Toshiba TCB-IFDMX01UP-E User manual

VRF DX COIL INTERFACE
MODEL NAME
Dx-coil controller
TCB-IFDMX01UP-E
(Terminal block without relay)
TCB-IFDMR01UP-E
(Terminal block with relay)
Dx-valve kit
RBM-A101UPVA-E
RBM-A201UPVA-E
Design Guideline
DG003-03

1. Application
…………… 1
2. System compatibility, Overview
…………… 2
3. Operating conditions
…………… 3
4.
Pipe Size
…………… 4
5. Pipe length and height difference
…………… 5
6. Product Configuration
6.1. Product Configuration
…………… 6
6.2. Major Specifications
…………… 8
6.3. Control Input / Output Details
…………… 9
7. AHU / DX COIL Design
7.1. Equipment selection procedure -Selection flow chart-
…………… 20
7.2. Correction charts for Outdoor unit capacity calculation
…………… 21
7.3. Charging requirement with additional refrigerant
…………… 21
7.4. How to select DX COIL Design Guideline
…………… 22
7.5. DX COIL Guideline HP
…………… 23
7.6. DX COIL Guideline CO Pattern A
…………… 27
7.7. DX COIL Guideline CO Pattern B
…………… 31
7.8. DX COIL Guideline TF
…………… 35
7.9. DX COIL Manufacturing
…………… 37
7.10. DX Controller Installation
…………… 37
7.11. Sensor Connections
…………… 38
7.12. Dx-valve KIT Installation
…………… 39
8. Control Outline
8.1. Cautions regard with DDC's programing
…………… 41
8.2. Protection Function Summary
…………… 42
9. Cable specifications
…………… 43
10. Modbus setting method
…………… 44
11. Function code (DN code)
…………… 47
12. Dx-coil Controller , Dx-valve kit Dimensions
…………… 48
13. Wiring Diagram
…………… 50
14. Compatibility with R/C, BMS, Open network system
…………… 52
15. Check Codes
…………… 54
16. Related cautions
…………… 55
17. Warranty
…………… 55
CONTENTS

1. Application
The VRF Dx-coil Interface comes with DX-coil Controller which has 3 types of application（DDC type,TA type,TF type）.
Application types can be set and enable system to response according to the application.
・
TA type :(Main application target
– Room temperature conditioning)
The VRF Dx-coil Interface(TA type) enables TA control of Toshiba Outdoor units connected to
a DX COIL (with a field supplied AHU). It is compatible with either a Toshiba VRF system.
・
DDC type :(Mainly discharge air temperature control linked AHU system.)
The VRF Dx-coil Interface(DDC type) enables BMS capacity demand control of Toshiba Outdoor units
connected to a DX COIL (with a field supplied AHU). It is compatible with either a Toshiba VRF system.
・
TF type :(Main application target
– Ventilation)
The VRF Dx-coil Interface(TF type) enables TF control of Toshiba Outdoor units connected to
a DX COIL (with a field supplied AHU). It is compatible with either a Toshiba VRF system.
Settings for each type (TA, TF, DDC)
Set with the SW501 switch on the control P.C. board MCC-1777.
TA Type ： SW501 all Bit=OFF
TF Type ： SW501 Bit2=ON
DDC Type （0-10V) Stepped Control：SW501 Bit3=ON
DDC type (0-10V) Linear Control ： SW501 Bit3,Bit４ = ON
Product Model name Capacity HP
RBM-A101UPVA-E 22.4kW , 28.0kW , 33.5kW 8 , 10 , 12*
RBM-A201UPVA-E 40.0kW , 45.0kW , 50.4kW , 56.0kW 14*, 16 , 18 , 20
＊12HP，14HP designed to connect with SMMS-u,SMMS∞ only.
Dx-valve kit
Dx-coil controller
TCB-IFDMX01UP-E
（Terminal block without relay)
22.4kW , 28.0kW , 33.5kW ,40.0kW , 45.0kW ,
50.4kW , 56.0kW
8 , 10 , 12 , 14 , 16 ,
18 , 20
TCB-IFDMR01UP-E
（Terminal block with relay)
61.5kW~336.0kW will be in form of
combinations.
22~120 in
combinations.
SW501
SW501︓type setting
Bit1 Bit2 Bit3 Bit4
ON - TF type 0-10V type*2 Liner AI
OFF - TA type - *1 Stepped AI
*1︓When Bit3 is OFF, type depends on the Bit2 setting.
*2︓When Bit3 is ON, Bit2 setting is invalid.(Type is 0-10V type.)
P1

2. System compatibility, Overview
・ Outdoor Unit
- SMMS-u Heat Pump Model (MMY-MUP✻✻✻1HT8✻P✻ / MMY-MUP✻✻✻1HT7✻P✻)
-
SMMS
∞
Cooling Only Model (MMY-MUP
✻✻✻1
T8
✻
P
✻ /
MMY-MUP
✻✻✻1
T7
✻
P)
-
SMMS-7 Model (MMY-MAP
✻✻✻7
T8
✻
P
✻ /
MMY-MAP
✻✻✻7
T7
✻
P)
-
SMMS-e Heat Pump Model (MMY-MAP
✻✻✻6
HT8
✻
P
✻ /
MMY-MAP
✻✻✻6
HT7
✻
P
✻)
- SMMS-e Cooling Only Model (MMY-MAP✻✻✻6T8✻P✻ / MMY-MAP✻✻✻6T7✻P)
-
SHRM-e (MMY-MAP
✻✻✻6
FT8
✻
P
✻ /
MMY-MAP
✻✻✻6
FT7
✻
P
✻) (8
HP, 10 HP only)
TA type
・
Diversity
-
60% - 110%
・
Overview
For example schematic of system ;
DDC type
（
１
：
１
only
）
・
Diversity
-
75% - 100%
・
Overview
For example schematic of system ;
Type SMMS-u SMMS∞ SMMS-7 SMMS-e SHRM-e
(communication)
TA type
DDC type ×
TF type × × ×
(TU2C-LINK or TCC LINK) (TCC-LINK)
○60-110%
○75-100%
○80-100%
P2

TF type(1
：1
only)
・
Diversity
-
80% - 100%
・
Overview
For example schematic of system ;
3. Operating conditions
Ensure the "Coil on Air" temperature is within the range of the Dx-coil design guideline.
OA
Outdoor Air
SA
Supply Air
CA
Coil on Air
(After Heat Recovery Exchanger)
RA Return Air
EA
Exhaust Air
AHU
Note: If intake air temperature is out of range of the specification, the damage for the
system may be caused.
Outdoor unit Refer to specification of outdoor unit
15 - 24 C WB 15 - 32 C WB
*Outdoor unit model or select cooling only mode with HP model
**Outdoor/Suction air temp. 46 - 52 °C(DB) is also available but Temporaty operatable.
TF or DDC
TA or DDC
Control
HP(TA)
(Heating & Cooling)
Cooling Only*
Pattern A
Pattern B
HP(TF)
(Heating & Cooling)
(
18
-
43
C DB
)
Heating mode "Coil on Air" temp. 12 - 28 C DB
(Pull down to 7 C)
－10 - 15 C DB
--- ---
Cooling mode "Coil on Air" temp.
15
-
24
C WB
10
-
32
C WB
(
18
-
32
C DB
)
(
19
-
46
C
**
DB
)
(
18
-
32
C DB
)
P3

4. Pipe Size
・
Maximum real piping length between valve kit and Dx coil is up to 5 m.
28~34
36~42
Ø 38.1
Ø 22.2
76~92
Ø 54.0
94~
Ø 25.4
44~52
54
Ø 41.3
56~60
62~74
Ø 44.5
8
Ø 19.1
Ø 12.7
10
Ø 22.2
12
Ø 28.6
14~18
Ø 15.9
20
22
Ø 19.1
24~26
Ø 34.9
Outdoor Unit Capacity
Pipe diameter
(1) Gas pipe (2) Liquid pipe (3)Liquid Pipe
P4

5. Pipe length and height difference
Item
Main pipe equivalent length
Total piping length
Furthest equivalent pipe length L (real length)
Furthest equivalent pipe length from the 1st branch
Max, real length of pipes connected to indoor units
Maximum equivalent between branching section
outdoor unit - indoor unit (Upper outdoor unit) H1
H2>3m
H2≦3m
Indoor unit - indoor unit (Upper outdoor unit) H2
Indoor unit - indoor unit (Lower outdoor unit) H2
Amount of Additional Refrigerant
Refer to specification of Outdoor unit
Max.
Height
Difference
40 m or the outdoor
unit spec. Whichever is
shorter of outdoor unit.
40m
outdoor unit - indoor unit (Lower outdoor unit) H1
-
-
20ｍ
-
30ｍ
-
130m(120m)
100m
40m
-
Furthest equivalent pipe length between outdoor unit
Same as piping length
restriction of outdoor unit
-
TA type
TF, DDC type
Same as piping length restriction of outdoor unit
200m
120m(100m)
P5

6. Product Configuration
6.1 Product Configuration
・8
HP
～40
HP
・42
HP
～120
HP
TCB-IFDMX01UP-E RBM-A101 RBM-A201 TCB-IFDMX01UP-E RBM-A101 RBM-A201
TCB-IFDMR01UP-E UPVA-E UPVA-E TCB-IFDMR01UP-E UPVA-E UPVA-E
Connectable 8 HP 1 1 - 1
Dx-coil 10 HP 1 1 - 1
Capacity 12 HP 1 1 - 1
14 HP 1 - 1 1
- - - -
2(8+8) 2 - 2
- - - -
2(8+10) 2 - 2
- - - -
2(10+10) 2 - 2
22 HP - - - - 2(12+10) 2 - 2
2(12+12) 2 - 2
3(8+8+8) 3 - 3
26 HP - - - - 3(10+8+8) 3 - 3
2(14+14) - 2 2
3(10+10+8) 3 - 3
30 HP - - - - 3(10+10+10) 3 - 3
32 HP 1 - 2 1 2(16+16) - 2 2
34 HP - - - - 2(18+16) - 2 2
36 HP 1 - 2 1 2(18+18) - 2 2
38 HP - - - - 2(20+18) - 2 2
40 HP 1 - 2 1 2(20+20) - 2 2
1 - 2 1HP28
1
24 HP 1 2 - 1
120 HP 1 -
18 HP 1 - 1 1
HEX
number
Model name
16 HP 1 - 1 1
DX COIL type
Normal
Interlaced, Split face
Type Dx-coil controller Dx-Valve kit HEX
number
Dx-coil controller Dx-Valve kit
TCB-IFDMX01UP-E RBM-A101 RBM-A201 TCB-IFDMX01UP-E RBM-A101 RBM-A201
TCB-IFDMR01UP-E UPVA-E UPVA-E TCB-IFDMR01UP-E UPVA-E UPVA-E
42 HP - - - - 3(14+14+14) - 3 3
44 HP - - - - 3(16+14+14) - 3 3
46 HP - - - - 3(16+16+14) - 3 3
48 HP 2(24+24) 4 - 2 3(16+16+16) - 3 3
50 HP - - - - 3(18+16+16) - 3 3
52 HP - - - - 3(18+18+16) - 3 3
54 HP - - - - 3(18+18+18) - 3 3
- - 3(20+18+18) - 3 3
4 2 4(14+14+14+14) - 4 4
58 HP - - - - 3(20+20+18) - 3 3
60 HP - - - - 3(20+20+20) - 3 3
62 HP - - - - 4(16+16+16+14) - 4 4
64 HP 2(32+32) - 4 2 4(16+16+16+16) - 4 4
66 HP - - - - 4(18+16+16+16) - 4 4
68 HP - - - - 4(18+18+16+16) - 4 4
70 HP - - - - 4(18+18+18+16) - 4 4
72 HP 2(36+36) - 4 2 4(18+18+18+18) - 4 4
74 HP - - - - 4(20+18+18+18) - 4 4
76 HP - - - - 4(20+20+18+18) - 4 4
78 HP - - - - 4(20+20+20+18) - 4 4
80 HP 2(40+40) - 4 2 4(20+20+20+20) - 4 4
82 HP - - - - 5(18+16+16+16+16) - 5 5
- - 5(18+18+16+16+16) - 6 5
6 3 6(14+14+14+14+14+14) - 6 6
86 HP - - - - 5(18+18+18+16+16) - 5 5
88 HP - - - - 5(18+18+18+18+16) - 5 5
90 HP - - - - 5(18+18+18+18+18) - 5 5
92 HP - - - - 5(20+18+18+18+18) - 5 5
94 HP - - - - 5(20+20+18+18+18) - 5 5
- - 5(20+20+20+18+18) - 5 5
6 3 6(16+16+16+16+16+16) - 6 6
98 HP - - - - 5(20+20+20+20+18) - 5 5
100 HP - - - - 5(20+20+20+20+20) - 5 5
102 HP - - - - 6(18+18+18+16+16+16) - 6 6
104 HP - - - - 6(18+18+18+18+16+16) - 6 6
106 HP - - - - 6(18+18+18+18+18+16) - 6 6
108 HP 3(36+36+36) - 6 3 6(18+18+18+18+18+18) - 6 6
110 HP - - - - 6(20+18+18+18+18+18) - 6 6
112 HP - - - - 6(20+20+18+18+18+18) - 6 6
114 HP - - - - 6(20+20+20+18+18+18) - 6 6
116 HP - - - - 6(20+20+20+20+18+18) - 6 6
118 HP - - - - 6(20+20+20+20+20+18) - 6 6
120 HP 3(40+40+40) - 6 3 6(20+20+20+20+20+20) - 6 6
96 HP 3(32+32+32) -
56 HP 2(28+28) -
84 HP 3(28+28+28) -
DX COIL type
Interlaced, Split face
Type Dx-coil controller Dx-Valve kit HEX
number
Dx-coil controller Dx-Valve kit HEX
number
Model name
Interlaced, Split face
P6

・Dx-coil type Interlaced, Split face︓16HP〜120HP（TA type）
・Dx-coil type Interlaced, Split face︓16HP〜40HP（DDC,TF type）
・Dx-coil type normal︓8HP〜40HP（All type）
・RBM-A101UPVA-E and RBM-A201UPVA-E
CANNOT
combine in one refrigerant cycle system.
Therfore, two or more AHU from 12HP and below HP combination is available.
In the other way, two or more AHU over 14 HP combination is available.
Please see examples below:
・Dx-TA type with RBMA101UPVA-E can mix AHU with normal IDUs.
Combination AHU from 12 HP and below HP with VRF FCU is available.
Combination AHU over 14 HP with VRF FCU is
prohibited.
For example:
・For the AHU prepared on-site, please design by reference of AHU submittal.
a refrigerant cycle system CANNOT mix valve kit
RBM-A101UPVA-E (12HP) and RBM-A201UPVA-E (14HP)
P7

6.2 Major Specifications
TCB-IFDMX01UP-E / TCB-IFDMR01UP-E (Dx-coil Controller)
Description
Dx-coil controller in Metal Enclosure, comprising:-
・ MCC-1777 (Main Indoor(DX) P.C. board)
・ TA sensor, Length:7.5m, Connector color : Yellow
・ TC1 sensor, Length:7.5m, Connector color : Brown
・ TC2 sensor, Length:7.5m, Connector color : Black
・ TC sensor, Length:7.5m, Connector color : Red
・ TF sensor, Length:7.5m, Connector color : Green
・ Strainers
・ Terminal Block without relay : TCB-IFDMX01UP-E
・ Terminal Block with relay : TCB-IFDMR01UP-E
External Dimensions
H x W x D (mm)
420 x 330 x 122
Net Weight(kg)
TCB-IFDMX01UP-E
：4.0
kg
、
TCB-IFDMR01UP-E
：4.1㎏
Notes:
1.Capacity code (DN11) needs to be setup upon installation using wired remote controller (not supplied).
HP
8
10
12*
14*
16
18
20
24*
DN[11]
0021
0023
0024
0025
0026
0027
0028
0031
HP
28*
32
34*
36
38*
40
DN[11]
0047
0035
0048
0037
0049
0039
・ Only Heating and Cooling Modes are available on the DDC Type (No Automatic or Fan Only).
・
Components supplied loose, requires brazing and local pipework.
*
Only outdoor units that support TU2C-LINK can be set.
2.Valve kit type name speci
fication (This is basically set automatically).
・
In case of installation of any combinations that are not listed in standard combination in P.6
Please confirm combination of Valve kit model and DN[4AE] correctly.
RBM-A101UPVA-E / RBM-A201UPVA-E (Dx-valve kit)
Description
The PMV(Pulse Motor Valve, 2 models), comprising:-
・ PMV body & PMV Motor
・ Terminal Block
RBM-A101UPVA-E
8HP & 10HP & 12HP Size
RBM-A201UPVA-E
14HP & 16HP & 18HP & 20HP Size
RBM-A101UPVA-E
RBM-A201UPVA-E
Valve kit model
DN[4AE]
0001
0002
P8

6.3 Control Input / Output Details
-Analog Input functions -
Input
Name
Description
TA
DDC
TF
AI1
FAN interlock
FAN interlocking control by external input
Analog Input 1 (4 - 20 mA)
・FAN mode is switched by external 4 - 20 mA input.
・Both FAN control with 4 - 20 mA input and FAN mode change with remote controller are valid, but boost
priority is given.
・The FAN priority control is switched by the DN setting of [4A0].
0000: Default (no change in FAN mode by 4 - 20 mA input)
0001: FAN control by 4 - 20 mA input, but priority is given to FAN control from the outdoor unit
0002: FAN control 4 - 20 mA input with priority
・The FAN mode switching threshold value for 4 - 20 mA input can be changed in the DN setting
* The change in FAN speed with 4 - 20 mA input is also reflected in the 0 - 10 V output of AO1 / AO1.
AI2
Nothing
Cannot be used.
Analog Input 2 (4 - 20 mA)
✓✓✓
‐‐‐
✓ :Available × : Prohibition
P9

Input
Name
Description
TA
DDC
TF
AI3
Analogue Input Capacity Control
Analogue Input to Capacity control.
Analog Input 1 (DC 0 - 10 V)
SW501 bit-4(MCC-1777)
OFF
STEPPED response to analogue input
SW501 bit-4(MCC-1777)
ON
LINEAR response to analogue input
・To ease the integration of the Dx-coil with the DDC the capacity control is able to operate with a
STEPPED or LINEAR function from the analogue input.
・To select either a STEPPED(default) or LINEAR response, from the analogue input, use
SW501 bit4 located on the DDC(0-10V) interface P.C. board(MCC-1777)
AI4 Nothing Cannot be used.
Analog Input 2 (DC 0 - 10 V)
・ Capacity control signal(analogue input voltage) will be used as the main control value for the compressor frequency.
・ The control of capacity may not be able to be performed according to the state of an air-conditioner
(During oil recovercontrol, defrost etc.).
１）Capacity control 0-10V（Overview of capacity control）*
*There are possibilities of thermodynamic and/or mechanical limitation from many factors. which may affect our system's heat pump cycle
(refrigerant cycle) during operation. Hence, there is a possibility that the capacity output may be different from capacity control setting.
‐‐‐
× ✓ ×
✓ :Available × : Prohibition
0.00
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
0 1 2 3 4 5 6 7 8 9 101112
(V)
STEP
SW501 Bit4 OFF(stepped)
0.00
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
0123456789101112
(V)
STEP
SW501 Bit4 ON(Li er)
0-10V Analogue input capacity control
Cooling Mode ON OFF Heating Mode
Capacity Control STEP
(Linear) (Stepped)
Capacity Control STEP
10.00 10.00 (V)
STEP 13 (100%)
ON OFF 9.00 9.70
(Max demand, Approx. ΔT=-2℃) (Stepped) (Linear)
(Linear) (Stepped)
9.50 8.80
10.00 10.00 (V) 8.00 8.95
STEP 12 (90%)
STEP 11 (100%)
8.75 7.80
9.50 8.20
(Max demand, Approx. ΔT=+2℃) (Stepped) (Linear)
7.00 8.20
STEP 11 (80%)
8.00 9.30 8.00 6.80
9.00 7.45
STEP 10 (95%)
6.00 7.45
STEP 10 (70%)
7.25 8.80 7.25 5.80
8.50 6.70
STEP 9 (90%)
5.00 6.70
STEP 9 (60%)
6.50 8.30 6.50 4.80
STEP 8 (85%) STEP 8 (50%)
8.00 5.95
(Approx. ΔT=+1℃)
4.50 5.95
(Approx. ΔT=-1℃)
5.75 7.80 5.75 4.30
7.00 5.20
STEP 7 (80%)
4.00 5.20
STEP 7 (45%)
5.00 6.80 5.00 3.80
6.00 4.45
STEP 6 (70%)
3.50 4.45
STEP 6 (40%)
4.25 5.80 4.25 3.30
5.00 3.70
STEP 5 (60%)
3.00 3.70
STEP 5 (35%)
3.50 4.80 3.50 2.80
STEP 4 (50%) STEP 4 (30%)
4.00 2.95
(Keep the curent tenperature, ΔT=0℃)
2.50 2.95
(Keep the curent tenperature, ΔT=0℃)
2.75 3.80 2.75 2.30
3.00 2.20
STEP 3 (40%)
2.00 2.20
STEP 3 (25%)
2.00 2.80 2.00 1.80
2.00 1.45
STEP 2 (30%)
1.50 1.45
STEP 2 (20%)
1.25 1.80 1.25 1.30
STEP 1 (20%) STEP 1 (15%)
1.50 0.70
(Min demand, Approx. ΔT=-1℃)
1.00 0.70
(Min demand, Approx. ΔT=+1℃)
0.50 1.30 0.50 0.80
0.00 0.00
STEP 0(No operation)
0.00 0.00
STEP 0(No operation)
SW501 bit4
SW501 bit4
0.00
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
0 1 2 3 4 5 6 7 8 9 1011121314
(V)
STEP
SW501 Bit4 OFF(stepped)
0.00
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
01234567891011121314
(V)
STEP
SW501 Bit4 ON(Li er)
0-10V Analogue input capacity control
Shield wire MAX. 200m
P10

Input
Name
Description
TA
DDC
TF
AI3
Set temperature chang
・
To use this control, set DN [4A9] = 1.
・
For TA and TF type, the set temperature can be changed
according to the 0 - 10 V input of AI3.
・
In the set temperature with the remote controller and this control,
the post-setting is prioritized.
・
The set temperature can be changed only for cooling and
heating operations.
AI4
Nothing
Cannot be used.
Analog Input 2 (DC 0 - 10 V)
✓ × ✓
‐‐‐
✓ :Available × : Prohibition
Shield wire MAX. 200m
P11

-Digital Input functions -
Input
Name
Description
TA
DDC
TF
DI1
Safety contact.
・
MODE 1 (Normally close, DC12 V) *When Bit1 of SW505 is OFF
If this contact is open for more than 1 minute, the check code P10 is
generated and the Dx-coil controller switches off automatically.
・MODE 2 (Normally open, DC12 V) *When Bit1 of SW505 is ON
If this contact is short for more than 1 minute, the check code P10 is
generated and the Dx-coil controller switches off automatically.
✓✓✓
✓ :Available × : Prohibition
MAX. 100m MAX. 100m
MAX. 100m MAX. 100m
MAX. 100m MAX. 100m
P12

Input
Name
Description
TA
DDC
TF
DI2
External trouble Input
An AHU fan operation monitor (Field supply), could be attached at
this dry contact terminal (For example, the abnormality of the fan motor).
A closed contact generates the check code L30.
DI3
Forced thermostat OFF Input
When signal input, AHU is in “thermostat-off” status forcibly.
✓
✓
✓
DI4
Notice code Input
・
If there is input, a spanner mark will be displayed on the remote controller.
The system will not stop.Check “DN settings” for the setting method.
・Enter the Notice code when you want to report an abnormality that does
not stop the air conditioner from the outside.
・Used by switching functions with settings of Code No. (DN Code).
・Notice code is continuously issued while input signal is ON.
・201 is displayed in the Notice code history when there is input in DI4.
＊Notice code is a function dedicated to TU2C-Link communication.
Set data corresponding to Notice code to be used to one of
Code No. 180 to 189, in accordance with following table.
In case where data other than 0000 is already set, set to other
Code No. (DN Code).
*1: Refer to the Service Manual for support.
* It may take up to ten minutes to be displayed on remote controller after
Notice code is issued.
DI5
Operation Mode Input
Digital Input to control Mode:-
(Cool / Heat)
・
Only cool mode and heat mode are available.
DI2
～
DI4
✓✓✓
✓✓✓
× ✓ ×
✓ ✓✓
✓ :Available × : Prohibition
MAX. 100m
P13

Input
Name
Description
TA
DDC
TF
DI6
Operation ON/OFF Input
When using with DDC, it starts by turning on this terminal.
External trouble Input signal type(pulse / static) is selectable by
umper Wire 01
on the Indoor(DX) P.C. board - MCC-1777
・ Connect (Default) : Pulse / Cut : Static
Note the unit will not operate until there is an appropriate 0-10V
Capacity Control signal.
× ✓ ×
✓ :Available × : Prohibition
P14

- Digital Output functions -
Output
Name
Description
TA
DDC
TF
DO1
Operating Output
Displayed when the system starts operation (output with both thermostat ON / OFF)
✓
✓
✓
DO2
Alarm Active Digital Output
During Alarm operation, Alarm Active Digital Output is active.
✓
✓
✓
DO3
Fan Motor Active
A fan control signal is output. It is usually the ON output at the time
Digital Output
of operating, but it is the OFF output in defrosting.
DO4
Defrost Mode Digital Output
During Defrost operation, Defrost Mode Output is active.
✓
✓
✓
DO5
DO_1 Digital Output1
Output function set using rotary switch "
SW503
"
on the DDC(0-10V)
(User Defined)
interface P.C board(MCC-1777)
SW503
Output function
1
Outdoor unit(s) operation level is lower than capacity command
2
Outdoor unit(s) operation level is higher than capacity command
3
Cooling oil recovery/Heating refrigerant recovery control
4
Cooling operation output
5
Heating operation output
6
Thermostat ON
7～15
Do not use
16
Under Hz upper limit regulation due to heat sink overheating
DO6
DO_2 Digital Output2
Output function set using rotary switch "
SW504
" on the DDC(0-10V)
(User Defined)
interface P.C board(MCC-1777)
SW504
Output function
1
Outdoor unit(s) operation level is lower than capacity command
2
Outdoor unit(s) operation level is higher than capacity command
3
Cooling oil recovery/Heating refrigerant recovery control
4
Cooling operation output
5
Heating operation output
6
Thermostat ON
7～15
Do not use
16
Under Hz upper limit regulation due to heat sink overheating
✓✓✓
✓✓✓
✓✓✓
✓ :Available × : Prohibition
Locally procured
MAX. 500m
MAX. 500m
P15

Output
Name
Description
TA
DDC
TF
DO7
Thermostat On Digital Output
Thermostat ON signal is output. It is usually the ON output at the
time of operating.
DO8
Outputs the start control signal for cooling and heating operation.
DO9
Pre defrost signal
Outputs just before defrosting (at least 5 minutes before).
DOA
Cooling/ heating output
Output as OPEN during cooling operation, and CLOSE duing heating operation.
DOB
Notice code Output
Output to disply Notice code (if there is any at the time.)
For details, see the outdoor unit Service Manual.
DOC
FAN mode Output
Output Fan Mode : DOC
＝
High
・
If select the fan output from interface, use this output. For TA and TF types,
the output changes by changing the fan speed from the remote controller.
DOD
FAN mode Output
Output Fan Mode : DOD
＝
Mid
・
If select the fan output from interface, use this output. For TA and TF types,
the output changes by changing the fan speed from the remote controller.
DOE
FAN mode Output
Output Fan Mode : DOE
＝
Low
・
If select the fan output from interface, use this output. For TA and TF types,
the output changes by changing the fan speed from the remote controller.
- Analog Output functions -
Output
Name
Description
TA
DDC
TF
AO1
FAN speed 0 - 10 V output
・
Each FAN speed is output at 0 - 10 V.
Analog Output 1 (0 - 10 V)
・
The output voltage can be changed by DN setting [4A4] to [4A6].
AO2
Nothing
Cannot be used.
Analog Output 2 (0 - 10 V)
Cooling / heating start up
control signal output
✓✓✓
---
✓✓✓
✓✓✓
✓✓✓
✓✓✓
✓✓✓
✓✓✓
✓✓✓
✓✓✓
✓ :Available × : Prohibition
✓ :Available × : Prohibition
Shield wire MAX. 200m
Locally procured
MAX. 500
m
P16

- Summary of Digital input / output function (MCC-1777) -
1 (WHI) -
2 (YEL) -
3 (ORN) -
4 (BLU) -
5 - -
6 (RED) DC12V
1 (WHI) -
2 (YEL) -
3 (ORN) -
4 (BLU) -
5
-
-
6
(RED)
DC12V
(BRN)
1
(BLU)
-
3
(RED)
1
(RED)
-
2
(BLK)
1
(BLK)
-
2
(YEL) 1 (BLK) -
2
(GRN)
1
(RED)
-
2
(WHI) 1 - -
2
Defrost mode Digital output
60
(WHI)
2
(BLU)
Output
60
(WHI)
3
(ORN)
Output
62
(BLU)
1
(RED)
12V
Fan motor active Digital output
60
(WHI)
6
(BLK)
Output
(BLU)
1
(BLU)
Output
2
(BLK)
GND
(BLU)
3
(BLU)
Output
4
(BLK)
GND
(WHI)
1
(WHI)
Input
2
(BLK)
GND
(WHI)
3
(WHI)
Input
4
(BLK)
GND
(WHI)
3
(BLU)
Input
4
(BLK)
GND
(WHI)
5
(YEL)
Input
6
(BLK)
GND
*1 : TX temperature sensor is an option accessory part. TX can be used with application TA type or TF type.
TC1
Specification
PMV1 82 (BLU)
PMV2 84 (BLK)
Function
Connector
No. CN
Connector
collar Pin No. Wire collar
Input1(0-10V)
Input2(0-10V)
(No function)
Input1(4-20mA)
Input1(4-20mA)
(No function)
Thermostat on Digital output
Output1(0-10V)
Output2(0-10V)
(No function)
TC
TF
TX
*1
103
104
101
105
TC2
TA
600
601
602
100
102
P17

1 (BLU) 5V
2
(BLK)
GND
4
(WHI)
Output
5
(RED)
12V
Alarm active Digital output
(YEL)
6
(BRN)
Output
FAN speed HH
(RED)
2
(YEL)
Output
FAN speed H
(RED)
3
(GRN)
Output
FAN speed L
(RED)
4
(BLU)
Output
Pre defrost signal output
(BLU)
4
(BRN)
Output
Cool(open)/Heat(close)output
(BLU)
5
(BLU)
Output
Notice output
(BLU)
6
(GRN)
Output
1 (RED)
GND
*2
2
(WHI)
Input
External error input
(GRN)
3
(BLU)
Input
Forced
thermostat
OFF
Input
(GRN)
4
(ORN)
Input
Notice Input
(GRN)
5
(GRN)
Input
Operation Mode Input (Cool/Heat)
(GRN)
6
(YEL)
Input
Modbus A
(WHI)
5
(YEL)
-
Modbus B
(WHI)
4
(ORN)
-
Degital output1 (user defined)
(RED)
2
(RED)
Output
Degital output2 (user defined)
(RED)
3
(WHI)
Output
*2 : Safety (SW701) output will depend on combinations. For more detail, please refer to Terminal DI1/
＊
DI1.
SpecificationFunction
Connector
No. CN
Connector
collar Pin No. Wire collar
External ON/OFF input
Operating output 61
(YEL)
(YEL)
64
45
90
(BLU)
Cooling oil recovery/Heating refrigerant
recovery control
Safety (Normal close) (GRN)
(WHI) Output
63
62
3
P18
