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
A.4.1 Special Cable for Engineering Tool . . . . . . . . . . . .92
A.4.2 Serial Bus Relay Cable . . . . . . . . . . . . . . . . . . . . .92
A.4.3 Tracking Data Cable (TD) . . . . . . . . . . . . . . . . . . .93
A.4.4 Tracking Status Cable (TS) . . . . . . . . . . . . . . . . . .93
B Outline Drawing . . . . . . . . . . . . . . . . . . . 95
B.1 Basic Base Unit (BU748) . . . . . . . . . . . . . . . . . . . . . 95
B.2 L3 CPU Module (L3PU11/L3PU21) . . . . . . . . . . . . . 96
B.3 Power Supply Module (PS791/PS791S/PS735) . . . . 97
B.4 Serial I/O Expansion Module (IF735) . . . . . . . . . . . . 98
B.5 Duplexing Interface Module (IF719) . . . . . . . . . . . . . 99
C Table of Trace Information . . . . . . . . . 101
C.1 Error Trace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
C.2 Event Trace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

6F8C0882 1
1
Chapter 1 Overview of
Loop Controller L3
The loop controller L3 is a Toshiba Integrated Controller V series control station which
uses Ethernet control LAN. The L3 controller is composed of an L3 CPU module
(L3PU11/L3PU21), an Ethernet module (EN7 module) and various IF modules (all of
which constitute a main unit or basic unit), and I/O modules. The L3 CPU module has a
capacity for 512K steps of program and is capable of executing up to 256 loops of PID,
sequence and batch controls. With the serial bus duplexed (for standard specification)
for redundancy and the main unit adaptable to duplex configuration, the L3 controller is a
highly reliable control station. An object-oriented tool in compliance with the IEC61131-3
is available for control-function engineering, enabling efficient development of application
programs using the Ladder Diagram (LD), Function Block Diagram (FBD), and
Sequential Function Chart (SFC).
Figure 1-1 Appearance of the L3 Main Unit




2model 3000 Loop Controller L3 User’s Manual - Basic Hardware -
Chapter 1 Overview of Loop Controller L3
1
1.1 L3 System Configuration
The L3 controller is composed of a main unit and intelligent PI/O and G3 I/O modules
which are connected via serial bus and G3 I/O bus, respectively, with the main unit. The
main unit comprises a power supply module, an L3 CPU module, an EN7 module for
connection with an Ethernet control LAN, and other IF modules.
The following system configuration is possible for the L3 controller.
•Up to three CPU modules (S/L/C) are installable in the main unit, to implement a multi-
controller.
•A maximum of 16 L3 controllers and a maximum of eight control monitor stations
OIS1200 can be connected to a system via Ethernet control LAN (10BASE5/
10BASE2), which can be constructed for duplex configuration.
•The L3 controller communicates process information with each PI/O module via
duplex serial bus (standard) and a communication module. For the standard
specification, one line is connected to the serial bus. A maximum of four lines can be
connected to the serial bus. Each serial bus can accommodate up to 15
communication modules.
•As for G3 I/O modules, one basic base unit and a maximum of 28 expansion units (a
maximum of seven expansion units/line x 4 lines can be connected.
•The L3 controller can be used in single configuration, or in stand by duplex
configuration.
Figure 1-2 shows an example of L3 system configuration.
Figure 1-2 An Example of L3 System Configuration



























OIS Tool Ethernet
L3 CPU module
(L3PU**) Main unit (Single)
RS-232C Tool
4 lines max. 3 lines
1 line Serial bus
(line A/B)
Direct bus Communication
base unit 1-1 Communication
base unit 1-15
Terminal unit
Expansion unit 1-1 I/O bus
Expansion unit 1-7

6F8C0882 3
1.2 Configuration of Main Unit
1
1.2 Configuration of Main Unit
There are two types of basic base units for the L3 controller: one for single configuration
and the other for duplex configuration.
The L3 main unit (basic unit) comprises an L3 CPU module which is the core component
of the L3 controller, an EN7 module for connection to the Ethernet, various other IF
modules, and a power supply module which supplies power to each of these modules.
Each module is installed in each slot of the basic base unit.
1.2.1 Single Configuration
The basic base unit is available in four types which differ in the number of slots for
connection with station bus: 2-slot, 4-slot, 6-slot and 8-slot types. The power supply
module is installed in slot [PS], the L3 CPU module, EN7 module, and IF modules in the
station-bus-connectable slots ([S1] through [S*]: * represents number 1, 3, 5 or 7), and
G3 I/O modules in slots for connection with direct bus ([S#] through [S10]: # represents
number 2, 4, 6 or 8).
Figure 1-3 shows an example of basic unit in single configuration (BU748).
Figure 1-3 An Example of Basic Unit in Single Configuration (BU748)
Slot No. Module installed
[PS] Power supply module
[S0] Direct I/O expansion module
[S1] CPU module (G3 I/O access)
[S2] CPU/IF module
[S3] CPU/IF module
[S4] CPU/IF module
[S5] CPU/IF module
[S6] CPU/IF module
[S7] CPU/IF module
[S8] Direct I/O module
[S9] Direct I/O module
[S10] Direct I/O module



PS S0 S1 S2 S3 S4 S5 S6 S7 S8 S9 S10

4model 3000 Loop Controller L3 User’s Manual - Basic Hardware -
Chapter 1 Overview of Loop Controller L3
1
1.2.2 Duplex Configuration
Figure 1-4 shows an example of basic unit in duplex configuration (BU748) (implemented
on two single-configuration basic base units).
Figure 1-4 An Example of Basic Unit in Duplex Configuration (BU748)
(on Two Single-configuration Basic Base Units)
For the duplex-configuration basic unit on two single-configuration basic base units,
install a duplexing interface module in slot [S0].
Figure 1-5 shows another example of basic unit in duplex configuration (BU784).
Figure 1-5 An Example of Basic Unit in Duplex Configuration (BU784)
For this duplex configuration as well, install a duplexing interface module in slot [S0] of
each of the primary and secondary basic base units.
Slot No. Module installed
Primary
[PS] Power supply module
[S0] Duplexing interface module (with direct I/O expansion cable)
[S1] CPU module (G3 I/O access)
[S2] CPU/IF module
[S3] CPU/IF module
Secondary
[PS] Power supply module
[S0] Duplexing interface module (with direct I/O expansion cable)
[S1] CPU module (G3 I/O access)
[S2] CPU/IF module
[S3] CPU/IF module

6F8C0882 5
1.3 Connection with Intelligent PI/O System
1
1.3 Connection with Intelligent PI/O System
The L3 controller can be connected with an intelligent PI/O system via serial bus.
Connection with an intelligent PI/O system requires the following components, for system
construction:
•Communication base unit (USCB1)
•Communication module (SBIF1/SBIF2)
•Serial bus (ZCS004A***1)
•Terminal unit (UT***)
•I/O bus (ZCS005A***1)
•Terminal resistor (FSTM1)
•Serial bus terminator (UTMN3)
•Relay cable (ZCS010A***1)
•Relay terminal unit (4TBBEMB007F31S)
For connection of the main unit to an intelligent PI/O system, connect relay cable with
serial bus via the relay terminal unit. Standard serial bus is duplexed (lines A and B). A
maximum of 15 communication base units can be connected to each line of this serial
bus, and a maximum of 14 terminal units to I/O bus. Communication modules can also
be connected for duplex configuration. For duplex configuration, install two
communication modules in the communication base unit. For single configuration, install
one communication module on the left side (P).
Be sure to terminate the serial bus with a terminal resistor, and the I/O bus with a serial
bus terminator.
IMPORTANT
•Communication module (SBIF1) and high-speed communication module (SBIF2) cannot be
connected to the same I/O bus (the same communication base unit).

6model 3000 Loop Controller L3 User’s Manual - Basic Hardware -
Chapter 1 Overview of Loop Controller L3
1
Figure 1-6 shows example cable connections between the main unit and intelligent PI/O
system for duplex configuration.
Figure 1-6 Example Cable Connection with Intelligent PI/O System
Table 1-1 and table 1-2 give the specifications of various types of PI/O modules and
terminal units, respectively. Table 1-1 PI/O Modules
Name Type Specification
Analog input module SAI01 mV/V, 8 points
SAI02 1 to 5 Vdc, 4 points (Insulated)
SAI03 1 to 5 Vdc, 4 points (Insulated, equipped with
distributor)
SAI06 mV/V, 8 points (Duplex)
STC01 Thermocouple, 8 points (Insulated)
SRT01 Resistance bulb, 4 points (Insulated)
Analog output module SAO01 DC 4 to 20 mA, 8 points
SAO02 DC 4 to 20 mA, 4 points (Insulated)
SAO06 DC 4 to 20 mA, 8 points (Duplex)
Pulse input module SPI01 No-voltage contact/Voltage pulse, 4 points
Pulse output module SPO01 Open collector, 8-bit resolution, 4 points
Digital input module SDI01 24 Vdc - 5 mA, 32 points
Digital output module SDO01 24 Vdc - 100 mA, 32 points
Distributor module SDA01 Two-wire sensor power supply, 8 points
 
 
 
For one line
Main unit (Duplex)
3 lines
Relay cable
(Max length: 3 m)
Terminal
resistor Relay terminal
unit Serial bus (Max. length: 30 m)
One SBIF1 module
(Two modules for
duplex configuration)
One SBIF2 module
(Two modules for
duplex configuration)
Provided with
a terminal resistor
Same
as
left
Same
as
left
Same
as
left
PI/O module
(14 modules max.) PI/O module
(28 modules max. for
duplex configuration)
I/O bus
(Length: 5 m max.)
Terminal connector
