Strata CIX100
Big Capability for Small Business
Small businesses need a flexible telecommunication system
that can easily adapt to your changing and growing needs. The
Strata®CIX™100 is specifically designed to provide the exact
telecommunication features your business requires today, and
as it grows in the future. That makes the Strata CIX100 the
ultimate cost-effective telecommunication solution to give
you the investment protection you need.
Toshiba’s expertise makes the Strata CIX100 the optimum solution,
whether you need a basic telephone system or advanced capabilities.
For example, you can add valuable options like Voice Mail/
AutoAttendant/Unified Messaging, Automatic Call Distribution,
Voice Over Internet Protocol, Strata Net multiple system networking,
FeatureFlex®adaptability/customization tools, and more to
improve your business’ overall productivity and customer service.
SYSTEM
APPLICATIONS COLLABORATION
UNIFIED
COMMUNICATIONS
PRODUCT
OVERVIEW
CALL
CENTER
TOSHIBA
OVERVIEW
SPECIFICATIONS
CIX100-S Capacities Base configuration 16 ports (combination of trunks and endpoints) expandable to CIX100 full capacity 112 ports (64 trunks/72 endpoints).
CIX100 Capacities 64 trunks or 72 endpoints and combinations up to 112 total.
Chassis Base Cabinet Expansion Cabinet
Measurements
Metric
English
Width
302 mm
11.9 in.
Height
371 mm
14.6 in.
Depth
259 mm
10.2 in.
Weight
8.8 kg
19.4 lbs.
Width
203 mm
8 in.
Height
371 mm
14.6 in.
Depth
259 mm
10.2 in.
Weight
6.9 kg
15.2 lbs.
Power Supply Unit (PSU) Initially Built-in (one per cabinet).
Primary AC Power Input AC 120VAC, 4.0 amps maximum.
AC Frequency Single-phase (48Hz - 62Hz).
100 watts per cabinet (maximum).
Power Backup Two or four 12VDC external batteries (80 ampere-hours max.) with ABCS charger can provide power
backup operation for 12 - 50 hours depending upon configuration (batteries and ABCS optional).
Chassis Installation Wall-mount (preferred) or Table top.
Compliance Safety: UL
EMC: FCC Part 15 Class A (Subpart A)
HAC and Volume Control: FCC Part 68
Network safety: TIA-968-2-A
FCC Registration PBX: CJ6MUL-35931-PF-E
Hybrid: CJ6MUL-35930-MF-E
Key: CJ6MUL-35929-KF-E
Operating Temperature 32~104° F (0~40° C)
Operating Humidity 20~80% Relative humidity without condensation
Storage Temperature -4~140° F (-20~60° C)
Voice Mail Compatibility Strata Media Application Server, Stratagy®ES, iES16, LVMU1A, Strata Messaging
Trunk Compatibility Analog: Loop or ground start, DID, E&M
Digital: T1 and ISDN PRI
IP: Strata Net IP Networking, SIP Trunking
E911: ISDN PRI

Toshiba America Information Systems, Inc.
Telecommunication Systems Division
9740 Irvine Blvd., Irvine, CA 92618-1697
To locate an Authorized Dealer, call: [phone]
National Accounts [phone]
www.telecom.toshiba.com
© 2011 Toshiba America Information Systems, Inc. All product, service and company names are trademarks,
registered trademarks or service marks of their respective owners. Information including without limitation
specifications, availability, content of services, and contact information is subject to change without notice.
Literature Order #:TSD-CIX-BR-100-DS-VJ/4500145
SPECIFICATIONS
IP Telephone Compatibility Toshiba IP5000-Series MEGACO+ models:
nIP5022-SD full-duplex speakerphone with 10 programmable
buttons, 4-line x 24-character LCD, and Gigabit Ethernet
switch for PC connection.
nIP5122-SD full-duplex speakerphone with 10 programmable
buttons, 4-line x 24-character Backlit LCD with contrast
adjustment, and Gigabit Ethernet switch for PC connection.
nIP5122-SDC full-duplex speakerphone with 10 programmable
buttons, 4-line x 24-character Backlit LCD with contrast
adjustment, analog CO line interface, and Gigabit Ethernet
switch for PC connection.
nIP5132-SD full-duplex speakerphone with 20 programmable
buttons, 4-line x 24-character Backlit LCD with contrast
adjustment, and Gigabit Ethernet switch for PC connection.
nIP5131-SDL full-duplex speakerphone with 20 programmable
buttons and LCD key labels, 4-line x 24-character Backlit LCD
with contrast adjustment, and Gigabit Ethernet switch for
PC connection.
nIP5522-SD full-duplex speakerphone with 10 programmable
buttons, 4-line x 24-character LCD, and 10/100 Ethernet
switch for PC connection.
nIP5531-SDL full-duplex speakerphone with 20 programmable
buttons and LCD key labels, 4-line x 24-character LCD, and
10/100 Ethernet switch for PC connection.
nIP5622-SD full-duplex speakerphone with 10 programmable
buttons, 4-line x 24-character Backlit LCD with contrast
adjustment, and 10/100 Ethernet switch for PC connection.
nIP5631-SDL full-duplex speakerphone with 20 programmable
buttons and LCD key labels, 4-line x 24-character Backlit LCD
with contrast adjustment, and 10/100 Ethernet switch for
PC connection.
802.3af Power-over-Ethernet compliant.
802.1Q Virtual Local Area Network (VLAN) compliant.
Digital Telephone
Compatibility
Toshiba DP5000-Series models:
nDP5008 single-line telephone with one programmable button.
nDP5018-S speakerphone with 10 programmable buttons.
nDP5022-SD speakerphone with 10 programmable buttons and
4-line x 24-character LCD with contrast adjustment.
nDP5122-SD speakerphone with 10 programmable buttons and
4-line x 24-character Backlit LCD with contrast adjustment.
nDP5032-SD speakerphone with 20 programmable buttons
and 4-line x 24-character LCD with contrast adjustment.
nDP5132-SD speakerphone with 20 programmable buttons and
4-line x 24-character Backlit LCD with contrast adjustment.
nDP5130-SDL speakerphone with 20 programmable LCD-label
buttons and 4-line x 24-character Backlit LCD with contrast
adjustment.
Analog Device Compatibility Dealer-supplied standard telephones with or without Caller ID, FAX machines, modems, etc.
Answer Position Options LM5110 Add-On Module with 10 programmable Backlit LCD-label buttons.
KM5020 Add-On Module with 20 programmable buttons.
IDM5060 and DDM5060 DSS/BLF Console with 60 programmable buttons.
Strata PC Attendant Console.
User Mobility Options uMobility dual-mode smartphones via W-Fi and cellular networks.
SoftIPT®soft phone client on laptop or tablet PC via Wi-Fi Wireless LAN or Internet.
SoftIPT soft phone client on PDA via Wi-Fi Wireless LAN.
Wireless IP telephone support via Wi-Fi Wireless LAN.
Cordless digital telephone.
IP4100 Wireless SIP DECT Telephone.
System Administration Browser-based unified administration of PBX and voice mail functions.
Network eManager®centralized installation/maintenance of all Strata CIX systems for technicians and administrators.
eMonitor monitoring of alarm conditions from multiple Strata CIX systems.
My Phone Manager®personal administration for individual users.
Traffic measurement reports stored on local SD flash memory card.
Standard System Features Over 300 standard telephony features to provide the functionality you need.
Advanced Application
Options
Add valuable options like Voice Mail/Auto Attendant, Unified Messaging, Fax Integration, Automated Speech Recognition,
Text-To-Speech, Interactive Voice Response, Automatic Call Distribution and Reporting, Voice Over Internet Protocol,
Strata Net multiple system networking, FeatureFlex adaptability/customization tools, centralized network SMDR, and more.
Multi-system Networking Strata Net networking of up to 128 nodes via IP or ISDN PRI.
Feature Customization FeatureFlex adaptability tools for feature creation/customization.
