Cover
Unified C o n t r o l le r
nv series
TC-net I/O
Serial Communication Module IS911
Instruction Manual
6F8C1509

Notes
1. The technical information provided herein describes typical operations and applications of the product and
does not guarantee the intellectual property rights or other rights of Toshiba or third parties nor allows
license of its use.
2. No part or the whole of this document may be reproduced without prior consent.
3. The information herein may be changed in the future without notice.
4. All possible measures have been taken to prepare the information herein. If you have any question,
comment, or find any error, please contact us.
PROSEC, TOSLINE, TOSDIC are registered trademarks of Toshiba Infrastructure Systems & Solutions
Corporation.
Microsoft, Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.
Ethernet are registered trademarks of Xerox Corporation.
SYSMAC are registered trademarks of OMRON Corporation.
MELSEC are registered trademarks of Mitsubishi Electric Corporation.
© Toshiba Infrastructure Systems & Solutions Corporation. 2019
All rights reserved

Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
Safety Precautions
i
SafetyPrecautions
On the product and this operation manual, important information for safe and correct use to
prevent danger to the user and other people as well as property damage is described.
Understand the following information (signs and symbols) before reading the text, and follow
the described items.
Description of signs
Sign
Description
DANGER
Indicates that failure to avoid it will result in an immediate risk of death or
serious injury(*1).
WARNING
Indicates that failure to avoid it will result in a risk of death or serious
injury(*1).
CAUTION
Indicates that failure to avoid it will result in a risk of light or medium
injury(*2) or only property damage(*3).
*1: A serious injury indicates loss of sight, injury, burns (high/low temperature), electric shock, broken
bones, or intoxation that will have aftereffects and require hospitalization or long-term hospital visits
for healing.
*2: An injury indicates an injury, burn, or electric shock that does not need hospitalization or long-term
hospital visits for healing.
*3: A property damage indicates consequential damage in terms of breakage of properties or
materials.
Description of symbols
Symbol
Meaning
Prohibited
Indicates “Prohibition” or “You must not do”.
Specific details are indicated near the symbol with pictures and text.
Mandatory
Indicates “MandatoryAction”or “Do as indicated”.
Specific details are indicated near the symbol with pictures and text.
Warning
Indicates Warning.
Specific details are indicated near the symbol with pictures and text.
(Note) Descriptions of Prohibition, MandatoryAction, andWarning vary depending on the displayon the
main unit.

6F8C1509
ii
1. Safety Precautions on Installation
WARNING
Ground
Ground the device.
Otherwise, it may cause an electric shock
or fire.
CAUTION
Prohibited
Do not install, store, or use it
in the following environments.
A place with a lot of dust
A place with corrosive gases (SO2,
H2S) ore flammable gases
A place with vibrations and shocks
exceeding the allowed values
A place with condensations due to
rapid temperature changes
A place with low or high temperature
outside of the installation condition
A place with high humidity outside of
the installation condition
A place with direct sunlight
A place near equipment generating
strong radio waves or magnetic fields
It may cause accidents.
Mandatory
Install the device in a place
where maintenance and
inspection can be done easily.
Otherwise, it may cause accidents.
Prohibited
Do not block the ventilation
hole or air inlet/outlet.
It may cause fire or failure due to
overheat.
Mandatory
For installation and wiring of
the system, observe the
installation conditions and
methods described in this
document.
Otherwise, it may cause a fall, fire,
failure, or malfunction.

Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
iii
2. Safety Precautions on Maintenance and Inspection
WARNING
Mandatory
When installing or removing
the module after wiring, make
sure that the external power
supply is off.
Otherwise, there will be live electric
poles on the back of the external
terminal block of the module, causing an
electric shock.
CAUTION
Prohibited
Do not drop, crush, or apply
strong shocks to the device or
board.
It may cause failure.
Mandatory
Before touching the device or
board, touch a grounded
metal to discharge the static
electricity of your body.
Otherwise, it may cause malfunction or
failure due to static electricity.
Mandatory
Wipe off stain on the device,
module, or board with a soft
cloth.
For severe stain, use a wet cloth wrung
tightly.
Leaving them stained may cause wrong
decision or malfunction.
Mandatory
Place a board or module
removed from the unit or base
unit on a conductive mat or
conductive bag (used for a
backup board, etc.) on a
grounded table.
Otherwise, parts may be damaged due
to static electricity.
Prohibited
Do not use benzene or thinner
to remove stain on device,
module, or board.
It may cause deformation or
discoloration of the device panel,
module, or board.

6F8C1509
iv
3. Safety Precautions on Replacement of Life Limited Parts
WARNING
Mandatory
If the device has power fuses
or alarm fuses, when
replacing them, turn off the
switch of the device.
Otherwise, it may cause an electric
shock or fire.
4. Safety Precautions on Daily Use
WARNING
No touch
Do not touch the terminals of
the module and unit during
energization.
It may cause an electric shock.
Prohibited
Do not modify, repair,
disassemble, or adjust the
device, module, or board.
It may cause an electric shock, fire,
injury, or failure.
Upon faulty operation or failure, contact
our branch office or service offices.
Mandatory
Before using, check that the
power capacity, frequency,
voltage, and regulation
comply with the device
specifications.
If not, it may cause damage of the
device, or fire due to overheat, as well
as not obtaining the original
performance of the device.
Mandatory
When the ambient or internal
temperature of the device
rises abnormally or failure
occurs in the device, stop
using the device, turn off the
power, and contact one of our
service representatives.
Using it as it is may cause fire due to
overheat.
No touch
Do not touch the terminals of
the module and unit during
energization.
It may cause an electric shock.
The power supply module is for the nv
series only. Do not use it alone for any
other purposes.

Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
v
CAUTION
Prohibited
Do not touch anything other
than the operation part
(setting switches inside the
module), such as the IC parts
and terminals, connectors,
and soldered surfaces inside
the module.
Doing so may result in electrostatic
breakdown of the ICs and LSIs, causing
failure. Also, an injury may occur due
to the ends of the part lead wires, or
burns may occur due to hot parts.
Prohibited
Do not disassemble or modify
the device or module.
It may cause malfunction or failure as
well as loss of safety of the device.
Prohibited
Do not forcefully bend, pull, or
twist the power cord and
cables.
It may cause breaks or heating.
Prohibited
Do not insert any metal into
the gaps of the device main
body.
It may cause fire.
5. Safety Precautions on Transportation, Storage, and Disposal
CAUTION
Mandatory
Observe ordinances and
rules.
When destroying the product, observe
the ordinances and rules of the local
government.
Prohibited
For transportation and
storage of the product, use a
conductive bag and
packaging box.
Otherwise it will cause failure.

6F8C1509
vi
Restrictions on Application
This product is not developed/manufactured for use in systems involving devices that
directly affect human life (Note 1). Do not use them for such applications.
To use this product for systems that involve devices that significantly affect human safety or
maintenance of public functions (Note 2), special considerations (Note 3) are required in
system operation, maintenance, and management. In this case, contact one of our sales
representatives.
(Note 1) Devices that directly affect human life include the following.
Medical devices such as life supporting devices and devices for surgical units.
(Note 2) Systems that involve devices that significantly affect human safety or maintenance
of public functions include the following.
Main unit control systems of nuclear power plants, safety protection systems of
nuclear facilities, and other systems that are critical for safety
Operation control systems of mass transportation systems and air traffic control
systems
(Note 3) Special considerations indicate sufficient discussions with our engineers to
construct a safe system (e.g. employing fool-proof design, fail-safe design, or
redundant design).
Disclaimer
Toshiba shall not be responsible for any damage caused by fire or earthquake, acts of a
third party, other accidents, the user's willful acts or negligence, misuse, or use in abnormal
conditions.
Toshiba shall not be responsible for any incidental damage (loss of business profits,
interruption of business, change or loss of stored memory) caused by use of or being unable
to use this product.
Toshiba shall not be responsible for any damage caused by failure to observe the
information described in the operation manual.
Toshiba shall not be responsible for any damage caused by malfunctions due to
combination with any connected device.
Toshiba shall not be responsible for any damage caused by malfunctions due to
combination with any application program created by the customer.
Note
Use your cellular phone or PHS 1 meter or more away from the product main unit in operation,
various transmission cables, and I/O bus cable. Otherwise, the system may malfunction.

Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
vii
Introduction
This manual describes the functions, methods of installation and setting, and maintenance and
inspection of the IS911 Serial communication module ("IS911 module" hereafter) for connecting
to TC-net I/O of the Unified Controller nv series.
To use this device correctly, read "Safety precautions" first.
The manuals related to the IS911 module are as follows.
Unified Controller nv series Controller Unit Instruction Manual (6F8C1220)
Describes the unit hardware of the nv series controller.
Unified Controller nv series type 2 Function Manual (6F8C1362)
Describes the functions and basic use of the nv series type 2.
Unified Controller nv series/Integrated Controller V series Programming Instructions
(6F8C1226)
Describes the detailed specifications of the instruction words of the program languages
(LD, FBD, and SFC) supported by the nv series and Integrated Controller V series.
Unified Controller nv series/Integrated Controller V series Engineering Tool 4 (Basic)
Instruction Manual (6F8C1290)
Describes how to create, debug, print, and save programs using nV-Tool.
Introduction

6F8C1509
viii
●Notational conventions
The following are the notational conventions for better understanding of this document.
Important:
Describes what the user should be particularly aware of to handle the product correctly.
Note:
Describes what the user should observe to handle the product correctly.
Remark:
Describes a remark.
●Reading this document
This document consists of the following chapters.
Chapter 1 Introducing the IS911 module
Describes the functions, characteristics, and names and functions of the
parts.
Chapter 2 Installation and wiring
Describes how to install it to the basic unit and how to connect cables.
Chapter 3 Setting
Describes how to set the switches and parameters to use the module
correctly.
Chapter 4 Operation
Describes the operations such as checking before operation, startup, and
shutdown.
Chapter 5 Troubleshooting
Describes troubleshooting such as what to do when failure occurs.
Chapter 6 Maintenance and inspection
Describes troubleshooting regarding daily inspection and periodical
inspection and how to perform inspections.
Chapter 7 Application interface
Describes the user application interface and usage constraints.

Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
ix
CONTENTS
Chapter 1
Introducing the
IS911 Module
...1
1.1 Functions and Characteristics of the IS911 Module····· 2
1.2 Names and Functions of the parts······························4
1.2.1 Names of the parts ·············································· 4
1.2.2 Functions of the parts··········································· 5
1.3 Serial communication and Network configuration······· 7
1.3.1 SYSMAC host link serial communication··················· 7
1.3.2 MELESEC Computer link serial communication·········· 9
Chapter 2
Installation and
Wiring
...11
2.1 Types of I/O Base Units ············································ 14
2.2 Installing IS911 Module············································· 15
2.3 Replacing IS911 Module ··········································· 19
2.3.1 Remove·························································· 19
2.3.2 Installation······················································· 19
2.4 Transmission cable connection································ 20
2.4.1 Connection with SYSMAC (CS1W-SCB41-V1)········· 20
2.4.2 Connection with SYSMAC (C500-LK201)················ 21
2.4.3 Connection with MELSEC Aseries (AJ71UC24) ······· 22
2.4.4 Connection with MELSEC Q series (QJ71C24N) ······ 23
Chapter 3
Setting
...25
3.1 Switch Setting ························································ 26
3.1.1 TC-net I/O bus address switch (I/O)······················· 26
3.1.2 Operation mode setting switch (MODE)·················· 26
3.1.3 Maintenance switch (MAINT) ······························· 27
3.2 IS911 module registration and Parameter setting······ 28
3.2.1 System Registration··········································· 31
3.2.2 PLC Registration··············································· 33
3.2.3 Module Parameter Setting··································· 35
3.2.4 Talker Block Setting ··········································· 39
3.3 RAS data variables Registration······························· 44
Chapter 4
Operation
...45
4.1 Operation ······························································· 46
4.1.1 Checking before operation··································· 46
4.1.2 Startup operation··············································· 46
4.1.3 Stop operation·················································· 46

6F8C1509
x
Chapter 5
Troubleshooting
...47
5.1 Troubleshooting······················································· 48
5.1.1 Fault diagnosis method using LED ························ 48
5.1.2 Loading System Log and RAS Data······················· 49
5.1.3 Error code ······················································· 50
5.1.4 Others ···························································· 51
5.1.5 OIS Alarm Display ············································· 52
Chapter 6
Maintenance and
Inspection
...53
6.1 Inspection································································ 55
6.1.1 Daily inspection················································· 55
6.1.2 Periodical inspection ·········································· 55
6.2 Life Limited Parts····················································· 56
Chapter 7
Application
Interface
...57
7.1 Usage Constraints···················································· 58
7.1.1 Restriction on the number of mounting ··················· 58
7.1.2 The combination of firmware································ 58
Appendix A
Specifications
...59
A.1 General Specifications ············································· 60
A.2 IS911 Module Specifications····································· 61
Appendix B
Outside
Dimensions
...63
B.1 Outline drawing························································ 64
Appendix C
Related Products
...65
C.1 Related Products······················································ 66
Appendix D
Decimal-
hexadecimal
Conversion Table
...67
D.1 Decimal-hexadecimal Conversion Table ··················· 68

1
Chapter 1IntroducingtheIS911Module
Introducing the IS911
Module
This chapter describes the functions and characteristics of the IS911
module, and the names and functions of each part.
1.1 Functions and Characteristics of the IS911 Module······· 2
1.2 Names and Functions of the parts································ 4
1.2.1 Names of the parts ················································ 4
1.2.2 Functions of the parts············································· 5
1.3 Serial communication and Network configuration········· 7
1.3.1 SYSMAC host link serial communication····················· 7
1.3.2 MELESEC Computer link serial communication············ 9

Chapter 1 Introducing the IS911 Module
6F8C1509
2
1.1 Functions and Characteristics of the IS911 Module
IS911 module is a serial communication module used connecting with TC-net
I/O of unified controller nv series.
IS911 module can communicate between type2 controller of unified controller
nv series ("type2" or "type2 controller" hereafter), SYSMAC, or MELSEC.
Characteristics of the IS911 module
IS911 module can be connected with external equipment by RS-232C or
RS-485, and can perform data transmission. There are the following
characteristics in IS911 module.
Communication Protocol
The communication protocol supports SYSMAC host link method and
MELSEC computer link dedicated protocol format 4.
MELSEC has two types of commands, “ACPU common command” and “AnA
/ AnU common command”, depending on the frame format. For details, refer
to the "MELSEC" manual.
Command format
MELSEC series that can
communicate
Address
Number of
digits
Notation in
this manual
A series
Q series
ACPU common
command
〇
〇
4 digits
A
AnA/ AnU common
command
☓
〇
6 digits
Q
Data input / output
Data can be input / output by registering the link register type and address in
the module parameters of the IS911 module, and then assigning the size
and network variables to the Network Talker Block.
Standard input / output
By registering the above network variable in the process tag, the
transmission data can be taken into the tag variable.
Note
Only SYSMAC serial communication module (CS1W-SBC-V1 / C500-LK201) and
MELSEC computer link unit (AJ71UC24, QJ71C24N) can communicate with the
IS911 module.

1.1 Functions and Characteristics of the IS911 Module
Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
3
The function of IS911 module
Data is transmitted between the IS911 module and the PLC to read and
write PLC data. On the other hand, the type2 controller reads and writes
IS911 module transmission data via the TC-net I/O Loop. In this way, data is
exchanged between the type2 controller and the PLC.
The following figure shows a system configuration example using IS911
module.
PU821: type2 controller module
FN812: Interface module for DS connection
SA91*: TC-net I/O interface module
SA96*: TC-net I/O interface module (for instrumentation I/O module *1)
I/O: TC-net I/O Instrumentation I/O module
PLC: SYSMAC PLC or MELSEC PLC
*1: “SA911” is used to represent instrumentation I/O module models in the following figures.
Figure 1-1 System configuration example using IS911 module
I/O
I/O
I/O
SA961
SA961
IS911
PLC
TC-net I/O Loop
nv-type2
OIS-DS
Instrumentation I/O unit
（BU927F）
Data Transmission
（RS-232C or
RS-485 / RS-422）
PU821
FN812
PU821
FN812
SA911
SA911
Ethernet
nV Engineering tool
SA911 or SA961
is available.
Data input / output
via TC-net I/O Loop

Chapter 1 Introducing the IS911 Module
6F8C1509
4
1.2 Names and Functions of the parts
1.2.1 Names of the parts
Figure 1-2 shows the names of the parts of the IS911 module.
Figure 1-2 Names of the parts of the IS911 module
State display LED
RUN
ERR
I/O
TX
RX
MOD
Rotary setting switch
I/O
STN-H
STN-L
Operation mode setting switch
MODE
Maintenance Communication Port
TOOL
RS-485 I/F Terminal block
Maintenance Switch
RS-232C I/F Connector
IS911
TX RX MOD
RUN ERR I/O
STN-H
STN-L
I/O
TOOL
MODE
RS-232C
MAINT
↓RUN
RS-485
2W/4W
D1/TXD1
D0/TXD0
- /RXD1
- /RXD0
SG
1
2
3
4
5

1.2 Names and Functions of the parts
Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
5
1.2.2 Functions of the parts
The major functions of the parts are as shown below.
State display LED
RUN, ERR, and I/O indicate the hardware operating status.
Table 1-1 RUN, ERR, I/O display and contents
LED Name
Representation
Normal display
RUN
(Green)
Displays the hardware operation state. *1
ON
ON
Running
OFF
Down
ERR
(Red)
Displays the hardware operation state. *1
ON
ON
Down
OFF
Running
I/O
(Green)
I/O bus transmission
ON
ON
TC-net I/O bus side scan transmission is
being executed successfully
OFF
TC-net I/O bus side scan transmission is
being suspended
*1 : RUN LED and ERR LED light up immediately after the power is turned on.After
transmission parameters are automatically downloaded, the display will be
normal.
TX, RX, and MOD indicate the communication status.
Table 1-2 TX, RX, MOD display and contents
LED Name
Status
TX(Green)
RX(Red)
MOD(Green)
OFF
OFF
OFF
Initialization state
BLINK
BLINK
ON
Normal display
ON
―
―
Sending
―
ON
―
Receiving
―
―
ON
Normal on all communication requests
BLINK
BLINK
BLINK
Engineering information parameter range
check error
―
―
BLINK
Anomaly detection in some requests in
communication
―
―
OFF
Anomaly detection for all communication
requests

Chapter 1 Introducing the IS911 Module
6F8C1509
6
Rotary setting switch (I/O, STN-H, STN-L)
For setting method, refer to "Chapter 3 - 3.1 Switch Setting "
SW Name
Setting details
I/O
Used to set the TC-net I/O bus address.
STN-H
This setting is not used.
STN-L
Operation mode setting switch (MODE)
Used when removing a module. Refer to “Chapter 2 - 2.3 Replacing IS911
Module” and “Chapter 3 - 3.1 Switch Settings” for usage. Normally, set all to
OFF.
Maintenance switch (MAINT)
Switches to install or replace modules.
Refer to “Chapter 2 - 2.3 Replacing IS911 Module” and “Chapter 3 - 3.1 Switch
Settings” for usage.
SW Name
Setting details
MAINT
Please select before removing the IS911 module.
RUN
Please select after installing the IS911 module.
Maintenance communication port (TOOL)
A port for maintenance. It cannot be used by the user.
RS-232C I/F connector
RS-232C communication connector.
Refer to “Chapter 2 - 2.4 Transmission cable connection”to connect the
RS-232C transmission cable.
RS-485 I/F connector
RS-485 / RS-422 communication connector.
Refer to “Chapter 2 - 2.4 Transmission cable connection” to connect the
RS-485 / RS-422 transmission cable.

1.3Serial communication and Network configuration
Unified Controller nv series TC-net I/O Serial Communication Module IS911 Instruction Manual
7
1.3 Serial communication and Network configuration
The IS911 module serial communication supports SYSMAC host link method
and MELSEC computer link method communication protocol. Next, the network
configuration of serial communication is explained.
1.3.1 SYSMAC host link serial communication
The SYSMAC host link system supports 1:1 transmission using an RS-232C
line and 1:N transmission using an RS-485 / RS-422 line.
1. 1:1 transmission
The IS911 module and SYSMAC PLC can be connected via an RS-232C
line for 1:1 transmission.
The following figure shows a system configuration example for performing
1:1 transmission with SYSMAC PLC.
(1) Data is written and read by performing a SYSMAC host link transmission
between the IS911 module and the PLC.
(2) The type2 controller inputs / outputs IS911 module transmission data via
the TC-net I/O Loop.
PU821: type2 controller module
SA911: TC-net I/O IF module
IS911: Serial communication module
CPU: CPU unit
CMU: Serial communication board (CS1W-SCB41-V1)
Figure 1-3 System configuration example of 1:1 transmission of
SYSMAC host link
Note
Each station must be set with a station number. Set the station number so that
the station number does not overlap. (The station number can be set in the
range of 0 to 31.)
PU821
FN812
SA911
IS911
TC-net I/O Loop
RS-232C
(1) Host link type data
transmission
(2) Data input / output
via TC-net I/O Loop
SYSMAC PLC
CMU
CPU
Unified Controller nV
series type2

Chapter 1 Introducing the IS911 Module
6F8C1509
8
2. 1:N transmission
When IS911 module and SYSMAC PLC are connected via RS-485 line, up
to 32 SYSMAC PLCs can be connected to IS911 module.
The following figure shows a system configuration example for performing
1:N transmission with SYSMAC PLC.
(1) Data is written and read by performing a SYSMAC host link transmission
between the IS911 module and the PLC.
(2) The type2 controller inputs / outputs IS911 module transmission data via
the TC-net I/O Loop.
PU821: type2 controller module
SA911: TC-net I/O IF module
IS911: Serial communication module
CPU: CPU unit
CMU: Serial communication board (CS1W-SCB41-V1)
Figure 1-4 System configuration example of 1:N transmission of
SYSMAC host link
Note
For RS-485 / RS-422 line connection, connect a terminating resistor to the
communication module connected to the line end. Refer to “2.4 Transmission
Cable Connection” for how to attach a terminating resistor to the IS911 module.
Each station must be set with a station number. Set the station number so that
the station number does not overlap. (The station number can be set in the
range of 0 to 31.)
Only 4-wire (4W) lines can be used.
PU821
FN812
SA911
IS911
TC-net I/O Loop
RS-485
CMU
CPU
CMU
CPU
CMU
CPU
RS-485
RS-485
RS-485
Termination
ON
Connect the
terminating
resistor.
SYSMAC PLC
Station １
(1) Host link type data
transmission
(2) Data input / output
via TC-net I/O Loop
SYSMAC PLC
Station 0
SYSMAC PLC
Station ３１
Unified Controller nV
series type2
