Toshiba TOSVERT VF-AS3 User manual

E6582116
Instruction Manual for Load Reduction
NOTICE
1. Read this manual carefully before installing or operating the inverter.
2. All information contained in this manual will be changed without notice.

E6582116
Contents
1 Introduction .................................................................................................................................................................... 1
2 Installation...................................................................................................................................................................... 1
2.1 Installation environment...................................................................................................................................... 1
2.2 How to install ...................................................................................................................................................... 3
3 Load Reduction.............................................................................................................................................................. 5

1
E6582116
Depending on the way in which the inverter is installed, the ambient temperature and the carrier frequency setting, you may
need to reduce the inverter's continuous output current.
This instruction manual shows the output current reduction rate of each model in these graphs.
Take special care with the installation environment of the inverter. Install the inverter in a location that secures space for
ventilation and heat emitting (in the cabinet, etc.), considering heat generation and occurrence of noise.
2.1 Installation environment
This inverter is an electronic control instrument. Take full consideration to install it in the proper operating environment as
follows.
(1) Do not install in any location of high temperature, high
humidity, moisture condensation and freezing and avoid
locations where there is exposure to water and/or where
there may be large amounts of dust, metallic fragments and
oil mist.
1. Introduction
2. Installation
WARNING
Prohibited
• Do not place any inflammable object near the inverter.
If flame is emitted due to failure in the inverter, this will lead to fire.
• Do not install the inverter in any location where the inverter could come into contact with water or other
fluids.
This will result in electric shock or fire.
Mandatory
action
• Operate under the environmental conditions prescribed in the instruction manual.
Operations under any other conditions will result in failure.
CAUTION
Prohibited
• Do not install the inverter in any place with large vibration.
The unit will fall due to the vibration, resulting in injury.

2
E6582116
(2) Do not install in any location where corrosive gases or
grinding fluids are present.
(3) Operate in areas where ambient temperature ranges from
-15°C to +60°C.
• When using the inverter in locations with temperatures above 50°C, remove
the top cover and operation panel of the inverter to use it.
For details of how to remove the top cover, refer to [2. 2] of instruction manual
(E6582062).
• The inverter is a heat-emitting body. Make sure proper space and ventilation
are provided when installing in the cabinet.
• Measure the ambient temperature in the positions shown in the figure on the
right.
(4) Do not touch the heat sink as it may have a high tempera-
ture.
(5) Do not install in any location subject to large amounts of
vibration.
• If the inverter is installed in a location that is subject to vibration, anti-vibra-
tion measures are required. Please consult with your Toshiba distributor
about these measures.
(6) If the inverter is installed near any of the equipment
listed below, provide measures to insure against
errors in operation.
• Solenoids: Attach a surge suppressor on the coil.
• Brakes: Mount a surge absorber on the coil.
• Magnetic contactors: Mount a surge absorber on the coil.
• Resistors: Place far away from the inverter.
Position for measuring
ambient temperature
Measurement
position
Measurement
position
5 cm 5 cm
10 cm
Resistors

3
E6582116
2.2 How to install
Select an indoor location with good ventilation, and then install the inverter upright on a flat metal plate.
For the positions and sizes of the mounting holes, refer to [12. 2] of instruction manual (E6582062).
■If multiple inverters are installed
To install multiple inverters in one location, either normal basic installation or side-by-side installation (to align inverters
side-by-side horizontally with no space) can be adopted.
WARNING
Prohibited
• Do not install and operate the inverter if it is damaged or any of its components is missing.
This will result in electric shock or fire. Please call your Toshiba distributor for repairs.
Mandatory
action
• Mount the inverter on a metal plate.
The rear panel will get high temperature. Do not mount the inverter on an inflammable object, this will
result in fire.
• Do not operate the inverter with the front cover removed.
The unit contains high voltage parts and contact with them will result in electric shock.
• An emergency stop device must be installed that is configured in accordance with the system
specifications.
If such an emergency stop device that can activate mechanical brake by shutting off power supply is not
installed, operation cannot be stopped immediately by the inverter alone, thus resulting in an accident or
injury.
• All options to be used must be those specified by Toshiba.
The use of options other than those specified by Toshiba will result in an accident.
CAUTION
Prohibited
• For transporting or carrying the inverter, do not hold by the front cover.
The cover will come off and the unit will drop, resulting in injury.
Mandatory
action
• Carry the inverter by two people or more when the inverter is the model mass 20kg or more (VFAS3-
2110P - 2370P, VFAS3-4220PC - 4750PC).
If you carry the inverter alone, this will result in injury.
• Install the inverter at a place which can support the unit's mass.
If you install the inverter at a place which does not support the unit's mass, the unit will fall, resulting in
injury.
• Install the mechanical brake when it is necessary to hold a motor shaft.
A brake function of the inverter cannot perform mechanical hold, and it results in injury.

4
E6582116
1) Basic installation
When installing multiple inverters, leave at least 11 cm or more of space between each inverter and install them
aligned horizontally.
When using the inverter in locations with temperatures above 50°C, remove the top cover and operation panel of the
inverter (refer to [2. 2] of instruction manual (E6582062)) and use the inverter with the output current reduced (refer
to [3]).
2) Side-by-side installation
To align the inverters side-by-side horizontally with no space, remove the top cover of the inverter before use (refer
to [2. 2] of instruction manual (E6582062)). When using the inverter in locations with temperatures above 50°C, use
the inverter with the operation panel removed and use the inverter with the output current reduced (refer to
"Instruction manual for load reduction").
The space shown in the figure above is the minimum allowable space. Because the inverter has cooling fans built in
on the top or bottom surfaces, make the space on top and bottom as large as possible to allow for air passage.
Type H1(cm) H2(cm) H3(cm)
VFAS3-2004P - 2370P
VFAS3-4004PC - 4750PC 10 10 10
VFAS3-2450P, 2550P
VFAS3-4900PC - 4132KPC 25 25 25
VFAS3-4160KPC 15 15 25
VFAS3-4200KPC - 4280KPC 20 15 25
Important
• Do not install in any location with high humidity or high temperatures and where there are large amounts
of dust, metallic fragments and oil mist.
Memo • We also provide models with IP55 protective construction for adverse environments.
11 cm
or more
11 cm
or more
H 2 or more
H 1 or more
H 3 or more
H 3 or more

5
E6582116
Depending on the way in which the inverter is installed, the ambient temperature and the carrier frequency setting, you may
need to reduce the inverter’s continuous output current.
Reduction rates vary depending on the inverter capacity.
The 100% value of output current shown in these graphs is output current value shown in [12.1] of instruction manual
(E6582062).
■VFAS3-2004P
■VFAS3-2007P
■VFAS3-2015P
3. Load Reduction
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C

6
E6582116
■VFAS3-2022P
■VFAS3-2037P
■VFAS3-2055P
■VFAS3-2075P
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C

7
E6582116
■VFAS3-2110P
■VFAS3-2150P
■VFAS3-2185P
■VFAS3-2220P
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C

8
E6582116
■VFAS3-2300P
■VFAS3-2370P
■VFAS3-2450P
■VFAS3-2550P
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
40°C or less
40.1°C to 50°C
50.1°C to 60°C
Ambient temperature
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C

9
E6582116
■VFAS3-4004PC
■VFAS3-4007PC
■VFAS3-4015PC
■VFAS3-4022PC
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C

10
E6582116
■VFAS3-4037PC
■VFAS3-4055PC
■VFAS3-4075PC
■VFAS3-4110PC
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C

11
E6582116
■VFAS3-4150PC
■VFAS3-4185PC
■VFAS3-4220PC
■VFAS3-4300PC
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
Continuous output current
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
40%
50%
30%
4kHz1kHz 8kHz 12kHz 16kHz
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
Continuous output current
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
40%
50%
30%
4kHz1kHz 8kHz 12kHz 16kHz

12
E6582116
■VFAS3-4370PC
■VFAS3-4450PC
■VFAS3-4550PC
■VFAS3-4750PC
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
4kHz1kHz
Continuous output current
8kHz 12kHz 16kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
Continuous output current
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
40%
50%
30%
4kHz1kHz 8kHz 12kHz 16kHz
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C

13
E6582116
■VFAS3-4900PC
■VFAS3-4110KPC
■VFAS3-4132KPC
■VFAS3-4160KPC
HD ND
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C

14
E6582116
■VFAS3-4200KPC
■VFAS3-4220KPC
■VFAS3-4280KPC
HD ND
HD ND
HD ND
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 50°C
50.1°C to 60°C
110%
100%
90%
80%
70%
60%
50%
40%
2.5kHz1kHz
Continuous output current
4kHz 6kHz 8kHz
Carrier frequency (f300)
Ambient temperature
40°C or less
40.1°C to 45°C
50.1°C to 60°C
45.1°C to 50°C

©Toshiba Schneider Inverter Corporation 2016
