Toshiba Strata CTX DKT2001 Service manual

Strata®DK
Technical Bulletin
1 of 1
Toshiba America Information Systems, Inc.
Telecommunication Systems Division
9740 Irvine Blvd., Irvine, CA 92618-1697 [phone]
http://telecom.toshiba.com
Di
g
ital Sin
g
le Line Telephone
I&M and Pro
g
rammin
g
Updates
Version D.1 to D.2
The pages included with this bulletin will update your Strata DK Installation and Maintenance
(I&M) and Programming Manuals to documentation version D.2.
Recently, we started shipping Strata DK Digital Single Line Telephones (DKT2001). Enclosed are
two update pages with instructions on installing and programming the DKT2001. The Digital
Single Line Telephone User Guide (DKA-UG-DKSLT-VA) is also available for operating
instructions.
♦Insert the enclosed Page 9-53/9-54 at the end of Chapter 9 – Station Apparatus into your
Strata DK I&M Manual.
♦Remove the existing Page 3-113/3-114 from your Strata DK Programming Manual and
replace it with the enclosed updated page.
Programming Considerations
One of the differences between the Strata DKT2001 and the other Strata DK 2000-series
telephones is that the DKT2001 has a single flexible feature button. This difference requires a
modified approach to programming the DKT2001.
Important! The
 button on the DKT2001 is flexible button 01. Only program a [PDN] onto
this button. Do not program CO lines or secondary line appearances onto button 01
or in any other position. Since the system assigns CO lines 01~17 by default, be sure
to remove any CO line appearances by programming them as Station Speed Dial
buttons (code ).
4031049
TBDK-0021
October 19, 1998

Station Apparatus DKT2001 Digital Single Line Telephone
9-53
Strata DK I&M September 1998
DKT2001 Digital Single Line Telephone
The following provides information on how to connect the
DKT2001 Digital Single Line Telephones (SLTs) to the DK
system.
Before proceeding, see warning and caution notes in “Telephone
Installation”.
The digital SLTs connect to the digital telephone ports via the
MDF with standard twisted-pair jacketed telephone cable. If
using 24 AWG cable, single-pair wiring is sufficient inmost cases
for DKT2001 model standard telephones to operate effectively at
up to 1000 feet from the system.
To accommodate the digital telephone line cord, the cable should
be terminated in a modular station connector block (RJ-11) at the
station location. The standard single-pair, modular DKT2001
model standard telephone cord that is sent with the telephone is 7 ft. (the maximum allowed is
25 ft.).
Digital telephone cable runs must not have cable splits (single or double), cable bridges (of any
length), or high resistance or faulty cable splices.
➤To wall mount DKT2001 digital SLTs
1. Loosen the screws, and remove the
telephone base.
2. Using a suitable cutter, remove the
handset hanger from the base.
3. Insert the handset hanger in the slot on
the front of the phone. The hanger fits
in the notch on the handset cradle.
4. Rotate the telephone base 180 degrees
and secure it to the telephone with its
four screws.
5. Connect the phone to the wall modular
connector with a cord approximately
four inches long (available at most
telephone supply companies).
6. Route the cord into the hollow portion
of the base.
7. Mount the phone on the wall mounting
modular connector plate.
Handset Hanger
3633
Figure 9-20 Removing the Telephone Base

DKT2001 Digital Single Line Telephone Station Apparatus
9-54 Strata DK I&M September 1998
Installation
1. Set the DIP switches to match
Figure 9-21.
2. If required to achieve maximum
distance (greater than 1000 ft.),
install a two-pair house cable (or
external power).
Programming
Program 03: Specify Code 61 to
indicate a station line PDKU2.
Program 27: Adjusts initial off-hook
volume level for digital telephone
handsets.
Program 38: Specify Code 21.
Program 39: Specify button 01 as a
[PDN].
Important! Do not program CO lines or
secondary line appearances onto
button 01or in any other position.
Since the system assigns CO lines
01~17 by default, be sure to
remove any CO line appearances
by programming them as Station Speed Dial buttons (code ).
Note If the
   button is removed, the key becomes the  

button. While on an outside call, the user must press then  to activate the
and
 DTMF tones for the duration of the call.
Program 92-5: Initializes initial ringing, speaker, and muted ring volume levels of digital
telephones.
Also, refer to the Numerical Programming Listing in the Strata DK Programming Manual for
other station-related programs.
3482
1
ON
234
1
ON
234
Figure 9-21 DKT2001 Single Line Digital
Telephone Settings

System & Station Program 39 Flexible Button Assignments
3-113
Strata DK Programming September 1998
Program 39
Flexible Button Assignments
Processor Type:
DK14, DK40, All RCTUs
Program Type:
Station
Initialized Default:
See Program 38



 



                   
Port No. _______ 10 ❏
20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏
Location: Location: Location: Location:
Button Code Button Code Button Code Button Code Button Code Button Code Button Code Button Code
10 20 10 20 10 20 10 20
09 19 09 19 09 19 09 19
08 18 08 18 08 18 08 18
07 17 07 17 07 17 07 17
06 16 06 16 06 16 06 16
05 15 05 15 05 15 05 15
04 14 04 14 04 14 04 14
03 13 03 13 03 13 03 13
02 12 02 12 02 12 02 12
01 11 01 11 01 11 01 11
Port No. _______ 10 ❏
20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏
Location: Location: Location: Location:
Button Code Button Code Button Code Button Code Button Code Button Code Button Code Button Code
10 20 10 20 10 20 10 20
09 19 09 19 09 19 09 19
08 18 08 18 08 18 08 18
07 17 07 17 07 17 07 17
06 16 06 16 06 16 06 16
05 15 05 15 05 15 05 15
04 14 04 14 04 14 04 14
03 13 03 13 03 13 03 13
02 12 02 12 02 12 02 12
01 11 01 11 01 11 01 11
Port No. _______ 10 ❏
20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏Port No. _______ 10 ❏ 20 ❏LCD ❏ DIU ❏
Location: Location: Location: Location:
Button Code Button Code Button Code Button Code Button Code Button Code Button Code Button Code
10 20 10 20 10 20 10 20
09 19 09 19 09 19 09 19
08 18 08 18 08 18 08 18
07 17 07 17 07 17 07 17
06 16 06 16 06 16 06 16
05 15 05 15 05 15 05 15
04 14 04 14 04 14 04 14
03 13 03 13 03 13 03 13
02 12 02 12 02 12 02 12
01 11 01 11 01 11 01 11
Enter the port number(s) to which class of
service must be assigned. To add a port range,
enter XXX*XXX (low port *high port).
Code
Press LED Button to be defined.
SELECT = Port Number

Program 39 Flexible Button Assignments System & Station
3-114 Strata DK Programming September 1998
